O W N E R S M A N U A L

S u p e r L i n e

E N G L I S H D E U T S C H F R A N Ç A I S I T A L I A N 0

Introduction

Naim Audio products are conceived with performance as the top priority. Careful

installation will help ensure that their full potential is achieved. This manual covers

the SuperLine phono amplifier. It begins with some general installation notes. Product

specific information begins in Section 3.

1 Connections

It is important for both safety and performance that

any standard cables supplied with Naim Audio

products are not modified.

1.1 Interconnect Cab les

Interconnect plugs and sockets should be kept clean

and free from corrosion. The easiest way to clean them

is to switch off the equipment, pull the plugs out of their

sockets, and push them back in again. Contact cleaners

and “enhancers” should not be used as the film they

deposit may degrade the sound.

2 General Installation

Naim equipment is designed to offer the finest

performance possible avoiding compromise

wherever practical. This can lead to circumstances

that may be unfamiliar. The notes that follow contain

advice specifically related to Naim equipment as

well as more general warnings about the use of

domestic audio products. Please read them carefully.

2.1 Siting The Equipm ent

In order to reduce the risk of hum audible from the

loudspeakers, power supplies and power amplifiers

should be located a reasonable distance away from

other equipment. The maximum separation distance for

connected equipment is that allowed by the standard

interconnect lead.

2.2 Switching On

Source components and power supplies should be

switched on before power amplifiers. Always switch

amplifiers off and wait a minute before connecting or

disconnecting any leads. Always use the power switch on

the product rather than a mains outlet switch.

2.3 Running In

Naim equipment takes a considerable time to run in

before it performs at its best. The duration varies, but under

some conditions the sound may continue to improve for

over a month. Better and more consistent performance

will be achieved if the system is left switched on for long

periods. It is worth remembering however that equipment

left connected to the mains can be damaged by

lightning.

2.4 Radio Interference

In some circumstances, depending on where you live

and the earthing arrangements in your home, you may

experience radio frequency interference. Controls on

broadcasting in some territories allow very high levels of

radio frequency radiation and both the choice and exact

siting of equipment may be critical. Susceptibility to radio

frequency interference is related to the wide internal

bandwidth necessary for high sound quality. A radio

frequency filter kit is available for some Naim equipment

but sound quality will be progressively compromised as

more elements of the kit are fitted. In situations of extreme

radio interference Naim equipment may be unsuitable.

2.5 Lightning Prec a utions

Your Naim hi-fi system can be damaged by lightning and

should be turned off and disconnected from the mains

when there is risk of lightning strike.

2.6 Problem s?

Consumer protection varies from country to country. In

most territories a retailer must be prepared to take back

any equipment he has sold if it cannot be made to work

satisfactorily. A problem may be due to a fault in the

system or its installation so it is essential to make full use of

your dealer’s diagnostic skills. Please contact your local

distributor, or Naim Audio directly, if any difficulties cannot

be resolved.

Some Naim equipment is made in special versions for

different territories and this makes it impracticable to

arrange international guarantees. Please establish the

local guarantee arrangements with your retailer. Contact

Naim Audio directly for help and advice if necessary.

2.7 Service a nd Upda tes

It is essential that repairs and updates are only carried

out by an authorised Naim retailer or at the factory by

Naim itself. Many components are custom made, tested

or matched and appropriate replacements are often

unobtainable from other sources.

Direct contact to Naim for service or update information

should be made initially through Customer Services:

Tel: +44 (0)1722 426600

Email: info@naimaudio.com

Please quote the product serial number (found on its rear

panel) in all correspondence.

SuperLine Installation

3 SuperLine Insta llation

The SuperLine moving coil phono amplifier is designed to extract the best possible musical

performance from vinyl disc replay. It should be mounted horizontally on an equipment

stand intended for the purpose. It is important to ensure that it is level.

The SuperLine contains no internal power supply and must be connected either to a Naim

amplifier incorporating an appropriate power supply output, or to a dedicated Naim

power supply. SuperLine output is muted for 2 minutes following switch-on to allow its

circuitry to reach optimal status.

Cartridge loading resistance and capacitance can be adjusted by inserting combinations

of resistive and capacitive “load plugs” into sockets on the SuperLine rear panel.

The SuperLine incorporates a suspension system to isolate its sensitive components from

vibrational energy. The suspension system is protected during shipping by two transit

screws. The transit screws must be removed before use. Once the transit screws are

removed the SuperLine must not be inverted. Transit screw removal is best carried out

once the SuperLine is installed in its final location and all connections are made.

3.1 Transit S crews

Two transit screws must be removed from the underside of

the SuperLine before use and replaced if it is to be carried

any distance, packed or shipped. Transit screw removal is

illustrated in Diagram 3.2. SuperLine transit screws must not

be used with any other Naim product.

Damage may result if the SuperLine is inverted either

during or after transit screw removal.

To gain access to the transit screws, position one end

of the SuperLine over the edge of a table, remove (or

replace) the screw that becomes accessible and then

repeat with the other end.

3.2 Transit S crew Remova l

3.3 Connecting SuperLine

3.3.1 Power Supply

The SuperLine must be connected to a dedicated

Supercap, Hi-Cap or Flatcap power supply (option

one) or a Naim preamplifier or integrated amplifier that

incorporates an appropriate power supply output (option

two).

If option one is chosen, connect the SuperLine to the

dedicated power supply using, in the case of a Hi-Cap

or Flatcap, a Naim SNAIC interconnect cable, and in the

case of a Supercap, the appropriate Naim Burndy cable.

In either case take care to connect with the correct cable

orientation.

If option two is chosen, connect the SuperLine to the

preamplifier or integrated amplifier’s 5 pin DIN aux input/

power output socket using a Naim SNAIC interconnect

cable. Take care to connect with the correct cable

orientation.

Note: If the SuperLine’s Burndy power supply socket is

not used the supplied Burndy link plug must be inserted.

Similarly, if the SuperLine’s DIN power supply socket is not

used the supplied dust cover should be fitted.

3.3.2 Signal Input

Connect the output cable of the pick-up arm to either

the BNC or phono input sockets. Only one option, phono

or BNC, should be connected at any time. Take care to

ensure that the left and right channels are connected to

the appropriate sockets.

Connect the pick-up arm earth lead to the rear panel

ground terminal.

3.3.3 Signal Output

The SuperLine output signal is carried on the power supply

cable either directly to the preamplifier or via an optional

power supply.

front transit

screw

rear transit

screw

Product specificaties

Merk:	Naim
Categorie:	Receiver
Model:	Superline
Kleur van het product:	Zwart
Gewicht:	7700 g
Breedte:	207 mm
Diepte:	314 mm
Hoogte:	87 mm
Connectiviteitstechnologie:	Bedraad
Audio-uitgangskanalen:	- kanalen
Frequentiebereik:	10 - 200000 Hz
Signaal/ruis-verhouding:	82 dB
Totale harmonische vervorming (THD):	0.005 procent
Input sensitiviteit:	500 mV
Piekvermogen per kanaal:	- W
Speakers connectiviteit type:	RCA
