DataVac Pro Series 1 Manual
ALL MODELS ARE: Sturdy All Steel; Single Speed; .75 Peak HP Motor; 4.0 Amps; 500 Watts; 12’
Grounded Cord.
Different models and what they come with:
MDV-1BA (117-926931): ESD Safe: No; 20” Flexible Hose; Crevice Tool Air “Pin Pointer”, , Dust Brush,
Shoulder Strap, Five Extra Disposable Bags, plus 4 Pc. Micro Cleaning Tool Kit. &
MDV1BA18/3 (117-577287): ESD Safe: No; 20” Flexible Hose Air “Pin Pointer”, Crevice Tool, , Dust Brush,
Shoulder Strap, Five Extra Disposable Bags plus 4 Pc. Micro Cleaning Tool Kit. , &
MDV-1ESD (117-117513): ESD Safe: Yes; All accessories ESD Safe: Anti- - , static 3’ 6’ Stretch Hose
Crevice Tool, Dusting Brush, Grounded Wrist Strap, 4 pcs. Micro Tool Kit, Shoulder Strap, & Five Extra
Disposable Bags.
(Model shown.)
INSTRUCTIONS (Instructions are general for all AM-VM models. Some of the below information may
not pertain to your specific model. Check list above for parts and accessories that go with your particular
machine):
VACUUM:
Slide attachment or hose to the vacuum end cap. Push on/off button. on
BLOWER OR INFLATOR (ONLY ON VAC N BLO MODELS):
Remove vacuum end cap and bag. Insert optional germ trap filter (optional but highly recommended, sold
separately). Slide attachment or hose on exhaust end. Push on/off button
APPLYING SHOULDER STRAP:
Pull one end through the handle. Loop through other end.
ADDITIONAL PARTS FOR PURCHASE (the below items are available for purchase on our website
www.MetroVac.com; use the provided product # in the search):
• Permanent Cloth Bag MVC 9PCB – –
• Disposable Bags DVP 26RP – –
• Optional Germ Trap Filter P 101 – – –29
• Shoulder Strap MVC-204A –
• Micro Tool Kit MCT-4-BLUE (NON ESD) –
• Dust Brush MVC-206BBB (NON ESD) –
• Crevice Tool MVC- (NON ESD) –188
• 20” Flexible Hose –(NON ESD) MVC- 176A
• ESD–Safe Micro Tool Kit MVC 211E – –
• Hose: MVC 235 ESD Safe–3’ – 6’ Stretch Hose – –
• Techni Stat Grounding Wrist Strap MVC 236A –(ESD SAFE) – –
Changing the disposable bag:
1. Remove all attachments including hose.
2. Twist off top.
3. Pull out and replace paper bag.
4. To put the top back on, make sure the bag is properly seated, align grooves and twist to lock.
Use of optional filter:
1. Fits in behind bag on vacuum end.
WARRANTY:
This machine carries a Five Year Limited* Warranty.
The Five Year Warranty includes the unit and the motor.*
There is also a on Parts, Switches, and Cords. One Year Warranty*
This warranty covers any defects in materials or workmanship, including installation, with the exceptions
stated below:
• *MetroVac will repair or replace any defective or malfunctioning part* at no charge. If the machine
is not repairable, it will be replaced.
• *Mechanical alterations made to the machine will void the warranty.
• *Warranty does not cover carbon brushes, carbon brush wear, filters, or general maintenance.
• *The warranty does not cover physical damage made to the machine from tampering with or
attempting to take the appliance apart, improper electrical connections, or water damage.
*Customer is responsible for shipping charges to and from our facility.
***Even if the product is beyond the warranty period, we suggest you send the unit back to our
factory for expert repairs and maintenance at reasonable rates. Please click the following link to
access our Repairs and Maintenance form***
WARNING: To reduce the risk of fire, electric shock, or injury Do not leave appliance when plugged
in. Unplug from outlet when not in use and before servicing.
• Do not allow it to be used as a toy. Close attention is necessary when used by or near children.
• Use only as described in this manual. Use only manufacturer's recommended attachments.
• Do not use it with damaged cord or plug. If appliance is not working as it should, has been
dropped, damaged, left outdoors, or dropped into water, return it to a service center.
• Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp
edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any object into the openings. Do not use with any opening blocked; keep free of dust,
lint, hair, and anything that may reduce air flow.
• Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
• Do not pick up anything that is burning or smoking, such as cigarettes, matches or hot ashes.
• Do not use without dustbag and/or filters in place.
• Turn off controls before unplugging.
• Use extra care when cleaning on stairs.
• Do not use to pick up flammable or combustible liquids such as gasoline or use in areas where
they may be present.
• To avoid electric shock, do not use it on wet surfaces, do not expose to rain; store indoors.
• To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than
the other). This plug will fit into an outlet only one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do
not change the plug in any way.
• For a grounded appliance: "Connect to a properly grounded outlet only. See Grounding
Instructions."
MetroVac / Metropolitan Vacuum Cleaner Co.
5 Raritan Road, Oakland, NJ 07436
800-822-1602 / 201-405-2225
www.MetroVac.com
