I N S T A L L A T I O N G U I D E

for the

SB-T-TUNDB3/10TW3

SKU# 94592 - 94594

2007 - Up Toyota Tundra Double Cab

Thank you for choosing a JL Audio Stealthbox® for your automotive sound system.

With proper installation, your new vehicle-specific enclosed subwoofer system

will deliver years of listening pleasure.

We strongly recommend that you have your new Stealthbox® installed by your

authorized JL Audio dealer. The installation professionals employed by your

dealer have the necessary tools and experience to disassemble and reassemble

your vehicle properly. If you prefer to perform your own installation, please read

this installation guide completely before beginning the process.

If you choose to perform the installation yourself, it is absolutely vital

that the Stealthbox® be properly mounted to the vehicle according to

these instructions. Failure to mount the enclosure properly presents two

problems:

1) The sub-bass performance will suffer due to the movement of the

enclosure caused by the force exerted by the woofer(s).

2) A loose enclosure presents a serious safety hazard in the event of a

collision or sudden deceleration.

INSTALLATION

DIFFICULT Y:

EST IMATED T IME:

1/2 HOUR

Enclosure Type: Sealed

Driver Type: 10TW3-D8

Nominal Impedance: 2 ohms

Continuous Power Handling: 800 watts (RMS method)

Continued on Next Page

OUT

SB-T-TUNDB3/10TW3 INSTR_SKU# 011373

I N C L U D E D H A R D W A R E

Continued on Next Page

Page 2 • JL Audio, Inc., 2017

SB-T-TUNDB3/10TW3 INSTR_SKU# 011373

P O W E R R E C O M M E N D AT I O N

JL Audio recommends high quality ampliers such as the JL Audio HD750/1. The diagram below shows the recommended crossover settings for the HD750/1. For a detailed description of the

amplier settings, consult the owner’s manual for the amplier. If another amplier is being used, please reference this illustration and use similar settings on that amplier.

C O N N E C T I O N S

Using quality power, signal, and speaker wire is essential in ensuring the performance of your Stealthbox®. JL Audio recommends using a 4 AWG power kit such as the XD-PCS4-1B for your

Stealthbox® amplier. Other kits are available should you be using more than one amplier. Signal wire such as the JL Audio Premium Audio Interconnect Cables should be used to provide signal for
