Pagina 1/12
1 800 284- - -2131
www.smartavi.com
USER MANUAL
4x2 Multiviewer KVM switch
QKVMPro 4x2 Mulviewer KVM switch
QKVMPro
4x2 Multiviewer KVM switch 2
TECHNICAL SPECIFICATIONS_____________________________________________________________ 3
WHAT S IN THE BOX?_____________________________________________________________________’ 4
QKVMPRO FRONT AND REAR_____________________________________________________________ 4
INSTALLATION____________________________________________________________________________ 5 6-
SYSTEM OPERATION______________________________________________________________________ 6
FRONT PANEL CONTROL_________________________________________________________________ 7
HOTKEY AND RS 232 SERIAL CONTROL___________________________________________________- 8
OSD MENU_______________________________________________________________________________ 9
TROUBLESHOOTING______________________________________________________________________ 10
TECHNICAL SUPPORT_____________________________________________________________________ 10
LIMITED WARRANTY STATEMENT________________________________________________________ 11
Table of content
4x2 Multiviewer KVM switch 3
VIDEO
Format -DVI I Dual Link
Host Interface (4) DVI D 29- -pin (female)
User Console Interface (2) DVI -D 29 pin (female) -
Max Resoluon 2560 x 1600 @ 60Hz
DDC 5 volts p - p (TTL)
Input Equalizaon Automac
Input Cable Length Up to 20 î™›.
Output Cable Length Up to 20 î™›.
USB
Signal Type USB 2.0, 1.1, and 1.0 w/ internal hub
Input Interface (4) USB Type B
Output Interface (2) USB 1.1 Type A for KVM Devices
(2) USB 2.0 Type A Transparent
AUDIO
Input (4) Connector Stereo 3.5mm Female
Output (1) Connector Stereo 3.5mm Female
POWER
Power Requirements 12V DC, 3A power adapter with center -pin posive polarity
ENVIRONMENT
Operang Temp 32° to 104° F (0° to 40° C)
Storage Temp 4° to 140° F ( 20° to 60° C) - -
Humidity -0 80% RH, non condensing -
CONTROL
Front Panel Push Buîš‚ons with LED indicators
RS-232 Via Serial @ 115200 bps
Hot Keys Via Keyboard
CONTROL
Emulaon Keyboard, Mouse and Video
Technical Specifications
