WIZARD C2
MULTI FLASHLIGHT
2 ENG USER MANUAL
5 GER BENUTZERANLEITUNG
9 FRA MANUEL D’UTILISATEUR
12 RUS РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ
15 FIN KÄYTTÖOHJE
18 SWE ANVÄNDARMANUAL
21 NOR BRUKSANVISNING
24 POL INSTRUKCJA OBSŁUGI REV_00-0003
2 ENG USER MANUAL WIZARD C2 REV_00-0003
ENG USER MANUAL
Thank you for choosing the products of Armytek.
Please read this manual carefully before using the flashlight.
Specifications
Headlamp: simple one-hand operation, reliable headmount. Solid body
without long wires, weak rubber connectors and unnecessary boxes.
The flashlight is easily installed, removed and 180° rotatable in the
mount. Quick-release rubber ring provides additional fixation
Every Day Carry light: compact design, convenient side button, spe-
cial matt anti-abrasive finish without rough knurling, strong built-in tail
magnet and robust removable steel clip
Bicycle light: body made from durable and lightweight aircraft-grade
aluminium, improved shock resistance, new springs for better bat-
tery and driver protection. Constant light without flickering, optional
quick-release mount
• Convenient wide beam of fully upgraded optical system, TIR-lense
is protected from scratches by tempered glass with anti-reflective
coating
• Innovative technology allows using any 18650 Li-Ion batteries and
provides full protection against short circuit even in case of contact
between magnetic connector and metal objects
• Active real-time temperature control to prevent overheating above
+58 °C
• Total protection from water, dirt and dust in accordance with IP68
standard — flashlight continues to work even at 10 meters depth.
Withstands fallings from up to 10 meters
• Robust and water resistant magnetic connector
Set description
Flashlight, 18650 Li-Ion 3200 mAh battery, magnetic USB charger,
headmount, clip, 2 spare O-rings, user manual.
The producer reserves the right to change the package at his own
discretion without modifying this manual. Specifications are sub-
ject to change without notice.
Model Wizard C2 (White)
LED/Optics Samsung LH351D/TIR
Brightness stabilization type DIGITAL (CPU brightness control)
Light output 1200 lm
Peak beam intensity 2890 cd
Hotspot : Spill 70°:120°
Beam distance 108 m
Modes, light output and
runtimes (measured with
18650 Li-Ion 3200 mAh
battery until the light output
drops to 10% of the initial
value)
Turbo 1200 lm/2 h 45 min (580 lm after 4 min)
Main3 390 lm/4 h 45 min
Main2 180 lm/11 h
Main1 40 lm/51 h
Firefly2 2 lm/26 d
Firefly1 0.11 lm/200 d
Power source 1x18650 Li-Ion
Length/Body diameter/Head diameter 112 mm/20.4 mm/33 mm
Weight without/with battery 64 g/114 g
Submersion and Impact resistance IP68, 10 m for 2 h. Height up to 10 m
XLight output for flashlights with Warm light is about 7% less, beam distance is about 3% less.
All the above specifications are test results based on ANSI/NEMA FL1-2009 Standard. The tests are performed using the battery included in the set.
The data may vary due to environment, heat dissipation and other factors.
3WIZARD C2 USER MANUAL ENG
REV_00-0003
Initial Service
TO SET/REPLACE BATTERY
1. Unscrew the tailcap.
2. Place the battery with the positive contact (+) facing the head of the
flashlight.
3. Adjust the tailcap and tighten it as far as it can go.
The flashlight is ready for operation.
HOW TO CONNECT THE MAGNETIC CHARGER
Unscrew the tailcap to 1/4 of a circle and adjust the magnetic charger
to the tailcap.
CHARGER COLOR INDICATION
Charger not plugged in:
• Green — device is in waiting mode.
Charger plugged in:
• Green blinking — evaluation of battery voltage.
• Red blinking — unscrew the tailcap to 1/4 for charging.
• Orange blinking — USB power source voltage is too low for correct
continuation of charging or bad contact between charger and battery.
Clean the tailcap and the threads of the flashlight parts, use a die-
rent power source.
• Red — charging with rated charging current is going on.
• Orange — USB power source voltage is too low, charging current may
be reduced.
• Green — charging is finished.
Operation
Before use: Tighten the tailcap as far as it can go.
In OFF state:
1 click: To turn on the last used mode.
Press and hold: To start cycling through Firefly modes. Release to
select. Keeping button pressed will start cycling through Main modes.
In ON state:
1 click: To turn o the flashlight.
Press and hold: To start cycling through Main modes from any mode. In
Firefly1 cycling through Main modes starts after cycling through Firefly
modes. Release to select.
2 clicks: To turn on Turbo mode from any mode. The second double click
brings back last used mode.
MOMENTARY ACCESS
Firefly. Press and hold the button in OFF state to start cycling through
Firefly modes. Release to select. Keeping button pressed will start
cycling through Main modes.
Main. Short click from OFF state activates Main mode if it was the last
used mode.
Turbo. Double click in any mode in ON state. The second double click
brings back last used mode.
Cycling through Main modes. In ON state press and hold the button
in any mode. Main modes will start switching cyclically. In Firefly1
cycling through Main modes starts after cycling through Firefly modes.
Release to select.
Automemorizing. After switching othe last used mode is memorized
for quick access at next switching on.
Active temperature control. When the temperature of the flashlight
becomes close to +58 °С, brightness decreases to safe value, allowing
the flashlight to avoid overheating for a long period of time. In condi-
tions of good air-cooling the flashlight delivers light without stepping
down.
Low battery level. When the brightness is approximately <25% from
the nominal value, the LED will flash 2 times. If you are not sure wheth-
er or not it flashed, switch the flashlight
o and on: in case the battery is low, the flashes will repeat after 30 sec
from switching on. At critical level light output decreases to Firefly1.
Lock-out function. Unscrew the tailcap to 1/4 for the protection from
accidental switching on.
