Pagina 1/48

H0579200_REVD

WARNING

FOR YOUR SAFETY - This product must be installed and serviced by a contractor who is licensed and

qualified in pool equipment by the jurisdiction in which the product will be installed where such state

or local requirements exist. The maintainer must be a professional with sufficient experience in pool

equipment installation and maintenance so that all of the instructions in this manual can be followed

exactly. Improper installation and/or operation can create dangerous high pressure which can cause a

catastrophic product failure and/or cause the multiport valve to be blown off possibly causing death,

serious injury or property damage.

Before installing this product, read and follow all warning notices and instructions that accompany this

product. Failure to follow warning notices and instructions may result in death, serious injury or property

damage. Consult Zodiac customer service at 1-800-822-7933 for assistance. Improper installation and/or

operation will void the warranty.

ENGLISH | FRAN ES | ESPAÑOLÇ

INSTALLATION AND

OPERATION MANUAL

Top Mount Sand Filter

Models SFTM22-1.5, SFTM24-2.0

Page 2 ENGLISH Jandy

Pro Series Sand Filter SFTM22-1.5, SFTM24-2.0 | Installation & Operation Manual

Section 1. Important Safety Instructions 3 ............................................................

Section 2. Package Contents 4 ...............................................................................

2.1 SFTM22-1.5 .................................................................................................... 4

2.2 SFTM24-2.0 .................................................................................................... 4

2.3 Required Tools/Equipment .............................................................................. 5

Section 3. Equipment Location 5 ............................................................................

3.1 Equipment Pad 5 ................................................................................................

3.2 Filter Location 5 ..................................................................................................

Section 4. Initial Setup 6 ..........................................................................................

4.1 Install Base 6 ......................................................................................................

4.2 Install Hub and Laterals SFTM22-1.5 6 ..............................................................

4.3 Install Hub and Laterals SFTM24-2.0 6 ..............................................................

4.4 Fill With Sand 6 ..................................................................................................

4.5 Assemble Multiport Valve 7 ................................................................................

4.6 Install Multiport Valve 8 ......................................................................................

4.7 Plumbing ......................................................................................................... 8

Section 5. Operation 8 .............................................................................................

5.1 Filter Valve Functions 8 ......................................................................................

5.2 Initial Start up 9 ..................................................................................................

5.3 Operating pressure 9 ..........................................................................................

5.4 Changingtheltersand .................................................................................. 10

5.5 Winterizing .......................................................................................................10

Section 6. Dimensions and Replacement Parts 10 .................................................

6.1 Approximate Dimensions 10 ................................................................................

6.2 Replacement Parts .......................................................................................... 11

Table of Contents

Page 3

ENGLISH

Jandy

Pro Series Sand Filter SFTM22-1.5, SFTM24-2.0 | Installation & Operation Manual

SECTION 1. IMPORTANT SAFETY INSTRUCTIONS

READ AND FOLLOW ALL INSTRUCTIONS

WARNING

MAXIMUM OPERATING PRESSURE OF THE FILTER IS 35 PSI. NEVER SUBJECT THE

FILTER TO ANY OPERATING PRESSURE EXCEEDING 35 PSI

• Do not connect the system to an unregulated city water system or other

external source of pressurized water producing pressures greater than 35 PSI.

• Thislteroperatesunderhighpressure.Whenanypartofthecirculating

system,i.e.,lter,pump,valve(s),etc.isserviced,aircanenterthesystemand

become pressurized when the system is restarted.

• Pressurized air in a system can cause product failure or also cause the dial

valve to be blown off which can result in death, serious personal injury or property damage.

• Tominimizeriskofsevereinjuryordeath,thelterand/orpumpshouldnotbesubjectedtothepiping

pressurization test. Local codes may require the pool piping system to be subjected to a pressure

test.Theserequirementsaregenerallynotintendedtoapplytothepoolequipmentsuchasltersor

pumps. Jandy pool equipment is pressure tested at the factory.

If however, this WARNINGcannotbefollowedandpressuretestingofthepipingsystemmustincludethelterand/

or pump BE SURE TO COMPLY WITH THE FOLLOWING SAFETY INSTRUCTIONS.

• Check all clamps, bolts, lids, locking devices and system accessories to ensure they are properly

installed and secured before testing.

• RELEASE ALL AIR in the system before testing.

• Water pressure for test must NOT EXCEED 35 PSI

• WatertemperaturefortestmustNOTEXCEED100ºF(38ºC).

• Limit test to 24 hours. After test, visually check system to be sure it is ready for operation.

NOTICE: These parameters apply only to Jandy equipment. For non-Jandy equipment, consult the equipment

manufacturer.

To avoid electrical shock hazard, which can result in serious injury or death:

• Ensure that all electrical to the system is turned off before approaching, inspecting or troubleshooting

any leaking valves or plumbing that may have caused other electrical devices in the surrounding area

to get wet.

• Waterdischargedfromanimproperlypositionedlterorvalvecancreateanelectricalhazardwhich

can cause death, serious injury or property damage.

• Improperdialvalveinstallationcancauseproductfailureoralsocausethelterdialtobeblownoff,

which can result in death, serious personal injury or property damage.

• Never attempt to adjust or remove the dial valve when the pump is running or there is pressure in the

system.thiscancauseproductfailureoralsocausethelterdialtobeblownoff,whichcanresultin

death, serious personal injury or property damage.

CAUTION

• Maintain your pressure gauge in good working order. The pressure gauge is the primary indicator of

howthelterisoperating.

• Creating high vacuum levels can cause the tank vessel to crack and leak with the potential for

property damage.

• Be sure that all provisions for waste water disposal meet local, provincial or national codes. During

any backwash or draining process, 100 gallons or more of water will be discharged. Do not discharge

waterwhereitwillcauseﬂoodingordamage.

• Toavoiddamagingthelaterals(spokes),slowlyaddtheltermediauntilthelateralsarefullycovered.

ConsultInstallationandOperationManualforcompletesandllinginstructionsCrackedorbroken

laterals(spokes)willcausesandtobedischargedtothepool.

Attention installer: This manual contains important information about the installation, operation

and safe use of this product. This information should be given to the owner/operator of this

equipment. SAVE THESE INSTRUCTIONS
