Pagina 1/12

SM-DPN SERIES

Advanced 2-Port DISPLAYPORT KVM Switch

USER MANUAL

Designed and Manufactured in the USA

1-800-284-2131

www.smartavi.com

SM-DPN-2S 2-Port Single-Head DisplayPort KVM Switch

SM-DPN-2D 2-Port Dual-Head DisplayPort KVM Switch

2-Port DisplayPort KVM Switch with Audio and USB 2.0 Support 2

OVERVIEW

TECHNICAL SPECIFICATIONS_________________________________________________________________

WHAT’S IN THE BOX?_________________________________________________________________________

FRONT AND BACK___________________________________________________________________________

INSTALLATION_______________________________________________________________________________

SYSTEM OPERATION_________________________________________________________________________

FRONT PANEL CONTROL_____________________________________________________________________

HOTKEY AND RS232 SERIAL CONTROL_______________________________________________________

CUSTOM HOTKEY TRIGGERS_________________________________________________________________

LED’S BEHAVIOUR___________________________________________________________________________

TROUBLESHOOTING_________________________________________________________________________

TECHNICAL SUPPORT________________________________________________________________________

LIMITED WARRANTY STATEMENT____________________________________________________________

5-6

2-Port DisplayPort KVM Switch with Audio and USB 2.0 Support 3

Technical Specifications

VIDEO

Format DisplayPort1.2

Maximum Pixel Clock 165 MHz

Input Interface SM-DPN-2S (2) DisplayPort

SM-DPN-2D (4) DisplayPort

Output Interface SM-DPN-2S (1) DisplayPort

SM-DPN-2D (2) DisplayPort

Resoluon 3840 x 2160 @ 30 Hz

Color Mode 24-bit

DDC 5 volts p-p (TTL)

Input Equalizaon Automac

Input Cable Length Up to 20 

Output Cable Length Up to 20 

Data Rate 1.65 Gbps per color

Console Monitors Supports both digital and analog monitors

AUDIO

Input Interface (2) 3.5 mm Stereo Audio

Output Interface (1) 3.5 mm Stereo Audio

Impedance 600 Ohm

Frequency Response 20 Hz to 20 kHz

Nominal Level 0-1.0 V

Common Mode Rejecon at 60 dB

USB

Signal Type USB 2.0, 1.1, and 1.0 w/ internal hub

Input Interface (2) USB Type B (female)

Output Interface (2) USB Type A (female) for K/M emulaon; (2) for USB 2.0 Transparent

CONTROL

Front Panel Push Buons with LED Indicators

RS-232 DB9 Female - 115200 N,8,1, No ow control

Hot Keys Via Keyboard

OTHER

Power Adapter External 100-240 VAC/12VDC2A @ 24W

Dimensions 8.8” W x 2.63” H x 6.69” D

Weight 3.85 lbs

Approvals UL, CE, ROHS Compliant

Operang Temperature +32 to +104°F (0 to +40°C)

Storage Temperature -4 to 140°F (-20 to +60°C)

Humidity Up to 80% (No Condensaon)

Emulaon Keyboard and Mouse

Product specificaties

Merk:	Smart-AVI
Categorie:	Niet gecategoriseerd
Model:	SM-DPN-2S
Kleur van het product:	Zwart
Ingebouwd display:	Nee
Gewicht:	884.5 g
Breedte:	101.6 mm
Diepte:	165.1 mm
Hoogte:	76.2 mm
Stroombron:	AC
LED-indicatoren:	Ja
Stroom:	2 A
USB-connectortype:	USB Type-A, USB Type-B
Maximum resolutie:	3840 x 2160 Pixels
HD type:	4K Ultra HD
Aantal DisplayPorts:	3
Temperatuur bij opslag:	-20 - 60 °C
Rack-montage:	Nee
Seriële poort(en):	1
Aansluiting video:	DisplayPort
AC-ingangsfrequentie:	50-60 Hz
Stroomverbruik (typisch):	24 W
Bedrijfstemperatuur (T-T):	0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	0 - 80 procent
Aansluiting toetsenbord:	USB
Aansluiting muis:	USB
Aantal computers:	2
Videobandbreedte:	60 Hz
Data transfer snelheid (max):	1.65 Gbit/s
Audio-aansluitingen:	Ja
Seriële poort type:	RS-232
