UPS Systems

Models:

ECO350UPS, ECO550UPS, ECO650UPSM, ECO750UPS,

ECO850LCD, ECO900LCDU2, ECO900UPSM

(Series Number: AG-0306, AG-0310, AG-0313, AG-0315,

AG-0316, AG-0318, AG-0319)

Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Español 21 • Français 41

WARRANTY REGISTRATION

automatically entered to win an ISOBAR®

surge protector in our monthly drawing!

tripplite.com/warranty

20-08-195-9338D5.indb 1

20-08-195-9338D5.indb 1 9/1/2020 1:28:43 PM

9/1/2020 1:28:43 PM

Table of Contents

Important Safety Instructions 3

Quick Installation (All Models) 5

Basic Operation for Models with an LED Interface 8

(ECO350UPS, ECO550UPS, ECO650UPSM, ECO750UPS, ECO900UPSM)

Basic Operation for Models with an LCD Panel 11

(ECO850LCD, ECO900LCDU2)

UPS Features 15

Battery Replacement 17

Storage and Service 18

Speciﬁcations 18

Product Registration 19

Regulatory Compliance 19

20-08-195-9338D5.indb 2

20-08-195-9338D5.indb 2 9/1/2020 1:28:43 PM

9/1/2020 1:28:43 PM

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during the

installation, maintenance and storage of the UPS and batteries. Failure to heed

these warnings may affect the warranty.

UPS Location Warnings

• Install your UPS indoors, away from excess moisture or heat, conductive contaminants, dust

or direct sunlight.

• For best performance, keep the indoor temperature between 32º F and 104º F

(0º C and 40º C).

• Leave adequate space around all sides of the UPS for proper ventilation.

• Optional mounting: The UPS may be securely mounted in a horizontal or vertical position.

To mount, use two screws (not provided) to secure the UPS rear keyholes to a ﬂat surface.

UPS Connection Warnings

• Connect your UPS directly to a properly-grounded AC power outlet. Do not plug the UPS into

itself; this will damage the UPS.

• Do not modify the UPS plug, and do not use an adapter that would eliminate the UPS

ground connection.

• Do not use extension cords to connect the UPS to an AC outlet.

• If the UPS receives power from a motor-powered AC generator, the generator must provide

clean, ﬁltered, computer-grade output.

• The mains socket outlet that supplies the UPS should be easily accessible and located near

the UPS.

Equipment Connection Warnings

Install in accordance with National Electrical Code standards ANSI/NFPA

70 and Canadian Electrical Code, Part I, C22.1.

Short-circuit backup protection and overcurrent protection is provided by

the building installation.

To reduce the risk of ﬁre, connect only to a circuit with a maximum 20A

provided branch circuit overcurrent protection in accordance with the

National Electrical Code, ANSI/NFPA 70 and the Canadian Electrical Code,

Part I, C22.1. The plug on the power supply cord is intended to serve as

the disconnect device. Be sure that the socket-outlet is installed near the

equipment and is made easily accessible.

The UPS is intended for use on a TN power distribution system.

Important Safety Instructions

20-08-195-9338D5.indb 3

20-08-195-9338D5.indb 3 9/1/2020 1:28:43 PM

9/1/2020 1:28:43 PM

Product specificaties

Merk:	Tripp Lite
Categorie:	UPS
Model:	ECO750UPS
Kleur van het product:	Zwart
Gewicht:	3090 g
Breedte:	130 mm
Diepte:	309.9 mm
Hoogte:	85.1 mm
Snoerlengte:	1.5 m
Gewicht verpakking:	3780 g
Breedte verpakking:	151.9 mm
Diepte verpakking:	379 mm
Hoogte verpakking:	198.9 mm
Gebruikershandleiding:	Ja
Materiaal behuizing:	Acrylonitrielbutadieenstyreen (ABS)
LED-indicatoren:	Ja
Vormfactor:	Compact
USB-poort:	Ja
Meegeleverde kabels:	USB-kabel
Land van herkomst:	China
Aantal USB 2.0-poorten:	1
Aantal Ethernet LAN (RJ-45)-poorten:	2
Geluidsalarm(en):	Ja
Responstijd:	6 ms
Duurzaamheidscertificaten:	RoHS, ENERGY STAR
Uitgangsvermogen:	450 W
Temperatuur bij opslag:	-15 - 50 °C
ECO mode:	Ja
Frequentie:	- Hz
Modem (RJ-11) poort:	1
Stekker:	NEMA 5-15P
(Buitenste) hoofdverpakking hoogte:	428 mm
(Buitenste) hoofdverpakking breedte:	395 mm
(Buitenste) hoofdverpakking brutogewicht:	21360 g
(Buitenste) hoofdverpakking lengte:	475 mm
Hoeveelheid per (buitenste) hoofdverpakking:	6 stuk(s)
Bedrijfstemperatuur (T-T):	0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	0 - 95 procent
GTIN (EAN/UPC)-nummer (buitenste) hoofdverpakking:	10037332211115
Surge energy rating:	316 J
Aantal AC uitgangen:	12 AC-uitgang(en)
Stopcontacttypes:	NEMA 5–15R
Golf protectie functies:	Digital Subscriber Line (DSL), Network, Telephone
Stroom (max.):	10 A
Output power capacity:	0.75 kVA
Ingang operation voltage (min):	110 V
Ingang operation voltage (max):	120 V
Uitgang operation voltage (min):	110 V
Uitgang operation voltage (max):	120 V
UPS-topologie:	Stand-by (Offline)
Aantal input fases:	1
Typische backup tijd op halve lading:	8.6 min
Typische backup tijd op volledige lading:	2 min
Output frequentie:	50/60 Hz
EMI/RFI geluidsfiltering:	Ja
Spanningsbeveiliging:	Ja
Golfvorm:	Sinus
Koude start:	Ja
