Lees hieronder de 📖 handleiding in het Nederlandse voor Shelly 1PM (4 pagina's) in de categorie Schakelaar. Deze handleiding was nuttig voor 44 personen en werd door 2 gebruikers gemiddeld met 4.5 sterren beoordeeld

Download PDF

Pagina 1/4

INITIAL INCLUSION

Before installing/mounting the Device ensure that the grid is

powered off (turned down breakers). Connect the Relay to

the power grid and install it in the console behind the switch/

power socket following the scheme that suites the desired

purpose:

1. Connecting to the power grid with power supply 110-240V

AC - g. 1

2. Connecting to the power grid with power supply 24-60V

DC - g. 2

For more information about the Bridge, please visit:

http://shelly-api-docs.shelly.cloud/#shelly-family-overview

or contact us at: developers@shelly.cloud

You may choose if you want to use Shelly with the Shelly

Cloud mobile application and Shelly Cloud service. You can

also familiarize yourself with the instructions for Manage-

ment and Control through the embedded Web interface.

CONTROL YOUR HOME WITH YOUR VOICE

All Shelly devices are compatible with Amazon Echo and

Google Home. Please see our step-by-step guide on:

https://shelly.cloud/compatibility/alexa

https://shelly.cloud/compatibility/assistant

SHELLY APPLICATION

Shelly Cloud gives you opportunity to control and adjust all

Shelly® Devices from anywhere in the world. You only need

an internet connection and our mobile application, installed

on your smartphone or tablet.

Registration

The rst time you load the Shelly Cloud mobile app, you have to

create an account which can manage all your Shelly® devices.

Forgotten Password

In case you forget or lose your password, just enter the e-mail

address you have used in your registration. You will then re-

ceive instructions to change your password.

⚠WARNING! Be careful when you type your e-mail address

during the registration, as it will be used in case you forget

your password.

First steps

After registering, create your rst room (or rooms), where you

are going to add and use your Shelly devices.

Shelly Cloud gives you opportunity to create scenes for auto-

matic turning on or off of the Devices at predened hours or

based on other parameters like temperature, humidity, light

etc. (with available sensor in Shelly Cloud).

Shelly Cloud allows easy control and monitoring using a mo-

bile phone, tablet or PC.

Device Inclusion

To add a new Shelly device, install it to the power grid fol-

lowing the Installation Instructions included with the Device.

Step 1

After the installation of Shelly following the Instalation In-

structions and the power is turned on, Shelly will create its

own WiFi Access Point (AP).

⚠WARNING! In case the Device has not created its’ own AP

WiFi network with SSID like shelly1pm-35FA58, please check if

the Device is connected accordingly to the Instalation Instruc-

tions. If you still do not see an active WiFi network with SSID

like shelly1pm-35FA58, or you want to add the Device to anoth-

er Wi-Fi network, reset the Device. If the Device has been pow-

ered on, you have to restart by powering it off and on again.

After turning the power on, you have one minute to press 5

consecutive times the button/switch connected SW. You have

to hear the Relay trigger itself. After the trigger sound, Shelly

should return to AP Mode. If not, please repeat or contact our

customer support at: support@Shelly.cloud

Step 2

Choose “Add Device”. In order to add more Devices later, use

the app menu at the top right corner of the main screen and

click “Add Device”. Type the name (SSID) and password for

the WiFi network, to which you want to add the Device.

Step 3

If using iOS: you will see the following screen:

Press the home button of your iPhone/iPad/iPod. Open

Settings > WiFi and connect to the WiFi network created by

Shelly, e.g. shelly1pm-35FA58. If using Android your phone/

tablet will automatically scan and include all new Shelly De-

vices in the WiFi network that you are connected to.

Upon successful Device Inclusion to the WiFi network you will

see the following pop-up:

Step 4

Approximately 30 seconds after discovery of any new Devic-

es оn the local WiFi network, а list will be displayed by default

in the “Discovered Devices” room.

Step 5

Enter Discovered Devices and choose the Device you want to

include in your account.

Step 6

Enter a name for the Device (in the Device Name eld).

Choose a Room, in which the Device has to be positioned.

You can choose an icon or add a picture to make it easier to

recognize. Press “Save Device”.

Step 7

To enable connection to the Shelly Cloud service for remote

control and monitoring of the Device, press “YES” on the fol-

lowing pop-up.

Shelly devices settings

After your Shelly device is included in the app, you can con-

trol it, change its settings and automate the way it works.

To switch the Device on and off, use the respective Power

button. To enter at the details menu of the respective Device,

simply click on it’s name. From the details menu you may con-

trol the Device, as well as edit its appearance and settings.

Timer - to manage the power supply automatically, you may

use:

• Auto OFF: After turning on, the power supply will automat-

ically shutdown after a predened time (in seconds). A value

of 0 will cancel the automatic shutdown.

• Auto ON: After turning off, the power supply will be auto-

matically turned on after a predened time (in seconds). A

value of 0 will cancel the automatic power-on.

Weekly schedule - this function requires an Internet connec-

tion. Shelly may turn on/off automatically at a predened

time.

Sunrise/Sunset - this function requires an Internet connec-

tion. Shelly receives actual information about the time of

sunrise and sunset in your area. Shelly may turn on or off

automatically at sunrise/sunset, or at a specied time before

or after sunrise/sunset.

Internet/Security

• WiFi Mode - Client - Allows the device to connect to an

available WiFi network. After typing the details in the respec-

tive elds, press Connect.

• WiFi Mode - Acess Point - Congure Shelly to create a

Wi-Fi Access point. After typing the details in the respective

elds, press Create Access Point.

• Cloud - Enable or Disable connection to the Cloud service.

• Restrict Login - Restrict the web interface of Shely with a

Username and Password. After typing the details in the re-

spective elds, press Restrict Shelly.

Safety - Max Power Protection, congure Shelly to turn off when

a dened power consumption is reached. The range is 1-3500W.

After typing the desired power consumption, press Save.

Settings

• Power On Default Mode - This sets the default output state

when Shelly is powered. ON: Congure Shelly to turn ON,

when it has power. OFF: Congure Shelly to turn OFF, when

it has power.

• Restore Last Mode - Congure Shelly to return to last state

it was in, when it has power.

• Firmware Update - Update the rmware of Shelly, when a

new version is released.

• Time Zone and Geo-location - Enable or Disable the auto-

matic detection of Time Zone and Geo-location.

• Factory Reset - Return Shelly to its factory default settings.

• Device Information - Here you can see the device ID(Unique

ID of Shelly), Device IP(the IP of Shelly in your Wi-Fi network)

• Edit Device - from here you can edit the device name, de-

vice room, device picture.

THE EMBEDDED WEB INTERFACE

Shelly can be set and controlled through a browser.

Abbreviations used

Shelly ID - the unique name of the Device. It consists of 6

or more characters. It may include numbers and letters, for

example 35FA58.

SSID - the name of the WiFi network, created by the Device,

for example shelly1pm-35FA58.

Access Point (AP) - the mode in which the Device creates its

own WiFi connection point with the respective name (SSID).

Client Mode (CM) - the mode in which the Device is connect-

ed to another WiFi network.

Initial inclusion

Step 1

Install Shelly to the power grid following the schemes de-

scribed above and place it into the console. After turning the

power on Shelly will create its own WiFi network (AP).

⚠WARNING! If you don’t see the WiFi please follow the step

1 from the device inclusion section of the guide.

Step 2

When Shelly has created an own WiFi network (own AP), with

name (SSID) such as shelly1pm-35FA58. Connect to it with

your phone, tablet or PC.

Step 3

Type 192.168.33.1 into the address eld of your browser to

load the web interface of Shelly.

General - Home Page

This is the home page of the embedded web interface. If it

has been set up is correctly, you will see information about

Settings menu button, Current state and Present time.

Settings - general settings. In this menu, you can congure

the Shelly device’s work and connection modes.

WiFi settings - the WiFi connection settings.

Access Point (AP) mode - allows the Device to operate as a

WiFi access point. The User can change the name (SSID) and

the password to access the AP. After you have entered the

desired settings, press Connect.

WiFi client mode (CM) - allows the Device to connect to an

available WiFi network. In order to switch to this mode, the

User must enter the name (SSID) and the password to con-

nect to a local WiFi network. After entering the correct details,

press Connect.

⚠ATTENTION! If you have entered incorrect information

(wrong settings, usernames, passwords etc.), you will not be

able to connect to Shelly and you have to reset the Device.

Leave unprotected - removing the notication for disabled

authorization.

Enable authentication – you can turn authentication on or

off. This is where you can change your username and pass-

word. You must enter a new username and the new pass-

word, then press Save to save the changes.

Connect to cloud - you can turn the connection between

Shelly and Shelly Cloud on or off.

Firmware upgrade - Shows present rmware version. If a

newer version is available, you can update your Shelly Device.

Device reboot - Reboots the device.

MANAGING IN RELAY MODE

Relay Screen

In this screen you can control, monitor and change the set-

tings for turning the power on and off. You can also see the

current status of the connected appliance to Shelly, Buttons

Settings, On and OFF. To control Shelly press Relay:

• To turn on the connected circuit press Turn ON

• To turn off the connected circuit press Turn OFF

Press the icon to go to the previous menu.

Shelly management settings

The same as in inclusion section of the guide.

Product specificaties

Merk:	Shelly
Categorie:	Schakelaar
Model:	1PM
Kleur van het product:	Rood
Wi-Fi-standaarden:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Duurzaamheidscertificaten:	CE, RoHS
Wifi-frequentie:	2.4 GHz
Naleving van duurzaamheid:	Ja
Op afstand bedienbaar:	Ja
Aantal kanalen:	1 kanalen
DC voltage bereik:	24 – 60 V
Afmetingen (B x D x H):	41 x 36 x 17 mm
Overbelastingsprotectie:	Ja
Maximum indoorbereik:	30 m
Zendvermogen:	1 mW
Wifi:	Ja
AC-ingangsspanning:	110 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Stroomverbruik (typisch):	1 W
Bedrijfstemperatuur (T-T):	0 - 40 °C
Stroom (max.):	16 A
Zonsopkomst/zonsondergang tijd:	Ja
Weekschema:	Ja
Intelligent aan/uit:	Ja
