● 12000DPI PRECISION GAMING SENSOR TECHNOLOGY

ADNS-9800 high performance laser sensor for accuracy cursor control

● 32-BIT ARM PROCESSOR

Offer superior computing speed

● ALUMINUM FRAMING STRUCTURE

Components are built on a simply folded aluminum chassis to provide more rigid and robust

● MUZZLE BRAKE SR

Extended metal tube is inspired from the weapon and increase the flexibility of the cable

for smoother motions

● PALM REST HIGH/LOW ADJUSTMENT (TOOL-LESS)

In order for better palm supporting, the arched frame can be raised with the knob rotation

● INTERCHANGEABLE PALM REST (TOOL-LESS)

You can change to “Sport Mode” by replacing the palm rest

● FIRE BUTTON (PROGRAMMABLE)

Ergonomic design and quickly simplify actions to press the fire button at key moments

● 45 DEGREE SNIPER BUTTON (PROGRAMMABLE)

Provide a quick access, better stability and more precise aiming during game play

● 8 PROGRAMMABLE BUTTONS

Reassign command or macro to any one of 8 programmable buttons

● AERO-DYNAMICAL SYSTEM

Keep your hand cool and Increase the flexibility of moving

● WEIGHT ADJUSTMENT DESIGN

Weight cartridge contains four 4.5 gram metal weights, letting you to customize the

mouse weight

● COUGAR UIX™ SYSTEM

Integrated software combine COUGAR peripherals into one application

● 1000HZ POLLING RATE / 1MS RESPONSE TIME

125Hz – 1000Hz USB rate fine-tuning

● 512KB ON-BOARD MEMORY

Storage up to 3 profiles on the mouse and you can bring your setup to other PC

● ON-THE-FLY DPI ADJUSTMENT

Quickly switch between different DPI settings on the go

● 4-STAGE DPI LED DISPLAY

Quick confirm DPI stage without moving the hand

● MULTI-COLOR PROFILE BACKLIT SYSTEM

Choose 1 out of 16.8 million colors and set a unique color to profile

● OMRON MICRO SWITCHES

Guaranteed 5 million clicks for the longest gaming life

● ANTI-SLIP DESIGN

Hexagonal pattern on the left and right panel for maximum grip

● GAMING-GRADE SCROLL WHELL

ALPS encoder and rubberized scroll wheel provide accurate tactile feedback

● GAMING-GRADE MOUSE FEET

Best gliding performance and improve accuracy

● BRAIDED CABLE & GOLDEN-PLATED USB PLUG

Sturdy and durable solutions for gaming

COUGAR 700M is an adjustable gaming mouse which is dedicated to professional

gamers. With the design strategy ,“Framing Structure”, the parts and components are

built on a simply folded aluminum chassis; which provides better product strength.

The arched frame supports the palm ergonomically, and it’s an adjustable and

interchangeable palm rest module. The standard palm rest module can be replaced with

a “Sport Mode” version provided.

The sniper button is designed with a 45 degree angle activation, to provide a quick

access, better stability and more precise aiming during game play.

Left Click Right Click Wheel click DPI Cycle

Forward Backward Fire button 45° sniper button

ALUMINUM FRAMING STRUCTURE

To provide more rigid and robust input device for the fierce computer gaming, the

design principle of the COUGAR mouse ''Framing Structure makes the product ''

different from the existing mice in the market:

Inspired from the vertebrate animal, the COUGAR mouse is built on a backbone chassis;

and the metallic chassis provides extra brace to the whole device: the electronic

compartment, the ergonomic related features and the mechanical structures are

trapped and screwed on the chassis.

TIP : Fire button and 45° sniper button are disable on default, please customize

command by COUGAR UIX TM SYSTEM.

INTERCHANGEABLE PALM REST

Per user's preference, an extra palm rest is provided. With tool free design, users can

replace the palm rest by themselves.

FIRE BUTTON

Ergonomic design and quickly

simplify actions to press the fire

button at key moments.

PALM REST HIGH/LOW ADJUSTMENT

In order for better palm supporting, the

arched frame can be raised with the knob

rotation.

HOW TO SWITCH PALM REST

Gently hold down the clip and then slide

the palm rest backward.

45 DEGREE SNIPER BUTTON

The function of the sniper button on

a gaming mouse is for the gamers to

quickly switch the display resolution

of the computer monitor and provide

more accurate mouse cursor control

in the sniper mode of the first person

shooting game (' 'FPS game ); however,

placing the sniper button on the side

will generate the side force when the

users activate the button and then

deviate the cursor, that is against the

accuracy requirement.

Instead of pressing the button toward

to the mouse, the 45 degreed sniper

button can provide more stable

control in FPS gaming.

WEIGHT ADJUSTMENT

17g optional weight

MULTI-COLOR PROFILE BACKLIGHT

Choose 1 out of 16.8 million colors and

set a unique color to profile.

AERO-DYNAMICAL SYSTEM

Keep your hand cool and Increase the flexibility of moving.

Product name

Sensor

Resolution

Processor

Game type

Polling rate

Material

Software

On-board

memory

COUGAR 700M

gaming mouse

32-bit ARM Cortex-M0

FPS / MMORPG /

MOBA / RTS

COUGAR

UIX™ SYSTEM

ADNS-9800

Laser gaming sensor

12000 DPI

1000Hz / 1ms

512KB

Aluminum / Plastic

Switching

Frame rate

Dimension

Interface

Weight

adjusting

OMRON gaming switch

150 IPS

30G

Cable length

Profile LED

backlight

Maximum

tracking speed

Maximum

acceleration

17g optional weight

16.8 million colors

12000 FPS

Golden-plated

USB plug

1.8m Braided

110g

127(L) X 83(W)

X 38 (H) mm

The specification maybe varies depending on the country or region

Programmable

buttons

● ESTRUCTURA DE ALUMINIO

● SENSOR LASER DE 12000 DPI

● PROCESADOR DE 32-BIT

Y MEMORIA INTERNA DE 512KB

● REPOSAMANOS AJUSTABLE

● BOTÓN DE DISPARO Y BOTÓN

FRANCOTIRADOR DE 45°

● SOPORTA COUGAR UIX™ SYSTEM

ESPAÑOL

3 4

5 6

7 8

9 10

11 12

13 14

15 16

17 18

19 20

45°

PULL

The COUGAR UIX™ SYSTEM is the ultimate gaming device configuration tool.

This user-friendly software allows you, through an intuitive interface, to fully

configure all compatible COUGAR peripherals with a single application,

integrating all of them and unleashing their full power.

Another important feature is the ability to record and store macros for both

mouse and keyboard in a “Macro Arsenal” that will allow you to use them in

any compatible COUGAR keyboard or mouse without recording it again.

Convenience and compatibility on a fully featured device management

application.

●

MOUSE GAMING USB PER PC 700M

●

SENSORE 12000 DPI

ITALIANO

HUNGARIAN

●

ALUMÍNIUM KERET

●

12000DPI PRECÍZIÓS SZENZOR

TECHNOLÓGIA

●

32 BITES ARM PROCESSZOR

●

KÉZZEL ÁLLÍTHATÓ TENYÉRTÁMASZ

(MAGAS / MÉLY)

●

PROGRAMOZHATÓ 45°-OS

LÖVÉSZ GOMB

●

COUGAR UIX™ RENDSZER

POLISH

● ALUMINIOWY SZKIELET

● LASEROWY SENSOR 12000DPI

● 32-BITOWY PROCESOR ARM /

512 KB WBUDOWANEJ PAMIĘCI

● DOSTOSOWANIE WYSOKO CI OPARCIA Ś

DŁ Ż ĘONI (BEZ U YCIA NARZ DZI)

● PRZYCISK SNIPER )

(45°, PROGRAMOWALNY)

● SYSTEM COUGAR UIX™

РУССКИЙ

● ÀËÞÌÈÍÈÅÂÀß ÐÀÌÊÀ ÌÛØÈ

● ËÀÇÅÐÍÛÉ ÑÅÍÑÎÐ 12000 DPI

● ÏÐÎÖÅÑÑÎÐ 32-BIT È ÂÍÓÒÐÅÍÍßß

ÏÀÌßÒÜ ÍÀ 512KB

● ÐÅÃÓËÈÐÓÅÌÛÅ ÄËß ËÀÄÎÍÅÉ

● ÊÍÎÏÊÀ ÎÃÎÍÜ È ÊÍÎÏÊÀ 45°

SNIPER (ÑÍÀÉÏÅÐ)

● Ïîääåðæêà COUGAR UIX™ SYSTEM

中文

●

3D铝合金架构

●

12000 DPI激光传感器

●

32-BIT处理器 & 512KB板载内存

●

可调节式掌托设计

●

火力键 & 45° 狙击键

●

COUGAR UIX™ SYSTEM 软件支持

PORTUGUÊS

●

ESTRUTURA DE MOLDURA DE ALUMINIO

●

SENSOR LASER DE 12000 DPI

●

PROCESSADOR DE 32-BIT E MEMÓRIA

512KB ON-BOARD

●

POUSA PALMAS AJUSTÁVEL

●

BOTÃO DE DISPARO E BOTÃO

FRANCO-ATIRADOR DE 45°

●

SUPORTE COUGAR UIX™ SYSTEM

한국어

●

알루미늄 프레이밍 구조

●

12000 DPI 레이져 센서

●

32-BIT 프로세서 & 512KB ON-BOARD

MEMORY

●

조정가능한 손목 받침대

●

FIRE BUTTON & 45° SNIPER BUTTON

●

COUGAR UIX™ SYSTEM 지원

日本語

● アルミフレーム

● 解像度12000 DPI

● 32bitプロセッサ& 512KB

オンボードメモリを搭載

● 調整なパームレスト

● 連射機能& 45°スナイパーボタン

● COUGAR UIX™ SYSTEM対応

FRANÇAIS

● STRUCTURE EN ALUMINIUM BROSSÉ

● CAPTEUR LASER 12000 DPI

● PROCESSEUR 32 BITS ET MÉMOIRE

512KB ON-BOARD

● REPOSE POIGNET AJUSTABLE

● FIRE BUTTON & 45° SNIPER BUTTON

● COUGAR UIX™ SYSTÈME

DEUTSCH

● LASERSENSOR MIT 12000 DPI

● 32-BIT-ARM-PROZESSOR

● ALUMINIUMRAHMEN

● FIRE-BUTTON

● 45°-SNIPER-BUTTON

● 8 PROGRAMMIERBARE TASTEN

● AERODYNAMISCHES SYSTEM

● EINSTELLBARES GEWICHT

● COUGAR UIX™ SYSTEM

●

1000 HZ ABTASTRATE / 1 MS REAKTIONSZEIT

● 512 KB ON-BOARD-SPEICHER

●

ANPASSBARE HANDBALLENAUFLAGE

(WERKZEUGLOS)

●

DPI-EINSTELLUNG ON-THE-FLY

●

DPI-LED-ANZEIGE IN 4 STUFEN

●

HINTERGRUNDBELEUCHTUNG IN

MEHREREN FARBEN

●

OMRON-SWITCHES

●

RUTSCHFESTES DESIGN

●

ALPS HOCHWERTIGES MAUSRAD

●

MOUSE-GLIDES IN PROFI-QUALITÄT

●

UMMANTELTES KABEL

ENGLISH

1.Go to the COUGAR official website. (http://www.cougargaming.com)

2.Download the COUGAR UIXTM

SYSTEM_700M SUPERIOR installer from the

700M SUPERIOR download page.

DEUTSCH

1. Gehe zur offiziellen COUGAR Homepage. (http://www.cougargaming.com)

2. Download COUGAR UIXTM

SYSTEM_700M SUPERIOR installer von der 700M SUPERIOR

download seite.

中文

1.连上COUGAR官方网站（http://www.cougargaming.com）

2.进入700M SUPERIOR的下载页面，下载COUGAR UIXTM SYSTEM_700M SUPERIOR

한국어

1. COUGAR 공식 웹사이트 ( )http://www.cougargaming.com 로 이동합니다.

2. 700M SUPERIOR 다운로드 페이지에서 COUGAR UIXTM SYSTEM_700M SUPERIOR

설치 프로그램을 다운로드합니다.

日本語

1. COUGAR 公式サイトに移動します。 (http://www.cougargaming.com)

2. COUGAR_700M SUPERIOR COUGAR UIX ダウンロードページから TM SYSTEM_

700M SUPERIOR のインストーラーをダウンロードします。

РУССКИЙ

1. Ïåðåéäèòå íà âåá-ñàéò COUGAR. (http://www.cougargaming.com)

2. Çàãðóçèòå ïðîãðàììó óñòàíîâêè äðàéâåðà COUGAR UIXTM SYSTEM_700M SUPERIOR

ñî ñòðàíèöû çàãðóçîê äëÿ 700M SUPERIOR.

PORTUGUÊS

1. Visite o website oficial da COUGAR. (http://www.cougargaming.com)

2. Transfira o programa de instalação COUGAR UIXTM SYSTEM_ a partir 700M SUPERIOR

da página de transferência .700M SUPERIOR

ESPAÑOL

1. Vaya a la web oficial de COUGAR. (http://www.cougargaming.com)

2. Descargue el instalador de COUGAR UIXTM SYSTEM_700M SUPERIOR de la página de

descarga 700M SUPERIOR.

Download

COUGAR UIX TM

SYSTEM

www.cougargaming.com

1. Plug the USB connector of your COUGAR product into your computer's motherboard's

USB port and wait for the Operating System to finish installing the device driver. The

system will notify you when this process has been completed and the device is ready

to be used.

2. Click on the UIX installer and follow the on-screen instructions.

3. UIX™ will check your device's firmware version and automatically update it during the

installation process.

4. The firmware update process might take several minutes, please be patient and do

not disconnect the device or shut the computer down.

1. Connettere la presa USB al PC

2. Scarica e installa i driver da http://cougargaming.com/downloads/

3. Il vostro device è pronto per essere utilizzato.

ITALIANO

Windows 7 , Windows 8, Windows 10

Compucase Enterprise Co.,Ltd.

No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, R.O.C

Tel:+886-6-356-0606

Service E-Mail: service@cougargaming.com

More information you will find at cougargaming.com

Compucase Enterprise Co.,Ltd.

Made in China

Please do not directly look into the optical beam!

This manual was created by Compucase Enterprise and may not be completely or

partially copied, passed on, distributed or stored without written consent by Compucase

Enterprise.

COUGAR® is a registered brand of Compucase Enterprise Other product and company

names mentioned in this documentation may be brands or trademarks of their respective

owners.

Compucase Enterprise reserves the right to make changes concerning the contents of

the manual and the technical data of the product without previous announcement.

All o t h er registered trade marks belo n g

to t h eir re spect ive comp a nie s.

MSIP-REI-CEE-

COUGAR700M

Tested to comply with FCC standards

FOR HOME OR OFFICE USE

DISCLAIMERS

● COUGAR product is not authorized for use as critical components in life support

device or for incorrect application software or malfunction of the product.

● COUGAR is not liable for the death or damage of person or loss of property when

product is using as, including but not limited to, medical equipment, military equipment,

traffic equipment and disaster prevention system.

● COUGAR's warranty liability is limited to repair, replacement.

● COUGAR is not liable for any damages, expenses, lost data, lost revenues, lost savings,

lost profits, or any incidental or consequential damages due to using defect product

of COUGAR.If you have any question about the warranty, please feel free to contact us.

Customer support: service@cougargaming.com

WARRANTY AGREEMENT

● If the product has defects in material or manufacture, COUGAR will provide product

repair and replacement service within the warranty period.

● Our warranty service is based on the date of the invoice or warranty card (must be

affixed with the store stamp). If you lose the aforementioned evidence, we will apply

the original shipping date of the product as the beginning date of warranty period.

The shipping date will be identified by the product serial number(S/N).

CONDITIONS WHERE FREE MAINTENANCE IS NOT PROVIDED

● Any fault or damage caused by natural disasters (including storm, fire, flood, thunder,

earthquake, etc).

● Any fault or damage caused by accidental factors and man-made reasons

(including hit, scrape, crash, moving, compression, stain, corrosion, use of incurred on

unsuitable voltage, computer virus, riot, misuse, malicious damage, etc).

● Use in an improper operating environment (including high temperature, high humidity,

water inflow, etc).

● Inability to provide the product warranty card, purchase receipt or invoice to prove the

product is still within the warranty period and the shipping date of the product is out

of warranty.

● The warranty card or product serial number has been altered or its number is hard to

identify.

● The warranty period has expired.

● Any fault or damage caused by non-compliance with regulations stated on the user

manual or improper, rough and careless treatment.

● Any fault or damage caused by use of parts not certified by COUGAR original

manufacturer.

● The problem is caused by improper repair or adjustment by the buyer or any

manufacturer without authorization from COUGAR.

● The product is not acquired from an authorized distributor of the company or is

acquired from illicit sources.

● Paper carton, instruction and other accessories are not warranted.

21 22

WARRANTY PERIODS OF COUGAR GAMING DEVICES

Product : COUGAR 700M gaming mouse

Warranty : 1 Year

This warranty gives you specific legal rights. You may also have other rights granted

under local law. These rights may vary.

R63088

1 2 3 4

1 2

Product specificaties

Merk:	Cougar
Categorie:	Muis
Model:	700M Superior
Kleur van het product:	Grey, Orange
Ingebouwd display:	Ja
Gewicht:	110 g
Breedte:	83 mm
Diepte:	127 mm
Hoogte:	38 mm
Snoerlengte:	1.8 m
Stroombron:	Kabel
Gebruiksaanwijzing:	Ja
Vormfactor:	Rechtshandig
Materiaal:	Aluminium, Plastic
Responstijd:	1 ms
Bedoeld voor:	Gamen
Aantal:	1
Aanbevolen gebruik:	PC
Aantal knoppen:	8
Maximaal 30 frames per seconde:	12000 fps
Aansluiting:	USB Type-A
Scroll type:	Wiel
Bewegingsresolutie:	12000 DPI
Contact geleider materiaal:	Goud
Aantal programmeerbare knoppen:	8
Soort knoppen:	Drukknoppen
Bewegingsdetectietechnologie:	Laser
Aantal scroll wheels:	1
Ingebouwd geheugen:	Ja
Type beeldscherm:	LED
Belichting:	Ja
Programmeerbare muisknoppen:	Ja
Stemmingsrato:	1000 Hz
Versnelling (max):	30 G
Ingebouwde geheugen capaciteit:	512 KB
Bewegingssnelheid (max):	150 duim/min
