Quick Installation Guide
Wireless Access Point
Note: EAP650 is used as an example throughout the Guide. Images may dier from your actual product.
Hardware Overview
1
RESET
With the device powered on, press and hold the button for about 5 seconds until the LED flashes quickly. Then
release the button. The device will restore to factory default settings.
Ethernet Port: ETH (PoE)
The port is used to connect to a router or a switch to transmit data, or to a PSE (Power Sourcing Equipment),
such as a PoE switch, for both data transmission and Power over Ethernet (PoE) through Ethernet cable.
Note: For EAPs with 10Gbps port, if you use a CAT5E cable, the 10Gbps link of the Ethernet port is less than 55m. To achieve a longer
transmission distance, use a shielded CAT6A cable.
Power Port
Plug one end of the power adapter to this port and the other end to a standard electrical wall outlet to power the
EAP.
Note: Power adapter is not included in the package contents of certain models. For details, refer to the product specications or
datasheet. For power supply specications, refer to the product label.
Self-tapping ScrewsPlastic Wall Anchors
1
Remove the ceiling tile.
Note: Make sure that the ceiling tile is larger than the EAP.
Wing NutsWashers Pan-head Screws
The EAP can be mounted to the ceiling, the wall, or in a junction box, using the screws in the
package. Choose the appropriate mounting and installation steps below.
Note: This product requires heat dissipation through the metal bracket during use, please be
careful not to touch the metal bracket in the heat dissipation.
Hardware Installation
2
2
Insert the plastic wall anchors into the holes.
Front Panel
Rear Panel
Option 1: Ceiling Mounting
Option 2: Wall Mounting
5
Connect the Ethernet cable to the Ethernet port.
Please pay attention to the triangle sign. Attach
the EAP to the mounting bracket, then rotate it
until it locks into place, as shown on the left.
2
Place the mounting bracket in the center of the
ceiling tile. Mark positions for the screw holes
and a location for the Ethernet cable hole.
Drill holes for the screws and a hole for the
Ethernet cable at the marked positions.
3
Secure the mounting bracket to the ceiling tile
using pan-head screws, washers, and wing nuts,
as shown on the left.
5
Attach the EAP to the mounting bracket by
rotating it until it locks into place, as shown on
the left.
2
Connect the Ethernet cable to the Ethernet
port on the EAP.
3
Attach the EAP to the mounting bracket by
rotating it until it locks into place, as shown on
the left.
Setup with videos
Visit https://www.tp-link.com/support/setup-video/ or scan the QR code
to search for the setup video of your product model.
4
Feed the Ethernet cable through the hole and
set the ceiling tile back into place.
3
Secure the mounting bracket to the wall by
driving the self-tapping screws into the
anchors. Make sure that the shoulders of the
mounting bracket are on the outside.
1
If your Ethernet cable feeds through the wall,
position the mounting bracket below the cable
hole. Mark positions for the screw holes and
drill holes at the marked positions.
Φ 7.6 mm (19/64 in)
Option 2: Wall MountingOption 1: Ceiling Mounting Option 3: Junction Box Mounting
Blue On:
Working normally/Initializing. For EAPs with dual-color LED: Normal power supply
Orange On:
For EAPs with dual-color LED: Low power supply
Flash: • Flash twice:
Initialization is completed.
• Flash quickly:
The EAP is resetting, or the Omada controller is locating the device*.
• Flash once per second:
The EAP is upgrading.
• Flash Slowly:
The EAP is in the isolated state.
LED Indicator
Off:
Working abnormally/Power o/LED is turned o.
* When the Locate feature is activated in the Omada controller, the LED îž°ashes quickly to locate and identify the
device. The LED will îž°ash for 10 minutes. You can disable the feature manually to stop it from îž°ashing.
Option 3: Junction Box Mounting
Prepare the cables and the junction box in advance. Ensure that the mounting holes align
to your junction box.
Route the cables through the square cable
hole on the mounting bracket, and secure the
mounting bracket to the junction box using
screws.
1
The EAP can be powered via a power adapter or a PSE device (such as a PoE switch) which
complies with Power Source Class 2 ( PS2) or Limited Power Source (LPS) of IEC 62368-1.
Option 1: Via PoE Switch
Option 2: Via Power Adapter
Plug one end of the power adapter into the power port of the EAP and the other end to a
standard electrical wall outlet.
Note: Power adapter is not included in the package contents of certain models. For details, refer to the product specications or
datasheet. For power supply specications, refer to the product label.
Power Supply
3
Switch
Power Adapter
PoE Switch
Connect an Ethernet cable from the PoE switch to the Ethernet port.
Note: For PoE power supply specications, refer to the product label.
*Compatible wall junctions:
©2023 TP-Link 7106510781 REV1.5.1
4
Connect the Ethernet cable to the Ethernet
port on the EAP.
Φ 25 mm (63/64 in)
Φ 4 mm (5/32 in)
Method 2: Controller Mode
Note:
• Before you start, be sure to your devices according to the topology figure.power up connect and
• A DHCP server (typically a router with DHCP function enabled) is required to assign IP addresses to
the EAPs and clients in your local network.
Choose a type of Omada Controller:
Choose from the following methods to set up your EAPs:
Method 1: Standalone Mode
Via Omada App
1. Connect your device to the EAP by using the default SSIDs printed on the label at the
bottom of the product.
2. Launch a web browser and enter http://tplinkeap.net in the address bar. Use admin for
both Username and Password to log in.
3. Set up a new Username and Password for secure management purpose. Then you can
configure the AP.
To configure other EAPs, connect your device to each EAP by the corresponding default
SSID and repeat the steps above. You can configure some basic functions in Standalone
Mode. If you want to configure advanced functions, use Controller Mode.
1. Download and install the TP-Link Omada App from App Store or Google Play.
2. Connect your mobile device to the EAP by using the default SSIDs printed on the label
at the bottom of the product.
3. Open the Omada App, go to the >Standalone Devices APs page, and wait for the
EAP to appear. Tap on the EAP to congure it.
The Omada App is designed to help you quickly configure common settings. If you want
to configure advanced settings, use the web page of your EAP or use Controller Mode.
Via Web Browser
Software Conguration
4
Internet
Clients
Router
EAP
EAP
EAP
• Method 1: Standalone Mode
To configure and manage EAPs separately (Convenient for a small network with only a few devices)
• Method 2: Controller Mode
To configure and manage EAPs in batches on a central platform, namely Omada Controller.
Note:
• Before you start, be sure to your devices according to the topology figure.power up connect and
• A DHCP server (typically a router with DHCP function enabled) is required to assign IP addresses
to the EAPs and clients in your local network.
Scan for Omada Omada
or
Switch
Router
Omada Cloud
Clients
EAPEAP EAP EAP
Omada Cloud-Based Controller is a good alternative without the need to install the
software controller on a PC or purchasing the hardware controller.
Licenses need to be purchased additionally.
Type 1: Omada Cloud-Based Controller
* Management via Omada App
After adding a Cloud-Based Controller, you can also manage it via the Omada App.
1. Download and install the TP-Link Omada App from App Store or Google Play.
Scan for Omada Omada
or
2. Launch the Omada App and log in with your TP-Link ID. Then go to Cloud Access. A list of
controllers that have been bound with your TP-Link ID will appear. Then you can launch
the controller adopt and manage devices.to
1. Contact the sales staff to grant the Omada Cloud-Based Controller permission.
2. Launch a web browser and enter https://omada.tplinkcloud.com in the address bar. Log
in with your TP-Link ID.
3. + Add ControllerClick and add a Cloud-Based Controller. Then you can launch the
controller adopt and manage devices.to
Web Configuration
Switch
Router
Clients
Omada Hardware Controller EAP EAP EAP
Switch
Router
Clients
EAP EAP EAP
Controller
Omada Software Controller
running on the Host PC
Note:
• Before you start, be sure to your devices according to the topology figure.power up connect and
• A DHCP server (typically a router with DHCP function enabled) is required to assign IP addresses to
the EAPs and clients in your local network.
• Omada Controller must have network access to your Omada devices (the router, switch, and EAPs) in
order to find, adopt, and manage them.
Note:
• Before you start, be sure to your devices according to the topology figure.power up connect and
• A DHCP server (typically a router with DHCP function enabled) is required to assign IP addresses
to the EAPs and clients in your local network.
• Omada Controller must have network access to your Omada devices (the router, switch, and
EAPs) in order to find, adopt, and manage them.
• Type 2: Omada Software Controller
On a PC with Windows OS or Linux OS, download the software controller from
https://www.tp-link.com/support/download/omada-software-controller/. Then run the file and
follow the wizard to install and launch the controller.
To manage your devices, the software controller needs to keep running on your computer.
• Type 3: Omada Hardware Controller
If you have no spare PC to keep running the software controller in the network, you can
purchase the hardware controller.
For more details, refer to the Installation Guide of your hardware controller.
Via Omada App
1. Download and install the TP-Link Omada App from App Store or Google Play.
2. Launch your Omada App and configure the controller at a local site or remote site.
• Local Management
a. Connect your mobile device to the EAP by using the default SSIDs printed on the
label at the bottom of the product.
b. Launch the Omada App and go to Local Access, tap the + button on the upper-right
corner to add the controller. Then you can launch the controller to adopt and manage
devices.
• Remote Management
Note: Before you start, make sure that both your controller and mobile device can access the
internet.
a. Make sure that Cloud Access is enabled on your controller and your controller has
been bound with your TP-Link ID.
b. Launch Omada App and log in with your TP-Link ID. Then go to Cloud Access. A list
of controllers that have been bound with your TP-Link ID will appear. Then you can
launch the controller adopt and manage devices.to
Scan for Omada Omada
or
Via Omada App
1. Download and install the TP-Link Omada App from App Store or Google Play.
2. Launch your Omada App and configure the controller at a local site or remote site.
• Local Management
a. Connect your mobile device to the EAP by using the default SSIDs printed on the
label at the bottom of the product.
b. Launch the Omada App and go to Local Access, tap the + button on the
upper-right corner to add the controller. Then you can launch the controller to
adopt and manage devices.
• Remote Management
Note: Before you start, make sure that both your controller and mobile device can access the
internet.
a. Make sure that Cloud Access is enabled on your controller. By default, Cloud
Access is enabled. Make sure that the Cloud LED is flashing slowly.
b. Launch Omada App and log in with your TP-Link ID. Then go to Cloud Access. Tap
the + button on the upper-right to add your controller. Then you can launch the
controller adopt and manage devices.to
Scan for Omada Omada
or
1. Open the controller’s web page.
Launch the software controller on your PC. After the initiation process, the controller
automatically opens its web page. If not, click Launch a Browser to Manage the Network.
2. On the controller’s web page, follow the wizard to complete the quick setup. Then you can
launch the controller adopt and manage devices.to
3. (For Remote Management) You can remotely access and manage your controller via
Omada Cloud Service.
Note: Before you start, make sure that both your controller and PC can access the internet.
a. Make sure that Cloud Access is enabled on your controller and your controller has
been bound with your TP-Link ID. On the controller’s web page, go to Settings > Cloud
Access to enable Cloud Access and bind your TP-Link ID. If you have set it up in the
quick setup, skip this step.
b. Launch a web browser and enter https://omada.tplinkcloud.com in the address bar.
Enter your TP-Link ID and password to log in. A list of controllers that have been bound
with your TP-Link ID will appear. Then you can launch the controller to adopt and
manage devices.
Via Web Browser
1. Open the controller’s web page.
Find the IP address of the controller on the gateway router’s DHCP client list. Enter the
IP address in the address bar to open its web page.
2. On the controller’s web page, follow the wizard to complete the quick setup. Then you
can launch the controller adopt and manage devices.to
3. (For Remote Management) You can remotely access and manage your controller via
Omada Cloud Service.
Note: Before you start, make sure that both your controller and PC can access the internet.
a. Make sure that Cloud Access is enabled on your controller. By default, Cloud
Access is enabled. Make sure that the Cloud LED is flashing slowly.
b. Launch a web browser and enter https://omada.tplinkcloud.com in the address bar.
Enter your TP-Link ID and password to log in. Click + Add Controller and choose
Hardware Controller to add your controller. Then you can further configure the
controller.
Via Web Browser
Safety Information
• Keep the device away from water, re, humidity or hot environments.
• Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.
• Do not use the device where wireless devices are not allowed.
• Do not use damaged charger or USB cable to charge the device.
• Do not use any other chargers than those recommended.
• Adapter shall be installed near the equipment and shall be easily accessible.
For the detailed configurations, refer to the User Guide of the controller and EAPs. The guides can
be found on the download center of our official website: https://www.tp-link.com/support/download/.
For technical support, the user guide and other information,
please visit https://www.tp-link.com/support, or simply scan the QR code.
To ask questions, find answers, and communicate with TP-Link users or engineers,
please visit https://community.tp-link.com to join TP-Link Community.
https://omada.tplinkcloud.com
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of
directives 2014/53/EU, 2009/125/EC, 2011 /65/EU and (EU) 2015/863.
The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce/
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of
the Radio Equipment Regulations 2017.
The original UK Declaration of Conformity may be found at https://www.tp-link.com/support/ukca/
Product specificaties
| Merk: | TP Link |
| Categorie: | Access point |
| Model: | Omada EAP773 |
Heb je hulp nodig?
Als je hulp nodig hebt met TP Link Omada EAP773 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Access point TP Link
11 December 2024
3 December 2024
15 November 2024
3 Oktober 2024
4 Mei 2024
25 April 2024
26 Maart 2024
26 Maart 2024
26 Maart 2024
14 November 2023
Handleiding Access point
- Access point Bosch
- Access point HP
- Access point Huawei
- Access point Asus
- Access point Honeywell
- Access point Airlive
- Access point Allied Telesis
- Access point Allnet
- Access point AVM
- Access point Buffalo
- Access point D-Link
- Access point Dell
- Access point Devolo
- Access point Digitus
- Access point Draytek
- Access point Edimax
- Access point Eminent
- Access point Engenius
- Access point EQ-3
- Access point Grandstream
- Access point Hercules
- Access point INCA
- Access point Interlogix
- Access point Lancom
- Access point LevelOne
- Access point Linksys
- Access point Media-tech
- Access point Mikrotik
- Access point Mojo
- Access point Netgear
- Access point Netis
- Access point Renkforce
- Access point Sitecom
- Access point SMC
- Access point Tenda
- Access point Trendnet
- Access point Zebra
- Access point ZyXEL
- Access point Macally
- Access point Steren
- Access point Ubiquiti Networks
- Access point Techly
- Access point Cisco
- Access point 3Com
- Access point Amped Wireless
- Access point Comtrend
- Access point CradlePoint
- Access point Juniper
- Access point Planet
- Access point Intellinet
- Access point Silex
- Access point Lindy
- Access point Black Box
- Access point Fortinet
- Access point DataVideo
- Access point Totolink
- Access point Dahua Technology
- Access point Mercusys
- Access point Aruba
- Access point EQ3
- Access point Homematic IP
- Access point Hawking Technologies
- Access point AMX
- Access point Moog
- Access point Crestron
- Access point StarTech.com
- Access point WatchGuard
- Access point LigoWave
- Access point Advantech
- Access point Moxa
- Access point Kingston
- Access point Vimar
- Access point Aerohive
- Access point Bountiful
- Access point V7
- Access point NUVO
- Access point Cudy
- Access point IP-COM
- Access point Syscom
- Access point Meru
- Access point Cambium Networks
- Access point Ruckus Wireless
- Access point Bintec-elmeg
- Access point Mach Power
- Access point ICC
- Access point Insteon
- Access point Brocade
- Access point Premiertek
- Access point Extreme Networks
- Access point Atlantis Land
- Access point FlyingVoice
- Access point Luxul
Nieuwste handleidingen voor Access point
23 December 2024
8 December 2024
8 December 2024
1 December 2024
1 December 2024
1 December 2024
1 December 2024
1 December 2024
1 December 2024
1 December 2024
