SAVE FOR CONSUMER
Single Handle Kitchen Faucet
Model # LKHA1041
INSTALLATION / OWNER'S MANUAL
Groove joint pliers Wrench Plumber's Putty
Screwdriver Sealant Tape
Secure the faucet assembly with the
washers (1&2) and nut (3). Hand tighten
the nut (3) onto the faucet assembly. Lock
the nut (3) into position by tightening the
screws (4) with a phillips screwdriver.
WARNING: Please carefully read and properly follow the instructions for installation found in this manual.
STEPS:
Install the weight clip (2) at the point of the
hose marking “Weight here”.
Insert the weight (1) onto the clip (2) by
sliding it down onto the clip (2).
Make connections to water lines.
Thread the nut (1) on the supply line onto
the outlet of the water supply valve (2) and
tighten with a wrench.
Do not overtighten.
1
2
Align male fitting (1) and tabs (2) on quick
connector. Push quick connector housing
firmly upward and snap onto receiving
male fitting. Pull down moderately to
ensure connection has been made.
2
1
1
2
34
Optional Deck Plate Installation:
Before installation, align the hole in the
gasket (1) and deck plate (2) with the
mounting hole in the sink. Place the
faucet assembly through the deck plate
(2) and mounting hole in the sink until
the faucet assembly sets on top of deck
plate (2).
NOTE: If the sink is uneven, use silicone
under the gasket (1).
Optional No Deck Plate Installation:
Before installation, place the faucet
assembly through the mounting hole in
sink.
2
1
1
Weight
here
1
2
2
CARTRIDGE REPLACEMENT
Loosen cartridge nut (1) by turning it
counter-clockwise and lift out the cartridge (2). Insert
new cartridge. Reinstall the handle.
Shut off water supply. With valves in "closed" position,
loosen the set screw (2) and remove handle (1).
Unscrew the cap (3) from the cartridge nut (4).
Congratulations on your purchase of an Elkay product.
Although your product is extremely durable, attention should
be given to the care, cleaning and maintenance of this
product. Cleaning agents and abrasives may cause damage,
which may result in oxidation and discoloration.
By following these simple guidelines for proper care and
cleaning, it will give you years of enjoyment:
TO CLEAN: Simply wipe gently with a damp cloth and blot dry
with a soft towel. A common rule of thumb is: when you dry off,
dry off your product.
· Avoid build-up of soap, toothpaste or mineral deposits, as
these tend to have an adverse effect on the appearance of
the product.
· NEVER use cleaning products of any kind on this product -
especially those containing ammonia, bleach or alcohol - or
those with any form of abrasive.
CARE AND CLEANING INSTRUCTIONS
FOR CARE AND MAINTENANCE:
·The water in certain areas of the world can be very caustic -
standing water around the product can cause damage. Be
sure to remove standing water with a dry, soft cloth as soon
as possible.
·For polished brass finishes, as often as once a week, you
can apply a paste wax or special, non-abrasive, brass
coating (DO NOT APPLY POLISH).
·Before applying a protective coating, gently brush the entire
fixture using a soft tooth brush. This will remove any dirt or
deposit build-up.
·These simple steps will add temporary protective coating to
your faucet and extend the life of the finish.
Failure to follow care and cleaning will void your warranty.
For additional information, please visit elkayusa.com .
Important: after installation is
completed, turn on hot and cold water
supplies. Check for leaks. Pull the
hose assembly out of the spout and
remove the spray head by unscrewing
it from the hose counterclockwise. Be
sure to hold the end of the hose down
into the sink and turn the faucet on to
the warm position where it mixes hot
and cold water. Flush water lines for
one minute. Check for leaks.
Re-tighten any connections if
necessary, but do not overtighten.
Reinstall spray head by hand
tightening it back onto the spray hose.
1
2
3
41
2
