10/21 Model 8356WCC Page 1 of 5
1455 Kleppe Lane Sparks, NV 89431-6467 (775) 359-4712 Fax (775) 359-7424
E-mail: website: haws@hawsco.com www.hawsco.com
No. (8) 0002080176
Model 8356WCC
Pull-Down Shower Eye/Face Wash
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS warrants that all of its products are guaranteed against defective material or poor workmanship for
a period of The foregoing notwithstanding warrants certain one year from the date of shipment. , HAWS
speci c products or components thereof for an adjusted period. A list of these excepted products and fi
components and a description of their respective warranty terms may be found here:
www.hawsco.com/warranty liability under s warranty shall be discha ed by furnishing without . HAWS’thi rg
charge F.O.B. factory any goods, or part thereof, which shall appear to the Company upon HAWS
inspection to be of defective material or not of rst-class workmanship, provided that a claim is made in
writing to Company within a asonable period after receipt of the product. Where claims for defects are re
made, the defective part or parts shall be delivered to the Company, prepaid, for inspection. shall HAWS
not be liable for the cost of repairs, alterations or replacements, or the labor required to implement them, or
for any expense connected therewith made by the owner or owner’s agents, except upon written authority
from shall not be liable for any damages caused by defective materials or p HAWS. HAWS oor
workmanship, except for r lacements, as provided above. Buyer agrees that has made no other ep HAWS
warranties either express or implied in addition to those above stated, except that of title with respect to
any of the products or equipment sold hereunder shall not be liable for general, special, and that HAWS
incidental, or consequential damages claimed to arise under the contract of sale.
Equipment manufactured by HAWS is warranted to function if installation and maintenance instructions
provided are hered to. The units also m t be used for the purpose for which they were intended. Any ad us
HAWS emergency equipment is intended to supplement rst-aid treatment. Due to widely varying
conditions, HAWS cannot guarantee that the use of this emergency equipm will prevent serious inju ent ry
or the aggravation of existing or prior injuries.
EXCEPT AS EXPRESSLY STATED HEREIN, HAWS HEREBY DISCLAIMS ALL WARRANTIES,
WHETHER EXPRESS OR IMPLIED, ARISING BY LAW OR OTHERWISE, INCLUDING WITHOUT
LIMITATION, ANY IMPL D WIE ARRANTIES OF MERCHANTABILITY D FITNESS FOR A AN
PARTICULAR PURPOSE. THIS WARRANTY MAY NOT BE MODIFIED OR EXTENDED WITHOUT THE
WRITTEN CONSENT OF HAWS. REMEDIES AND REPLACEMENTS STATED HEREIN ARE
EXCLUSIVE. IN NO EVENT SHALL HAWS BE LIABLE FOR ANY SPECI , P TIVEAL UNI ,
CONSEQUENTIAL OR INC ENTAL DAMAGES TO ANY PERSON INCLUDING BUT NOT LIMITED TO ID
DAMAGES FOR LOSS OF USE OR PROFITS, SUBSTITUTE PRODUCTS OR COSTS, PROPERTY
DAMAGE, OR OTHER MONETARY LOSS.
NOTE TO INSTALLER: Pl e leave this information with the Maintenance Department. eas
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1- -640-4297 888
10/21 Model 8356WCC Page 2 of 5
RECOMMENDED TOOLS: Adjustable wrench, pipe wrench, pipe joint sealant, Phillips
screwdriver, ¼” hex key wrench.
LOCATION OF U T: NI The Model WCC eye/face wash should be installed in close 8356
proximity to potential accident areas. It should be clearly identied free from obstructions
and easy to access. See ANSI Z358.1 guidelines for more information.
SUPPLY LINE: The minimum r ommended line size is 1" IPS with 30-90 psi (2-6 ATM) ec
owing pressure at supply inlet. Where sediment or mineral content is a problem, an inlet
lter is recommended.
PLUMBING CONNECTIONS: Inlet supply is male 1" IPS; waste is 2” IPS.
INSTALLATION PROCE DURE
Refer to installation drawing for clarication. Check Parts List to ensure all required parts are
included.
1.
Install all items at dimensions shown in installation drawing.
2.
Once valve assembly is installed, install mounting frame(s) over valve assembly.
3.
IMPORTANT: Showerhead must be positioned in-line with eye/face wash to allow for
simultaneous use by the same user per ANSI Z358.1.
4.
Install remaining items to dimensions shown.
5.
Each unit is factory preset to meet the 5 pound (22.2 N) maximum activation force
requirement for disabled persons. If adjustment is required after installation, follow the
adjustment directions below.
a)
Locate the two ball detents, one on each side of the eyewash tray. See installation
drawing.
b)
Using a at screwdriver, adjust each ball detent to make slight contact with the
eyewash housing just before the ball detent snaps into its locating position on the
housing.
c)
Once both ball detents are adjusted as above, tighten each ball detent ¼ turn.
d)
Using a force gauge, ensure the force required to open the eyewash unit does not
exceed 5 pounds (22.2 N).
CLEANING INSTRUCTIONS FOR STAINLESS ECROPOLISH PRODUCTS EL
Haws recommended cleaning procedure for stainless electropolish products is as follows:
1. Use a stainless-steel polish and cleaner for removing stains and ngerprints.
2. Spray cleaner onto stainless surfaces and wipe dry with clean cloth.
10/21 Model 8356WCC Page 3 of 5
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1.
No ow.
1.
Check the main shut-o valve.
2.
Insucient water ow at eye/face
wash.
2a.
Verify minimum 30 psi (2 ATM) owing
supply line pressure.
b.
Probable clogging of ow control due to
inadequate line ushing. Unscrew
eye/face wash head and remove the
four screws to disassemble the head,
clean the ow con ol and reassemble. tr
c.
Remove cap located on -line strainer in
housing using a ¼” Allen wrench to
access and clean lter screen. See
installation drawing for location.
3.
Eye/face wash streams do not
meet desired eye level.
3a.
Possible blocked ow c trol, see on
above solution.
b.
Possible non-leveled eye/face wash
assembly.
c.
Possible low supply pressure.
4.
Insucient water ow at the
showerhead, however, eye/face
wash is sucient.
4.
Probable clogging of ow control inside
showerh d. Remove showerhead by ea
unscrewing it and clean rubber ow
control.
5.
Tray too hard to open or does not
stay closed.
5.
See “Installation Procedure” Step 5.
For more information about Haws products, see our website: www.hawsco.com
© 2021 Haws® Corporation All Rights Reserved –
HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
INCLUDED PARTS
MODEL PACKAGE
QUANTITY
ITEMS INCLUDED
8356 C WC
1
Mounting Frame/Eyewash assembly
1
Valve assembly
1
Handle/screw assembly
1
Showerhead
1
Escutcheon
1
1” x 5” Nipple
1
1” X 22” Nipple
1
1” Elbow
1
Emergency Eyewash/shower sign
1
Test Tag
