Pagina 1/37
APANTAC LLC, 10200 SW Suite CAllen Blvd. , Beaverton, OR 97005 USA
info@apantac.com, TEL: +1 503 968 3000, FAX: +1 503 389 7921
Production Quality, Compact
SDI Converter er / Scal
Micro-Single
User Manual
V2
Micro- Single Production Quality, Compact SDI Converter / Scaler
APANTAC LLC, 10200 SW Allen Blvd. Suite C, Beaverton, OR 97005 USA
info@apantac.com, TEL: +1 503 968 3000, FAX: +1 503 389 7921
1
Table of Contents
1.0 What’s in the Box .................................................................................................... 2
2.0 Key Features ............................................................................................................. 2
3.0 Specifications ........................................................................................................... 3
4.0 Hardware and Installation ................................................................................. 4
4.1 Front Panel ................................................................................................................ 4
4.2 Rear Panel .................................................................................................................. 4
4.3 Installation ................................................................................................................. 5
5.0 Micro_Lite_Controller Software ....................................................................... 6
5.1 Getting Started ........................................................................................................ 6
5.2 Running the Micro_Lite_Controller ............................................................... 6
5.3 Connecting to -the Micro Single ..................................................................... 6
5.4 Configuring the Output .................................................................................... 10
5.5 Configuring the On-Screen Elements ........................................................ 12
5.5.1 Labels .................................................................................................................. 12
5.5.2 Audio Meters ...................................................................................................17
5.5.3 Border ............................................................................................................... 20
5.5.4 ags Alarm T ....................................................................................................... 22
5.5.5 Auto Aspect Ratio ........................................................................................ 23
5.5.6 Tally .................................................................................................................... 24
5.5.7 28 Safe Area..........................................................................................................
5.5.8 Presets .............................................................................................................. 30
5.5.9 Front Panel Definitions ............................................................................. 31
5.5.10 Write to Flash ................................................................................................. 32
5.5.11 Quit and Exit ................................................................................................... 33
Copywrite & Trademark..................................................................................................... 34
Warranty Statement ........................................................................................................... 34
Limitation of Liability ........................................................................................................... 35
Contact Apantac Technical Support ........................................................................... 36
HDMI- 8x8
39
1.0 What’s in the Box
• 1 x Micro- Single
• 1 x Mounting Plate
• 1 x RJ50 to DB9 cable for GPI/Tally
• 1 x DC 5V 3.2A Power Adapter
Impo
Impo
Impo
ImpoImpor
r
r
rrtan
tan
tan
tantant Note:
t Note:
t Note:
t Note:t Note:
Default IP address: 192.168.1.151
The configuration PC must be on the same subnet as the Micro-Single, for example,
“192.168.1.1”
The default output resolution is set to 1024x768@59.95 Hz for 60Hz countries and
1024x768@60Hz for 50Hz countries to accommodate the most common display resolution.
2.0 Key Features
• Low power consumption - s – n12 W and ilent o f ! an
• Single input SDI converters with OSD
• Accepts 3G SDI site video signals, HD SDI, SD SDI and Compo
• Simultaneous HDMI and SDI outputs
• Decode/display up to 8 embedded audio per SDI input
• Ethernet port for Configuration, Dynamic Labels & Tallies interface (TSL)
• Up to 32 characters per label per window
• Text, background c tolors, ransparency are adjustable
• Borders c an be turned ON or OFF
• Visual Alarms (Tags)
• 0 to 8 Embedded Audio Meters can be displayed for each Window
• Audio monitoring output – HDMI analog,
• Four f p b ront anel uttons configurable for presets
• Safe Area Markers
• Up to 4 tally levels control with TSL, 2 with GPI
• Support of the TSL protocol v. 3.1 over IP is standard
• 8 x GPI contacts: Configurable for tally or ASCII protocol
• Automatic aspect ratio
