Pagina 1/32
COPYRIGHT © 2011-2016 Dometic Corporation. All Rights Reserved.
No part of this publication may be reproduced, translated, stored in a retrieval system, or transmitted in any form or by any means
electronic, mechanical, photocopying, recording or otherwise without prior written consent by Dometic Corporation. Every precaution
has been taken in the preparation of this manual to insure its accuracy. However, Dometic Corporation assumes no responsibility for
errors and omission. Neither is any liability assumed fo this product and information contair damages resulting from the use of ned
herein.
Blizzard Turbo Split System
Installation and Operation Manual
Dometic Truck
Rev. 20170601
L-3448 English
P/N 339061
L-3448 ENGLISH
Table of Contents
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
IMPORTANT NOTICES . . . . . . . . . . . . . . . . . . . . . . . . . 2
SAFETY GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . 2
GENERAL SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . 2
S AFE HANDLING OF R . . . . . . . . . . . . . . 3EFRIGERANTS
BEFORE YOU START . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ADDITIONAL DOCUMENTATION AVAILABLE . . . . . . . . . . 4
TOOLS REQUIRED . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
POSSIBLE MODIFICATIONS TO VEHICLE 5
D O N AOT TTEMPT THIS INSTALLATION UNLESS . . . . . . 5
INSTALLATION INSTRUCTIONS . . . . . . . . . . . . . . . . . 6
PART 1: INSTALLATION OF THE CHEB . . . . . . . . . . . . . 6
CHEB INSTALLATION STEPS: . . . . . . . . . . . . . . . 6
INSTALLING IGNITION INTERLOCK . . . . . . . . . . . . 10
PART 2: CONDENSER INSTALLATION 10
INSTALLING THE CONDENSER . . . . . . . . . . . . . . 10
PART 3: SECURING LINE SETS ABLE & CONDENSER C 11
PART 4: INSTALLING QT CONTROL 12
PART AND 5: DUCT GRILLE INSTALLATION . . . . . . . . . 13
RETURN AIR GRILLE . . . . . . . . . . . . . . . . . . . . . 13
SUPPLY AIR GRILLES . . . . . . . . . . . . . . . . . . . . 14
INSTALLING OPTIONAL DUCT TOWERS 14
OPERATING THE SYSTEM WITH QT CONTROLS . . 16
QT QUICK START . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
QT BASIC OPERATION . . . . . . . . . . . . . . . . . . . . . . . 17
POWER ON . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
SYSTEM OFF . . . . . . . . . . . . . . . . . . . . . . . . . . 17
SELECTING SETPOINT . . . . . . . . . . . . . . . . . . . . 17
DISPLAYING TEMPERATURE . . . . . . . . . . . . . . . . 17
COOL MODE . . . . . . . . . . . . . . . . . . . . . . . . . . 17
HEAT MODE . . . . . . . . . . . . . . . . . . . . . . . . . . 17
AUTO MODE . . . . . . . . . . . . . . . . . . . . . . . . . . 17
AUTOMATIC FAN PEED LOW S (INTERNAL AIR F ) . 17
MANUAL SPEED CONTROL . . . . . . . . . . . . . . . . 18
ADJUSTING DISPLAY BRIGHTNESS . . . . . . . . . . . 18
PROGRAMMING YSTEM QT DIGITAL/CONTROL S . . . . . 18
FACTORY MEMORY RESET . . . . . . . . . . . . . . . . 18
FAHRENHEIT/CELSIUS DISPLAY . . . . . . . . . . . . . 18
LOW FAN PEED S ADJUSTMENT . . . . . . . . . . . . . 18
HIGH FAN PEED S ADJUSTMENT 20
FAN MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
AC LINE VOLTAGE CALIBRATION . . . . . . . . . . . . 20
TO CHECK OR CALIBRATE AC LINE VOLTAGE: . . 20
GENERATOR OUTPUT CALIBRATIONS . . . . . . . . . 20
TEMPERATURE CALIBRATION . . . . . . . . . . . . . . . 21
SOFTWARE VERSION AND REVISION NUMBERS . . 21
LED SLEEP MODE . . . . . . . . . . . . . . . . . . . . . . 21
ANTI-ICE ROUTINE . . . . . . . . . . . . . . . . . . . . . . . 21
POWER SAVER MODE . . . . . . . . . . . . . . . . . . . . 21
FAULT SHUTDOWNS AND ERROR MESSAGES 22
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . 23
QT CONTROL/DISPLAY TROUBLESHOOTING GUIDE . . . 23
SYSTEM TROUBLESHOOTING GUIDE 24
OPTIMIZING PERFORMANCE . . . . . . . . . . . . . . . . . . . 25
REDUCE HEAT LOAD . . . . . . . . . . . . . . . . . . . . . 25
OPERATION AND MAINTENANCE . . . . . . . . . . . . . 25
TOTAL SYSTEM CHARGE . . . . . . . . . . . . . . . . . . . . . . 26
STANDARD LENGTH LINE SET . . . . . . . . . . . . . . 26
EXTRA ENGTH L LINE SET . . . . . . . . . . . . . . . . . 26
SHORTER LENGTH LINE SET . . . . . . . . . . . . . . . 26
Blizzard Turbo Split System Manual INTRODUCTION
L-3448 ENGLISH 1
INTRODUCTION
The Dometic Blizzard Turbo is an auxiliary air conditioning system that cools the sleeper cab and keeps the driver comfortable
without running the engine.
Instead of wasting fuel by using an idling engine to power the truck's own air conditioning system, the Blizzard Turbo uses an
alternative source of power, such as:
• 115VAC power supplied by an onboard diesel genset
• A shorepower connection when an external AC power source is available, or
• A bank of deep cycle batteries using an inverter to convert the 12V battery output into usable 115VAC power
Dometic's patented Blizzard Turbo is a split system that consists of two separate components (see Figure 1):
•The outside unit contains the condenser and cooling fan. It can be bolted horizontally to the underside or vertically to
the back of the sleeper cab.
•The inside unit contains the compressor, heater (optional), evaporator, blower (CHEB). The CHEB also houses the
Power Logic Box (PLB) and other associated components. The inside unit is mounted under a berth or seat or in a side
storage locker.
The two units are connected by reusable pre-charged quick-connect refrigerant line sets. The system is designed so that both
units automatically charge to the correct refrigerant pressure as soon as the line sets are connected. No special tools are
required.
Figure 1: Blizzard Turbo Split System Components
Outside Unit Inside Unit
Compressor, Heater, Evaporator, Blower (CHEB)
Condenser & Fan
