INSTRUCTIONS AND USER MANUAL

www. .comrobbe

V1_05/2019

Standard Version No.: 2649

Night Version No.: 2650 RTF Version No.: 2651

E N G L I S H

I N S T R U C T I O N S A N D U S E R M A N U A L

GENERAL INFOR MATIO N

• The model is designed for the components specied by us. Unless otherwise stated, servos and

other electronic components are designed for standard supply voltage. Recommended cell

count for Lipo batteries also refers to standard Lipos voltage of 3.7V per cell. If you use other ser-

vos, a different motor and controller, batteries, or propellers, please make sure they t rst. In the

event of deviations, corrections and adjustments must be made by yourself.

• -Before starting construction, always put the servos into neutral. To do this, switch on the remo

te control and move the joysticks and trim buttons (save the one for the throttle) to the middle

position. Connect the servos to the corresponding outputs of the receiver and supply them with a

suitable power source. Please observe the connection diagram and the operating instructions of

the remote control system manufacturer.

• Do not leave your model in the blazing sun or in your vehicle for long periods of time. Too high

temperatures can lead to deformation/distortion of plastic parts or blistering of covering foils.

• Before the rst ight, check the wing symmetry, tail unit and fuselage. All parts of the model should

have the same spacing from the left and right wing or tail plane to the centre of the fuselage or

the same angle.

• If necessary, rebalance the propellers if vibrations are noticeable when the motor is running up.

• Bubble formation in the covering foils normal to a certain extent due to temperature and humidity

differences and can be easily eliminated with a foil iron or hairdryer.

• -For models in shell construction („full GFRP/CFRP“), burrs may occur at the seams due to the pro

duction process. Carefully remove them with ne sandpaper or a le.

SAFE TY INSTR UCTIONS FOR CONTRO LLERS

GENERAL SAFETY INFORMATION

• Be sure to read the safety instructions carefully before operating your model.

• Always follow the procedures and settings recommended in the instructions.

• If you are using remote-controlled model aircraft, helicopters, cars or ships for the rst time, we

recommend that you ask an experienced model pilot for help.

• Remote-controlled models are not toys in the usual sense and may only be used and operated by

young people under 14 years of age under the supervision of adults.

• Their construction and operation requires technical understanding, careful craftsmanship and

safety-conscious behaviour.

• Mistakes or negligence during construction, ying or driving can result in considerable damage to

property or personal injury.

• Since the manufacturer and seller have no inuence on the proper construction/assembly and

operation of the models, these risks are expressly pointed out and any liability is excluded.

• Propellers on aircraft and all moving parts in general pose a constant risk of injury. Avoid touching

such parts at all costs.

• Note that motors and controllers can reach high temperatures during operation. Avoid touching

such parts at all costs.

• Never stay in the danger area of rotating parts with electric motors with connected drive battery.

• Overcharging or incorrect charging can cause the batteries to explode. Make sure the polarity is

correct.

• Protect your equipment and Models from dust, dirt and moisture. Do not expose the equipment to

excessive heat, cold or vibration.

• Use only recommended chargers and charge your batteries only up to the specied charging

time. Always check your equipment for damage and replace defects with original spare parts.

• Do not use equipment that has been damaged or got wet due to a fall, even if it is dry again!

Either have it checked by your specialist dealer or in the Robbe Service or have it replaced.

Hidden faults can occur due to wetness or a crash, which lead to a functional failure after a short

operating time.

• Only the components and accessories recommended by us may be used.

• Do not make any changes to the remote control which are not described in these instructions.

• Observe the technical data of the controller.

• Observe the polarity of all connection cables.

• Avoid short circuits at all costs.

• Install or package the regulator so that it cannot come into contact with grease, oil or water.

• Ensure adequate air circulation.

• Never reach into the turning circle of the propeller during start-up Risk of injury

Important information:

The receiver system is powered by the built-in BEC system of the controller.

For commissioning, always move the throttle stick to the „Motor off“ position and switch on the

transmitter. Only then connect the battery. To switch off always disconnect the connection battery

motor controller, rst

then turn off the transmitter. During the functional test, move the servos of the rudders to neutral

position with the remote control (stick and trimming lever on the transmitter to the middle position).

Please make sure to leave the throttle stick in the lowest position so that the engine does not start.

For all work on

to the parts of the remote control, motor or controller, follow the instructions supplied with the units.

Also read the instructions of the battery and the charger carefully before commissioning.

Check the engine mounting bolts in the fuselage regularly for tightness.

SAFE TY NOTE FO R MO DE L OP ERATION

Attention, danger of injury!

• Always keep a safe distance from your model aircraft.

• Never y over spectators, other pilots or yourself.

• Always perform ight gures in a direction away from the pilot or spectators.

• Never endanger people or animals.

• Never y near power lines or residential areas.

• Do not operate your model near locks or public shipping.

• Do not operate your model on public roads, motorways, paths and squares, etc., but only in

approved locations.

• Do not operate the model in thunderstorms.

• Before each ight, check your remote control system for sufcient function and range.

• After ying, remove all batteries from the model.

Do not „aim“ the transmitter antenna at the model during operation. In this direction, the transmitter

has the lowest radiation. The best position of the antenna is to the side of the model.

Use of devices with image and/or sound recording function:

If you equip your model with a video or image recording device (e.g. FPV cameras, action scams

etc.) or the model is already equipped with such a device at the factory, please note that you

could violate the privacy of one or more persons by using the recording function. An overight or

driving on private ground without the appropriate permission of the owner or approaching private

ground can also be regarded as an invasion of privacy. You, as the operator of the model, are sole-

ly and fully responsible for your actions.

In particular, all applicable legal requirements must be observed, which can be found in the roof

associations or the relevant authorities. Failure to comply can result in substantial penalties.

E N G L I S H

I N S T R U C T I O N S A N D U S E R M A N U A L

CO NFOR MITY

Modellbau Lindinger GmbH hereby declares that this device complies with

the essential requirements and other relevant regulations of the correspon-

ding CE directives. The original declaration of conformity can be found

on the Internet at www.robbe.com, in the detailed product view of the

respective device description or on request. This product can be operated

in all EU countries.

WARR ANTY

Our articles are equipped with the legally required 24 months warranty. Should you wish to assert a

justied warranty claim, always contact your dealer, who is responsible for the warranty and the pro-

cessing. During this time, any functional defects that may occur, as well as manufacturing or other

problems, will be rectied.

Material defects corrected by us free of charge. Further claims, e.g. for consequential damages, are

excluded.

The transport to us must be free, the return transport to you is also free. Freight collect shipments can-

not be accepted. We cannot accept liability for transport damage and loss of your consignment.

We recommend appropriate insurance.

To process your warranty claims, the following requirements must be met:

• Attach the proof of purchase (receipt) to your shipment.

• The units have been operated in accordance with the operating instructions.

• Only recommended power sources and original robbe accessories have been used.

• There is no moisture damage, external interference, reverse polarity, overloading or mechanical

damage.

• Attach relevant information for nding the fault or defect.

This symbol means that small electrical and electronic devices must be dis-

posed of at the end of their useful life, separated from the household refuse.

Dispose of the device at your local municipal collection point or recycling

centre. This applies to all countries of the European Union and other Europe-

an countries with a separate collection system.

DISPOSAL

INSURANCE

Ground-based models are usually covered by personal liability insurance. Additional insurance or

extension is required for aircraft models. Check your insurance policy (private liability) and take out

suitable insurance if necessary.

DISCLAIMER

Modellbau Lindinger GmbH cannot monitor compliance with the assembly and operating instruc-

tions or the conditions and methods for installation, operation, use and maintenance of the model

components.Therefore, we accept no liability for losses, damage or costs arising from or in any

way connected with incorrect use and operation.To the extent permitted by law, the obligation to

pay damages, irrespective of the legal grounds, shall be limited directly to the invoice value of the

claims arising from the event causing the damage.

FLIGHT INST RUC TIONS

• Before the rst ight, observe the instructions in the „Safety Instructions“ section.

• When ying the model, you should choose a day with as little wind as possible

• A large, at area without obstacles (trees, fences power lines etc.) is suitable for the rst ights.

• Please carry out a functional test of the drive train / power set and remote control.

• After assembling the model on the aireld, check once again that all model components such as

wing, tail units, wing mounts, engine, linkages, etc. are rmly and properly fastened.

• For a hand start a helper should be present, who can throw the model with enough thrust into the

air.

• The start usually takes place against the wind.

• Do not stall the model near the ground

• Do not initiate tight turns in the immediate vicinity of the ground.

• Check the reactions of the model to the rudder deections. If necessary, adjust after landing to

increase or decrease the deections accordingly.

• The minimum ight speed must be at an adequate safety altitude.

• Initiate the landing with sufcient speed

SAFE TY INSTR UCTIONS FOR REC HARG EABLE BATTERIE S

• Do not immerse the battery in water or other liquids.

• Do not heat, throw into re or microwave.

• Do not short-circuit or charge with reversed polarity

• Do not expose, deform or throw the battery

• Do not solder directly on the battery

• Do not change or open the battery

• Only charge the battery with suitable chargers, never connect it directly to a power supply unit.

• Never charge or discharge the battery or charger on a ammable surface.

• Never leave the battery unattended during charging or discharging processes.

• Never charge or discharge the battery in direct sunlight or near heaters or re.

• Do not use the battery in places subject to high static discharge.

All this can cause the battery to be damaged, explode or even catch re!

• Keep the battery away from children

• Keep leaked electrolyte away from re, as it is highly ammable and may ignite.

• The electrolyte liquid should not get into the eyes, if it does, rinse immediately with plenty of clear

water and then see a doctor.

• -The electrolyte liquid can also escape from clothes and other objects with a lot of water or was

hed off.

• Observe the safety instructions of the battery manufacturer and the charger manufacturer.

Made in China

+14

This product is not a toy.

Operate only under the

direct supervision of adults.

Product specificaties

Merk:	Robbe
Categorie:	Radiografisch bestuurbaar speelgoed
Model:	Arcus II
Kleur van het product:	Black, Red, White
Gewicht:	850 g
Gebruikershandleiding:	Ja
Materiaal behuizing:	Carbon, Carbon Fibre Reinforced Polymer (CFRP), Expanded Polyolefin (EPO), Foam, Plastic
Lengte:	1190 mm
Constructietype:	Plug en Play (PNP)
Aantal kanalen:	4 kanalen
Type product:	Zweefvliegtuig
Type motor:	Borstelloos
Spanwijdte:	1840 mm
Aantal servo's:	4
Moeilijkheidsgraad:	Beginner
Gewicht servo:	8 g
Aanbevolen batterij:	3S/1300mAh LiXX
