Frequency Baby unit: 2412 - 2462 MHz
Channels 11
LCD 2.8’’ Color LCD
(IPS 320x240 pixels)
Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may
vary according to environmental conditions at the time of use.
Power requirement Parent unit/Baby unit power adapters:
VTech, VT05EUS05100
Rated output: 5V DC, 1000mA.
Parent unit battery: 3.6V 2600mAh, 9.36Wh Lithium-ion battery
Specifications are subject to change without notice.
© 2022 VTech Communications, Inc.
All rights reserved. 10/22. RM2751_CA_QSG_V1
Technical specications
Android TM and Google Play TM are trademarks of Google Inc.
App Store is a trademark of Apple Inc., registered in the U.S. and other countries.
IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license.
RM2751
2.8 inch Smart Wi-Fi 1080p
Video Monitor
What does Video Monitor do?
VTech 2.8 inch Smart Wi-Fi 1080p Video Monitor allows you to stay close to your baby when
you are on the move or away.
This monitor is Wi-Fi enabled, which uses your home wireless network to stream live video and
audio through the baby unit and 2.8 inch color screen parent unit. It allows you to maintain a
constant connection to your baby.
You can also monitor from your smartphone and mobile tablet.
VTech 2.8 inch Smart Wi-Fi 1080p Video Monitor uses MyVTech Baby Pro app to let you
instantly see and hear what’s happening with your baby from anywhere in the world.
The app can be downloaded from the App Store or the Google PlayTM Store, directly from your
smartphone or mobile tablet.
Quick start guide
(Canada version)
For more support information
UL STD.
62368-1
CERTIFIED TO
CSA STD.
C22.2 NO.62368-1
CO ORMS TO NF
Direct mode
The parent unit and the baby unit of your video monitor connect to each others in Direct mode
by default, which allows you to stream live video right out of the box. Direct mode connection
lets you stream live video from parent unit only.
• You may experience reduced signal strength if your parent unit and baby unit are far apart, or there are
obstructing factors, such as internal walls, between them. Move the parent unit closer to the baby unit to
improve the signal strength. You can also set up Router mode to connect via your home Wi-Fi network to
improve the connection between your parent unit and baby unit.
Router mode
You can continue using your video monitor
with connection, or you Direct mode
can set up your monitor in Router mode
connection.
Router mode uses your home Wi-Fi
network to connect your video monitor.
It supports streaming live video through
parent unit and smartphone app.
We recommend that you set up your
monitor in Router mode to enjoy streaming
live video via your parent unit with better
connection.
If you want to stream live video remotely with your mobile device, download and install the
MyVTech Baby Pro mobile app. With the mobile app, your Wi-Fi router (not included) provides
Internet connectivity to your video monitor system. It serves as a communicating channel
between your baby unit and mobile device, allowing you to monitor and/or control your baby
unit wherever you are. For detail, see Download app for mobile access section in this quick start
guide.
Notes
• Your parent unit detects the connection signal strength. If you have connected your video monitor with
your home Wi-Fi network, your parent unit automatically switches to direct or router mode - the one that
has stronger signal strength.
• When both parent unit and app are viewing the camera simultaneously, the video quality will be
optimised to deliver the best possible viewing result.
What’s in the box
Connect, charge and power on the baby monitor
x 2 x 2
Quick start guide
Your video monitor package contains the following items. Save your sales receipt and original
packaging in the event warranty service is necessary.
How the system works
For mobile access:
MyVTech Baby Pro mobile app
Network Wi-Fi
Wi-Fi router 2.4GHz 802.11 b/g/n
Internet connection 1.5 Mbps @ 720p or 2.5 Mbps @1080p upload
bandwidth per baby unit
Requirements
Connect the baby monitor
Fully insert the provided power adapters into the parent unit and baby unit power jack, then plug
into a power source. You can hear a clicking sound if it plugs correctly, and the battery LED light on the
parent unit turns on.
Notes
• The rechargeable battery in the parent unit is built-in.
• Use only the power adapters supplied with this product.
• Make sure the parent unit and the baby unit are not connected to an electronically controlled electric
outlet.
• Connect the power adapters in a vertical or floor mount position only. The adapter prongs are not
designed to hold the weight of the parent unit and the baby unit, so do not connect them to any ceiling,
under-the-table, or cabinet outlets. Otherwise, the adapters may not properly connect to the outlets.
• Make sure the parent unit, the baby unit and the power adapter cords are out of reach of children.
• To maintain compliance with the FCC’s RF exposure guidelines, place the baby unit at least 20cm from
nearby persons.
Charge the parent unit battery before use
The parent unit runs on an internal rechargeable battery or AC power. To continuously monitor
your baby, keep the parent unit connected to AC power. With the battery alone, the parent unit
can cordlessly run for a short time only.
Notes
• Before using the baby monitor for the first time, charge the parent unit battery for 12 hours. When the
parent unit battery is fully charged, the battery icon becomes solid .
• The standby time varies depending on your actual use.
The battery icon indicates the battery status (see the following table).
Battery indicators Battery status Action
alert displays on the parent
unit screen, the battery icon
becomes empty , with the
LED light flashes.
The battery has very little
charge and may be used
for only a short time.
Charge
without interruption
(about 30 minutes).
The battery icon becomes solid
.
The battery is fully
charged.
To keep the battery charged,
connect it to AC power.
The parent unit turns on automatically after
it connects to the power socket, and the
welcome screen appears. You can press and
hold to turn it on or off.
NOTE:
Camera lens and surface may get
warm during normal operation.
WARM
WARM
WARM
WARM
WARM
Parent unit overview
Local access
Mobile access Enhanced local access
Press and hold
The applied nameplate is located at the bottom of the baby unit’s base.
When using your equipment, basic safety precautions should
always be followed to reduce the risk of fire, electric shock and
injury, including the following:
1. Follow all warnings and instructions marked on the product.
2. Adult setup is required.
3. CAUTION: Do not install the baby unit at a height above 6.5
feet (2 meters).
4. This product is intended as an aid. It is not a substitute for
responsible and proper adult supervision and should not be
used as such.
5. This product is not intended for use as a medical monitor.
6. Do not use this product near water, for example, near to a
bath, sink, swimming pool or shower.
7. CAUTION: Use only the battery provided. There may be a risk
of explosion if a wrong type of battery is used for the parent
unit. The battery cannot be subjected to high or low extreme
temperature and low air pressure at high altitude during
use, storage or transportation. Disposal of battery in fire or
a hot oven, mechanically crushing or cutting the battery can
result in an explosion. Leaving the battery in an extremely
high temperature surrounding environment can result in an
explosion or the leakage of flammable liquid of gas. Battery
subjected to extremely low air pressure may result in an
explosion or the leakage of flammable liquid or gas. Dispose
of used battery according to the information in The RBRC seal.
8. Use only the adapters included with this product. Incorrect
adapter polarity or voltage can seriously damage the product.
Power adapter information:
Baby Unit Output: 5V DC 1A
VTech Telecommunications Ltd.
Model: VT05EUS05100
Parent Unit Output: 5V DC 1A
VTech Telecommunications Ltd.
Model: VT05EUS05100
Rechargeable battery information:
Zhuhai Great Power Energy Co., Ltd.
Li-ion battery, 3.6V, 2600mAh, 9.36Wh;
Model:
ICR18650-2.6Ah-3.6V-1S1P
9. The power adapter is intended to be correctly oriented in a
vertical or floor mount position. The prongs are not designed
to hold the plug in place if it is plugged into a ceiling, under-
the-table or cabinet outlet.
10. For pluggable equipment, the socket-outlet (power adapter)
should be installed near the equipment and should be easily
accessible.
11. Unplug this product from the wall outlet before cleaning.
Do not use liquid or aerosol cleaners. Use a damp cloth for
cleaning.
12. Do not modify the power adapters or replace with other
power adapters, as this causes a hazardous situation.
13. Do not allow anything to rest on the power cords. Do not install
this product where the cords may be walked on or crimped.
14. This product should be operated only from the type of power
source indicated on the marking label. If you are not sure of
the type of power supply in your home, consult your dealer or
electricity supply provider.
15. Do not overload wall outlets or use an extension cord.
16. Do not place this product on an unstable table, shelf, stand or
other unstable surfaces.
17. This product should not be placed in any area where proper
ventilation is not provided. Slots and openings in the back or
bottom of this product are provided for ventilation. To protect
them from overheating, these openings must not be blocked
by placing the product on a soft surface such as a bed, sofa
or rug. This product should never be placed near or over a
radiator or heat source.
18. Never push objects of any kind into this product through
the slots because they may touch dangerous voltage points
or create a short circuit. Never spill liquid of any kind on the
product.
19. To reduce the risk of electric shock, do not disassemble
this product, but take it to an authorized service facility.
Disassembling or removing parts of the product other than
via the battery door may expose you to dangerous voltages
or other risks. Incorrect reassembling can cause electric shock
when the product is subsequently used.
20. You should test the sound reception every time you turn on
the units or move one of the components.
21. Periodically examine all components for damage.
22. There is a very low risk of privacy loss when using certain
electronic devices, such as baby monitors, cordless
telephones, etc. To protect your privacy, make sure the
product has never been used before purchase, reset the baby
monitor periodically by powering off and then powering
on the units, and power off the baby monitor if you are not
intending to use it for some time.
23. Children should be supervised to ensure that they do not play
with the product.
24. The small parts of this monitor can be swallowed by babies or
small children. Keep these parts out of reach of children.
25. The product is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
SAVE THESE INSTRUCTIONS
Cautions
• Use and store the product at a temperature between 32 oF
(0oC) and 104oF (40oC).
• Batteries should not be exposed to excessive heat such as
bright sunshine or fire.
• Mishandling batteries can cause burn, fire or explosion
hazards.
• Do not expose the product to extreme cold, heat or direct
sunlight. Do not put the product close to a heating source.
• Strangulation Hazard—Children have STRANGLED
in cords. Keep this cord out of the reach of children
(more than 3 ft (0.9m) away). Do not remove
warning label on the adapter cord.
• Never place the baby unit(s) inside the baby’s
crib or playpen. Never cover the baby unit(s) or
parent unit with anything such as a towel or a blanket.
• Other electronic products may cause interference with your
baby unit. Try installing your baby unit as far away from these
electronic devices as possible: wireless routers, radios, cellular
telephones, intercoms, room monitors, televisions, personal
computers, kitchen appliances and cordless telephones.
Precautions for users of implanted cardiac pacemakers
Cardiac pacemakers (applies only to digital cordless devices):
Wireless Technology Research, LLC (WTR), an independent
research entity, led a multidisciplinary evaluation of the
interference between portable wireless devices and implanted
cardiac pacemakers. Supported by the U.S. Food and Drug
Administration, WTR recommends to physicians that:
Pacemaker patients
• Should keep wireless devices at least six inches from the
pacemaker.
• Should NOT place wireless devices directly over the
pacemaker, such as in a breast pocket, when it is turned ON.
WTR’s evaluation did not identify any risk to bystanders with
pacemakers from other persons using wireless devices.
Electromagnetic elds (EMF)
This VTech product complies with all standards regarding
electromagnetic fields (EMF). If handled properly and according
to the instructions in this user’s manual, the product is safe to be
used based on scientific evidence available today.
Important safety instructions
Basic operation
Talk to your baby via the baby unit
1. Press and hold the key.
2. icon displays on When the
screen, speak to your parent unit.
Your voice is transmitted to the
baby unit.
3. When finished talking, release
the key and hear your baby
again.
Adjust speaker volume
Press to adjust your parent or
unit speaker volume level received from
the baby unit.
After powering up your video monitor, the parent unit streams live video in direct mode.
We recommend you follow the instructions on screen to set up home Wi-Fi network
with your monitor for functionality enhancements and mobile access. See Auto software
and rmware update and Download app for mobile access in this quick start guide.
Use the menu
Press on the parent unit to enter the
main menu, choose a menu item, or
save a setting. You can use the parent
unit menu for advanced settings or
operations, such as to play or stop
lullaby, or adjust the motion and sound
detection settings.
While in the menu:
• Press or to scroll among the
menu options.
• Press to select an item.
• Press to return.
• Press to exit the menu.
To restore to the default settings or reset the
Wi-Fi connection, you can reset the parent
unit by pressing the key at the back of RESET
the unit.
Use a pin and insert it into the hole on the
back of the parent unit, and then gently press
the button inside.
Turn on/off the parent unit screen
You can turn on or off the parent unit screen
without powering off the parent unit. You
can still hear sound from the baby unit.
• Press on the parent unit to turn off
the screen.
• Press any keys on the parent unit to turn
on the screen again.
Muted
Press and hold
Press
Protect your privacy and online security
VTech cares about your privacy and peace of mind. That’s why we’ve put together a list of
industry-recommended best practices to help keep your wireless connection private and
your devices protected when online. We recommend you carefully review and consider
complying with the following tips.
Ensure your wireless connection is secure.
• Before installing a device, ensure your router’s wireless signal is encrypted by selecting
the “WPA2-PSK with AES” setting in your router’s wireless security menu.
Change default settings.
• Change your wireless router’s default wireless network name (SSID) to something unique.
• Change default passwords to unique, strong passwords. A strong password:
- Is at least 10 characters long.
- Is complex.
- Does not contain dictionary words or personal information.
- Contains a mix of uppercase letters, lowercase letters, special characters and numbers.
Keep your devices up to date.
• Download security patches from manufacturers as soon as they become available. This
will ensure you always have the latest security updates.
• If the feature is available, enable automatic updates for future releases.
Disable Universal Plug and Play (UPnP) on your router.
• UPnP enabled on a router can limit the effectiveness of your firewall by allowing other
network devices to open inbound ports without any intervention or approval from you.
A virus or other malware program could use this function to compromise security for the
entire network.
For more information on wireless connections and protecting your data, please review the
following resources from industry experts:
1. Federal Communications Commission: Wireless Connections and Bluetooth Security Tips
–
www.fcc.gov/consumers/guides/how-protect-yourself-online.
2. U.S. Department of Homeland Security: Before You Connect a New Computer to the
Internet –
www.us-cert.gov/ncas/tips/ST15-003.
3. Federal Trade Commission: Using IP Cameras Safely –
https://www.consumer.ftc.gov/articles/0382-using-ip-cameras-safely.
4. Wi-Fi Alliance: Discover Wi-Fi Security –
http://www.wi-fi.org/discover-wi-fi/security.
Overview
Baby unit overview
1Light sensor
2Camera lens
3Infrared LEDs
Allow you to see clearly in a dark surrounding.
4Microphone
5 Night light touch key
(for model with Serial Number starts
with 0KW)
• Tap to turn the night light on or off.
• Tap and hold to adjust night light
brightness.
6Night light
7Speaker
8 Night light control key
• Press to turn the night light on or off.
• Press and hold to adjust night light
brightness.
9PAIR
• The parent unit and baby unit(s) provided
are already paired.
• Reset the baby unit to factory default.
Press and hold PAIR key and Night light
control key at the same time, until you
hear a beep sound.
10 Power jack
11 Temperature sensor
12 Slots for wall mounting
• Wall mount bracket is included in your
package.
13 Product label
• Here show the product Serial Number
(S/N) and other specification. If the serial
number starts with 0KW, the product
comes with a night light touch key
feature.
3
4
5
6
2
1
10
11
9
8
7
12
WIFI M AC: XXXXXX
Mad e in China
For produ ct su pport ple as e
cal l: 1300 369 193
Mo del :RM275 -2 BU
S/N: XXXXXXXXXXX
13
Go to www.vtechcanada.com
for the latest VTech product news.
Str ang ul atio n
Haz a rd
Keep this cord out of reach of children.
The cord ne eds to be at lea s t thre e feet
away from t he child at all tim es . Do not
use with an e xtens ion cord. Do not
rem ove t his t ag.
Éloignez ce cordon des en fants. Le
cordon doit s e tro uve r à a u moins trois pieds d’un enfant e t ce, en tou t te mps .
N’utilisez pa s de ra llonge. Ne re tirez pa s cette é tiquett e.
Manten ga e st e cable fuera de la alcan ce
de los niños . Este cable deb e es ta r por
lo meno s t res pies fuer a de la alcance
del niño en to do m ome nto. No lo us e
con una exte ns ión inalá mbr ica. No quite es ta e tiquet a.
Ri s q u e
d’é tr an g le men t
Ri e sg o de
e str a n gu la ci ó n
Str ang ul atio n
Haz a rd
Keep th is cord out of reach of children.
The cord ne eds to be at lea s t thre e feet
away from t he child at all tim es . Do not
use with an e xtens ion cord. Do not
rem ove t his t ag.
Éloignez ce cordon des en fants. Le
cordon doit s e tro uve r à a u moins trois
pieds d’un enfant e t ce, en tou t te mps .
N’utilisez pa s de ra llonge. Ne re tirez pa s cette é tiquett e.
Manten ga e st e cable fuera de la alcan ce
de los niños . Este cable deb e es ta r por
lo meno s t res pies fuer a de la alcance
del niño en to do m ome nto. No lo us e
con una exte ns ión inalá mbr ica. No quite
es ta e tiquet a.
Ri s q u e
d’é tr an g le men t
Ri e sg o de
e str a n gu la ci ó n
1 / Menu/Select
• Press to enter the main menu.
• While in a menu, press to choose an
item, or save a setting.
2
/ Talk/Return
• Press and hold to talk to the baby unit.
• While in a submenu, press to go back.
3 / Power / LCD on/off / Exit
• Press and hold to power on/off the
parent unit.
• Press to screen on/off.
• While in a submenu, press to exit.
4 / / /
• Increase or decrease parent unit’s
volume.
• While in a submenu, press to navigate
leftward or rightward.
5Microphone
6 LED light
• On when the parent unit is connected
to AC power, and the battery is
charging.
• Flashes when the parent unit battery is
low and needs charging.
7LINK LED light
• On when the parent unit is linked to
the baby unit.
• Flashes when the link to the baby unit
is lost.
8Antenna
9Power jack
10 RESET
• Force reboot the parent unit.
11 Speaker
2
1
3
4
5
6
7
11
8
9
10
Raise the parent unit
antenna for better
reception.
mount the baby unit (optional)
1. Place the wall mount bracket on a
wall and then use a pencil to mark
two holes in parallel. Remove the
wall mount bracket and drill two
holes in the wall (7/32 inch drill bit).
Notes
• Check for reception strength and
camera angle of the baby unit before
drilling the holes.
• The types of screws and wall plugs you
need depend on the composition of
the wall. You may need to purchase
the screws and wall plugs separately to
mount your baby units.
2. If you drill the holes into a stud, go
to step 3.
• If you drill the holes into an
object other than a stud, insert
the wall plugs into the holes.
Tap gently on the ends with a
hammer until the wall plugs are
flush with the wall.
3. Align the wall mount bracket and screws with
the holes in the wall as shown. Tighten the screw
in the middle hole first, so that the wall mount
bracket position is fixed. You can tighten the
other screw in the top hole.
3. Insert the screws into the holes and
tighten the screws until only 1/4 inch of
the screws are exposed.
4. Place the baby unit on the wall
mount bracket, and then slide it
forward until it locks into place. Align
the holes on the wall mount bracket
with the screws on the wall, and slide
the wall mount bracket down until it
locks into place.
OR
4. Place the baby unit on the wall mount bracket,
and then slide it forward until it locks into place.
Connect the power adapter to the baby unit.
Download app for mobile access
Test the sound level and position the video monitor
Auto software and rmware update
Note
• This video monitor is intended as an aid. It is not a substitute for proper adult supervision, and should not
be used as such.
Testing the sound level of the video monitor
• For hearing protection, make sure the parent unit is more than 3 ft (1m) away from the baby
unit. If you hear any feeback noise from the parent unit, move the parent unit further until the
noise stops. You can also press on the parent unit to lower or mute the noise.
• Increase the parent unit speaker volume if you cannot hear the sounds transmitted from the baby unit.
Positioning the monitorvideo
• Keep the baby unit out of the reach of your baby. Never
place or mount the baby unit inside the baby’s crib or
playpen.
1. Place the baby unit more than 3 ft (1 m) away
from your baby.
2. Adjust the angle of the baby unit to aim at your baby.
3. To avoid causing feedback noise from your video monitor:
• Make sure your baby unit and parent unit are more than 3 ft (1m) apart; OR
• Turn down the volume of your parent unit.
>3ft (1 m)
>
<
3ft (1m)
3ft (1m)
To ensure that your video monitor is always at its best performance, the parent unit will
prompt a message and ask you to update its software and the baby unit's firmware
when there are new versions available.
• Follow the instructions on the parent unit screen to update your video monitor. If you
skip the updates, the parent unit and baby unit will be updated automatically when
the parent unit is powered off, and then powered on again.
• To check if your device is running on the latest software, p ress when the parent unit
is idle, go to: > > .
Connect your video monitor with home Wi-Fi network
• You must connect your video monitor to your secured home Wi-Fi network in order
to receive the latest software and firmware updates. To set Wi-Fi up, go to:
> /
b) From app store
1. Browse the App Store or the Google Play store .
2. Search for the mobile app with the keyword “myvtech baby pro“.
3. Download and install the MyVTech Baby Pro mobile app to your mobile device.
OR
Scan the QR codes on the right to get the app.
• Make sure your mobile device meets the minimum
requirement for the mobile app.
Minimum requirement
The mobile app is compatible with:
• AndroidTM 6.0 or later; and
• iOS 12 or later.
1
Set up user account
In your mobile device:
1. to run the mobile app in your mobile device, and then create a user Tap
account.
2. We recommend that you use common webmail services, such as Google Gmail
for registration of your user account. Check your email (and Spam folder), and
activate your new camera account via the email link, then sign in to your account.
2
12
If you plan to install your baby unit in a designated
location, and use your home Wi-Fi network to
connect your video monitor, you need to test
which of your selected monitoring areas within the
house have good Wi-Fi signal strength. After you
have powered on your parent unit, you can use
your parent unit’s Wi-Fi signal strength indicator
to assist in checking. Once you have identified the
suitable location, you can install your baby unit.
Adjust the distance between your baby unit and
the Wi-Fi router if needed.
• Depending on surroundings and obstructing
factors, such as the effect distance and internal
walls have on signal strength, you may experience
reduced Wi-Fi signal. To improve the Wi-Fi signal
strength, adjust the distance or direction of your
parent unit. Check with your parent unit again.
test the location for the baby unit
To keep this product working well and looking good, follow these guidelines:
• Avoid placing it near heating appliances and devices that generate electrical noise (for example, motors or
fluorescent lamps).
• DO NOT expose it to direct sunlight or moisture.
• Avoid dropping the product or treating it roughly.
• Clean with a soft damp cloth.
• DO NOT immerse the parent unit and the baby unit in water and do not clean them under running water.
• DO NOT use cleaning spray or liquid cleaners.
• Make sure the baby unit and parent unit are dry before you connect them to the mains again.
General product care
When you are not going to use the baby monitor for some time, store the parent unit, the baby unit and the
adapters in a cool, dry place.
Storage
Adult supervision
• This baby monitor should be for use by adults only.
• Do not place the baby unit inside the crib or playpen.
• To ensure your children’s safety, do not allow them to touch or play with the baby monitor and its
accessories. THIS IS NOT A TOY.
Parent unit icons
CABLE MANAGEMENT
1 2 3
What does this limited warranty cover?
The manufacturer of this VTech Product warrants to the
holder of a valid proof of purchase (“Consumer” or “you”)
that the Product and all accessories provided in the sales
package (“Product”) are free from defects in material
and workmanship, pursuant to the following terms and
conditions, when installed and used normally and in
accordance with the Product operating instructions. This
limited warranty extends only to the Consumer for Products
purchased and used in the United States of America and
Canada.
What will VTech do if the Product is not free from defects
in materials and workmanship during the limited warranty
period (“Materially Defective Product”)?
During the limited warranty period, VTech’s authorized service
representative will replace at VTech’s option, without charge,
a Materially Defective Product. If we choose to replace
the Product, we may replace it with a new or refurbished
Product of the same or similar design. We will retain
defective parts, modules, or equipment. Replacement of the
Product, at VTech’s option, is your exclusive remedy. VTech
will return the replacement Products to you in working
condition. You should expect the replacement to take
approximately 30 days.
How long is the limited warranty period?
The limited warranty period for the Product extends for ONE
(1) YEAR from the date of purchase (90 days on products
purchased as Refurbished*). This limited warranty also
applies to the replacement Product for a period of either (a)
90 days from the date the replacement Product is shipped
to you or (b) the time remaining on the original one-year
warranty (90-day limited warranty on products that are
purchased as Refurbished*); whichever is longer.
*Refurbished products purchased from our online store
carry a 90-day replacement warranty.
What is not covered by this limited warranty?
This limited warranty does not cover:
1. Product that has been subjected to misuse, accident,
shipping or other physical damage, improper installation,
abnormal operation or handling, neglect, inundation,
fire, water or other liquid intrusion; or
2. Product that has been damaged due to repair, alteration
or modification by anyone other than an authorized
service representative of VTech; or
3. Product to the extent that the problem experienced is
caused by signal conditions, network reliability, or cable or
antenna systems; or
4. Product to the extent that the problem is caused by use
with non-VTech accessories; or
5. Product whose warranty/quality stickers, product serial
number plates or electronic serial numbers have been
removed, altered or rendered illegible; or
6. Product purchased, used, serviced, or shipped for repair
from outside the United States of America or Canada, or
used for commercial or institutional purposes (including
but not limited to Products used for rental purposes); or
7. Product returned without a valid proof of purchase (see
item 2 below); or
8. Charges for installation or set up, adjustment of customer
controls, and installation or repair of systems outside the
unit.
How do you get warranty service?
To obtain warranty service in the USA, please visit our
website at www.vtechphones.com or call 1 (800) 595-9511.
In Canada, go to www.vtechcanada.com or call
1 (800) 267-7377.
NOTE: Before calling for service, please review the user’s
manual - a check of the Product’s controls and features may
save you a service call.
Except as provided by applicable law, you assume the risk
of loss or damage during transit and transportation and are
responsible for delivery or handling charges incurred in the
transport of the Product(s) to the service location. VTech
will return replaced Product under this limited warranty.
Transportation, delivery or handling charges are prepaid.
VTech assumes no risk for damage or loss of the Product in
transit.
What must you return with the Product to get warranty
service?
1. Return the entire original package and contents including
the Product to the VTech service location along with a
description of the malfunction or difficulty; and
2. Include a “valid proof of purchase” (sales receipt)
identifying the Product purchased (Product model) and
the date of purchase or receipt; and
3. Provide your name, complete and correct mailing
address, and telephone number.
Other limitations
This warranty is the complete and exclusive agreement
between you and VTech. It supersedes all other written or
oral communications related to this Product. VTech provides
no other warranties for this Product. The warranty exclusively
describes all of VTech’s responsibilities regarding the
Product. There are no other express warranties. No one is
authorized to make modifications to this limited warranty and
you should not rely on any such modification. State/Provincial
Law Rights: This warranty gives you specific legal rights, and
you may also have other rights, which vary from state to state
or province to province.
Limitations: Implied warranties, including those of fitness
for a particular purpose and merchantability (an unwritten
warranty that the Product is fit for ordinary use) are limited
to one year from the date of purchase. Some states/
provinces do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to you.
In no event shall VTech be liable for any indirect, special,
incidental, consequential, or similar damages (including,
but not limited to lost profits or revenue, inability to use
the Product or other associated equipment, the cost of
substitute equipment, and claims by third parties) resulting
from the use of this Product. Some states/provinces
do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion
may not apply to you.
Please retain your original sales receipt as proof
of purchase.
Limited warranty
FCC and IC regulations
FCC Part 15
NOTE: This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of
the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a
user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC
criteria. The baby unit shall be installed and used such that parts of all persons’ body are maintained at a distance of approximately 8 in
(20 cm) or more. The transmitter and antenna of the parent unit shall be held at least 1 in (2.5 cm) from your face.
This Class B digital apparatus complies with Canadian requirement:
CAN ICES-3 (B)/NMB-3(B)
Industry Canada
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s
licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
The term ‘’IC:‘’ before the certification/registration number only signifies that the Industry Canada technical specifications were met.
This product meets the applicable Innovation, Science and Economic Development Canada technical specifications.
RF radiation exposure statement
The product complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. The baby unit should be
installed and operated with a minimum distance of 8 in (20 cm) between the baby unit and all persons’ body. Use of other accessories
may not ensure compliance with FCC RF exposure guidelines. This equipment complies also with Industry Canada RSS-102 with respect
to Canada’s Health Code 6 for Exposure of Humans to RF Fields.
The RBRC seal on the lithium-ion battery indicates that VTech Communications, Inc. is voluntarily participating in an
industry program to collect and recycle these batteries at the end of their useful lives, when taken out of service within
the United States and Canada. The program provides a convenient alternative to placing used lithium-ion batteries into
the trash or municipal waste, which may be illegal in your area.
VTech’s participation makes it easy for you to drop off the spent product at local retailers participating in the program
or at authorized VTech product service centers. Please call 1 (800) 8 BATTERY® for information on Li-ion battery recycling and disposal
bans/restrictions in your area. VTech’s involvement in this program is part of its commitment to protecting our environment and
conserving natural resources.
The RBRC Seal and 1 (800) 8 BATTERY
® are registered trademarks of Call2recycle, Inc.
The RBRC seal Need help?
For operations and guides to help you use your video monitor, and for the
latest information and support, check out our online help topics and online
FAQs.
Use your smartphone or mobile device to access our online help.
• Go to https://phones.vtechcanada.com/manuals; OR
• Scan the QR code on the right. Launch the camera app or QR code
scanner app on your smartphone or tablet. Hold the device’s camera up
to the QR code and frame it. Tap the notification to be redirected to the
online help page.
- If the QR code is not clearly displayed, adjust your camera’s focus by
moving your device closer or further away until it is clear.
• Search for the model - .RM2751 or RM2751-2
You can also call our Customer Support at 1 (800) 267-7377 for help.
a) From parent unit
• Before installing the app, make sure your baby monitor is connected to your home Wi-Fi
network.
1. when the parent unit is idle.Press ,
2. Go to > .
3. Scan the QR code in the parent unit to download the app into your mobile
device.
App installation
Add camera
3
Follow the instructions in the mobile app to pair the camera. Tap , then Add Camera
in the mobile app to get started.
Main
Menu Options
General settings
• Adjust parent unit screen
brightness.
• Turn the screen off timer on/off,
or set to screen off after 1, 3 or 5
minutes, or auto screen on when
sound detected.
• Set the Sound Sensitivity level for
auto screen on.
• Adjust baby unit’s speaker volume.
• Change temperature format (°C/°F).
• Help information.
• System information.
• Factory reset.
Connection settings
• Change Wi-Fi network.
• Connect mobile phone.
• Reset connection to direct mode.
Main
Menu Options
Monitoring mode (For RM2751-2 only)
• View baby unit 1 or 2 in Single
mode.
• View both baby units in Patrol
mode.
Zoom
• Select from 4 zoom modes.
• Navigate in the zoom image.
Night light
• Turn on/off night light.
• Select from 10 color modes.
• Adjust the brightness level.
• You can also set the timer to turn
off night light after 15, 30 or 60
minutes, or remain on always.
Melodies and soothing sounds
• Play or stop the lullaby.
• Select to play all melodies, or play
one of the five melodies and five
soothing sounds.
• You can also set the timer to stop
playing after 15, 30 or 60 minutes,
or play non-stop.
• Adjust the playing volume level.
Alerts settings
• Turn on/off motion detection,
temperature detection lost link,
and low battery alerts.
• Select the motion detection
sensitivity level.
• Select maximum and minimum
temperature for alert range.
• Mute or adjust the alerts sound
level.
Status icons
Direct mode
Parent unit, baby unit 1 and baby unit 2 (For
RM2751-2 only) are connected to each other
directly.
Router mode
Parent unit, baby unit 1 and baby unit 2 are
connected to home Wi-Fi network.
Night vision is turned on.
Motion detection is turned on.
Sound light indicator
Melodies and soothing sounds are turned on.
Night light is turned on.
Auto night light is turned on.
Talkback is turned on.
Parent unit speaker is muted.
Temperature alert is turned on.
Product specificaties
| Merk: | VTech |
| Categorie: | Babyfoon |
| Model: | RM2751 |
Heb je hulp nodig?
Als je hulp nodig hebt met VTech RM2751 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Babyfoon VTech
13 December 2024
13 December 2024
13 December 2024
13 December 2024
13 December 2024
13 December 2024
16 November 2024
16 November 2024
16 November 2024
27 Februari 2024
Handleiding Babyfoon
- Babyfoon Philips
- Babyfoon IKEA
- Babyfoon Brondi
- Babyfoon Fysic
- Babyfoon Grundig
- Babyfoon Gigaset
- Babyfoon Motorola
- Babyfoon Medion
- Babyfoon Tefal
- Babyfoon Topcom
- Babyfoon Albrecht
- Babyfoon Alcatel
- Babyfoon Alecto
- Babyfoon Amplicomms
- Babyfoon Angelcare
- Babyfoon Ansmann
- Babyfoon Ariete
- Babyfoon Audioline
- Babyfoon Babyfon
- Babyfoon Babymoov
- Babyfoon BabySafe
- Babyfoon Basetech
- Babyfoon Beaba
- Babyfoon Bebetel
- Babyfoon Beurer
- Babyfoon Binatone
- Babyfoon BT
- Babyfoon D-Link
- Babyfoon Denver
- Babyfoon Duronic
- Babyfoon Duux
- Babyfoon Elro
- Babyfoon Esscom
- Babyfoon Eufy
- Babyfoon Ezviz
- Babyfoon Fischer Price
- Babyfoon Fisher Price
- Babyfoon Foscam
- Babyfoon Geemarc
- Babyfoon Goclever
- Babyfoon Graco
- Babyfoon Grixx
- Babyfoon Hama
- Babyfoon Hartig Helling
- Babyfoon HQ
- Babyfoon Hyundai
- Babyfoon Kodak
- Babyfoon Kogan
- Babyfoon Konig
- Babyfoon Lanaform
- Babyfoon Lorex
- Babyfoon Lupilu
- Babyfoon Luvion
- Babyfoon Manhattan
- Babyfoon ME
- Babyfoon Medisana
- Babyfoon MicroTalk
- Babyfoon Modern-Electronics
- Babyfoon Nedis
- Babyfoon Nova
- Babyfoon Pabobo
- Babyfoon Philips-Avent
- Babyfoon Reer
- Babyfoon Safety 1st
- Babyfoon Sanitas
- Babyfoon Silvercrest
- Babyfoon Stabo
- Babyfoon Swissvoice
- Babyfoon Switel
- Babyfoon Technaxx
- Babyfoon Terraillon
- Babyfoon Tesla
- Babyfoon Tommee Tippee
- Babyfoon Tomy
- Babyfoon Trebs
- Babyfoon Trendnet
- Babyfoon Tristar
- Babyfoon Truelife
- Babyfoon Uniden
- Babyfoon Withings
- Babyfoon Jablotron
- Babyfoon Jane
- Babyfoon Olympia
- Babyfoon Oregon Scientific
- Babyfoon Oretti
- Babyfoon Overmax
- Babyfoon Concept
- Babyfoon Niceboy
- Babyfoon Lionelo
- Babyfoon Cobra
- Babyfoon EMOS
- Babyfoon Chicco
- Babyfoon Cresta
- Babyfoon SereneLife
- Babyfoon M-e
- Babyfoon Hartig And Helling
- Babyfoon NUK
- Babyfoon Oricom
- Babyfoon Summer
- Babyfoon Tigex
- Babyfoon Lindam
- Babyfoon BabyOno
- Babyfoon Neno
- Babyfoon Xblitz
- Babyfoon IBaby
- Babyfoon Levana
- Babyfoon Mobi
- Babyfoon Neonate
- Babyfoon Chipolino
- Babyfoon Babysense
- Babyfoon Heimvision
- Babyfoon Summer Infant
- Babyfoon LeamsiQ
- Babyfoon Chillax Baby
- Babyfoon Hubble Connected
- Babyfoon Peekyboo
Nieuwste handleidingen voor Babyfoon
14 November 2024
10 December 2024
4 December 2024
23 November 2024
16 November 2024
15 November 2024
15 November 2024
10 November 2024
10 November 2024
5 November 2024
