Waterco Micron Top Mount Fibreglass Filters Handleiding
Waterco
Waterfilter
Micron Top Mount Fibreglass Filters
Lees hieronder de 📖 handleiding in het Nederlandse voor Waterco Micron Top Mount Fibreglass Filters (56 pagina's) in de categorie Waterfilter. Deze handleiding was nuttig voor 44 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld
Pagina 1/56
Waterco Limited ABN 62 002 070 733
(8290061) 07/2010
WATERCO FIBREGLASS FILTERS / WATERCO
GFK-FILTERKESSEL / FILTRES WATERCO A FIBRES DE VERRE
/ FILTROS DE FIBRA DE VIDRIO WATERCO /
MICRON
玻璃纤维过滤器
Notice to Installer
This manual contains important information about the installation, operation and safe use of this product.
Once the product has been installed this manual must be given to the owner/operator of this equipment.
Hinweise zur Montage
Diese Anleitung enthält wichtige Informationen zu Montage, Betrieb und sicherem Einsatz dieses Produkts.
Nach der Montage des Produkts ist diese Anleitung dem Eigentümer/Betreiber dieser Anlage zu übergeben.
Consignes destinées à l'installateur
Ce manuel contient des informations importantes concernant l'installation, l'exploitation et l'utilisation en toute sécurité de
ce produit. Une fois ce produit installé, il faut remettre ce manuel au propriétaire / exploitant de cet équipement.
Nota para el instalador
Este manual contiene información importante sobre la instalación, el funcionamiento y la utilización segura de este producto.
Una vez el producto haya sido instalado este manual debe entregarse al propietario/operador de este equipo.
安装人员注意：
此说明书包括产品安装，运行和安全使用的重要信息。一旦产品被安装，该说明书必须交到用户或操作者的手中。
This equipment must be installed and serviced by a qualified technician. Improper installation may result in
property damage, serious injury or death. Improper installation and/or operation will void the warranty.
Montage und Wartung dieser Anlage sind durch eine qualifizierte Fachkraft auszuführen.
Unsachgemäße Montage kann Tod, schwere Verletzungen oder Sachschäden zur Folge haben.
Bei unsachgemäßer Montage und/oder unsachgemäßem Betrieb erlischt die Garantie.
L'installation et l'entretien de cet équipement doivent être confiés à un technicien qualifié.
Une installation incorrecte risque de provoquer des dégâts, des blessures graves, voire même la mort.
Une installation et (ou) utilisation incorrecte(s) va (vont) rendre la garantie nulle et non avenue.
El equipo deben ser instalado y mantenido por un técnico cualificado. Una instalación inadecuada puede causar daños
en la propiedad, lesiones graves o la muerte. Una instalación y/o un funcionamiento inadecuados anulará la garantía.
警告：该设备须由合资格的技术人员安装和维护，不恰当的安装会导致缸体性能受损，严重损坏或无法使用。
不恰当的安装/操作方式会使保修无效。
OFFICES - AUSTRALIA
NSW - Sydney
(HEAD OFFICE)
Tel : +61 2 9898 8686
VIC/ TAS - Melbourne
Tel : +61 3 9764 1211
WA - Perth
Tel : +61 8 9273 1900
QLD - Brisbane
Tel : +61 7 3299 9900
SA/ NT - Adelaide
Tel : +61 8 8244 6000
ACT Distributor
Tel : +61 2 6280 6476
OFFICES - OVERSEAS
Waterco USA
Augusta, USA
Tel : +1 706 793 7291
Waterco Canada
St-Hyacinthe, QC, Canada
Tel : +1 450 796 1421
Waterco (Europe) Limited
Sittingbourne, Kent. UK
Tel : +44(0) 1795 521 733
Waterco (NZ) Limited
Auckland, New Zealand
Tel : +64 9 525 7570
Waterco (C) Limited
Guangzhou, China
Tel : +8620 3222 2180
Waterco (Far East) Sdn. Bhd.
Selangor, Malaysia
Tel : +60 3 6145 6000
PT Waterco Indonesia
Jakarta, Indonesia
Tel : +62 21 4585 1481
Waterco International Pte Ltd
Singapore
Tel : +65 6344 2378
Including / für / Dont / Incluyendo / 包含
Installation and
Operation Manual
Montage- und
Betriebsanleitung
Manuel d'installation
et d'utilisation
Instalación y Manual
de funcionamiento
操作说明书
SAFETY INFORMATION ---------------------------------------------- 01
WATERCO FIBREGLASS FILTERS ---------------------------------- 01
INSTALLATION -------------------------------------------------------- 02
MULTIPORT (4 & 6 Way) VALVE OPERATION ---------------------- 05
INITIAL STARTUP OF FILTER ---------------------------------------- 06
BACKWASHING ------------------------------------------------------ 06
MAINTENANCE ------------------------------------------------------- 08
WINTERISING -------------------------------------------------------- 08
TROUBLESHOOTING ------------------------------------------------ 09
WARRANTY ----------------------------------------------------------- 09
I pg 01
SAFETY INFORMATION
1. Waterco breglass lters are designed to work with water at a temperature > than 0ºC and < than
50ºC. The lter should never be operated outside of these temperatures or damage may occur.
2. The installation should be carried out in accordance to local safety standards and bylaws.
3. Any modication of the lter requires the prior consent from Waterco. Original replacement parts
and accessories authorised by the manufacturer ensure a high level of safety. Waterco assumes no
liability for the damage and injuries caused by unauthorised replacement parts and accessories.
4. The user should make sure that the installation is carried out by qualied authorised persons and that
these persons have rst carefully read the following instructions.
5. The operating safety of the lter is only guaranteed if the installation and operation instructions are
correctly followed.
6. In the event of defective operation or fault, contact Waterco or its nearest authorised service agent.
7. To reduce the risk of injury, do not permit children to use this product.
8. Incorrectly installed equipment may fail, causing severe injury or property damage.
9. Chemical spills and fumes can weaken Swimming Pool / Spa equipment. Corrosion can cause
lters and other equipment to fail, resulting in severe injury or property damage. Do not store pool
chemicals near your equipment.
WATERCO FIBREGLASS FILTERS
Waterco breglass lters embody the latest in breglass winding technology. Waterco breglass vessels
consist of an inner shell of berglass reinforced polyester resin wound over with breglass lament.
Waterco’s digitally controlled lament winding machine faultlessly winds continuous strands of high
quality breglass lament under controlled tension lament to create a seamless one-piece vessel with
rened consistency and superior quality.
There are no welds or seams or special tank linings which can corrode or electrolyse.
Six position Multiport valve with sight
glass and quick connect half unions.
Inow diffuser for even distribution
of water ow across the lter bed.
Pressure gauge.
Fibreglass wound tank, UV and
Corrosion Resistant.
Hydraulically balanced laterals to
maximise water ow and ltration.
Manual Drain*
Large lter base for stable oor
mounting.
Waterco Sidemount fibreglass filters Waterco Top Mount fibreglass filters
* Optional manual drain
Waterco Fibreglass Filters
