Pagina 1/4

Privacy Mode

Cable management

What’s in the box

Connect and Power On the Camera

x 2 x 2

Quick start guide

Your baby monitor package contains the following items. Save your sales receipt and original

packaging in the event warranty service is necessary.

Designed for extra peace of mind, turn on Privacy Mode for a moment of peace and quiet.

When the Privacy Mode is turned on, audio transmission and video monitoring will be disabled

so motion recording, motion detection, and sound detection will be temporarily unavailable.

Connect the power adapter to the camera and a power supply, then the camera powers on

automatically.

Overview

Camera

1Bee cover

2Light sensor

3Camera lens

4Microphone

5Night Light

6Speaker

7Status LED

8PAIR

• Press and hold for three seconds to enter

pairing mode.

• Reset the baby unit to factory default.

1. Press and hold PAIR key until you hear a

beep sound.

2. Release the PAIR key, and then press the

PAIR key again ﬁve times until you hear

another beep sound.

3. The baby unit will sound another beep

when the reset completes. Then, the

baby unit will reboot.

9Temperature sensor

10 Power jack

11 Wall mount slots

• Use only the power adapter supplied with this product.

• If the camera is connected to a switch controlled electric outlet, make sure the switch is on.

• Connect the power adapters in a vertical or ﬂoor mount position only. The adapters’ prongs are not

designed to hold the weight of the camera, so do not connect them to any ceiling, under-the-table, or

cabinet outlets. Otherwise, the adapters may not properly connect to the outlets.

• To maintain compliance with the FCC’s RF exposure guidelines, place the camera at least 20cm from

nearby persons.

1 set for RM9751

Important safety instructions

After installing the MyVTech Baby Pro App...

• Sign up for an account

• Pair the camera with your mobile device

• Monitor your baby using a wide range of features

Start monitoring from anywhere.

Download the free MyVTech Baby Pro mobile app and install it to a mobile device, then

use your mobile device and the mobile app to monitor your areas remotely.

Download app for mobile access

Pair the Camera with your Mobile Device

App Compatibility

• AndroidTM 6.0 or later

• iOS 12 or later.

On Baby Care App

Before you start...

• Connect your mobile device to a 2.4GHz Wi-Fi network for a better connection and smoother video

streaming.

• Enable the Location Service of your mobile device for the purpose of camera setup.

With a 2.4GHz Wi-Fi network and enabled Location Service...

You can start to pair the camera with your own mobile device following the instructions in the app.

Upon the successful pairing, you can hear and watch your baby via your mobile device.

Tips:

• Move the camera and the Wi-Fi router closer to each other in order to strengthen the network signal.

• It takes up around 1 minute to search the camera.

The applied nameplate is located at the bottom of the camera’s

base. When using your equipment, basic safety precautions

should always be followed to reduce the risk of ﬁre, electric shock

and injury, including the following:

1. Follow all warnings and instructions marked on the product.

2. Adult setup is required.

3. CAUTION: Do not install the camera at a height above 2

meters.

4. This product is not a substitute for adult supervision of the

infant. Supervising the infant is the parent’s or caregiver’s

responsibility. This product could cease operating, and

therefore you should not assume it will continue working

properly for any given period of time. Further, this is not a

medical device and should not be used as such. This product

is intended to assist you in supervising your baby.

5. Do not use this product near water. For example, do not use

it next to a bath tub, wash bowl, kitchen sink, laundry tub or

swimming pool, or in a wet basement or shower.

6. Use only the adapters included with this product. Incorrect

adapter polarity or voltage can seriously damage the product.

Power adapters information:

Camera Output: 5V 1A;

VTech Telecommunications Ltd.;

Model: VT05EUS05100

7. The power adapters are intended to be correctly oriented in a

vertical or ﬂoor mount position. The prongs are not designed

to hold the plug in place if it is plugged into a ceiling, under-

the-table or cabinet outlet.

8. For pluggable equipment, the socket-outlet shall be installed

near the equipment and shall be easily accessible.

9. Unplug this product from the wall outlet before cleaning.

10. Do not use liquid or aerosol cleaners. Use a damp cloth for

cleaning. Do not cut off the power adapters to replace them

with other plugs, as this causes a hazardous situation.

11. Do not allow anything to rest on the power cords. Do not

install this product where the cords may be walked on or

crimped.

12. This product should be operated only from the type of power

source indicated on the marking label. If you are not sure of

the type of power supply in your home, consult your dealer or

local power company.

13. Do not overload wall outlets or use an extension cord.

14. Do not place this product on an unstable table, shelf, stand or

other unstable surfaces.

15. This product should not be placed in any area where proper

ventilation is not provided. Slots and openings in the back or

bottom of this product are provided for ventilation. To protect

them from overheating, these openings must not be blocked

by placing the product on a soft surface such as a bed, sofa

or rug. This product should never be placed near or over a

radiator or heat register.

16. Never push objects of any kind into this product through

the slots because they may touch dangerous voltage points

or create a short circuit. Never spill liquid of any kind on the

product.

17. To reduce the risk of electric shock, do not disassemble this

product, but take it to an authorized service facility. Opening

or removing parts of the product other than speciﬁed access

doors may expose you to dangerous voltages or other risks.

Incorrect reassembling can cause electric shock when the

product is subsequently used.

18. You should test the sound reception every time you turn on

the units or move one of the components.

19. Periodically examine all components for damage.

20. There is a very low risk of privacy loss when using certain

electronic devices, such as cameras, cordless telephones,

etc. To protect your privacy, make sure the product has never

been used before purchase, reset the camera periodically by

powering off and then powering on the units, and power off

the camera if you will not use it for some time.

21. Children should be supervised to ensure that they do not play

with the product.

22. The product is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of the

appliance by a person responsible for their safety.

SAVE THESE INSTRUCTIONS

Cautions

1. Use and store the product at a temperature between 32oF

(0oC) and 104oF (40oC).

2. Do not expose the product to extreme cold, heat or direct

sunlight. Do not put the product close to a heating source.

3. Warning—Strangulation Hazard—Children

have STRANGLED in cords. Keep this cord out of

the reach of children (more than 3 ft (0.9m) away).

Do not remove this tag.

4. Never place the camera(s) inside the baby’s crib or playpen.

Never cover the camera(s) with anything such as a towel or a

blanket.

5. Other electronic products may cause interference with your

camera. Try installing your camera as far away from these

electronic devices as possible: wireless routers, radios, cellular

telephones, intercoms, room monitors, televisions, personal

computers, kitchen appliances and cordless telephones.

Precautions for users of implanted cardiac pacemakers

Cardiac pacemakers (applies only to digital cordless devices):

Wireless Technology Research, LLC (WTR), an independent

research entity, led a multidisciplinary evaluation of the

interference between portable wireless devices and implanted

cardiac pacemakers. Supported by the U.S. Food and Drug

Administration, WTR recommends to physicians that:

Pacemaker patients

• Should keep wireless devices at least six inches from the

pacemaker.

• Should NOT place wireless devices directly over the

pacemaker, such as in a breast pocket, when it is turned ON.

WTR’s evaluation did not identify any risk to bystanders with

pacemakers from other persons using wireless devices.

Electromagnetic ﬁelds (EMF)

This VTech product complies with all standards regarding

electromagnetic ﬁelds (EMF). If handled properly and according

to the instructions in this user’s manual, the product is safe to be

used based on scientiﬁc evidence available today.

Position the Camera

> 3ft (1m)

Tips:

• You can ﬁnd the wall mounting tutorial video and step-

by-step guide by visiting our Online Manual.It takes up

around 1 minute to search the camera.

Pan and Tilt your camera

RM9751

What does HD Video Monitor do?

Quick start guide

(Canada version)

Wi-Fi 1080p Yellow Daisy Baby Camera allows you to stay close to your baby when you are

on the move or away. This monitor is Wi-Fi enabled, using your home wireless network to

stream live video and audio through the 1080p baby camera and mobile devices. It allows

you to maintain a constant connection to your baby. Wi-Fi 1080p Yellow Daisy Baby Camera

uses MyVTech Baby Pro app to let you instantly see and hear what’s happening with your

baby from anywhere in the world. The app can be downloaded from the App Store or the

Google Play

TM Store.

You can also monitor from your smartphone and mobile tablet. VTech 5” Smart Wi-Fi

1080p Video Monitor uses MyVTech Baby Pro app to let you instantly see and hear what’s

happening with your baby from anywhere in the world. The app can be downloaded from

the App Store or the Google PlayTM Store.

1 2 3

Wi-Fi 1080p

Yellow Daisy Baby Camera

Go to www.vtechcanada.com

for the latest VTech product news.

Congratulations

on purchasing your new VTech product. Before using this HD video monitor, please read

Important safety instructions.

For support, shopping, and everything new at VTech, visit our website at

www.vtechcanada.com.

For more support information

VTech cares about your privacy and peace of mind. That’s why we’ve put together a list of industry-

recommended best practices to help keep your wireless connection private and your devices protected

when online. We recommend you carefully review and consider complying with the following tips.

Ensure your wireless connection is secure.

• Before installing a device, ensure your router’s wireless signal is encrypted by selecting the “WPA2-PSK

with AES” setting in your router’s wireless security menu.

Change default settings.

• Change your wireless router’s default wireless network name (SSID) to something unique.

• Change default passwords to unique, strong passwords. A strong password:

- Is at least 10 characters long.

- Is complex.

- Does not contain dictionary words or personal information.

- Contains a mix of uppercase letters, lowercase letters, special characters and numbers.

Keep your devices up to date.

• Download security patches from manufacturers as soon as they become available. This will ensure you

always have the latest security updates.

• If the feature is available, enable automatic updates for future releases.

Disable Universal Plug and Play (UPnP) on your router.

• UPnP enabled on a router can limit the effectiveness of your ﬁrewall by allowing other network devices

to open inbound ports without any intervention or approval from you. A virus or other malware

program could use this function to compromise security for the entire network.

For more information on wireless connections and protecting your data, please review the following

resources from industry experts:

1. Federal Communications Commission: Wireless Connections and Bluetooth Security Tips –

www.fcc.gov/consumers/guides/how-protect-yourself-online.

2. U.S. Department of Homeland Security: Before You Connect a New Computer to the Internet –

www.us-cert.gov/ncas/tips/ST15-003.

3. Federal Trade Commission: Using IP Cameras Safely –

https://www.consumer.ftc.gov/articles/0382-using-ip-cameras-safely.

4. Wi-Fi Alliance: Discover Wi-Fi Security –

http://www.wi-ﬁ.org/discover-wi-ﬁ/security.

Mount the Camera (Optional)

How the system works ?

Protect Your Privacy and Online Security Test the Location for the Camera

Your home Wi-Fi network provides Internet connection to your camera so that you can

monitor and control your camera whenever you are through the MyVTech Baby Pro App.

Your Wi-Fi router (not included) provides the Internet connectivity, which serves as a

communicating channel.

If you plan to install your camera to a designated location, and will use your home Wi-Fi network to

connect your mobile device, test whether your selected monitoring areas have good Wi-Fi signal

strength. Adjust the direction and distance between your camera, mobile device and Wi-Fi router until

you have identiﬁed a suitable location with good connection.

Note:

• Depending on surroundings and obstructing factors, such as the effect distance and internal walls

have on signal strength, you may experience reduced Wi-Fi signal.

Disclaimer and Limitation of Liability

Technical Specications

FCC and IC regulations

Notes:

• Check for reception strength and the camera viewing angle before drilling the holes.

• The types of screws and anchors you need depend on the composition of the wall. You may need to

purchase the screws and anchors separately to mount your camera.

VTech and its suppliers assume no responsibility for any damage or loss resulting from the use of this handbook. VTech and its

suppliers assume no responsibility for any loss or claims by third parties that may arise through the use of this software. VTech

and its suppliers assume no responsibility for any damage or loss caused by deletion of data as a result of malfunction, dead

battery, or repairs. Be sure to make backup copies of important data on other media to protect against data loss.

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO

CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT

ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

CAN ICES-3 (B)/NMB-3(B)

Caution: Changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s authority

to operate the equipment.

Warranty: Please visit our website at vtechphones.com for full details of the warranty provided in your country.

Mobile access

Wi-Fi connection

1. Place the wall mount

bracket on a wall and then

use a pencil to mark the

top and the bottom holes

as shown. Remove the

wall mount bracket and

drill two holes in the wall

(7/32 inch drill bit).

2. If you drill the holes into a

stud,go to step 3.

• If you drill the holes into an

object other than a stud,

insert the wall anchors into

the holes. Tap gently on the

ends with a hammer until the

wall anchors are ﬂush with

the wall.

4. Place the camera on the wall mount bracket. Insert the

mounting studs into the wall mount holes. Then, slide the

camera forwards until it locks securely. Align the holes on

the wall mount bracket with the screws on the wall, and

slide the wall mount bracket down until it locks into place.

3. Insert the

screwsinto the

holes and tighten

the screws until

only 1/4 inch of

the screws are

exposed.

5. You can maximize your camera viewing anglesby

tilting the wall mount bracket.

Hold the camera, and then rotate the knob in an

anti-clockwise direction. This will loosen the joint of

the wall mount bracket.

Tilt your camera up or down to adjust to your

preferred angle. Then, rotate the knob in a

clockwise direction to tighten the joint and secure

the angle.

FCC Part 15

This equipment has been tested and found to comply

with the requirements for a Class B digital device under

Part 15 of the Federal Communications Commission

(FCC) rules. These requirements are intended to provide

reasonable protection against harmful interference in

a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions,

may cause harmful interference to radio communications.

However, there is no guarantee that interference will

not occur in a particular installation. If this equipment

does cause harmful interference to radio or television

reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment

and receiver.

• Connect the equipment into an outlet on a

circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV

technician for help.

WARNING: Changes or modiﬁcations to this equipment

not expressly approved by the party responsible for

compliance could void the user’s authority to operate

the equipment.

This device complies with Part 15 of the FCC rules.

Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received,

including interference that may cause undesired

operation.

To ensure safety of users, the FCC has established criteria

for the amount of radio frequency energy that can be

safely absorbed by a user or bystander according to

the intended usage of the product. This product has

been tested and found to comply with the FCC criteria.

The camera shall be installed and used such that parts

of all persons’ body are maintained at a distance of

approximately 8 in (20 cm) or more.

This Class B digital apparatus complies with Canadian

requirement: CAN ICES-3 (B)/NMB-3(B)

Industry Canada

This device contains licence-exempt transmitter(s)/

receiver(s) that comply with Innovation, Science and

Economic Development Canada’s licence-exempt RSS(s).

Operation is subject to the following two conditions: (1)

This device may not cause interference. (2) This device

must accept any interference, including interference that

may cause undesired operation of the device.

The term ‘’IC:‘’ before the certiﬁcation/registration

number only signiﬁes that the Industry Canada technical

speciﬁcations were met.

This product meets the applicable Innovation, Science

and Economic Development Canada technical

speciﬁcations.

RF radiation exposure statement

The product complies with FCC RF radiation exposure

limits set forth for an uncontrolled environment.

The camera should be installed and operated with a

minimum distance of 8 in (20 cm) between the camera

and all persons’ body. Use of other accessories may not

ensure compliance with FCC RF exposure guidelines. This

equipment complies also with Industry Canada RSS-102

with respect to Canada’s Health Code 6 for Exposure of

Humans to RF Fields.

Technology

Channels

Internet Connection

Nominal effective

range

Power requirements

Wi-Fi 2.4GHz 802.11 b/g/n

1-11 (2412 - 2462 MHz)

Minimum Requirement: 1.5 Mbps @ 720p or 2.5 Mbps @ 1080p

upload bandwidth per camera

Maximum power allowed by FCC and IC. Actual operating range

may vary according to environmental conditions at the time of use.

Camera unit power adapter: Output: 5V DC @ 1 A

Credits:

The Background Noise sound ﬁle was created by Caroline Ford, and is used under the Creative Commons license.

The Stream Noise sound ﬁle was created by Caroline Ford, and is used under the Creative Commons license.

The Crickets At Night sound ﬁle was created by Mike Koenig, and is used under the Creative Commons license.

The Heart Beat sound ﬁle was created by Zarabadeu, and is used under the Creative Commons license.

Specifications are subject to change without notice.

UL STD.

62368-1

CERTIFIED TO

CSA STD.

C22.2 NO.62368-1

CO ORMS TO NF

What does this limited warranty cover?

The manufacturer of this VTech product, VTech

Communications, Inc. (“VTech”), warrants to the holder of a

valid proof of purchase (“Consumer” or “you”) that the Product

and all accessories provided by VTech in sales package

(“Product”) are free from material defects in material and

workmanship, pursuant to the following terms and conditions,

when installed and used normally and in accordance with

operating instructions. This limited warranty extends only to

the Consumer for Products purchased and used in the United

States of America and Canada.

What will VTech do if the Product is not free from defects in

materials and workmanship during the limited warranty period

(“Materially Defective Product”)?

During the limited warranty period, VTech’s authorized service

representative will replace at VTech’s option, without charge,

a Materially Defective Product. If we choose to replace the

Product, we may replace it with a new or refurbished Product

of the same or similar design. VTech will return replacement

products to you in working condition. VTech will retain defective

parts, modules, or equipment. Replacement of the Product, at

VTech’s option, is your exclusive remedy. You should expect the

replacement to take approximately 30 days.

How long is the limited warranty period?

The limited warranty period for the product extends for

ONE (1) YEAR from date of purchase (90 days on products

purchased as Refurbished*). This limited warranty also applies

to replacement Products for a period of either (a) 90 days from

the date the replacement Product is shipped to you or (b)

the time remaining on the original one-year limited warranty

(90-day limited warranty on products that are purchased as

Refurbished*). Whichever is longer.

*Refurbished products purchased from our online store carry a

90-day replacement warranty.

What is not covered by this limited warranty?

This limited warranty does not cover:

1. Product that has been subjected to misuse, accident,

shipping or other physical damage, improper installation,

abnormal operation or handling, neglect, inundation, ﬁre,

water or other liquid intrusion; or

2. Product that has been damaged due to repair, alteration or

modiﬁcation by anyone other than an authorized service

representative of VTech; or

3. Product to the extent that the problem experienced is caused

by signal conditions, network reliability, or cable or antenna

systems; or

4. Product to the extent that the problem is caused by use with

non-VTech accessories; or

5. Product whose warranty/quality stickers, product serial

number plates or electronic serial numbers have been

removed, altered or rendered illegible; or

6. Product purchased, used, serviced, or shipped for repair

from outside the United States of America or Canada, or used

for commercial or institutional purposes (including but not

limited to Products used for rental purposes); or

7. Product returned without a valid proof of purchase (see item

2 below); or

8. Charges for installation or set up, adjustment of customer

controls, and installation or repair of systems outside the unit.

How do you get warranty service?

To obtain warranty service in the United States of America,

please visit our website at www.vtechphones.com or call

1 (800) 595-9511 for instructions regarding where to return the

Product.In Canada, go to phones.vtechcanada.com or dial 1

(800) 267-7377.

NOTE: Before calling for service, please review the user’s

manual - a check of the Product’s controls and features may

save you a service call.

Except as provided by applicable law, you assume the risk

of loss or damage during transit and transportation and are

responsible for delivery or handling charges incurred in the

transport of Product(s) to the service location. VTech will

return replaced product under this limited warranty to you,

transportation, delivery or handling charges prepaid. VTech

assumes no risk for damage or loss of the Product in transit.

What must you return with the Product to get warranty service?

1. Return the entire original package and contents including the

Product to the VTech service location along with a description

of the malfunction or difﬁculty; and

2. Include a “valid proof of purchase” (sales receipt) identifying

the Product purchased (Product model) and the date of

purchase or receipt; and

3. Provide your name, complete and correct mailing address,

and telephone number.

Other limitations

This warranty is the complete and exclusive agreement

between you and VTech. It supersedes all other written or

oral communications related to this product. VTech provides

no other warranties for this product. The warranty exclusively

describes all of VTech’s responsibilities regarding the product.

There are no other expressed warranties. No one is authorized

to make modiﬁcations to this warranty and you should not rely

on any such modiﬁcation.

State Law Rights: This warranty gives you speciﬁc legal rights,

and you also have other rights which vary from state to state.

Limitations: Implied warranties, including those of ﬁtness for

a particular purpose and merchantantability (an unwritten

warranty that the product is ﬁt for ordinary use) are limited

to one year from date of purchase. Some states do not allow

limitations on how long an implied warranty lasts, so the above

limitation may not apply to you.

In no event shall VTech be liable for any indirect, special,

incidental, consequential, or similar damages (including, but not

limited to lost proﬁts or revenue, inability to use the product, or

other associated equipment, the cost of substitute equipment,

and claims by third parties) resulting from the use of this

product. Some states do not allow the exclusion or limitation of

incidental or consequential damages, so the above limitation or

exclusion may not apply to you.

Please retain your original sales receipt as proof of purchase.

Limited warranty

Need help?

Driven by system updates, the software, online help topics, and online

FAQs will be updated periodically.

For operations and guides to help you using your HD video monitor,

and for latest information and supports, go and check the online help

topics and online FAQs.

You can also call our Customer Support at for help.1-888-211-2005

Use your smartphone or mobile device to access our online help.

1. Go to https://phones.vtechcanada.com/manuals; OR

Scan the QR code on the right. Launch the camera app or

QR code scanner app on your smartphone or tablet. Hold

the device’s camera up to the QR code and frame it. Tap the

notification to trigger the redirection of the

online help.

- If the QR code is not clearly displayed, adjust your camera’s

focus by moving your device closer or further away until it

is clear.

2. Search for the model - RM9751

Product specificaties

Merk:	VTech
Categorie:	Babyfoon
Model:	RM9751

Heb je hulp nodig?

Als je hulp nodig hebt met VTech RM9751 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden

Uw naam*

Jouw email*

Schrijf hier uw vraag

Handleiding Babyfoon VTech

VTech RM9751 Handleiding

13 December 2024

VTech RM5754-2HD Handleiding

13 December 2024

VTech RM5764-2HD Handleiding

13 December 2024

VTech VC2105 Handleiding

13 December 2024

VTech RM2751 Handleiding

13 December 2024

VTech RM5754HD Handleiding

13 December 2024

VTech VM3252 Handleiding

16 November 2024

VTech RM5764HD Handleiding

16 November 2024

VTech DM1211 Handleiding

16 November 2024

VTech RM5766HD Handleiding

27 Februari 2024

Handleiding Babyfoon

Nieuwste handleidingen voor Babyfoon

Alecto DVM-200 Handleiding

14 November 2024

Oricom SC330 Handleiding

10 December 2024

Alecto DVM200XL Handleiding

4 December 2024

D-Link DCS-825L Handleiding

23 November 2024

Chipolino Polaris Handleiding

16 November 2024

Neno Bambino Handleiding

15 November 2024

Babymoov YOO-Care A014422 Handleiding

15 November 2024

Oricom RVSL01 Handleiding

10 November 2024

Oricom RGB Handleiding

10 November 2024

Alecto DVM2028 Handleiding

5 November 2024
