Pagina 1/8
ST1200-PT/ST1000-PT
STRIDER PLATINUM SERIES
The perfect balance of performance,
efciency, and quality
High efficiency with 80 PLUS Platinum certification
139mm Air Penetrator fan with intelligent semi-fanless operation
FF141 magnetized fan filter included
100% modular cables
24/7 continuous power output with 40℃ operating temperature
Strict ±3% voltage regulation and low ripple & noise
Dual EPS 8pin with multiple individual one-on-one PCI-E 8/6pin connectors
SPECIFICATION
SilverStone Strider Platinum
SST-ST1200-PT
SST-ST1000-PT
ATX12V / EPS 12V Switching Power Supply
With Active PFC
80Plus Platinum
PS/2
01
1.1 AC input requirements
Table 1 AC Input Line Requirements
Parameter
Vin( Full range )
Vin Frequency
Iin(1000W)
Min.
90
47
　
Max.
264
63
　
Nom.
100---240
60-----50
12-------6
Unit
VACrms
Hz
Arms
This specification describes the requirements of 1000W,1200Watts switching power supply with an stretch
ATX form-factor and EPS 12V, +5V standby voltage, remote on/off control, full range line input capability
and forced air cooling characteristics.
The input voltage, current, and frequency requirements for continuous operation are stated below.
1. AC INPUT
02
2.1 DC voltage regulation
2. DC OUTPUT
Power factor correction (PF)>0.90 at full load.
The power supply must meet inrush requirements for any rated AC voltage, during turn on at any phase of AC
voltage, during a single cycle AC dropout condition, during repetitive ON/OFF cycling of AC, and over the
specified temperature range (Top). The peak inrush current shall be less than the ratings of its critical
components (including input fuse, bulk rectifiers, and surge limiting device).
Note:1>Voltage tolerance is requied at main connector and S-ATA connector(if used)
2.2.1:(ST1000-PT Load Range)
1.Maximum continuous total DC output power should not exceed 1000W.
2.Maximum continuous combined load on +3.3V and +5V outputs shall not exceed 120W.
3.Maximum combined current for the +12V outputs shall be 83A(996W).
4.Peak DC output power should not exceed 1050W for 12 second.
2.2 Load ranges
Parameter
+3.3V
+5V
+12V
-12V
+5VSB
Range
+/-3ï¼…
+/-3ï¼…
+/-3ï¼…
+/-10ï¼…
+/-5ï¼…
Min
+3.20
+4.85
+11.64
-13.2
+4.75
Max
+3.39
+5.15
+12.36
-10.8
+5.25
Nom.
+3.30
+5.00
+12.00
-12.00
+5.00
Unit
Volts
Volts
Volts
Volts
Volts
Parameter
+3.3V
+5V
+12V
-12V
+5VSB
Min(optional)
0.1
0.2
0.15
0
0
Nom.
-
-
-
-
-
Peak
　
　
　
　
　
Max
25
22
83
0.3
2.5
Unit
Amps
Amps
Amps
Amps
Amps
Table 2 AC Input Line Requirements
Parameter
Vin( Full range )
Vin Frequency
Iin(1200W)
Min.
105
47
Max.
264
63
　
Nom.
115---240
60-----50
12.6---6 or 12---6
Unit
VACrms
Hz
Arms
