Pagina 1/33

PREDATOR PRO

TACTICAL FLASHLIGHT

2 ENG USER MANUAL

6 GER BENUTZERANLEITUNG

10 FRA MANUEL D’UTILISATEUR

14 RUS РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ

18 FIN KÄYTTÖOHJE

22 SWE ANVÄNDARMANUAL

26 NOR BRUKSANVISNING

30 POL INSTRUKCJA OBSŁUGI REV_00-0000

2 ENG USER MANUAL PREDATOR PRO REV_000000

• Special precisely calculated reflector for High Intensity LED modifi-

cation, which provides 1.5 times the light range compared to a usual

LED, and tempered glass with anti-reflective coating for maximum

throw create clear central spot with minimal side spill at 1500 lumens

brightness. Spill diameter is 9 meters at 100 meters distance

• Powerful electronics provides constant brightness even at a tem-

perature of -40 °C and not fully charged battery

• Two types of operation: hunting and tactical. Tactical operation for

quick access to maximum brightness mode and Strobe mode

• Withstands any recoil due to improved springs and installation of the

driver inside a reinforced capsule filled with protective compound

• Standard 1 inch body is compatible with any accessories, including

original magnetic remote switch and magnetic mount for quick

one-motion attachment and removal

• Two-phase electronic button retained two levels of pressing similar to

mechanical switch, but became noiseless and 20 times more durable

• Non-flat button allows to easily switch the flashlight with a palm

Specifications

• Innovative technology allows using any standard 18650 Li-Ion bat-

teries with 10A discharge current and provides full protection against

short circuit even in case of contact between magnetic connector and

metal objects

• Solid body made from aircraft-grade aluminium, special matt anti-

abrasive finish without rough knurling

• Steel striking bezel with matt non-reflective black titanium coating,

which prevents location disclosure, is used for additional protection of

the optical system in the event of a fall and as a shock-crushing tool

• Active real-time temperature control to prevent overheating above

+58 °C and warning indication of low battery level

• Total protection from water, dirt and dust in accordance with IP68

standard — flashlight continues to work even at 25 meters depth up

to 5 hours. Withstands fallings from the 10th floor

• Robust and water resistant magnetic connector

ENG USER MANUAL

Thank you for choosing the products of Armytek.

Please read this manual carefully before using the flashlight.

Model Predator Pro (White)

LED/Optics Cree XHP35HI/Smooth reflector

Brightness stabilization type FULL (constant light)

Light output 1500 lm

Peak beam intensity 62800 cd

Hotspot : Spill 5°:40°

Beam distance 501 m

Modes, light output and runtimes (measured

with 18650 Li-Ion 3500 mAh battery until the

light output drops to 10% of the initial value)

Turbo 1500 lm/1 h 33 min (700 lm after 3 min)

Main3 300 lm/5 h 13 min

Main2 120 lm/12 h 20 min

Main1 40 lm/32 h

Strobe2 1500 lm/15 Hz/3 h (700 lm after 3 min)

Strobe1 120 lm/15 Hz/23 h

Power source 1x18650 Li-Ion

Length/Body diameter/Head diameter 160 mm/25.4 mm/41 mm

Weight without/with battery 136 g/186 g

Dust, water and impact resistance IP68. Submersion at 25 m up to 5 h. Fallings from 25 m

XLight output for flashlights with Warm light is about 7% less, beam distance is about 3% less. All the above specifications are test results based on ANSI/NEMA FL1-2009 Standard. The tests are

performed using the battery included in the set. The data may vary due to environment, heat dissipation and other factors.

3PREDATOR PRO USER MANUAL ENGREV_000000

Set description

Flashlight, 18650 Li-Ion 3500 mAh battery, magnetic USB charger, clip,

lanyard, holster, silicone grip, 2 spare O-rings, user manual.

The producer reserves the right to change the package at his own

discretion without modifying this manual. Specifications are sub-

ject to change without notice.

Initial Service

TO SET/REPLACE BATTERY

1. Unscrew the tailcap.

2. Place the battery with the positive contact (+) facing the head of the

flashlight.

3. Adjust the tailcap and tighten it as far as it can go.

The flashlight is ready for operation.

HOW TO CONNECT THE MAGNETIC CHARGER

Tighten the head of the flashlight as far as it can go and adjust the

magnetic charger to the tailcap.

CHARGER COLOR INDICATION

Charger not plugged in:

• Green — device is in waiting mode.

Charger plugged in:

• Green blinking — evaluation of battery voltage.

• Red blinking — clean the external and internal contacts of the tailcap,

as well as the contact areas of the charger.

• Orange blinking — USB power source voltage is too low for correct

continuation of charging or bad contact between charger and battery.

Clean the tailcap and the threads of the flashlight parts, use a dier-

ent power source.

• Red — charging with rated charging current is going on.

• Orange — USB power source voltage is too low, charging current is

reduced.

• Green — charging is finished.

Operation

Before use: Tighten the tailcap as far as it can go.

IN ANY MODE

Permanent on. First full click of the button turns the flashlight on.

Second full click turns it o.

Momentary on. Switched on by half-pressing of the button (no click)

and active till the button is released.

To switch between types of operation unscrew and tighten up the

head of the flashlight at least 10 times (during rotation the modes will

be changing). The pause between the moves must be less than 1 sec.

The flashlight blinks once, confirming the action.

HUNTING TYPE (BY DEFAULT)

Turbo. Before switching on the flashlight in Turbo mode, tighten the

head of the flashlight if it is unscrewed.

Additional modes. Before switching on the flashlight in Additional

mode, unscrew the head to 1/8 if it is tightened. Full click switches on

the last used Additional mode.

Cycling through Additional modes. To switch the mode turn the

flashlight o and on (by full click or half-pressing). The flashlight must

not be turned o for more than 2 sec. The modes switch cyclically:

Main1 – Main2 – Main3 – Strobe2 (if enabled).

Add/Remove Strobe2 in Additional modes. Switch on the flashlight

by half-pressing at least 20 times. The flashlight must not be turned on

for more than 1 sec. Last switch must be full click. The flashlight blinks

once, confirming the action.

Remote switch must be used in Turbo mode.

TACTICAL TYPE

Constant light. Before switching on the flashlight in Constant light

mode, tighten the head if it is unscrewed.

Changing Constant light modes. The head is tightened: unscrew it to

1/8 and tighten again in 1 sec. Turbo and Main2 will switch cyclically.
