GRAPE PHASER®
The Grape Phaser® provides lush, analog phase shifting courtesy of a
simple, two-knob layout. RATE controls the speed of the modulation
while COLOR feeds a portion of the signal back through the phase
shifting circuit, creating new and super funky bass sounds!
Features:
x All analog technology
x Gig-saver bypass (signal passes even if your battery dies)
x Powered by a nine-volt battery or optional universal power
supply
x Heavy duty steel construction
x Three-year limited warranty
Owner ’s Manual
Manual Version 1.0
I. Functions
A. Top Panel:
RATE: Controls the speed of the modulation.
COLOR: Controls how much of the original signal is d back through the phase fe
shifting circuit.
ENGAGE: Toggles between on and off. The blue LED indicates that the effect is on.
B. Side Panel:
IN: ¼” input
DC IN: This is a standard 2.1mm DC jack. The center terminal polarity is negative.
OUT: ¼” output
C. Specifications:
C 3 urrent consumption:……………………….. .5mA
Input impedance: .............. (Effect On) ..............................1MΩ
Output impedance: .........................................1 K Ω
External DC Power: -10VDC, center terminal negative ………………………..9
II. Sample Settings
Please visit our website, www.aguilaramp.com, for sample settings.
III. How to change the battery
This operation can be done quickly and easily with a standard #2 Philips screw
driver!
The battery is easily accessible by loosening the screw on the bottom of the unit. The
battery compartment will slide forward and you will be able to see the padded area
to insert the battery and attach the battery clips. Once the battery has been replaced,
simply slide the compartment back in and tighten the screw.
