Pagina 1/2

4-Port DVI Splitter

USE A SINGLE PC TO DISPLAY

IDENTICAL IMAGES ON

MULTIPLE DVI MONITORS

Quick Start Guide

VIDEO

Format DVI 1.0

Input interface (1) DVI Female

Output interface (4) DVI Female

Resolution Up to 1920 x 1200 60 Hz

Cable Distance Up to 10 m

OTHER

Power Supply DC5V/1.5A

Dimensions 7.38” L x 3.56” W x 1.56” H

Weight .65 lbs

Operating Temp. 32 to 104°F (0 to 40°C)

Storage Temp. -4 to 140°F (-20 to 60°C)

Humidity Up to 95% (non-condencing)

NOTICE

The information contained in this document is

subject to change without notice. SmartAVI makes

no warranty of any kind with regard to this material,

including but not limited to, implied warranties of

merchantability and tness for particular purpose.

SmartAVI will not be liable for errors contained

herein or for incidental or consequential damages in

connection with the furnishing, performance or use of

this material.

No part of this document may be photocopied,

reproduced, or translated into another language

without prior written consent from SmartAVI

Technologies, Inc.

800.AVI.2131, 702.800.0005

2455 W Cheyenne Ave, Suite 112

North Las Vegas, NV 89032

SmartAVI.com

TECHNICAL SPECIFICATION

DVS4P

WHAT’S IN THE BOX

PART NO. DESCRIPTIONQ-TY

DVS4P 1 4-Port DVI Splitter

PS5VDC2A 1 5 V DC 2 A power supply

Quick Start Guide 1

OPERATION FOR CASCADE

TROUBLESHOOTING

If you need to add more monitors, you need to attach an

addition splitter box.

Connect a DVI male/male extension cable between a Video

Out port or the primary splitter (the splitter connected

to the computer) and the Video In port on the cascaded

splitter.

NOTE: Even though you can cascade the splitter, the image

might become unstable if you cascade too many tiers of

splitters.

No Power

• Make sure that the power adapter is securely

connected to the power connector of the unit.

• Check the output voltage of the power supply and

make sure that the voltage value is around 5VDC.

• Replace the power supply.

No Video

• Check if all the video cables are connected properly.

• Connect the computer directly to the monitor to verify

that your monitor and computer are functioning

properly.

• Try replacing the video cable.

• Restart the computers.

1. Turn off the power of all devices (computer, monitors and splitter).

2. Connect the video source’s DVI output port to the splitter DVI input port using standard DVI cable.

3. Connect the video source’s DVI output port to the splitter DVI output port.

4. Plug the power supply into the DVI splitter.

5. Plug the power supply into the wall outlet or power bar. Check to see if the power LED light is active on the front of the DVI

splitter.

6. Turn on the displays.

7. Turn on the video source.

DVS4P FRONT

HARDWARE INSTALLATION

DVI IN

DVI OUT

DVS4P

Product specificaties

Merk:	Smart-AVI
Categorie:	Splitter
Model:	DVS4P
Kleur van het product:	Paars
Gewicht:	900 g
Snoerlengte:	10 m
Materiaal behuizing:	Metaal
Volledige HD:	Nee
Aansluiting voor netstroomadapter:	Ja
Ondersteunde grafische resoluties:	1920 x 1200 (WUXGA)
Power LED:	Ja
Spanning:	5 V
Stroomvoorziening via USB:	Nee
Video uit:	4x DVI-D
Aansluiting video:	DVI
AC-ingangsspanning:	100-240 V
AC-ingangsfrequentie:	50 - 60 Hz
Hoeveelheid Video ports:	4
