Pagina 1/2
Got questions or need a repair or want to mail us some cookies?
Email help@walrusaudio.com
All our pedals come with a limited lifetime warranty.
walrusaudio.com/pages/warranty-and-repair for more info.
9 volt DC, Center Neg.
100ma min*
Output Jack
Bypass LED
Bypass Switch
Rate LED
Input Jack
*The use of an isolated power supply is recommended for powering all Walrus Audio Pedals.
Daisy chain power supplies are not recommended.
WALRUSAUDIO.COM
RATE
Set the speed at which the LFO sweeps. From little or no movement at lower settings,
to crazy whirling phase.
WIDTH
Controls the frequency range that the filters sweep through.Set low for a narrow range
and a less dramatic effect, or higher for a wider range resulting in more defined phaser
tones.
FEEDBACK
Determines how much of your phase shifted signal gets sent back through the filter
stages.Set this control lower for more traditional phaser tones, and higher for more of a
resonate filter sound.
D-P-V
Blend between Dry, Phase Shifted, and Vibrato (labeled d-p-v on the pedal). The
Dry-Phase-Vibrato blend changes the ratio of dry to wet signal sent to the output.
At minimum, you will hear no effect. Set it to noon for equal parts dry and wet – the
traditional Phaser setting.
D-P-V continued
Set it to maximum for 100% wet resulting in pitch vibrato. Explore
the ground between minimum and noon for adding slight amounts
of movement to your dry signal and the area between noon and
maximum for all sorts of unheard phase/vibrato combinations.
Stages Switch
Allows the user to select 4 or 6 stages which alters the overall
voice of the effect from warm and tight phasing with 4 stages to
a more complex filtered sound with 6. Each pair of stages creates
a notch filter and a certain frequency range that the LFO sweeps
through. This means, in 4 stage mode, there are 2 swept filter
notches, and in 6 stage mode there are 3 swept notches.They
each have their own “voice”, so flip the switch and have fun!
SMART MOMENTARY BYPASS SWITCH
When the bypass switch is in the off position, press and hold
to temporarily activate the effect. Releasing the switch turns
the effect off.
During WWII, from 1943-1944, over 1,000 women volunteered to fly in the
military to help while so many men were away fighting. This program
was called W.A.S.P. (Woman Air Force Service Pilots). One specific pilot,
Lillian Yonally, inspired us with her story of traversing dangerous skies.
From there, the idea of the Lillian Analog Phaser was born.
CONTROLS
The Lillian is a true bypass, all analog, multi-stage Phaser drawing
control layout inspiration from the Julia Chorus. With controls like Rate,
Width, Feedback, and D-P-V blend, the Lillian is packed with a wide
array of analog phaser goodness waiting to be dialed in. The “Stages
switch allows the user to select 4 or 6 stages which alters the overall
voice of the effect from warm and tight phasing with 4 stages
to a more complex filtered sound with 6. The D-P-V knob lets
you blend between dry, phase shifted, and vibrato sounds
allowing for a wide range of control over the intensity and
type of effect. Top mounted input, output, and power
jacks as well as soft switch relay bypassing make the
Lillian fit well on your board and ensure smooth
operation for years to come.
