Pagina 1/2
QKVMPro
Quick St
Quick St
Quick St
Quick StQuick Star
ar
ar
arart Guide
t Guide
t Guide
t Guidet Guide
A full Manual can be downloaded from
www.smartavi.com/QKVMPro/
4-Por
4-Por
4-Por
4-Por4-Port DV
t DV
t DV
t DVt DVI-D
I-D
I-D
I-DI-D Multivie
Multivie
Multivie
Multivie Multiview
w
w
wwer &
er &
er &
er & er &
KVM Switch with Dual Video
KVM Switch with Dual Video
KVM Switch with Dual Video
KVM Switch with Dual Video KVM Switch with Dual Video
Outputs
Outputs
Outputs
OutputsOutputs
TECHNICAL SPECIFICATIONS
VIDEO
Format DVI Dual Link
Host Interface (4) DVI-D 29-pin (female)
User Console
Interface (2) DVI-D 29-pin (female)
Max Resolution 2560 x 1600 @ 60Hz
DDC 5 volts p-p (TTL)
Input Equalization Automatic
Input Cable Length Up to 20 ft.
Output Cable Length Up to 20 ft.
USB
Signal Type USB 2.0, 1.1, and 1.0 w/ internal
hub
Input Interface (4) USB Type B
Output Interface
(2) USB 1.1 Type A for KVM Devices
(2) USB 2.0 Type A Transparent
AUDIO
Input (4) Connector Stereo 3.5mm Fe-
male
Output (1) Connector Stereo 3.5mm Fe-
male
POWER
Power Requirements 12V DC, 3A power adapter with
center-pin positive polarity
ENVIRONMENT
Operating Temp 32° to 104° F (0° to 40° C)
Storage Temp -4° to 140° F ( 20° to 60° C) -
Humidity 0-80% RH, non-condensing
CONTROL
Front Panel Push Buttons with LED indicators
RS- Via Serial @ 115200 bps 232
Hot Keys Via Keyboard
OTHER
OTHER
OTHER
OTHER OTHER
Emulation Keyboard, Mouse and Video
WHAT’S IN THE BOX
PART NO. QTY DESCRIPTION
QKVMPro 1 4-port, DVI-I Multiviewer KVM
Switch
PS12VDC3A 1
12V DC, 3A power adapter with
center-pin positive polarity.
1 Quick Start Guide
NOTICE
The information contained in this document is subject
to change without notice. SMART-AVI makes no war-
ranty of any kind with regard to this material, includ-
ing but not limited to, implied warranties of merchant-
ability and fitness for particular purpose. SMART-AVI
will not be liable for errors contained herein or for
incidental or consequential damages in connection
with the furnishing, performance or use of this materi-
al. No part of this document may be photocopied,
reproduced, or translated into another language with-
out prior written consent from SMART-AVI, Inc.
20170518
Toll Free: (800) AVI-2123
Phone: (702) 800 0005-
2455 W. Cheyenne Ave, Suite 112
North Las Vegas, NV 89032
smartavi.com
4-por
4-por
4-por
4-por4-port D
t D
t D
t Dt DVI-D Multivie
VI-D Multivie
VI-D Multivie
VI-D MultivieVI-D Multiviewer &
wer &
wer &
wer & wer &
KVM Switch with
KVM Switch with
KVM Switch with
KVM Switch withKVM Switch with A
A
A
A Audio, USB
udio, USB
udio, USB
udio, USB udio, USB
2.0, an
2.0, an
2.0, an
2.0, an2.0, and Pre
d Pre
d Pre
d Pred Preview Sc
view Sc
view Sc
view Scview Screen
reen
reen
reen reen
HARDWARE INSTALLATION
1. Ensure that power is turned off or disconnected from the unit and the computers.
2. Use DVI cables to connect the DVI output ports from each computer to the corresponding DVI-I IN ports of the
unit.
3. Use a USB cable (Type-A to Type-B) to connect a USB port on each computer to the respective USB ports of the
unit.
4. Optionally connect a stereo audio cable (3.5mm to 3.5mm) to connect the audio output of the computers to the
AUDIO IN ports of the unit.
5. Connect monitors to the DVI-I OUT console ports of the unit using DVI cables.
6. Connect a USB keyboard and mouse in the two USB console ports.
7. Optionally connect stereo speakers to the AUDIO OUT port of the unit.
8. Finally, power on the KVM by connecting a 12VDC power supply to the power connector, and then turn on all the
computers.
EDID LEARN
The QuadKVMPro has 3 preset EDIDs that can be
triggered from the front panel by pressing:
ï‚· A
A
A
AA 1
1
1
11 and simultaneously will invoke IPG - DVI
ï‚· A
A
A
AA and 2
2
2
22 simultaneously will invoke IPG - HDMI
ï‚· A
A
A
AA and 3
3
3
3 3 simultaneously will invoke IPG - HDMI+
SYSTEM CONTROL
There are four ways to control the QKVMPro: Key-
board HotKeys, RS-232 Serial Commands, OSD Menu
and Front Panel Buttons.
The settings for the serial connection are as follows:
Baud rate: 11520
11520
11520
11520115200
0
0
00; Data Bits: ; Parity: ; Stop
8
8
8
88 None
None
None
NoneNone
Bits: ; Flow Control: .
1
1
1
11 None
None
None
NoneNone
The following commands can be used:
Command HotKey RS-232
Switch KVM [CT][CT] [#]<CR>m //m[#]<CR>
Full Screen [CT][CT] [#]<CR>f //f[#]<CR>
PiP [CT][CT] [a][b]p
<CR>
//p[a][b]
<CR>
T Quad- [CT][CT] [#]<CR>t //t[#]<CR>
Quad [CT][CT] <CR>q //q<CR>
Audio Only [CT][CT] [#]<CR>a //a[#]<CR>
KM Only [CT][CT] [#]<CR>c //c[#]<CR>
USB Only [CT][CT] [#]<CR>u //u[#]<CR>
Learn EDID [CT][CT] <CR>e // <CR>e
SW Reset [CT][CT]r // <CR>r
Status Query N/A // <CR>??
Chart Key
[CT] = Ctrl
<CR> = Carriage Return (Enter Key)
Command HotKey
OSD ON/OFF [CT][CT] <CR>o
OSD UP ↥(UP arrow)
OSD DOWN ↧(DOWN arrow)
OSD LEFT ↤(LEFT arrow)
OSD RIGHT ↦(RIGHT arrow)
OSD Enter [ENTER]
OSD Esc [ESC]
OSD MENU
Important: When in OSD Menu, all keyboard
and mouse functionality will be blocked from
the computer and only used for the OSD com-
mands. After exiting the OSD menu, all key-
board and mouse functionality will be restored.
NOTE: When entering one of the Function com-
mands, the Enter Key must be pressed for the
function to take effect
