Pagina 1/2

Specifications

Armytek Optoelectronics Inc. is a Canadian manufacturer that produces powerful and reliable flashlights designed especially for your

needs. The components made in the USA and Japan. .10 years no-hassle warranty

§Impressively powerful multi-flashlight with 1050 LED lumens brightness.

§Rechargeable flashlight with magnet USB charger.

§TIR-optics provides wide light for efficient area illumination.

§Easy operation and 6 comfortable modes of light output.

§Reliable headband made of soft and flexible materials for comfortable fixation of the flashlight on the head.

§Small and light, but at the same time durable and multi-functional flashlight.

§Prolonged runtimes — up to 60 days with one power element .

§Removable pocket clip and flat tailcap for vertical standing.

§Complete correspondence to the highest standards of durability and reliability: the flashlight easily withstands fallings, impacts

and vibration.

§Solid body without long wires, weak rubber connectors and unnecessary boxes.

§Total protection from water, dirt and dust penetration – flashlight continues to work even at the depth of 10 meters.

Tiara Magnet USB

Thank you for choosing the products of Armytek Optoelectronics Inc., Canada.

Please read this manual carefully before using the flashlight.

USER MANUAL

* Light output for flashlights with Warm light are about 7% less, beam distances are about 3% less.

Warnings

Specifications are subject to change without notice.

Armytek Optoelectronics Inc.

Web: www.armytek.com Email: service@armytek.com

Address: 13-85 West Wilmot St, Richmond Hill, Ontario, L4B 1K7, Canada

Care and Storage

1. Always follow the instructions from this manual and recommendations on battery usage.

2. Apply only the recommended power sources.

3. Do not reverse battery polarity.

4. Do not use different power sources together, i.e. old ones with new ones, charged with

discharged. Do not use different types of batteries combined as the element with less

capacity can be damaged.

5. Do not modify or recast the flashlight and its components as it will deprive you of the

warranty.

6. Do not allow water or any other liquid to leak into the flashlight.

7. Do not aim a switched-on flashlight at people's or animals' eyes – it can cause temporary

blindness.

8. Do not allow children to use the flashlight without your assistance.

The producer will not be liable for any harm done to the user if it was caused by

improper use of the product.

It is recommended to clean the threads and O-ring off dirt and old greases once or twice per year. Remember that reliable protection

from water and dust cannot be provided by worn out sealing. The fouling as well as lack of lubricant cause fast wear-out of threads and

sealing rings.

To clean the threads do the following:

1. Unscrew the tailcap and remove the sealing ring carefully with a toothpick (do not use sharp metal things as they can damage the ring).

2. Wipe the sealing ring thoroughly with a soft cloth (or tissue). Do not use solvents. If the sealing ring is worn out or damaged

replace it by a new one.

3. Clean the metal threads with a brush using ethanol. Be careful not to allow the applied liquid to get inside the flashlight or tailcap as

it can cause fails in functionality of the flashlight.

After cleaning lubricate the thread and the sealing ring with polyalphaolefin-based silica grease, e.g. Nyogel 760G.The application of

automotive and other improper grease can cause swelling and damage of the sealing rings.

In case of active operation and exploitation in dusty environments, it is recommended to perform cleaning and lubricating of the parts

as often as required.

Model

Tiara C1 Magnet USB

LED / Optics

Cree XP-L / TIR

Brightness stabilization type

DIGITAL (CPU brightness control)

Light output, LED / OTF lumens*

1050 / 900

Peak beam intensity, candelas

2830

Hotspot / spill

70 ° / 1 0°2

Beam distance*

106 meters

Modes, light output (OTF lumens*)

and runtimes (measured with

18350 Li-Ion 0 mAh until the 90

light output drops to 10% of the

initial value)

Turbo

90 lm / 30min0

Main3

220 lm / 2.4h

Main2

90 lm / 6.5h

Main1

34 lm / 15h

Firefly2

2.5 lm / 8d

Firefly1

0.4 lm / 60d

Power source

1x18350 Li-Ion

Size and weight (without batteries)

Length 79mm, body diameter 24 5mm, head diameter 29mm, weight 60g.

Remember that old or low-quality disposal batteries can be damaged under heavy load and explode.

THE MOST TECHNICALLY ADVANCED

Service and Warranty

Armytek provides free warranty repair for 10 years (excluding batteries, chargers, switches and connectors which have 2 years

warranty) from the date of buy with the document confirming the purchase.

Guarantee does not extend to damage during:

1. Improper usage.

2. Attempts to modify or repair the flashlight by nonqualified specialists.

3. Longtime application in chlorinated or polluted water, or other liquids (other than water).

4. High temperatures and chemicals' exposure (including the exposure of liquid from defected batteries).

5. Usage of low-quality batteries.

Items included in the package:

1 - Flashlight

2 - Headband

3 - Plastic holder

4 - Clip

5 - 2 spare O-rings

6 - 18350 Li-Ion battery

7 - Magnet USB charger

8 - User manual

4x2

5 876

Tiara Magnet USB

Set description

1 32

Initial Service

1. 2. 3.

We DO NOT RECOMMEND to leave power sources inside the flashlight for a long storage period, as batteries (especially, non-rechargeable) can

leak for various reasons and damage the inner parts of the flashlight. If you want to keep your flashlight in a stand-by state with batteries in then

use new and high-quality batteries store the flashlight in acceptable for batteries operational temperature and revise the batteries' state at and

least once a month. If you have noticed any signs of batteries' defects then withdraw them from the flashlight and utilize. It is also recommended

to replace discharged batteries with new ones before the storage as the chance of leakage is higher with discharged batteries.

ьYour flashlight can inconsiderably differ from the pictures in the manual.

ьThe producer reserves the right to change the package at his own discretion without modifying this manual.

To set/replace batteries:

1. Unscrew the tailcap.

2. Place the batteries with the positive contact (+) facing the

head of the flashlight.

3. Adjust the tailcap and tighten it as far as it can go.

The flashlight is ready for operation.

How to turn on a magnet charger:

Unscrew the tailcap for 1/4 of a circle and turn on a magnet

charger device to the tailcap.

Approximate time for charging a fully discharged battery is 6-8

hours. We recommend using adapters with 1A and higher.

Charger device battery indication:

1. Red color – the charging is going on.

2. Green color – the charging is finished.

3. Red color blinking – unscrew the tailcap for 1/4 for

charging.

1/4

Put in the band in the first clasp. Put in the band through the slots in the plastic holder

and fix the flashlight. Adjust elastic band to the size

of your head.

1.3.

Pass the end of the band through the second clasp and fix it.

To use the headmount with the flashlight:

Operation

Click x1

OFF Main (if last used)в

Main

Press & Hold

OFF Firefly1 Firefly2в в

Firefly

ON Turboв

Turbo Last modeв

Click x2 Turbo

Main1 Main2в

ез

Main3

Press & Hold

In OFF state:

Click: To turn on the last used mode.

Press and hold: To go through 2 Firefly modes (release to select). Keeping button pressed will start cycling through the Main modes.

In ON state:

Click: To turn off the flashlight.

Press and hold: To start cycling through the Main modes.

Double click: To turn on the Turbo mode. The second double click brings back the last used mode.

For comfortable operation you have a convenient momentary access to all the following modes:

Main. Short click from OFF-state activates the Main mode (if

it was the last mode used previously).

Firefly. Press and hold the button in OFF-state to turn on the

desired Firefly mode and then release immediately. Keeping

the button pressed will start cycling through the Main

modes.

Turbo. The mode is activated by double click, when the

flashlight is on. To return to the last mode make double-click

again.

Cycling through the Main modes. In ON-state press and hold

the button (in any mode): the 3 Main modes will start

switching cyclically. Release the button to select the desired

mode. In Turbo mode it starts cycling through the Main

modes.

Automemorizing. After switching off the last used Mode is memorized for quick 1-click access at next switching on.

Lock-out function. Unscrew the tailcap to 1/4 for the protection from accidental switching on.

Low Battery Indication. If the brightness is <25% from the nominal value, the LED flashes 2 times

ONCE (after 30sec from switching on). If you are not sure if it flashed or not switch the flashlight

off and on: in case the battery is low flashes will repeat. Light output decreases to Firefly mode at

critical level.

Active temperature control. T can quickly heat up Turbo . W the he flashlight in mode hen

temperature become +60 C – small steps °the brightness decreases by . After cooling-down

( ) Turboprovided that battery voltage is sufficient the brightness increases to the mode again.

This stepping goes cyclically to maintain the user's safety and the flashlight's functionality. In

conditions of good air-cooling the flashlight delivers light without stepping down even in Turbo

mode. There are no preset timers for stepping, but real- active temperature measurements.time

Cycling through Modes

Warning

Low Battery Indication

Critical

вFirefly1

вOFF
