Pagina 1/3
1
CRAYON
Full-Range Overdrive
Congratulations on your purchase of the Crayon a colorful overdrive in a ,
compact, pedalboard-friendly enclosure. Unlike many mid-focused overdrive
pedals, the Crayon is a
full-range
overdrive with rich harmonic content and a full
bodied tone allowing you to dial in the perfect overdrive for any situation. The
GAIN knob ranges from just a touch of dirt to full-on distortion while individual
BASS and TREBLE controls open up the frequency response capabilities of the
Crayon yielding wide range of versatile overdriven sounds. a
- CONTROLS -
GAIN Knob Controls the amount of input gain. As you turn clockwise, GAIN
the overdrive ranges from just a touch of grit, in the fully counter-clockwise
position, to classic distortion, in the fully clockwise setting.
TREBLE Knob As you turn TREBLE clockwise, the overdrive’s high end is
accentuated, making your tone brighter Turn TREBLE counter-clockwise for a .
darker sound .
BASS Knob As you turn BASS clockwise, the low end is boosted. Turn BASS
counter-clockwise to reduce low end.
VOL Knob Sets the output level of the Crayon. As VOL is turned clockwise, the
output volume increases.
FOOTSWITCH and LED The Footswitch selects whether the Crayon is
engaged or in true-bypass mode. When the effect is engaged, the LED lit. is
INPUT Jack Crayon. The input This ¼” jack is the audio input for the
impedance is k . 315
AMP Jack Crayon The output This ¼” jack is the audio output from the .
impedance is . 50
2
9V Power Jack The Crayon can run off of a 9V battery or you can use an
optional 9VDC AC Adapter capable of delivering at least 25mA to the 9V power
jack, such as the Electro-Harmonix 9.6DC-200 power supply. The AC Adapter
must have a center negative plug. The battery may be left in or taken out when
using an AC Adapter. The Crayon has a current draw of mA at 9VDC. 10
- CHANGING THE BATTERY -
To change the 9V battery, remove the four screws on the bottom of the Crayon.
Once the screws are removed, take off the bottom plate change the battery. to
Please do not touch the circuit board while the bottom plate is off or you risk
damaging a component.
3
- WARRANTY INFORMATION -
Please register online at http://www.ehx.com/product-registration or complete and return
the enclosed warranty card within 10 days of purchase. Electro-Harmonix will repair or
replace, at its discretion, a product that fails to operate due to defects in materials or
workmanship for a period of one year from date of purchase. This applies only to original
purchasers who have bought their product from an authorized Electro-Harmonix retailer.
Repaired or replaced units will then be warranted for the unexpired portion of the original
warranty term.
If you should need to return your unit for service within the warranty period, please
contact the appropriate office listed below. Customers outside the regions listed below,
please contact EHX Customer Service for information on warranty repairs at info@ehx.com
or +1- -937-8300. USA and Canadian customers: please obtain a 718 Return
Authorization Number (RA#) from EHX Customer Service before returning your product.
Include with your returned unit: a written description of the problem as well as your
name, address, telephone number, e-mail address, and RA#; and a copy of your receipt
clearly showing the purchase date.
United States & Canada
EHX CUSTOMER SERVICE
ELECTRO-HARMONIX
c/o NEW SENSOR CORP.
47-50 33RD STREET
LONG ISLAND CITY, NY 11101
Tel: 718-937-8300
Email: info@ehx.com
Europe
JOHN WILLIAMS
ELECTRO-HARMONIX UK
13 CWMDONKIN TERRACE
SWANSEA SA2 0RQ
UNITED KINGDOM
Tel: +44 179 247 3258
Email: electroharmonixuk@virginmedia.com
This warranty gives a purchaser specific legal rights. A purchaser may have even greater
rights depending upon the laws of the jurisdiction within which the product was purchased.
To hear demos on all EHX pedals visit us on the web at www.ehx.com
Email us at info@ehx.com
