Sensor MUI EX

-1-

Assignment of the MUI sensor is measurement of voltage, current and consumed capacity of ﬂight

batteries in the model. The wireless data transmission by the DUPLEX 2,4GHz system is monitored by

the JETIBOX terminal.

For communication purposes the Duplex system takes advantage of the 2,4 GHz band, which besides

sending remote control data to the model also receives data from the model back to the transmitter.

During ﬂight obtained telemetric data are transmitted in real time and the actual values of the measured

data can be displayed on the JETIBOX LCD. Telemetric MUI sensors execute voltage and current

measurements in your model and transmit these informations with the aid of the DUPLEX system

(receivers and transmitter modules). Thanks to exact current measurements these sensors render it

possible to trace the spent capacity of the measured battery. The MUI unit is recording the spent current

ﬂow time and its average as well as maximum value. Furthermore it oﬀers exact voltage measurements

and recordings of voltage minimum and maximum values.

The task of parameter adjustment and measured data setup is performed by the well known alround talent

– the JETIBOX terminal.

MUI sensors allow setting of acoustical signals in order to announce violation of set parameters. Such

alarms may be set for measurements of maximum current and minimum voltage as well as for a

maximum of consumed battery capacity. The sound signal is generated by a siren integrated in the

transmitter module. For better diﬀerentiation are the particular alarms distinguished by Morse alphabetic

letters. The acoustical alarm generation in case of parameter violation is working even if the JETIBOX is

not connected. With the JETIBOX in place the LCD display shows which parameter has been violated. In

case of violation of several parameters the alerts alter consecutively as well as the indications on the LCD

display.

Technické parametry

MUI 30

MUI 50

MUI 75

MUI 150

MUI200

Dimensions [mm]

20 x 16,5 x 5

27 x 19 x 11

27x19x11

Weight

10 g

19 g

21 g

25 g

30g

Range of measured voltage

0 60 V –

Range of measured current

0 30 A –

0 50 A –

0 75 A –

0 150 A –

0 200 A –

Accuracy of voltage

measurment

0,1 %

Accuracy of current

measurment

1 %

Operation temperature

- 10 to + 85° C

Supply voltage

5 8,4V –

Sensor internal consumption

24 mA

32 mA

32mA

Menu of the telemetric MUI Sensor

Take advantage of the JETIBOX for parameter adjustment and data readout. After connection to the MUI

sensor the sensor identiﬁcation is shown and in the second line the preadjusted actual measured data. By

long pushing down button R (right) a fast deletion of all measured parameters can be triggered (min. and

max. voltage, max. current, average current, runtime, capacity). Fast deletion is indicated in the ﬁrst line

of the display by an asterix „*“.

By pushing the push button D (downward arrow) of the JETIBOX you will enter the MUI sensor menu.

MUI MENU : Actual Value –by pushing D (downward arrow) you will select the display of actual

measured values

Volt / Current – displays actual measured voltage and the current passing through the sensor. By

simultaneously pushing arrows R and L (right and left) the zero value of the sensor current is calibrated.

To the actual measured current value the zero current display is added, i. e. the so called zero shift.

Capacity shows the actual consumed capacity –

Run Time shows the total time of current passage through the sensor. Included is also the time when the –

current has exceeded the adjusted current value in the Start Trigger Setting menu.

Sensor MUI EX

-2-

MUI MENU: MIN / MAX by pushing the button D (downward arrow) you will select the display of –

extreme voltage and current value recordings which occurred during the measurement. The extreme

recordings are deleted automatically or they can be deleted in the menu Automatic Setting - Erase Data.

deletion occurs when the MUI sensor has just been connected to the voltage supply and the current, as set

in the menu will be exceeded. If after connection of the sensor the set current will Setting-Start Trigger,

not be exceeded, values of the previous sensor operation will be displayed.

U MIN / MAX shows the minimum and maximum value of the measured voltage –

I AVG / MAX shows the average value of the measured current and its maximum –

MUI MENU: Setting by pushing the button D (downward arrow) you will enter the basic sensor setup –

Start Trigger setup of a current value, at which after sensor connection recording of values like –

minimum, maximum and current transit time starts. If the adjusted value is 0 A, values will be recorded

immediately after connection of the sensor to its power supply and data read out of the previous operation

will not be possible.

Erase Data by pushing arrows R and L (right and left) simultaneously the records of measured –

parameters will be deleted

First Parametr adjustment of the display of the ﬁrst parameter in the JETIBOX LCD, which is shown –

in the second line of the basic sensor menu (the first line shows the identiﬁcation, for instance SENSOR

MUI 30)

Second Parametr - adjustment of the display of the second parameter in the JETIBOX LCD, which is

shown in the second line of the basic sensor menu (the ﬁrst line shows the identiﬁcation, for instance

SENSOR MUI 30)

Auto. Erase - This function of automatical deletion after overstepping the trigger level can be activated or

deactivated.

MUI MENU: ALARMS by pushing button D (downward arrow) you enter setup of particular alarms. –

If one of the adjusted parameters becomes exceeded, the JETIBOX LCD will in the second line of the

basic menu alternately show the original display with the pertinent alarm and the transmitter module siren

will emit an acoustical alarm. The ﬁrst tone is a revelation signal and the second one is signalling a Morse

Code character of the relevant alarm. If the alarm is set to OFF, this kind of alarm will be switched oﬀ.

Voltage alarm (alarm U ) adjustment of the value of voltage signalling, if the measured voltage –..-

decreases beyond the set value, the voltage alarm U will be activated.

Current alarm – (alarm I ) adjustment of the value of current signalling, if the measured current ..

increases beyond the set value, the current alarm I will be activated.

Capacity alarm (alarm C ) adjustment of the signalling value of consumed capacity , if the –-.-.

adjusted value of maximum consumed capacity is exceeded, alarm C will be activated.

MUI MENU: SERVICE by pressing button D (arrow down) you will change to depiction of the –

ﬁrmware version and to renewal of the sensor default setting.

Factory Defaults by simultaneous pressing of arrows R and L (right and left) the factory settings of the –

MUI are loaded.

MUI v. xx.xx ID xxxxx:xxxxx product marking with ﬁrmware version and series number (ID). –

Particular phases of current measurements

A when after switching on of the sensor the –

current did not exceed the set value Start Trigger.

Measured values (U MIN / MAX, I AVG / MAX,

Capacity, Run Time) correspond with measured

values of the previous operation.

B the value has been exceeded –Start Trigger .

Previous measured values (U MIN / MAX, I AVG /

MAX, Capacity, Run Time) will be deleted and

actualized by the actual measurement course.

Sensor MUI EX

-3-

C the set current has been exceeded and current alarm has been activated –

D the measured current decreased beyond the set alarm value, alarm will be cut oﬀ. The measured –

current decreased beyond the set level . The timer is switched oﬀ. Recording of Start Trigger Run Time

extremes and consumed capacity is going on.

Connection of the MUI Sensor

1. The triple cable with JR connector can be connected directly to the JETIBOX (the connector marked

Pulse, + - ). Connect to the other JETIBOX input marked by (+ - ) the power supply voltage of 5-8,4V.

This connection mode does not take advantage of wireles data transmission, measured data are shown

directly on the JETIBOX LCD display. This mode does not allow acoustic alarm generation because the

siren is a part of the transmitter module which is not connected in this case. Alarms are only shown on the

LCD display.

2. Connect the MUI sensor triple cable with JR connector to the DUPLEX receiver socket (marked Ext.)

on the receiver back side. For parameter setup connect the JETIBOX to the transmitter module. The MUI

sensor gets its power supply from the receiver.

3. Connect the MUI sensor triple cable with JR connector to one of the EXPANDER inputs. The

expander renders it possible to connect several telemetric sensors to a single receiver. In this case the

MUI sensor gets its power suply from the Expander and the Expander from the receiver.

Firmware Update

The equipment ﬁrmware may be updated by a PC via the . In the converter unit JETI USB Adapter

USB Adapter instructions you will ﬁnd a description of the installation procedure of the USB Adapter

controller as well as the update program.

Connection of the MUI Sensor

There are two inputs available at the MUI sensor, one for current measurement purposes (marked A)

and the other one for connection of the measured voltage (marked V).

The current must pass through the MUI, it is therefore necessary to connect it in series with the current

supply (battery). If the current polarity is reversed the sensor will show instead of the real current value

just 0 A. In that case reverse the current measurement input wires. Do not forget to use proper connectors

with suﬀicient load capacity for current measurements. For currents up to 30A we recommend G3,5

connectors, up to 75A G4 connectors and up to 150A G5,5 connectors or even better.
