Tips
For initial registration of the ONT, you can configure the quick registration function according to the page
prompts. In INTERNET Settings module, you can set the parameters to set up a WAN connection
according to your ISP and your own needs, and click . If not, refer to the following to set up Apply Changes
a WAN connection.
➊ Choose > .WAN PON WAN
➋ Tick .Enable VLAN
➌ Enter the VLAN ID provided by your ISP.
➍ Set Channel Mode to .PPPoE
➎ Set Connection Type to INTERNET.
➏ Enter the PPPoE UserName and Password provided by your ISP.
➐ Set other parameters according to your ISP and your own needs.
➑ Click .Apply Changes
➒ Click when OK Change setting successfully is shown on the page.
Step 2: Set up a WAN connection
UserName:
Password:
PON WAN
Apply Changes Delete
This page is used to configure the parameters for PONWAN
Enable VLAN:
VLAN ID:
Channel Mode:
Connection Type:
ppp0_nas0_0
11
test
11
PPPoE
INTERNET
LED indicator Color Status Description
Solid on
Solid on
PWR
INET
PON
LOS
LAN
WPS
TEL
Green
Green
Green
Green
Green
USB Green
Red
The ONT is powered on.
The internet access is available through the ONT.
Data is being transmitted through the ONT.
No internet access is available through the ONT.
Solid on The ONT is registered successfully.
Blinking
Blinking
Blinking
Blinking
Solid on
Off
Off
Green
WLAN/
2.4G/5G Green
The received optical power is at a proper value.
Off
Off
The ONT is registering.
Off The ONT is powered off.
The received optical power is lower than the optical receiver sensitivity.
The LAN port is connected. No data is being transmitted.
The ONT is unregistered.
The LAN port is transmitting data.
The LAN port is disconnected.
Blinking
Solid on
Off
The ONT is registered with IMS. No data is being transmitted.
The ONT is registered with IMS and is transmitting data.
The ONT is not registered with IMS.
Blinking
Solid on
Off
The USB port is connected. No data is being transmitted.
The USB port is transmitting data.
The USB port is disconnected.
Blinking
Solid on for
2 minutes
Off
A WPS connection is established.
The WPS negotiation is ongoing.
The WPS function is not activated.
Blinking
Solid on
Off
The Wi-Fi network is enabled.
Data is being transmitted wirelessly.
For the device without the LED indicator: If the WPS function is WPS
activated on the device, the WLAN/2.4G/5G LED indicator blinking
means that the device is performing WPS negotiation.
The Wi-Fi network is disabled.
Port/Button Description
ON/OFF
PON
WLAN
WPS/RST
LED
Press the button to turn on or turn off the ONT.
Optical fiber port. Used to connect to optical network through a fiber cord.
PWR Used to connect the ONT to a power source using the included power adapter.
USB USB 2.0 port. Used to connect to a USB storage for resource sharing.
Wi-Fi on/off button. Press the button to enable or disable the Wi-Fi function of the ONT.
TEL
LAN1-4
Telephone port. Used to connect to a telephone for voice service using a telephone cable.
Gigabit LAN ports. Used to connect to such devices as routers, switches, computers or IPTV
set-top boxes.
LED indicator on/off button. Press the button to turn on or off the LED indicators of the ONT.
WPS/Reset button.
• : WPS-supported devices can connect to the Wi-Fi networks of the ONT without entering WPS
the password through WPS negotiation.
Press the button for about 1-3 seconds to start the WPS negotiation process of the ONT. The
WPS (marked ) LED indicator blinks quickly. Within 2 minutes, enable the WLAN/2.4G/5G/WPS
WPS function to establish a WPS connection on a WPS-supported device.
• : Restore the ONT to the configurations preset by the ISP or restore the ONT to factory Reset
settings.
- To restore the ONT to the configurations preset by the ISP: After the ONT completes
startup, press the button for 10 to 60 seconds and release it. All LED indicators will light
off in a few seconds. When the LED indicator lights solid on again, the ONT is PWR
restored to the configurations preset by the ISP.
- To restore the ONT to factory settings: After the ONT completes startup, press the button
for more than 1 minute and release it. All LED indicators will light off in a few seconds.
When the LED indicator lights solid on again, the ONT is restored to the factory PWR
settings.
Tips
This ONT supports wall mounting (two mounting holes on the bottom). The recommended parts are as follows:
- Expansion bolt: Thread diameter: 6.0 mm; Length: 26.4 mm; Inner diameter: 2.4
- Screw: Quantity: 2; Diameter: 3.0-4.0 mm; Head diameter: 5.0-6.5 mm.
Tips
• HG15 is used for illustration here unless otherwise specified. The actual product prevails
• Press button (if any) to turn on the ONT.ON/OFF
• If ISP provides any parameters for registration, you can use them to manually register the ONT with the quick
registration function. The quick registration function is available only when the ONT is registered for the first time.
Method:
Refer to Step 1 Router mode 2. Configure the internet access in the of the .
➊ Log in to the web UI of the ONT.
➋ In (or ) module, register with the parameters provided by your ISP and click GPON Settings EPON Settings
Apply Changes.
➋
Get to know the ONT
1. Connect and register the ONT
Caution, laser
DO NOT look directly at the port when the device is powered on, as well as the terminal of the indoor fiber PON
cord, to prevent any harm to your eyes.
Connect the ONT as shown in the figure. Wait until the LED indicator lights solid on, then the ONT is PON
registered successfully.
(Example: HG15)
Tips
HG15 is used for illustration here unless otherwise specified. The actual product prevails.
(Example: HG15)
Power adapter
Rear panel
PON TEL LAN2 LAN1PWR
WPS / RST
Bottom panel
Fiber cord
PON port
Tips
If the above page does not appear, refer to in . Q1 FAQ
Tips
- PPPoE is used for illustration here. Change the parameters as required by your ISP.
- Choose a desired mode to configure your internet access:
Router mode: Configure the internet on the ONT.
Bridge mode: Dial-up on the router or terminal connected to the ONT.
Tips
You can log in to the web UI of the ONT with user permissions or administrator permissions. Administrator
permissions are for the installation and maintenance personnel only.
• : Able to view and modify partial configurations of the ONT. The default login user User Permissions
name is . You can get the password from the bottom label on the ONT.admin
• Administrator Permissions: Able to view and modify all configurations of the ONT. Some
configurations changed by the installation and maintenance personnel will affect the normal operation
of the ONT. Therefore, use the administrator permissions with caution. The default login user name and
password are both admin (or root).
2. Configure the internet access
➊ Connect to the ONT.
• Wired device: Connect a LAN port of the ONT to a wired device, such as a computer, using an Ethernet
cable.
• Wireless device: Connect your wireless device, such as a smartphone, to the Wi-Fi network of the ONT
using the (Wi-Fi name) and (Wi-Fi password) on the bottom label.SSID Key
➋ Start a web browser and visit .192.168.1.1
➌ Enter the and User Name Password according to the actual permissions.
➍ Click .Login
Step 1: Log in to the web UI
Router mode
192.168.1.1
User Name:
Password:
ResetLogin
Ports/Buttons
Quick Installation Guide
HG Series xPON ONT
Package contents
• xPON ONT x 1
• Power adapter x 1
• Ethernet cable x 1
• Telephone cable x 1 (if any)
• Optical fiber cable x 1 (if any)
• Quick installation guide x 1
LED indicators
The LED indicators may vary with models. The actual product prevails. The ports and buttons may vary with models. The actual product prevails.
➊
Tips
When the ONT is set to bridge mode, configure internet settings based on ISP requirements.
➊ Connect a LAN port of the ONT to the WAN port of the router using an Ethernet cable.
➋ Connect your computer to a LAN port of the router using an Ethernet cable.
➌ Set up a PPPoE connection on the router as required.
After the settings, you can access the internet through the router.
Done.
To access the internet:
• Connect your wired device, such as a computer, to a LAN port of the ONT.
• Connect your wireless device, such as a smartphone, to the Wi-Fi networks of the ONT, using the SSID
(Wi-Fi name) and (Wi-Fi password) on the bottom label. Key
Access internet over PPPoE
Bridge mode
PON TEL LAN2PWR LAN1
WPS / RST
WPSReset WAN 1 2 IPTV/3 POWER
Power source
Power source
Computer
LAN LAN
ONT Router
Optical fiber
Ethernet cable
Ethernet cable
FAQ
• Ensure that the ONT is powered on properly (the LED indicator is solid green).PWR
• If you use a wireless device, such as a smartphone, to configure the ONT:
- Ensure that your smartphone has disabled mobile data and is connected to the Wi-Fi network of the
ONT.
- Clear the cache of the web browser or change a web browser and try again.
- Use another smartphone and try again.
• If you use a wired device, such as a computer, to configure the ONT:
- Ensure that your computer is connected to the ONT properly (the LED indicator of the connected LAN
port lights up).
- Ensure that your computer is set to and Obtain an IP address automatically Obtain DNS server
address automatically.
- Use another computer and try again.
• Refer to to reset the ONT and try again.Q3
Q1: I cannot log in to the web UI by visiting 192.168.1.1. What should I do?
A1: Try the following solutions:
• Check the LED indicator status of ONT:
- If the LED indicator is off, ensure that the ONT is powered on properly.PWR
- If the LED indicator blinks, ensure that the port is clean and connected properly, the LOS PON
fiber cord is not bent excessively and the input optical power is within the normal range (Rx Power
between -28 dBm to -8 dBm in GPON mode (or -27 dBm to -3 dBm in EPON mode) on the Status
> PON page).
- If the LED indicator blinks, the ONT is not registered. Contact your ISP or verify the parameters PON
for registration are correct.
• Ensure that your ISP supports self-purchased PON device for internet access.
• If you set the ONT to the router mode:
-Ensure that the ONT obtains a valid IP address and gateway on the Status > Device > WAN
Configuration page. If not, the WAN connection is not set up successfully. Verify the parameters are
correct.
-Ensure that the wired device is connected to a LAN port of the ONT or downstream router (if any)
properly and set to Obtain an IP address automatically Obtain DNS server address and
automatically.
- Ensure that the wireless device is connected to the Wi-Fi network of the ONT or downstream router
(if any).
• If you set the ONT to bridge mode, ensure that the router or terminal used for dial-up is connected
and configured properly.
If the problem persists, consult your ISP.
Q2: I cannot access the internet after the configuration. What should I do?
A2: Try the following solutions:
Get support and services
For technical specifications, user guides and more information, please visit the product page or service
page on www.tendacn.com. Multiple languages are available.
You can see the product name and model on the product label.
https://www.tendacn.com/service/default.html
Safety Precautions
Before operating, read the operation instructions and precautions to be taken, and follow them to
prevent accidents. The warning and danger items in other documents do not cover all the safety
precautions that must be followed. They are only supplementary information, and the installation and
maintenance personnel need to understand the basic safety precautions to be taken.
- The device is for indoor usage only.
-For wall mounting, the device is only suitable for mounting at heights ≤ 2m.
- For desktop mounting, the device must be horizontally mounted for safe use.
- Do not use the device in a place where wireless devices are not allowed.
- Please use the included power adapter.
- If the device does not have the power button, the mains plug is used as the disconnect device and
shall remain readily operable. The power socket shall be installed near the device and easily
accessible.
- Operating environment: Temperature: 0℃ ℃ to 45 ; Humidity: (10% - 90%) RH, non-condensing;
Storage environment: Temperature: -40 ; Humidity: (5% - 90%) RH, non-condensing.℃ to +70℃
- Keep the device away from water, fire, high electric field, high magnetic field, and inflammable and
explosive items.
- Unplug this device and disconnect all cables during lightning storms or when the device is unused
for long periods.
- Do not use the power adapter if its plug or cord is damaged.
- If such phenomena as smoke, abnormal sound or smell appear when you use the device,
immediately stop using it and disconnect its power supply, unplug all connected cables, and contact
the after-sales service personnel.
- Disassembling or modifying the device or its accessories without authorization voids the warranty,
and might cause safety hazards.
For the latest safety precautions, see Safety and Regulatory Information on www.tendacn.com.
This is a Class B product. In a domestic environment, this product may cause radio interference, in
which case the user may be required to take adequate measures.
This equipment should be installed and operated with minimum distance 20cm between the device
and your body.
NOTE: (1) The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. (2) To avoid unnecessary radiation interference, it is
recommended to use a shielded RJ45 cable.
CE Mark Warning
Hereby, SHENZHEN TENDA TECHNOLOGY CO., LTD. declares that the device is in compliance with
Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
https://www.tendacn.com/download/list-9.html
This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE).
This means that this product must be handled pursuant to European directive 2012/19/EU in order to be
recycled or dismantled to minimize its impact on the environment.
User has the choice to give his product to a competent recycling organization or to the retailer when he
buys a new electrical or electronic equipment.
Attention: In EU member states, EFTA countries, Northern Ireland and Great Britain, the operation in
the frequency range 5150MHz - 5250MHz is only permitted indoors.
Declaration of Conformity
Shenzhen Tenda Technology Co., Ltd.
Floor 6-8, Tower E3, No.1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052
Website: www.tendacn.com
E-mail: support@tenda.com.cn
Technical Support
Tenda is a registered trademark legally held by Shenzhen Tenda Technology Co., Ltd. Other brand and
product names mentioned herein are trademarks or registered trademarks of their respective holders.
Specifications are subject to change without notice.
V1.0 Keep for future reference.
© 2023 Shenzhen Tenda Technology Co., Ltd. All rights reserved.
Operating Frequency/
Max Output Power
2412MHz-2472MHz/20dBm
5150MHz-5250MHz (indoor use only)/23dBm
Tips
• If you cannot access the internet after the configuration, refer to in . Q2 FAQ
• If you want to change the Wi-Fi name and Wi-Fi password, refer to in . Q4 FAQ
RECYCLING
• To restore the ONT to the configurations preset by the ISP: After the ONT completes startup, press
the button for 10 to 60 seconds and release it. All LED indicators will light off in a few WPS/RST
seconds. When the LED indicator lights solid on again, the ONT is restored to the PWR
configurations preset by the ISP.
• To restore the ONT to factory settings: After the ONT completes startup, press the WPS/RST
button for more than 1 minute and release it. All LED indicators will light off in a few seconds. When
the PWR LED indicator lights solid on again, the ONT is restored to the factory settings.
Method 2: Log in to the web UI of the ONT, navigate to Admin > Backup/Restore Reset and click
on the page. You can restore the ONT to the configurations preset by the ISP.
Q3: How to reset the ONT?
A3: Method 1:
Method 2: Log in to the web UI of the ONT, choose and repeat the following steps in WLAN wlan0
(5GHz) wlan1 (2.4GHz) and .
• Wi-Fi name: Choose and change the (Wi-Fi name). Click Basic Settings SSID Apply Changes,
and click when is shown.OK Change setting successfully
• Wi-Fi password: Choose , set Security Encryption to WPA/WPA2-PSK (recommended) and
change the Pre-Shared Key (Wi-Fi password). Click , and click when Apply Changes OK Change
setting successfully is shown.
Method 1: Log in to the web UI of the ONT, change the (Wi-Fi name) and the SSID Pre-Shared Key
(Wi-Fi password) in module with the quick registration function (initial WIFI Settings
registration of the ONT supported), and click Apply Changes.
Q4: How to change the Wi-Fi name and Wi-Fi password?
A4:
UK(NI)
UK
AT BE BG CH CZ DE DK EE EL ES FI FR HR HUCY
IS IT LI MT NL NO PL PT RO SE SI SKLT LU LV
IE
WAN
Tips
HG15 is used for illustration here unless otherwise specified. The actual product prevails.
(Exemplo: HG15)
Product specificaties
| Merk: | Tenda |
| Categorie: | Access point |
| Model: | HG10C |
Heb je hulp nodig?
Als je hulp nodig hebt met Tenda HG10C stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Access point Tenda
5 Maart 2024
5 Maart 2024
14 Mei 2023
1 Mei 2023
25 April 2023
18 Februari 2023
6 Februari 2023
23 November 2022
Handleiding Access point
- Access point Bosch
- Access point HP
- Access point Huawei
- Access point Asus
- Access point Honeywell
- Access point Airlive
- Access point Allied Telesis
- Access point Allnet
- Access point AVM
- Access point Buffalo
- Access point D-Link
- Access point Dell
- Access point Devolo
- Access point Digitus
- Access point Draytek
- Access point Edimax
- Access point Eminent
- Access point Engenius
- Access point EQ-3
- Access point Grandstream
- Access point Hercules
- Access point INCA
- Access point Interlogix
- Access point Lancom
- Access point LevelOne
- Access point Linksys
- Access point Media-tech
- Access point Mikrotik
- Access point Mojo
- Access point Netgear
- Access point Netis
- Access point Renkforce
- Access point Sitecom
- Access point SMC
- Access point TP Link
- Access point Trendnet
- Access point Zebra
- Access point ZyXEL
- Access point Macally
- Access point Steren
- Access point Ubiquiti Networks
- Access point Techly
- Access point Cisco
- Access point 3Com
- Access point Amped Wireless
- Access point Comtrend
- Access point CradlePoint
- Access point Juniper
- Access point Planet
- Access point Intellinet
- Access point Silex
- Access point Lindy
- Access point Black Box
- Access point Fortinet
- Access point DataVideo
- Access point Totolink
- Access point Dahua Technology
- Access point Mercusys
- Access point Aruba
- Access point EQ3
- Access point Homematic IP
- Access point Hawking Technologies
- Access point AMX
- Access point Moog
- Access point Crestron
- Access point StarTech.com
- Access point WatchGuard
- Access point LigoWave
- Access point Advantech
- Access point Moxa
- Access point Kingston
- Access point Vimar
- Access point Aerohive
- Access point Bountiful
- Access point V7
- Access point NUVO
- Access point Cudy
- Access point IP-COM
- Access point Syscom
- Access point Meru
- Access point Cambium Networks
- Access point Ruckus Wireless
- Access point Bintec-elmeg
- Access point Mach Power
- Access point ICC
- Access point Insteon
- Access point Brocade
- Access point Premiertek
- Access point Extreme Networks
- Access point Atlantis Land
- Access point FlyingVoice
- Access point Luxul
Nieuwste handleidingen voor Access point
11 December 2024
8 December 2024
8 December 2024
3 December 2024
1 December 2024
1 December 2024
1 December 2024
1 December 2024
1 December 2024
1 December 2024
