Pagina 1/17

Premium LNBs

5445 Single Universal 40mm PLL LNB IDLP-SNL410-PREMU-OPN

5446 Twin Universal 40mm PLL LNB IDLP-TWL410-PREMU-OPN

5447 Quad Universal 40mm PLL LNB IDLP-QDL410-PREMU-OPN

5448 Quattro Universal 40mm PLL LNB IDLP-QTL410-PREMU-OPN

5482 8 Output Universal 40mm LNB IDLP-OCT410-PREMU-OPN

Please read the information contained in this manual before installing the LNB.

The operations described in the instructions must be carried out in the order presented.

The LNB is intended for use with a satellite dish antenna equipped with a 40mm LNB holder for mounting.

The LNB allows receiving satellite signals in the Ku band.

Warning! The LNB and the satellite dish antenna shall be installed by a qualiﬁed satellite antenna installer, and in

compliance with safety regulations.

▪Do not install the LNB during a storm or other extreme weather conditions.

▪Connect the coaxial cable to the LNB before connecting the set top box.

▪Carry out your satellite dish and LNB installation with tools and accessories intended for this purpose only.

Premium LNBs

1. Place the LNB in the LNB holder/clamp of the dish antenna. Close the

LNB holder handle and lightly tighten the clamp screw so that the

LNB can still rotate (Fig. 1).

2. Set the correct tilt angle of the LNB by rotating the LNB clockwise

or counterclockwise: The tilt angle of the LNB (K) depends on the

location of the satellite dish antenna installation and the satellite to

be received. For example, for receiving Hotbird at 13°E in Warsaw,

the tilt angle of the LNB should be 6° counterclockwise. Fine angle

adjustment turning should be done using a satellite signal meter or

a satellite receiver measurement indications (Fig. 2).

3. After determining the correct position of the LNB, tighten screws

that secure the LNB clamp so that the LNB is ﬁxed in its place (Fig. 3).

4. The above description of the LNB installation applies to the case

when the satellite dish is correctly installed and aligned towards the

desired satellite. In other cases, you must complete the installation

and correct alignment of your satellite dish ﬁrst.

5. We strongly recommend that the satellite dish antenna is installed by

a qualiﬁed satellite antenna installer.

Note: Product images are for illustrative purposes only and may differ from the actual

product.

Fig. 1

Fig. 2 Fig. 3

Product specificaties

Merk:	Inverto
Categorie:	Niet gecategoriseerd
Model:	Premium LNBs
Kleur van het product:	Black, White
Gewicht:	218 g
Gewicht verpakking:	278 g
Breedte verpakking:	155 mm
Diepte verpakking:	91 mm
Hoogte verpakking:	76 mm
Aantal:	1
Stroomverbruik:	120 mA
Bedrijfstemperatuur (T-T):	-35 - 60 °C
Output impedance:	75 Ohm
Geluid figuur:	0.2 dB
Input frequentiebereik:	10.7 - 12.75 GHz
Output frequentiebereik:	950 - 2150 MHz
Voltage Standing Wave Ratio (VSWR):	2.5 : 1
Lage band LO frequentie:	9.75 GHz
Hoge band LO frequentie:	10.6 GHz
Conversieversterking:	55 dB
Spiegelonderdrukking:	40 dBmW
Temperatuurafwijking (±):	1 MHz
Versterkingsrimpel (±):	0.6 dB
Kruispolarisatie-isolatie:	22 dB
Compressiepunt (1 dB):	0 dBmW
