Quick Setup

Before using the projector, make sure you read these instructions and the safety

instructions in the online User’s Guide.

Note: Some product features may not be available in all regions.

Contents

Make sure your projector box includes all of these parts:

You can place the projector on almost any flat surface. See the online User’s

Guide for more information.

Connect the projector

Google TV™

Your projector includes built-in Google TV with apps that can be launched

when the remote control is paired to the projector. To stream content, make

sure you have a wireless Internet connection and an active streaming account,

and enter your login information as necessary for each app.

Google Cast™

You can stream content from supported devices using Google Cast. See the

online User’s Guide for details.

Google™ Search

You can send voice commands to the projector using the remote control or a

Google HomeTM speaker. See the online User’s Guide for details.

Note: This feature may not be available in all regions.

Video device or computer

You can connect video equipment or a computer. Connect one end of an HDMI

cable to the projector’s HDMITM (ARC) port and the other end to an HDMI port

on your video device or computer. See the online User’s Guide for details.

Caution: Do not turn on the video source before connecting it to the projector;

you may damage the projector.

HDMI cable

Connect audio

Built-in speakers

The projector has built-in speakers that can play audio from the video source

you are viewing.

You can also use the projector’s speakers to play sound from a device connected

via Bluetooth®. Press the button on the remote control then select

Bluetooth Speaker Mode. Enable the setting, then select the projector from

your device. See the online User’s Guide for details.

Headphones

You can connect the projector to headphones through the audio out port.

Note: Connecting headphones disables the projector’s internal speaker. If you

do not hear sound from an HDMI source, set the connected device to PCM

output.

Turn on your projector

Note: If you are projecting from an external video device or computer, make

sure it is connected to the projector first.

1 Plug in the projector, then press the power button on the projector or

remote control. The status light flashes blue while the projector warms up

and then stays on.

2 Follow the on-screen instructions to pair the remote control and projector,

select your language, connect to your wireless network, and sign in to

your Google Account.

Note: To shut down the projector, press the power button.

Adjust the image

1 To reduce or enlarge the image, move the projector closer to or farther

away from the screen or use the digital zoom feature. See the online

User’s Guide for details.

50” 100”

EF21 Series

7.2 ft

(2.2 m)

3.6 ft

(1.1 m)

2 To adjust the image height, press and hold the foot release lever on the

bottom of the projector to extend the front adjustable foot. Release the

lever to lock the foot in the desired position.

3 Your projector automatically focuses the image, but if necessary press

the button on the remote control to improve the appearance. Press

up and down on the directional pad on the remote control to adjust the

focus setting.

4 Your projector automatically adjusts an image between 30” and 100”

measured diagonally that looks like . To manually , , ,or

adjust the image, press the button on the remote control and

select Image Correction > Manual Keystone Correction. Use the

directional pad to adjust the image shape.

Note: For more adjustment methods, see the online User’s Guide.

Using the remote control

Install the provided batteries as shown below.

Go back to previous

function

Access projector menus

Start Netflix® application

Start Amazon® Prime Video

application

Start YouTube™

application

Display the user

profile

Enter a selection

Adjust image

brightness

Choose which source

to display

Search with your voice

Turn projector on or off

Display the dashboard

screen

Display Google TV home

screen

Navigate menus and

home screen

Switch to the HDMI

source

Turn volume up or

down

Display the focus

adjustment screen

Note: You must pair the remote control to the projector to use Google TV and

video-on-demand features. See the online User’s Guide for more information.

Troubleshooting

• If you see a blank screen, check the following:

• Make sure your computer or video device is properly connected.

• Make sure the status light on the projector is blue and not flashing.

• Press the power button on the projector or remote control to

wake the projector from standby or sleep mode, if necessary.

• If you see a blank screen when a computer is connected, check the

following:

• On Windows®, hold down the Windows key and press at the same P

time, then click Duplicate.

• If you are using a Mac laptop with macOS 13 or newer, select System

Settings Displays > . Select the projector, then choose the mirror

option for your display from the Use as pop-up menu.

On macOS 12, select System Preferences > Displays Display >

Settings. Select the projector, then choose the mirror option for your

display from the drop-down menu.

On macOS 11 and older, open System Preferences and select

Displays Arrangement Mirror . Click the tab and select the

Displays checkbox.

• If the projector does not respond to remote control commands, make sure

that the remote control is paired with the projector, and that the batteries

in the remote control are installed correctly. Pair the remote control again

and replace the batteries, if necessary.

Registration

Scan the QR code to register for product updates and exclusive offers.

Where to get help

Manual

For more information about using the projector, you can view or download the

online manual from the Epson website, as described below.

Internet support

Visit http://epson.com/support/ef21 (U.S.), http://epson.ca/support/ef21

(Canada) or http://latin.epson.com/support/ef21

(Latin America) to download software and utilities, view

the manual, get FAQs and troubleshooting advice, or contact Epson.

Telephone support services

To use the Epson® PrivateLine® Support service, call (800) 637-7661. This service

is available for the duration of your warranty period. You may also speak with a

support specialist by calling (562) 276-4394 (U.S.) or (905) 709-3839 (Canada).

Support hours are 7 a.m. to 4 p.m., Pacific Time, Monday through Friday. Days

and hours of support are subject to change without notice. Toll or long distance

charges may apply.

In Latin America, see the online User’s Guide for technical support information.

Optional accessories

For a list of optional accessories, see the online User’s Guide.

You can purchase screens or other accessories from an Epson authorized reseller.

To find the nearest reseller, call 800-GO-EPSON (800-463-7766). Or you can

purchase online at (U.S. sales) or http://epsonstore.com http://epsonstore.ca

(Canadian sales).

To find the nearest reseller in Latin America, go to http://latin.epson.com.

Notices

Supplier’s Declaration of Conformity

According to 47CFR, Part 2 and 15, Class B Personal Computers and Peripherals; and/or

CPU Boards and Power Supplies used with Class B Personal Computers.

We: Epson America, Inc.

Located at: 3131 Katella Ave, Los Alamitos, CA 90720

Telephone: (562) 981-3840

Declare under sole responsibility that the product identiﬁed herein, complies with

47CFR Part 2 and 15 of the FCC rules as a Class B digital device. Each product marketed,

is identical to the representative unit tested and found to be compliant with the

standards. Records maintained continue to reﬂect the equipment being produced can

be expected to be within the variation accepted, due to quantity production and testing

on a statistical basis as required by 47CFR 2.906. Operation is subject to the following

two conditions: (1) this device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

Trade Name: Epson

Type of Product: LCD Projector

Model: HB35A

Marketing Name: EF21

Wireless LAN with Bluetooth Safety and

Specifications

Contains wireless LAN with Bluetooth module model: CDW-N37663U-02

Bluetooth remote controller model: B064E-02-W7

This document provides safety instructions and describes the speciﬁcations. Read this

document carefully before use to ensure your safety and product performance.

This device is restricted to indoor operation only.

Frequency range: CDW-N37663U-02: 2402-2480MHz, 5180-5320MHz, 5500-5700MHz,

5745-5825MHz

B064E-02-W7: 2402-2480MHz

Data transmission is always initiated by software, which is then passed down through

the MAC, through the digital and analog baseband, and ﬁnally to the RF chip. Several

special packets are initiated by the MAC. These are the only ways the digital baseband

portion will turn on the RF transmitter, which it then turns off at the end of the packet.

Therefore, the transmitter will be on only while one of the aforementioned packets is

being transmitted. In other words, this device automatically discontinues transmission in

case of either absence of information to transmit or operational failure.

U.S. FCC Notices

Contains FCC ID: BKMAE-N37663U02

FCC ID: BKMAE-B064E02W7

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation. This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur

in a particular installation. If this equipment does cause harmful interference to radio

or television reception, which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Caution: Changes or modiﬁcations not expressly approved by the party responsible for

compliance could void the user’s authority to operate this equipment. Properly shielded

and grounded cables and connectors must be used for connection to host computers

and/or peripherals in order to meet FCC emission limits.

This transmitter must not be co-located or operating in conjunction with any other

antenna or transmitter.

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment and meets the FCC radio frequency (RF) Exposure Guidelines.

This equipment should be installed and operated keeping the radiator at least

7.9 inches (20 cm) or more away from person’s body (except for the Bluetooth

remote controller model: B064E-02-W7).

Innovation, Science and Economic Development Canada (ISED)

Notices

Contains IC: 1052D-N37663U02

IC: 1052D-B064E02W7

CAN ICES (B)/NMB (B)

This device complies with Innovation, Science and Economic Development Canada (ISED)’s

license-exempt RSSs. Operation is subject to the following two conditions: (1) This device

may not cause interference; and (2) this device must accept any interference, including

interference that may cause undesired operation of the device.

This equipment complies with ISED radiation exposure limits set forth for an uncontrolled

environment and meets RSS-102 of the ISED radio frequency (RF) Exposure rules. This

equipment should be installed and operated with a distance of at least 7.9 inches (20 cm)

between the radiator and your body (except for the Bluetooth remote controller Model:

B064E-02-W7).

Product specificaties

Merk:	Epson
Categorie:	Beamer
Model:	EF21R

Heb je hulp nodig?

Als je hulp nodig hebt met Epson EF21R stel dan hieronder een vraag en andere gebruikers zullen je antwoorden

Uw naam*

Jouw email*

Schrijf hier uw vraag

Handleiding Beamer Epson

Epson EB-L520U Handleiding

14 December 2024

Epson EB-L630U Handleiding

14 December 2024

Epson ELPAF63 Handleiding

14 December 2024

Epson ELPFP15 Handleiding

14 December 2024

Epson ELPMB67 Handleiding

14 December 2024

Epson ELPLX01S Handleiding

14 December 2024

Epson ELPMB56 Handleiding

14 December 2024

Epson 421i Handleiding

21 November 2024

Epson EF22R Handleiding

5 November 2024

Epson EF21R Handleiding

5 November 2024

Handleiding Beamer

Nieuwste handleidingen voor Beamer

XGIMI Horizon S Pro Handleiding

18 December 2024

Viewsonic M1XB Handleiding

18 December 2024

Nec NP-NC1503L Handleiding

18 December 2024

Sharp X141Q-B Handleiding

17 December 2024

Christie Jazz 4K1600-JS Handleiding

16 December 2024

Christie DWU860-iS 1DLP Handleiding

16 December 2024

Christie Griffyn 4K50-RGB pure Handleiding

16 December 2024

Christie Jazz 4K2100-JS Handleiding

16 December 2024

Mirabella Genio Aurora Handleiding

14 December 2024

JVC DLA-RS1200 Handleiding

14 December 2024
