SPEKTRUM STX2 USER GUIDE

NOTICE

All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby,

LLC. For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product.

Meaning of Special Language

The following terms are used throughout the product literature to indicate various levels of potential harm when operating

this product:

NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no

possibility of injury.

CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility

of serious injury.

WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and

serious injury OR create a high probability of superficial injury.

WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating.

Failure to operate the product correctly can result in damage to the product, personal property and cause serious

injury.

This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic

mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage to the

product or other property. This product is not intended for use by children without direct adult supervision. Do not attempt

disassembly, use with Incompatible components or augment product in any way without the approval of Horizon Hobby, LLC.

This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions

and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious

injury.

WARNING AGAINST COUNTERFEIT PRODUCTS: Always purchase from a Horizon Hobby, LLC authorized dealer to

ensure authentic high-quality Spektrum product. Horizon Hobby, LLC disclaims all support and warranty with regards,

but not limited to, compatibility and performance of counterfeit products or products claiming compatibility with DSM or

Spektrum technology.

Age Recommendation: Not for Children under 14 years. This is not a toy.

NOTICE: This product is only intended for use with unmanned, hobby-grade, remote-controlled vehicles. Horizon Hobby

disclaims all liability outside of the intended purpose and will not provide warranty service related thereto.

WARRANTY REGISTRATION

Visit www.spektrumrc.com/registration today to register your product.

SAFETY PRECAUTIONS

• Alwaysensureallbatterieshavebeenproperlychargedpriortousingthemodel.

• Alwayscheckallservosandtheirconnectionspriortoeachrun.

• Neveroperateyourmodelnearspectators,parkingareas

or any other area that could result in injury to people or damage of property.

• Neveroperateyourmodelduringadverseweatherconditions.Poorvisibilitycancausedisorientationandlossofcontrolof

your model.

• Neverpointthetransmitterantennadirectlytowardthemodel.Theradiationpatternfromthetipoftheantenna

is inherently low.

• Ifatanytimeduringtheoperationofyourmodelyouobserveanyerraticorabnormaloperation,immediatelystop

operation of your model until the cause of the problem has been ascertained and corrected.

2SPEKTRUM STX2 USER GUIDE

A. Servo Reversing

To reverse the Throttle (TH) or Steering (ST) channel, switch

the position of the correlating switch—“N” is for normal,

“R” is for reverse.

B. Throttle Trim

Adjusts the throttle neutral point

C. Steering Trim

Adjusts the steering center point. Normally, the steering

trim is adjusted until the vehicle tracks straight.

D. THROTTLE RATE

Adjusts the end point of the throttle

E. STEERING RATE

Adjusts the end point of the steering

F. Indicator Lights

• Solid red lights: Indicates radio connectivity and

adequate battery power

• Flashing red lights: Indicates the battery voltage is

critically low. Replace batteries

G. Throttle Limit

Limits throttle output to 50/75/100%

Select 50% or 75% for less experienced drivers or when

you are driving the vehicle in a small area.

H. Antenna

I. Power Button

J. Throttle/Brake

K. Steering Wheel

TRANSMITTER FUNCTIONS

2.4GHZ DIGITAL

RADIO SYSTEM

INSTALLING THE TRANSMITTER BATTERIES

CAUTION: If using rechargeable batteries, charge only rechargeable batteries. Charging non-rechargeable batteries

may cause the batteries to burst, resulting in injury to persons and/or damage to property.

This transmitter requires 4 AA batteries.

1. Remove the battery cover from the transmitter.

2. Install the batteries as shown.

3. Install the battery cover.

CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to

national regulations.

SPEKTRUM STX2 USER GUIDE

BINDING

Binding is the process of programming the receiver to recognize the GUID (Globally Unique Identiﬁer) code of a single

speciﬁc transmitter. The STX2™ transmitter and SPMSRX200 receiver are bound at the factory. If you need to rebind, follow

the instructions below.

SRX200 RECEIvER

Speciﬁcations

Type: FHSS 2.4GHz protocol

Dimensions (LxWxH): 35.8 x 23.6 x 14.3 mm)

Antenna Length: 8.27 in

Channels: 2

Weight: 8.8g

Band: 2.4GHz

Voltage Range: 3.5–9.6V

1. Insert the Bind Plug in the BIND port on the receiver.

2. Connect a fully charged battery pack to the ESC.

3. Power on the ESC. The red LED flashes, indicating the receiver is

in bind mode.

4. Center the ST TRIM and TH TRIM dials on the transmitter.

5. Turn the steering wheel to Full Right. Power the transmitter on

while holding the steering wheel to the Right.

6. Release the steering wheel when the receiver LED stops flashing.

7. Remove the Bind Plug, then power off the receiver to save the

settings.

8. Power off the transmitter.

9. Remove the bind plug and store it in a convenient place.

You must rebind when:

• Different failsafe positions are desired e.g., when throttle or

steering reversing has been changed.

• Binding the receiver to a different transmitter.

Your new Horizon Hobby SRX200 Receiver has a special water-resistant coating on the electronics to ensure reliable per-

formance in higher than average moisture conditions. This conformal coating can offer mild protection from light drops of water.

• DO NOT submerge this product under water for any period of time. If it is submerged, it may result in damage or loss of

function.

• DO NOT pour water onto or allow excess water to come in direct contact with the product.

• DO NOT operate this product in heavy rain or snow.

• DO NOT expose this product to salt water (ocean water or water on salt-covered roads), contaminated or polluted water.

In case of excess exposure to water or debris, immediately wipe down the SRX200 with a soft cloth, and allow it to fully dry

before next use.

NOTICE: Never use a pressure washer to clean your vehicle.

NOTICE: Make sure the other components in your vehicle are waterproof or water-resistant before driving in wet conditions.

Water-Resistant Component

Product specificaties

Merk:	Spektrum
Categorie:	Radiografisch bestuurbaar speelgoed
Model:	STX2
Kleur van het product:	Zwart
Ingebouwd display:	Nee
Frequentieband:	2.4 GHz
Ondersteund aantal accu's/batterijen:	4
Correct gebruik:	Car, Land vehicle
Modulatie:	FHSS
Merkcompatibiliteit:	Alle merken
Aantal kanalen:	2 kanalen
Type product:	Afstandsbediening
Type batterij:	AA
Werking gasklep:	Ja
Snelheidsfunctie-instellingen:	Steering (ST), Throttle (TH)
