Pagina 1/10
Installation and Operation Manual
Back-UPS® BR900G-GR
Connect the battery
Inventory Safety
This unit is intended for indoor use
only.
Do not operate this unit in direct
sunlight, in contact with fluids, or where
there is excessive dust or humidity.
1 2 3
4 5 Charge the battery for at least 16
hours before use
bu001a
bu055a
bu057a
bu059a
bu058a
bu060a
Back-UPS BR900G-GR Installation and Operation2
PowerChute® Personal Edition Software
Overview
PowerChute Personal Edition Software allows you to use your computer to access additional power protection and
management features of the Back-UPS.
Using PowerChute, you can:
• Preserve work in progress during a power outage by putting your computer into Hibernate mode. When the
power returns, the computer will appear exactly as it did before the power outage.
• Configure the Back-UPS management features, such as power-saving outlets, shutdown parameters, audible
alarms, and more.
• Monitor and view the status of the Back-UPS, including the estimated runtime, power consumption, power
event history, and more.
Available features will vary by Back-UPS model and operating system.
If you choose not to install PowerChute, the Back-UPS will still provide backup power and power protection to
connected equipment. However, you will only be able to configure a limited number of features using the display
interface.
Compatibility
PowerChute is compatible with Windows operating systems only. For a detailed list of supported operating systems,
go to www.apc.com, select Software & Firmware.
For Mac operating systems, we recommend using the native shutdown application (within System Preferences)
which recognizes your battery backup and allows you to configure shutdown of your system during power outages.
To access this application, connect a USB cable from the Back-UPS DATA PORT (POWERCHUTE PORT) to a USB port
on your computer, and see the documentation provided with your computer.
Installation
Connect the Back-UPS to a computer using a USB cable. Plug one end into the on the rear panel P C OWER HUTE PORT
of the Back-UPS and the other into a USB port on your computer.
Insert the PowerChute CD into your computer and follow the on-screen instructions. If your Back-UPS did not come
with a PowerChute CD, download the software from www.apc.com, select Software & Firmware.
Back-UPS BR900G-GR Installation and Operation 3
Connect the equipment
Battery Backup and Surge Protected outlets
When the Back-UPS is receiving input power, the
Surge Protection only outlets and the Battery
Backup with Surge Protection outlets will supply
power to connected equipment. During a power
outage or other utility problems, only the Battery
Backup outlets receive power for a limited time
from the Back-UPS.
Connect equipment such as printers, FAX
machines, scanners, or other peripherals that do not
need battery backup power to the Surge Protection
Only outlets. These outlets provide full time
protection from surges even if the Back-UPS is
switched off.
Master and Controlled outlets
To conserve electricity, when the device connected
to Master Outlet goes into Sleep or Standby mode,
or turns off, the Controlled by Master device(s)
will shut down as well, saving electricity.
Connect a master device, such as a desktop
computer or audio/visual receiver to the Master
outlet. Connect peripheral devices such as a printer,
speakers, or a scanner to the Controlled by Master
outlets.
1USB and Serial Data port To use PowerChute Personal Edition, connect the supplied USB software cable or serial cable
(not included).
2Telephone ports Connect a telephone cable to the IN port, and a modem to the port.OUT
3Surge Protection outlets,
Controlled by Master outlet
These outlets provide surge protection during a power outage. These outlets will disconnect
from A/C power during a power outage, or in the event that the Master outlet goes into Sleep
mode.
4Surge Protection outlets These outlets provide full-time surge protection, when the unit is turned on or off. Connect a
printer, scanner or other devices that do not require battery backup protection.
5AC Power Cable Connect the Back-UPS to A/C power.
6Battery Backup outlets with
Surge Protection
During a power outage or other utility problems, these outlets provide power from the
Back-UPS battery. Connect critical equipment such as desktop computer, computer monitor,
modem or other data sensitive devices to these outlets.
7Battery Backup, Controlled by
Master outlet with Surge
Protection
During a power outage or other utility problems, these outlets provide power from the
Back-UPS battery.
These outlets will disconnect from A/C power during a power outage, or in the event that the
Master outlet goes into Sleep mode.
Connect critical equipment such as desktop computer, computer monitor, modem or other data
sensitive devices to these outlets.
8Master outlet Connect the master device to this outlet, in most scenarios, this will be the main computer.
9Gigabit Ethernet
surge-protected ports
Use an Ethernet cable to connect a modem to the IN port, and a computer to the OUT port.
:Circuit breaker Use to reset the system after an overload or short circuit.
bu214a
Tel Out
Tel In
USB &
Serial
Battery
Backup
Surge
Only
MASTER
Controlled by MASTER
Controlled by MASTER
