HD Optical

Multiplex Unit

BRU-SF10

4-195-081-12 (1)

Operating Instructions _____ GB

Mode d’emploi____________ FR

Manual de instrucciones ___ ES

GB 2

Owner’s Record

The model and serial numbers are located on the top.

Record the serial number in the space provided below.

Refer to these numbers whenever you call upon your

Sony dealer regarding this product.

Model No. BRU-SF10

Serial No.

To reduce the risk of fire or electric

shock, do not expose this apparatus to

rain or moisture.

To avoid electrical shock, do not open the

cabinet. Refer servicing to qualified

personnel only.

WARNING

When installing the unit, incorporate a readily

accessible disconnect device in the fixed wiring, or

connect the power plug to an easily accessible socket-

outlet near the unit. If a fault should occur during

operation of the unit, operate the disconnect device to

switch the power supply off, or disconnect the power

plug.

CAUTION

Use of controls or adjustments or performance of

procedures other than those specified herein may result

in hazardous radiation exposure.

This BRU-SF10 is classified as a CLASS 1 LASER

PRODUCT.

Laser Diode Properties

Wavelength : 1310 nm

Emission duration : Continuous

Laser output power : 300 μW (Typical)

Standard : IEC60825-1 (2001)

CAUTION

The use of optical instruments with this product will

increase eye hazard.

For the customers in the U.S.A.

This equipment has been tested and found to comply

with the limits for a Class A digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful

interference when the equipment is operated in a

commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction

manual, may cause harmful interference to radio

communications. Operation of this equipment in a

residential area is likely to cause harmful interference in

which case the user will be required to correct the

interference at his own expense.

You are cautioned that any changes or modifications not

expressly approved in this manual could void your

authority to operate this equipment.

All interface cables used to connect peripherals must be

shielded in order to comply with the limits for a digital

device pursuant to Subpart B of Part 15 of FCC Rules.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1)

this device may not cause harmful interference, and (2)

this device must accept any interference received,

including interference that may cause undesired

operation.

For the customers in Canada

This Class A digital apparatus complies with Canadian

ICES-003.

For the customers in Europe, Australia and

New Zealand

WARNING

This is a Class A product. In a domestic environment,

this product may cause radio interference in which case

the user may be required to take adequate measures.

In the case that interference should occur, consult your

nearest authorized Sony service facility.

For the customers in Europe

The manufacturer of this product is Sony Corporation,

1-7-1 Konan, Minato-ku, Tokyo, Japan.

The Authorized Representative for EMC and product

safety is Sony Deutschland GmbH, Hedelfinger Strasse

61, 70327 Stuttgart, Germany. For any service or

guarantee matters please refer to the addresses given in

separate service or guarantee documents.

This apparatus shall not be used in the residential area.

WARNING

Table of Contents 3 GB

Table of Contents

Features .................................................................. 4

Connecting Cables .............................................. 4

Example of System Configuration ..................... 4

Location and Function of Parts ............................ 5

Attaching an Interface Card ................................ 8

Connecting the AC Adapter ................................. 8

Precautions ............................................................. 9

Specifications ........................................................ 10

Dimensions ....................................................... 11

Pin Assignments ............................................... 11

Using the VISCA RS-422 Connector Plug ...... 12

Product specificaties

Merk:	Sony
Categorie:	Niet gecategoriseerd
Model:	BRU-SF10
Gewicht:	2000 g
Breedte:	210 mm
Diepte:	240 mm
Hoogte:	86 mm
Ondersteunde video-modi:	720p, 1080p
Maximum resolutie:	- Pixels
Meegeleverde kabels:	AC, RS-232
Kleur behuizing:	Zwart
DC voltage input:	12 V
BNC output ports:	1
Aansluiting video:	BNC
