C
Page 1
Rev: 1
Date:09242024
Advanced Ampliîš¿er Interface
for Select Toyota Applications
AP4-TY14
The AP4-TY14 provides a 6-channel pre-amp output for use with aftermarket audio equipment. Using the full range
îš¿xed level head unit output, in conjunction with data bus messages, the AP4-TY14 delivers a variable 5v RMS pre-
amp output with fading, balance, equalization, and level control capabilities. The module also retains audio from
other vehicle features such as factory navigation prompts, Bluetooth and Voice Activation. An accessory controlled
remote ampliîš¿er turn on wire is also provided by the AP4-TY14. When used in conjunction with the APA-TOS1 (sold
separately), the module can provide a variable 2-channel îš¿ber optic digital audio output (TOSLINK).
Introduction and Features
Important Notes
1. Toyota Safety Connect (SOS) can easily be retained. See the page 3 for detailed instructions.
2. The aftermarket ampliîš¿er must have a very solid ground and the ampliîš¿er power/ground connections should be made
before connecting the RCA's or Remote on the AP4-TY14.
3. The factory radio's speed controlled volume, DSP, and surround sound mode are not supported by the AP4 outputs.
4. The factory ampliîš¿er must remain connected and in the vehicle after the AmpPRO has been installed.
5. Prior to testing, cycle the ignition off and back on again to properly initialize the AP4-TY14.
6. The radio's beep setting must be enabled on the factory radio in order to hear the audible tones when making selections
through the radio.
7. Initially, if the beep through the AP4-TY14 does not match the on/off selection through the radio, cycle the beep to the
opposite setting and back, then test again.
8. The radio's beep volume and minimum volume levels are set to 0 dB by default. If you are happy with this level in your
particular application, additional adjustment is not required. Please refer to the Setup and Conîš¿guration section on page 4
for more details.
9. The Radio's Nav / VR Voice, incoming E-mail tone, Ringtone, In-Call, Incoming SMS / MMS tone and Incoming SMS Voice
volumes can be adjusted through the radio's settings menu as they were prior to installation of the AP4-TY14.
10. The remote output is rated at 2A of current. If more current is needed, an external relay must be used.
11. Channels 5 and 6 are non-fading outputs. The output level of channels 5 and 6 can be controlled using the supplied level
control knob.
Wiring Connection Chart
To Aftermarket
Amplier
Non-FadingRearFront
1(L) 2(R) 4(R) 5(L) 6(R)3(L)
Non-Fading
Level Control
Knob
Remote Turn On Output (2A Max)
SOS Mute ( - Trigger Input )
GRAY GRAY
BLACK BLACK
WHITEWHITE
28-pin
10-pin
30-pin
© 2024 Stinger Solutions
C
Page 2
Rev: 1
Date:09242024
Advanced Ampliîš¿er Interface
for Select Toyota Applications
AP4-TY14
Installation
1. Remove the factory radio.
2. Disconnect the 28-pin, 30-pin and 10-pin connectors from the radio.
3. Ensure that you only remove the 28-pin and 30-pin connector that is
closest to the 10-pin connector, the correct 28-pin connector will be
either gray or white depending on the vehicle. There is another 28-
pin connector on the radio that will not be used. See Figure 1.
4. Connect the AmpPRO harnesses to the vehicle harnesses.
5. Connect the AmpPRO harnesses to the factory radio.
6. Set any feature DIP switches that apply to your install.
a. DIP switch 1 is used for two channel mode. In this mode, both
the TOSLINK and front RCA outputs (1 and 2) become non-
fading outputs and makes all chimes play through only the
TOSLINK and front RCA outputs (1 and 2).
b. Set DIP switch 2 on (down) to lower the RCA output voltage to
4v. Leave DIP switch 2 off (up) to keep the RCA output voltage at
5v. See troubleshooting section on Page 6 for more details.
c. DIP switch 3 is not used and should remain off (up).
d. DIP switch 4 is not used and should remain off (up).
6. If you are using the APA-TOS1 (sold separately) refer to the
instructions included with that product for its installation.
7. Connect the AmpPRO harness to the module.
8. Connect the level control knob to the module and install in an
accessible location.
9. Connect the signal cables and remote input from the aftermarket
ampliîš¿er.
10. The Yellow / Black "SOS Mute" wire will be used in conjunction with
the Safety Connect (SOS) Retention. See Page 3 for more details.
DIP
1 2 3 4
ON
Two Channel Mode 5v / 4v Preout Not Used Not Used
1 2 3 4
Set DIP switches to the ON position to activate the corresponding features.
Set DIP switches to the OFF position for any features that are not desired.
Module Layout
LED 1
Interface Connector 1
Expansion Port
TOSLINK Output
(APA-TOS1 sold separately)
Programming Button
Feature Select
DIP switches
Front Output
Ch. 1(L) and 2(R)
Non-Fading Level Control
Knob Connection
USB Connection Rear Output
Ch. 3(L) and 4(R)
Non-Fading Output
Ch. 5(L) and 6(R)
LED 2
Fig.1
10-pin 28-pin 30-pin
© 2024 Stinger Solutions
C
Page 3
Rev: 1
Date:09242024
Advanced Ampliîš¿er Interface
for Select Toyota Applications
AP4-TY14
Installation (cont.)
Safety Connect (SOS) Retention
In order to retain the factory feature of muting the radio's audio while an SOS call is taking place, the Yellow / Black "SOS
Mute" must be connected to the Telematics Mute Trigger wire in the vehicle. The Telematics Mute trigger wire is in the white
24pin connector at the factory ampliîš¿er (reference connector image and pin location below). A military splice connection to this
wire will be adequate.
12 11 10 9 8 7 6 5 4 3 2 1
24 23 22 21 20 19 18 17 16 15 14 13
WIRE SIDE
Setup and Conîš¿guration
Setting the radio's beep volume using the programming button
1. Start with the level control knob turned all the way down (counter-clockwise).
2. Press the programming button on the side of the interface.
3. LED 1 will turn green and beeps will begin continuously sounding.
4. Turn the level control knob clockwise until the desired beep volume level is reached.
5. You can now either press the programming button twice or wait ten seconds to exit the settings.
Manually Setting the Minimum Volume
If the minimum volume of the radio (factory radio volume level 1) is too loud, you can manually set the level of the minimum
volume using the programming button. If you would like to set the minimum volume using the AmpPRO app, please proceed to
the AmpPRO App section.
PLEASE NOTE: Level control knob must be connected to the module in order to set the Minimum Volume.
Setting the minimum volume using the programming button
1. Start with the level control knob turned all the way down (counter-clockwise).
2. Set the amp gains to the desired level.
3. Set the volume on the factory radio to 1.
4. Press the programming button on the side of the interface twice.
5. LED 1 will turn amber and the chimes will begin sounding every îš¿ve seconds.
6. Turn the level control knob clockwise until the desired minimum volume level is reached.
7. You can now either press the programming button once or wait ten seconds to exit the settings.
1. Turn the ignition on. LED 1 on the interface will turn on and the +12v remote output will turn on.
2. Set the amp gain(s) to the desired level. We recommend using an oscilloscope and test tones to set the amp gain(s).
Please refer to the MECP Advanced study guide if you are unfamiliar with this process.
3. Check volume, balance, fade and EQ settings.
4. If you would like to adjust the radio's beep volume or minimum volume, do so using one of the methods outlined below. If
you are happy with the default levels, no adjustments are necessary.
Manually Setting the Radio's Beep Volume
You can manually set the level of the factory radio beeps using the programming button on the side of the interface. If you would
like to set the beep volume using the PC app please proceed to the PC App section.
