MEMORY BOY

ANALOG DELAY WITH CHORUS/VIBRATO

Congratulations on your purchase of the Electro-Harmonix Memory Boy…a smooth

analog delay that takes its heritage from our 1970’s Memory Man and the legendary

Deluxe Memory Man. The Memory Boy uses the Deluxe Memory Man as a base,

expanding upon it with additional modulation features and an optional Expression

Pedal input allowing external control over Delay Time or Modulation Rate.

- OPERATING INSTRUCTIONS and CONTROLS -

Connect your guitar to the INPUT jack of the Memory Boy and the OUTPUT jack to

your amplifier. The Memory Boy can be used in combination with other effects

devices. Experiment with combinations to develop your own unique sounds. The true

bypass footswitch allows you to switch the effect in and out.

START UP TIME: The Memory Boy takes approximately 20 Seconds to fully warm

up. During this time you will hear the delay time slowly increase for a given DELAY

knob setting, especially if the DELAY knob is above 50%. After about 20 Seconds the

Memory Boy settles on the delay time set by the DELAY knob.

DELAY Knob Controls the delay time of your Memory Boy. The delay time range is –

30 mS to 550 mS with the maximum delay time at the full clockwise position of the

knob. Turning the DELAY knob, while listening to your echoes, will bend the pitch of

your notes. The DELAY knob is also used to set the maximum delay time for

expression pedal control.

DEPTH Knob – Sets the amount of modulation that is applied to your delayed

signal. Turning the DEPTH knob clockwise will increase the amount of the

modulation. To completely turn off the modulation, turn the DEPTH knob down to the

full counter-clockwise position.

WARNING: -200BI Use only the 96DC adapter that Memory Boy comes

supplied with. Do not use any other adapters. Using other adapters, even

those made by Electro-Harmonix, could cause harm to the unit, the adapter or

you.

BLEND Knob BLEND –The knob is a wet/dry control allowing you to vary the mix

between direct and delayed signals at the jack of the Memory Boy. Set the OUTPUT

BLEND knob to the full clockwise position for an output that is 100% Wet. Set the

Blend knob to full counter-clockwise for an output that is 100% dry. Setting BLEND

anywhere in between will mix the wet and dry signals together.

FEEDBACK – Controls the amount of signal that is circulated from the output of the

delay block to its input. Turning the FEEDBACK knob clockwise increases the number

of echoes. Setting the FEEDBACK control to its maximum clockwise position will cause

the Memory Boy to run-away, or self-oscillate. If instead you only want to hear one

echo for each of your notes, turn the FEEDBACK knob down to its full counter-

clockwise position. Fairly high feedback with short delay settings produces a reverb

type of effect.

Triangle / Square Toggle Switch – This two position toggle switch sets the shape

of the analog modulation waveform. To hear the effects of this switch, the DEPTH

knob must be turned up. When set to Triangle (UP position), Memory Boy’s

modulation will be smooth and continuous, similar to the modulation you would hear

in many Chorus effects. Set the switch to Square (Down position) and the modulation

will jump between two delay times creating a temporary pitch shifting type of effec t.

CHORUS, VIBRATO & EXP. PEDAL Toggle Switch – This three position, dual

function toggle switch has two jobs: it sets the rate of modulation and chooses the

parameter for the expression pedal to control.

MODULATION RATE: With nothing plugged into the EXP. PEDAL jack, this switch

selects three different modulation rates: CHORUS for a slow rate, EXP. PEDAL for a

medium rate and VIBRATO for a fast rate. When an expression pedal is plugged into

the EXP. PEDAL jack, the CHORUS and VIBRATO settings remain the same; flipping

the switch to the middle position, EXP. PEDAL, allows the expression pedal to control

the rate of modulation. The full range of the expression pedal extends past the two

rates set by CHORUS and VIBRATO.

EXPRESSION PEDAL CONTROL: An optional expression pedal can control either

the Memory Boy’s delay time or modulation rate. The CHORUS, VIBRATO, EXP.

PEDAL toggle switch selects the parameter for the expression pedal to control. When

this switch is set to either CHORUS or VIBRATO modes, the expression pedal controls

delay time. If the switch is set to EXP. PEDAL, the expression pedal controls the rate

of modulation. The modulation rate increases as the expression pedal moves from

toe up to toe down.

When you control delay time with an expression pedal, the shortest delay time will be

in the toe up position; the longest delay time will be in the toe down position. The

delay knob works in conjunction with the expression pedal to set the maximum delay

time in the toe down position. As you turn the DELAY knob clockwise, the maximum

delay time for the expression pedal will increase. Some expression pedals, such as

the M-Audio EX-P, have a knob on the side of the pedal. This knob can be used to set

the shortest delay time in the toe up position.

FOOTSWICH and STATUS LED – When the status LED is lit, the Memory Boy is in

effect mode, when the LED is off the Memory Boy is in true bypass mode. The

footswitch below the LED toggles between effect and true bypass modes.

- JACKS -

INPUT Jack – Connect the output of your instrument or another effects pedal to the

¼” INPUT jack. The input impedance presented at the input jack is 1 M.

OUTPUT Jack – Connect the output of the Memory Boy to the input of an amplifier

or another effects pedal.

EXP. PEDAL Jack – Allows the user to control the delay time or modulation rate

with an optional expression pedal or control voltage. The expression pedal should

have a Tip-Ring-Sleeve plug attached to it. It is important that the expression pedal

have the correct polarity. The tip of the plug must be connected to the wiper of the

potentiometer inside the expression pedal. If you are not sure what type of

expression pedal to use, try to purchase one with a polarity switch, so that it will

work with many different types of instruments. Some suggested Expression Pedals:

Moog EP-2, M-Audio EX-P or Roland EV-5. You may also connect a control voltage to

this jack. The Control Voltage range is 0 V to 5 V.

9V PWR JACK – Connect the output plug of the supplied AC Adaptor into the 9V

power jack at the top of the Memory Boy. The Memory Boy requires 45mA at

9VDC. The polarity of the power jack is center negative. There is also an optional 9V

battery clip inside your Memory Boy. with the Memory Only use alkaline batteries

Boy. You should get 3 to 4 hours use out of one battery.
