Pagina 1/2

GARDEN

ROLLER

570 x 320mm

ORIGINAL INSTRUCTIONS

SPECIFICATIONS

Roller Width: 570mm

Roller Diameter: 320mm

Roller Volume: 46 litres

Max Weight Water Filled: 57kg

Weight: 10.5kg

PSR-5732U

WHAT’S IN THE BOX

SPARE PARTS

ozito-diy.co.uk

1117

MAINTENANCE

General Maintenance

• Keep all nuts, bolts and screws tight.

• Replace worn or damaged parts for safety.

¥ Be careful during adjustments of the garden roller to prevent

entrapment of the ngers between moving roller and xed parts.

Assembly Fasteners

Dirt Wiper

Upper & Lower Handles

OZITO UK Unit 9 Stadium Court, Wirral International Business Park, Plantation Road, Bromborough, Wirral, CH62 3QG

All of our products undergo strict quality checks to ensure that they reach

you in perfect condition. In the unlikely event that your device develops a

fault, please contact our service department at the address shown on this

guarantee card. You can also contact us by telephone using the customer

service number shown. Please note the following terms under which

guarantee claims can be made:

1. These warranty terms regulate additional warranty services, which the

manufacturer mentioned below promises to buyers of its new products

in addition to their statutory guarantee claims are not affected by this

guarantee. Our guarantee is free of charge to you.

2. The warranty services only covers defects due to material or

manufacturing faults on a product which you have bought from the

manufacturer mentioned below are limited to either the rectication of said

defects on the product or the replacement of the product, whichever we

prefer.

Please note that our devices are not designed for use in commercial, trade

or professional applications. A guarantee contract will not be created if the

device has been used by commercial, trade or industrial business or has

been exposed to similar stresses during the guarantee period.

3. The following are not covered by our guarantee:

- Damage to the device caused by a failure to follow the assembly

instructions or due to incorrect installation, a failure to follow the operating

instructions (for example connecting it to an incorrect mains voltage or

current type) or a failure to follow the maintenance and safety instructions

or by exposing the device to abnormal environmental conditions or by lack

of care and maintenance.

- Damage to the device caused by abuse or incorrect use (for example

overloading the device or the use or unapproved tools or accessories),

ingress of foreign bodies into the device (such as sand, stones or dust,

transport damage), the use of force or damage caused by external forces

(for example by dropping it).

- Damage to the device or parts of the device caused by normal or natural

wear or tear or by normal use of the device.

4. Your Product is guaranteed for a period of 36 months from the original

date of purchase and is intended for DIY (Do It Yourself) use only. Warranty

excludes consumable parts. Guarantee claims should be submitted

before the end of the guarantee period within two weeks of the defect

being noticed. No guarantee claims will be accepted after the end of the

guarantee period. The original guarantee period remains applicable to the

device even if repairs are carried out or parts are replaced. In such cases,

the work performed or parts tted will not result in an extension of the

guarantee period, and no new guarantee will become active for the work

performed or parts tted. This also applies if an on-site service is used.

IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST

RETURN THE PRODUCT TO THE PLACE OF PURCHASE WITH YOUR

Please refer to the restrictions of this warranty concerning wearing parts,

consumables and missing parts as set out in the service information in

these operating instructions.

CUSTOMER SERVICE HELPLINE

GB: 0151 294 4488

IRL: 1850 882711

Ozito-diy.co.uk

WARRANTY

Spare parts can be ordered from the Special Orders Desk at your local

Bunnings Warehouse or Homebase store.

For further information, or any parts visit

www.ozito-diy.co.uk or contact Ozito Customer Service:

Great Britain: 0151 294 4488

Ireland: 1850 882711

E-mail: info@ozito-diy.co.uk

Roller

Roller Plug

ONLINE MANUAL

Scan this QR Code with your

mobile device to take you to

the online manual.

1 2

Changing the Weight

Changing the weight is easy,

and requires no tools. Simply

ll or empty the roller of water

or dry sand until the roller is at

the desired weight.

Overlapping Rows

When rolling a lawn, slightly overlap the row that has already been rolled.

Overlapping rows will also ensure a neat roll by attening grass or dirt that

may have been missed on the previous row.

Tips

¥ While using the garden roller always wear substantial footwear and

long trousers.

¥. Make sure the lawn is clear of sticks, stones, wire and debris; that

could be attened by the garden roller.

¥ Walk at a good, steady pace.

¥ Pull the roller over the ground you wish to roll in even strips.

¥ Adjust the dirt wiper so that as little soil as possible remains on the

roller.

¥ Only roll dry ground.

GARDEN ROLLER

KNOW YOUR PRODUCT

PSR-5732U

2. ASSEMBLY 4. HOW TO ROLL

3. ADJUSTMENTS

SETUP & PREPARATION OPERATION

1. BEFORE USE

Items Supplied

Please check that the article is complete as specied in the scope of

delivery. If parts are missing, please contact our service centre or the

sales outlet where you made your purchase at the latest within 5 working

days after purchasing the product and upon presentation of a valid bill of

purchase. Also, refer to the warranty table in the service information at

the end of the operating instructions.

• Open the packaging and take out the equipment with care.

• Remove the packaging material and any packaging and/or

transportation braces (if available).

• Check to see if all items are supplied.

• Inspect the equipment and accessories for transport damage.

• If possible, please keep the packaging until the end of the guarantee

period.

Danger!

The equipment and packaging material are not toys. Do not let

children play with plastic bags, foils or small parts. There is a

danger of swallowing or suffocating!

Proper Use

Lawn and garden roller for rolling surfaces and freshly sown seed (for

example grass seed but also seed in beds) to ensure that the seed is

perfectly inserted in the soil. The roller can also be used after the lawn

area has been scaried or fertilized.

The machine is to be used only for its prescribed purpose. Any other

use is deemed to be a case of misuse. The user / operator and not the

manufacturer will be liable for any damage or injuries of any kind caused

as a result of this.

Please note that our equipment has not been designed for use in

commercial, trade or industrial applications. Our warranty will be voided

if the machine is used in commercial, trade or industrial businesses or for

equivalent purposes.

Adjusting the Dirt Wiper

Rotate the dirt wiper so the

front part of the wiper wipes

away so that as little soil as

possible remains on the roller.

1. Upper Handle

2. Lower Handle

3. Dirt Wiper

4. Roller Plug

5. Roller

You will need 8mm,.13mm and 14mm open-ended spanners and a

#2 Phillips screwdriver for the assembly (not supplied).

1. Fit the lower handle onto

the roller.

Once assembled, ll the

roller with water or dry sand

via the ll port.

NOTE: Capacity 46 litres.

4 5

6. M5 Screw x 2

7. Thread Cover x 2

8. M8 Dome Nut x 2

9. M8 Locking Nut x 2

10. M5 Locking Nut x 2

11. Washer x 2

6 7 8 9 410 11

Thread Cover

Fitting the Lower Handles

2. Fit the thread of the dirt wiper into the lower handle and secure in

place, rst with M8 locking nut and then M8 dome nut.

Fitting the Upper Handles

1. Place the upper handle over

the upper ends of the lower

handle.

2. Fit the M5 screws through the

upper handle and then through

the holes in the lower handle.

Secure in place with a washer

and M5 locking nut.
