Pagina 1/40

ENGLISH FRANÇAIS

Contents:

How Cellular Boosters Work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Install Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Kit Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Installation Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 & 4

Outside Antenna Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installing the Inside Panel Antenna(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Installing The Signal Booster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Finding The Strongest Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Post Install Setup / LCD Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Warnings and Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back

Note: This manual contains important safety and operating information. Please read and follow the

instructions in this manual. Failure to do so could result in damage to your Signal Booster.

Appearance of device and accessories may vary.

INSTALLATION GUIDE

In-Building

SmarTech ®

Cellular Signal Boosters

PRO 70 PLUS™

-50 Ohm

PRO SERIES

1Contact Wilson Electronics Customer Support Team with any questions at

866-294-1660 or email: tech@wilsonelectronics.com

ENGLISH

1. Select a location on the roof or outside of the building to install the outside antenna. Refer

to pages 3 & 5.

2. Select a location to install the Signal Booster that is away from excessive heat,

direct sunlight or moisture, and has adequate ventilation. Airtight enclosures are not

recommended. Booster should be as close to the outside antenna as possible in order to

minimize losses from cable length to outside antenna.

3. Connect the cable from the outside antenna to the signal booster’s “outside antenna”

Install Overview

Refer to Installation Diagram on page 3 & 4. Contact Wilson Electronics Technical Support

Team with any questions at 866-839-9361.

How a Cellular Booster Improves Indoor Signals

Wilson cellular signal booster systems work as follows: an outdoor antenna placed

on a

building where some cell signal is present, (ideally on a roof or pole), receives and sends

that weak signal via coax cable (like used in satellite TV installs) to a signal booster located

indoors. That weak signal is amplified by the booster and delivered via coax cable to an

inside antenna(s) which rebroadcasts the amplified signal within one or several areas where

improved signal is required. Signals from indoor cell device(s) are likewise picked up by the

inside antenna(s), amplified by the signal booster and transmitted back to the cell tower via

the outside antenna. The improved signals result in reliable cellular connections

for indoor users.

About Gain and Improved Signal Area

The less signal strength at the outside antenna’s location and/or the greater the coverage

need, the more gain will be required. Conversely, the more signal present outside, the

greater the inside coverage area will be. Proper aiming of the outside antenna towards the

source of the cell signal is also important. The gains of the outside and inside antenna,

though reduced by losses from coax cable lengths, also affect area of improved coverage.

Placement of the inside antenna is also a factor as they have directional characteristics.

Inside wall materials will also affect indoor coverage area.

Another important factor affecting coverage area is inadequate isolation between outside

and inside antenna(s). Wilson boosters are designed to reduce their internal gain in

order to prevent any feedback “oscillations” which if unchecked, could affect nearby cell

site operation. The LCD status display on the booster is used to determine if a booster

is operating at optimal gain for each cellular band. Optimal gain can be achieved by

increasing antenna separation, i.e. isolation, until the max gain is indicated. If attainable

separation is limited by a building’s layout, gain will suffer. A nearby cell site, even if not

providing service to a user, can also cause the booster’s automatic network protection

circuitry to reduce gain or even turn off one or more of the booster’s bands so as to

prevent signal overload to the nearby site. The display on the booster can also be used

to determine if this condition is taking place. Refer to pages 9-11 for explanation of the

booster status display.

Contact Wilson Electronics Customer Support Team with any questions at

866-294-1660 or email: tech@wilsonelectronics.com

ENGLISH

connector. Refer to page 6 for more information on running cable. Lightning Surge

Protection is recommended for all in-building installations. Refer to pages 3 & 6.

4. Select a location for the inside antenna. Try to choose a position in the center of the area

needing improved signal. Keep in mind that proper inside antenna to outside antenna

isolation is necessary for the system to function properly. This may require as much as

50 to 75 feet of horizontal separation from the outside antenna. Vertical separation

also helps increase isolation. Alternate means of isolation are possible. If physical

separation is not possible, please contact Wilson Electronics Tech Support at

866-839-9361 for suggestions on alternate methods to achieve isolation.

5. Connect the cable from the inside antenna to the signal booster’s “inside antenna”

connector. Refer to page 6 for more information on running cable. Keep cable runs as

short as possible to reduce signal loss in the system.

6. Before powering up the signal booster, verify that both the outside antenna and the

inside antenna are connected correctly, and check that all connections are tight. Note:

Be careful when plugging the connectors in so as not to bend the center pins on the

connectors.

7. Power on the signal booster by plugging in the included power supply. If the lights are

not green, please refer to pages 10-11.

Pro 70 Plus 2’ LMR 400 Lightning Surge

Protector

Wide Band Directional

Antenna 75’ LMR 400

Wide Band Panel Antenna

60' LMR 400

463127 Kit

463227 Kit

Pro 70 Plus AC/DC

Power Supply

12V/3A

AC/DC

Power Supply

12V/3A

2’ LMR 400 Lightning Surge

Protector

Wide Band Directional

Antenna 75’ LMR 400

463327 Kit

Pro 70 Plus

AC/DC

Power Supply

12V/3A

2’ LMR 400 Lightning Surge

Protector

4G Dome Ceiling Antenna

60’ LMR400 Cable

4G Dome Ceiling Antenna

60’ LMR400 Cable

e Ceiling Anten

Multiple Kit Options Available Note: Kits may contain diﬀ erent accessories

To purchase Expansion Kits call Wilson Electronics Sales Department at: 888-503-5329

4G Omni Plus

Antenna 75’ LMR400

Cable

Product specificaties

Merk:	Wilson
Categorie:	Signaalversterker TV
Model:	Pro 70 Plus
Kleur van het product:	Blue, White
Gewicht:	1270 g
Breedte:	225 mm
Diepte:	152 mm
Hoogte:	38 mm
Soort:	Signaalversterker voor mobiele telefoons binnenshuis
Gebruikershandleiding:	Ja
3G bands ondersteund:	850,900,1900,2100 MHz
Meegeleverde kabels:	AC
Ingangsspanning:	110 - 240 V
Impedantie:	75 Ohm
Datanetwerk:	2G, 3G, 4G, CDMA, GSM, HSPA+, LTE
Frequentie:	50/60 Hz
2G-banden ondersteund:	850,900,1800,1900 MHz
Antenne:	Ja
Stroomverbruik (typisch):	20 W
Uplink frequentie bereik:	824 - 894 / 1850 - 1910 / 1710 - 1755 / 698 - 716 / 776 - 787 MHz
Downlink frequentie bereik:	- MHz
Uplink winst:	70 dB
4G FDD-LTE-banden ondersteund:	700,800,850,900,1800,1900,2100 MHz
