Pagina 1/6
[ 1 ]
Bitspower Notos 120 Fan Digital RGB White (3PCS) V2
Speci󽗉cation
Measurement 120x120x25mm Max Air󽗊ow 57CFM Min.:54CFM
Rated Voltage Fan:DC 12V / LED:DC 5V Air Pressure 2.1mm-H2O / Min.:1.8mm-H2O
Operation Voltage 7V~13.2V Noise Level 25dBA Max.:32dBA
Staring Voltage ≤ 7V Life Time 30000 Hours
Rated Current FAN:0.21A Max.:0.23A
LED:0.40A Max.:0.45A Number of Blades 7
Power Consumption FAN:2.5W Max.: 2.8W
LED:2.0W Max.:2.3W Bearing Type Hydro Bearing
Fan Speed 800~1800RPM±10% Power Connector PWM 4pin header /
DRGB 5V 3pin header
DRGB header
A
A:Negative electrode -
B:Negative electrode +
C: Speed message FG
D:Speed control PWM
B C D
A5v
BD
CGnd
C
A
B
Notice
Before filling in the water, please make sure all the components are
installed correctly. To prevent any leakage which may damage the PC
components, please perform a 24-hour leaking test with only the pump
connected to the power supply.
Bitspower reserves the right to change the product design and
interpretations. These are subject to change without notice. Product
colors and accessories are based on the actual product.
When using leak tester on water cooling loop, in order to avoid product
damage due to excessive pressure, the input pressure should not exceed
0.5kg/cm2 (Bar). If the product is damaged due to
excessive pressure, it will be borne by the customer. Forbidden to use the
leak teser when there is water in the loop or the pump is runing.
Bitspower recommends that consumers use the Bitspower Pellucid
Coolant for their water-cooling liquid. Also, they can add Bitspower Dye
to Pellucid Coolant for the color requirement. If the consumer chooses
di󽗈erent water-cooling liquids, the resulting impurities may cause peeling
off the coating on some of the hardware, water channels blockage by
built-up residue, improper operation of the water pump, water tank tube
breakage, and o-rings deformation leading to leakage. Any issues related
to the use of inappropriate water-cooling liquid will be the responsibility of
the consumer.
[ 2 ]
[ 3 ]
Bitspower Notos 120 Fan Digital RGB White (3PCS) V2
風 扇 規 格
尺寸 120x120x25mm 風量 57CFM Min.:54CFM
額定電壓 Fan:DC 12V / LED:DC 5V 風壓 2.1mm-H2O / Min.:1.8mm-H2O
工作電壓 7V~13.2V 噪音 25dBA Max.:32dBA
啟動電壓 ≤ 7V 壽命 30000 Hours
定額電流 FAN:0.21A Max.:0.23A
LED:0.40A Max.:0.45A 葉片數 7
功率消耗 FAN:2.5W Max.: 2.8W
LED:2.0W Max.:2.3W 軸承 Hydro Bearing
轉速 800~1800RPM±10% 轉接器 PWM 4pin header /
DRGB 5V 3pin header
A B C D
DRGB 分接
A5v
BD
CGnd
C
A
B
A: 電源負極 -
B: 電源負極 +
C: 轉速訊息 FG
D: 轉速調控 PWM
