1
Network Video Recorder
NVS
User Manual
NVSPRO8-2U-X
NVSPRO8-4U-X
model no.
Please carefully read these instructions before using this product.
Save this manual for future use.
2
31472AB 3
Surveillix™ NVS PRO
Operations Manual (G5 Hardware & Version 4.5 Software )
Manual Edition 31472 20AB – OCTOBER 12
Printed in USA
No part of this documentation may be reproduced in any means, electronic or mechanical, for any purpose, except as
expressed in the Software License Agreement. shall not be liable for technical or Toshiba America Information Systems (TAIS)
editorial errors or omissions contained herein. The information in this document is subject to change without notice.
THE INFORMATION IN THIS PUBLICATION IS P KIND. THE ENTIRE ROVIDED “AS IS” WITHOUT WARRANTY OF ANY
RISK ARISING OUT OF THE USE OF THIS INFORMATION REMAINS WITH RECIPIENT. IN NO EVENT SHALL TOSHIBA
BE LIABLE FOR ANY DIRECT, CONSEQUENTIAL, INCIDENTAL, SPECIAL, PUNITIVE, OR OTHER DAMAGES
WHATSOEVER (INCLUDING WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION OR LOSS OF BUSINESS INFORMAT ION), EVEN IF T IAS HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES AND WHE CONTRACT OR TORT, INCLUDING NEGLIGENCE. THER IN AN ACTION OR
This software and documentation are copyrighted All other rights, including ownership of the software, are reserved to . DVR
Support Center. TIAS and Surveillix are registered trademarks of in the United States and TOSHIBA CORPORATION
elsewhere; Windows, and Windows 2000 are registered trademarks of Microsoft Corporation. All other brand and product
names are trademarks or registered trademarks of the respective owners.
The following words and symbols mark special messages throughout this guide:
WARNING: Text set off in this manner indicates that failure to
follow directions could result in bodily harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to
follow directions could result in damage to equipment or loss of
information.
4
LIMITED WARRANTY
NETWORK VIDEO RECORDER
The Imaging Systems Division of Toshiba America Information Systems, Inc. ("ISD") makes the following limited warranties.
These limited warranties extend to the Original End- User ("You[r]").
Limited Three (3) Year Warranty of Labor and Parts
The Imaging Systems Division of Toshiba America Information Systems warrants this product and parts against defects in material or
workmanship for a period of three years from the date of original retail purchase by the end user. During this period, will repair or replace a - ISD
defective product or part with a new or refurbished item. The user must deliver the entire product to the Surveillix DVR Repair Facility. The user is
responsible for all transportation and insurance charges for the product to the DVR Repair Facility. ISD reserves the right to substitute Factory
Refurbished Parts and / or Factory Refurbished Product in place of those in need of repair.
Step-by- - step Procedures How to Obtain Warranty Service
[1] Verify operation of the unit by checking the instruction manual and web site for the latest updates at
www.toshibasecurity.com
[2] - If there is a defect in material or workmanship, contact the Surveillix DVR Support Center at (877) 855 1349
[877 855- -1FIX] to speak to a technical support representative and schedule service.
[3] Arrange for delivery of the product to the Surveillix DVR Repair Facility. Products must be insured and securely packed, preferably
in the original shipping carton. A letter explaining the defect and a copy of the bill of sale or other proof of purchase must be enclosed
with a complete return street address and daytime telephone number. The Tracking Number should also be indicated on your
documents. Charges for transportation and insurance must be prepaid by the end- user.
Critical Use Disclaimer
The product is not designed for any “critical applications.” “Critical applications” means life support systems, exhaust or smoke
extraction applications, medical applications, commercial aviation, mass transit applications, military applications, homeland security
applications, nuclear facilities or systems or any other applications where product failure could lead to injury to persons or loss of life or
catastrophic property dama Accordingly, Toshiba disclaims any and all liability arising out of the use of the product in any critical ge.
applications.
Your Responsibilities
The above warranty is subject to the following conditions:
[1] You must retain the bill of sale or provide other proof of purchase.
[2] You must schedule service within thirty days after you discover a defective product or part.
[3] All warranty servicing of this product must be made by the Surveillix DVR Repair Facility.
[4] The warranty extends to defects in material or workmanship as limited above, and not to any products or parts that have been lost
or discarded by user. The warranty does not cover damage caused by misuse, accident, improper installation, improper maintenance,
or use in violation of instructions furnished by ISD. The warranty does not extend to units which have been altered or modified without
authorization of ISD, or to damage to products or parts thereof which have had the serial number removed, altered defaced or rendered
illegible.
ALL WARRANTIES IMPLIED BY STATE LAW, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ARE EXPRESSLY LIMITED TO THE DURATION OF THE LIMITED WARRANTIES SET FORTH
ABOVE. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply.
WITH THE EXCEPTION OF ANY WARRANTIES IMPLIED BY STATE LAW AS HEREBY LIMITED, THE FOREGOING EXPRESS
WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WITH RESPECT TO THE REPAIR OR REPLACEMENT OF ANY
PRODUCTS OR PARTS. IN NO EVENT SHALL ISD BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES. Some
states do not allow the exclusion or limitation of incidental or consequential damages so the above limitation may not apply.
No person, agent, distributor, dealer, service station or company is authorized to change, modify or extend the terms of these
warranties in any manner whatsoever. The time within which an action must be commenced to enforce any obligation of ISD
arising under this warranty or under any statute, or law of the United States or any state thereof, is hereby limited to one year
from the date you discover or should have discovered, the defect. This limitation does not apply to implied warranties arising
under state law. Some states do not permit limitation of the time within which you may bring an action beyond the limits
provided by state law so the above provision may not apply to user. This warranty gives the user specific legal rights, and
u ser may also have other rights, which may vary from state to state.
TOSHIBA AMERICA INFORMATION SYSTEMS, INC.
Imaging Systems Division
Copyright © 201 Toshiba America Information Systems, Inc. All rights reserved.2
31472AB 5
IMPORTANT SAFEGUARDS
6
IMPORTANT SAFEGUARDS, continued
BATTERY EXPLOSION CAUTION STATEMENT
CAUTION: Risk of Explosion if Battery is replaced by an Incorrect Type.
Dispose of Used Batteries According to the Instructions.
NOTES ON HANDLING
Please retain the original shipping carton and/or packing materials supplied with this product. To ensure the integrity of this product
when shipping or moving, repackage the unit as it was originally received from the manufacturer.
Do not use volatile liquids, such as aerosol spray, near this product. Do not leave rubber or plastic objects in contact with this prod uct
for extended periods of time. Rubber or plastic objects left in contact with this product for extended periods of time will leave marks on
the finish.
The top and rear panels of the unit may become warm after long periods of use. This is not a malfunction.
NOTES ON LOCATING
Place this unit on a level surface. Do not use it on a shaky or unstable surface such as a wobbling table or inclined stand.
If this unit is placed next to a TV, radio, or VCR, the playback picture may become poor and the sound may be distorted. If this
happens, place the recorder away from the TV, radio, or VCR.
31472AB 7
AVOID VOLATILE LIQUID
Do not use volatile liquids, such as an insect spray, near the unit. Do not leave rubber or plastic products touching the unit for a long
time. They will leave marks on the finish. Do not use a chemically saturated cloth.
NOTES ON MAINTENANCE
To keep the recorder always operational we recommend regular inspection maintenance (cleaning parts or replacement). For details,
contact the nearest dealer.
NOTES ON MOISTURE CONDENSATION
Moisture condensation damages the recorder. Read the following information carefully.
Moisture condensation occurs during the following cases:
When this product is brought directly from a cool location to a warm location.
When this product is moved to a hot and humid location from a cool location.
When this product is moved to a cool and humid location from a warm location.
When this product is used in a room where the temperature fluctuates.
When this product is used near an air conditioning unit vent-
When this product is used in a humid location.
Do not use the recorder when moisture condensation may occur.
If the recorder is used in such a situation, it may damage discs and internal parts. Remove any CD discs, connect the power cord of
the recorder to the wall outlet, turn on the recorder, and leave it for two to three hours. After two to three hours, the recorder will warm
up and evaporate any moisture. Keep the recorder connected to the wall and moisture will seldom occur.
8
WARNING
TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE.
DO NOT OPEN THE CABINET.
REFER SERVICING TO QUALIFIED PERSONNEL ONLY.
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
C A U T I O N
RISK OF ELECTRIC SHOCK
DO NOT OPEN
31472AB 9
RACK MOUNT INSTRUCTIONS
Elevated Operating Ambient – If installed in a closed or multi unit rack assembly, the operating ambient temperature of the rack -
environment may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an
environment compatible with the maximum ambient temperature (Tma) specified by the manufacturer.
Reduced Air Flow – Installation of the equipment in a rack should be such that the amount of airflow required for safe operation of the
equipment is not compromised.
Mechanical Loading – Mounting of the equipment in the rack should be such that a hazardous condition is not achieved due to
uneven mechanical loading.
Circuit Overloading – Consideration should be given to the connection of the equipment to the supply circuit and the effect that
overloading of the circuits might have on over current protection and supply wiring. Appropriate consideration of equipment nameplate
ratings should be used when addressing this concern.
Grounding -Grounding of rack mounted equipment should be maintained. Particular attention should be given to supply connections
other than direct connections to the branch circuit (e.g. use of power strips).
FCC STATEMENT
INFORMATION TO THE USER: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
USERS OF THE PRODUCT ARE RESPONSIBLE FOR CHECKING AND COMPLYING WITH ALL FEDERAL, STATE, AND LOCAL
LAWS AND STATUTES CONCERNING THE MONITORING AND RECORDING OF VIDEO AND AUDIO SIGNALS.TOSHIBA SHALL
NOT BE HELD RESPONSIBLE FOR THE USE OF THIS PRODUCT IN VIOLATION OF CURRENT LAWS AND STATUTES.
10
Disclaimer
We disclaim any responsibility and shall be held harmless for any damages or losses incurred by the user in any of the following cases:
1. Fire, earthquake or any other act of God; acts by third parties; misuse by the user, whether intentional or accidental; use under extreme
operating conditions.
2. Malfunction or non function resulting in indirect, additional or consequential damages, including but not limited to loss of expected income -
and suspension of business activities.
3. Incorrect use not in compliance with instructions in this user's manual.
4. Malfunctions resulting from misconnection to other equipment.
5. Repairs or modifications made by the user or caused to be made by the user and carried out by an unauthorized third party.
6. Notwithstanding the foregoing, Toshiba's liabilities shall not, in any circumstances, exceed the purchase price of the product.
Usage Limitation
The product is not designed for any "critical applications." "Critical applications" means life support systems, exhaust or smoke extraction
applications, medical applications, commercial aviation, mass transit applications, military applications, homeland security applications,
nuclear facilities or systems or any other applications where product failure could lead to injury to persons or loss of life or catastrophic
property damage.
Accordingly, Toshiba/TAIS disclaims any and all liability arising out of the use of the product in any critical applications.
31472A 11B
Table of Contents
PREFACE ............................................................................................................................................................. 15
About this Guide ............................................................................................................................................ 15
Technician Notes ........................................................................................................................................... 15
INTRODUCTION ..................................................................................................................................................16
Product Description .......................................................................................................................................16
Features ......................................................................................................................................................... 17
CONTROLS AND CONNECTIONS ...................................................................................................................... 18
Front Panel Controls ...................................................................................................................................... 19
2U Front Panel ................................................................................................................................ 19
4U Front Panel ................................................................................................................................ 19
Rear Panel Connectors.................................................................................................................................. 20
2U Rear Panel ................................................................................................................................. 20
4U Rear Panel ................................................................................................................................. 20
GETTING STARTED ............................................................................................................................................ 21
Identifying Included Components ................................................................................................................... 22
Keyboard Setup ............................................................................................................................................. 23
Mouse Setup .................................................................................................................................................. 23
Monitor Setup ................................................................................................................................................ 24
Power Setup .................................................................................................................................................. 24
Hard Drive Array (2U Only)............................................................................................................................ 25
Removing a Hard Drive ................................................................................................................... 25
Inserting a Hard Drive ...................................................................................................................... 25
Hard Drive Array (4U Only) ............................................................................................................................ 25
Inserting a Hard Drive ...................................................................................................................... 25
Rackmount Kit Installation ............................................................................................................................. 26
Preparing for Setup ......................................................................................................................... 26
Separating the Section of the Rack Rails ........................................................................................ 26
Installing the Inner Rail Extensions .................................................................................................. 27
Installing the Outer Rack Rails ........................................................................................................ 27
Installing the Recorder into a Rack .................................................................................................. 27
4U Front Bezel Installation ............................................................................................................................. 28
Turning On the NVR ...................................................................................................................................... 28
Turning Off the NVR ...................................................................................................................................... 28
NVR Basics ............................................................................................................................................................. 29
Setting the Time and Date ............................................................................................................................. 30
Accessing the DVR Utility .............................................................................................................................. 30
Exporting Settings ........................................................................................................................... 30
Importing NVR Settings ................................................................................................................... 30
Changing Video Format ................................................................................................................... 30
Display Screen ............................................................................................................................................... 31
CPU Meter ....................................................................................................................................... 31
Live Camera Options ....................................................................................................................... 31
Camera View ................................................................................................................................................. 32
Recording Status Indicator .............................................................................................................. 32
Special Recording ...........................................................................................................................32
12
Edit Live View Channels ................................................................................................................................ 33
Screen Division Buttons ................................................................................................................................. 33
64 Channel Screen Division ............................................................................................................ 34
Custom Live View Divisions............................................................................................................. 34
Setup Options .......................................................................................................................................................... 35
Setup Overview .............................................................................................................................................36
Camera Setup ................................................................................................................................................ 37
Network Video ............................................................................................................................................... 38
Connecting a Network Device ......................................................................................................... 38
Assigning a Network Device to a Channel ....................................................................................... 39
Assigning Audio Channels to a Network Device .............................................................................. 40
Assigning Dual Streams .................................................................................................................. 41
Camera Configuration ..................................................................................................................... 42
Upgrade and Registration ................................................................................................................ 43
Motion Setup .................................................................................................................................................. 45
Create a Motion Area ...................................................................................................................... 45
Regular Interval Recording .............................................................................................................. 45
General Setup ................................................................................................................................................ 46
Voice Warning ................................................................................................................................. 47
Connecting to a Wide Screen Display ............................................................................................. 47
Connecting a Second Monitor .........................................................................................................47
Volume ............................................................................................................................................ 47
Hybrid Sensor Setup ....................................................................................................................... 48
Auto Sequence Setting .................................................................................................................... 49
Schedule Setup ............................................................................................................................................. 50
Recording Schedule ........................................................................................................................ 50
Sensor Schedule ............................................................................................................................. 51
Scheduling Alarm Events ................................................................................................................52
Emergency Agent Schedule ............................................................................................................ 52
Special Day Schedule ..................................................................................................................... 52
System Restart Setup ...................................................................................................................... 53
Network Setup ............................................................................................................................................... 54
Administrative Setup ...................................................................................................................................... 55
Disk Management ............................................................................................................................ 55
Setting Up DDNS ............................................................................................................................. 56
User Management ........................................................................................................................... 57
Changing the Administrator Password ............................................................................................ 58
Log Management ............................................................................................................................. 59
Status Check / Email ....................................................................................................................... 60
Information ..................................................................................................................................................... 63
Instant Recording ........................................................................................................................................... 63
Activate Instant Recording ............................................................................................................... 63
Searching ‘Instant Recorded’ Video ................................................................................................ 63
Search ..................................................................................................................................................................... 64
Search Overview ...........................................................................................................................................65
Play Controls ................................................................................................................................... 65
Adjust the Brightness of an Image ................................................................................................... 66
Zooming in on an Image .................................................................................................................. 66
Zooming in on a Portion of an Image ............................................................................................... 66
Open Video from a Saved Location ................................................................................................. 66
Time Sync........................................................................................................................................ 66
Clean Image .................................................................................................................................... 66
Performing a Basic Search ............................................................................................................................ 67
Printing an Image ........................................................................................................................................... 67
Daylight SAVIng Time .................................................................................................................................... 67
31472A 13B
Save to JPG or AVI ........................................................................................................................................ 68
Bookmarks....................................................................................................................................... 69
Clip Backup ..................................................................................................................................... 70
Index Search .................................................................................................................................................. 71
Performing an Index Search ............................................................................................................ 71
Index Search Results Display .......................................................................................................... 71
Preview Search .............................................................................................................................................. 72
Performing a Preview Search .......................................................................................................... 73
Graphic Search .............................................................................................................................................. 73
Performing a Graphic Search .......................................................................................................... 73
Object Search ................................................................................................................................................ 74
Performing an Object Search .......................................................................................................... 74
Motion Search ................................................................................................................................................ 75
Performing a Motion Search ............................................................................................................ 75
Audio Playback .............................................................................................................................................. 75
Search in Live ................................................................................................................................................ 76
Pan / Tilt / Zoom ...................................................................................................................................................... 77
Pan /Tilt / Zoom Overview .............................................................................................................................. 78
Enable the PTZ Settings .................................................................................................................. 78
Advanced PTZ Setup ..................................................................................................................................... 78
Creating and Viewing Preset Positions ............................................................................................ 79
Accessing PTZ Menus ................................................................................................................................... 79
Controlling a PTZ Camera ............................................................................................................................. 80
Using the Graphical PTZ Controller ................................................................................................. 80
Using the On-Screen Compass ....................................................................................................... 80
Understanding Tours ....................................................................................................................... 81
PTZ Tour Schedule .........................................................................................................................81
backing up Video Data ............................................................................................................................................ 82
Backup Overview ........................................................................................................................................... 83
Nero® Express ................................................................................................................................. 83
General Screen Overview ............................................................................................................... 84
Clip Screen Overview ...................................................................................................................... 85
Scheduled Screen Overview ........................................................................................................... 86
lan / isdn / pstn connections .................................................................................................................................... 87
LAN Overview ................................................................................................................................................ 88
Connecting to a LAN Using TCP/IP ............................................................................................................... 88
Configuring TCP/IP Settings ............................................................................................................ 88
LDAP Integration ..................................................................................................................................................... 89
Features ......................................................................................................................................................... 90
Installing Active Directory ............................................................................................................................... 90
Web Viewer ............................................................................................................................................................. 92
Web Viewer Overview.................................................................................................................................... 93
Configuring the Server for Remote Connection ............................................................................... 94
Connecting to a Recorder Using Web Viewer ................................................................................. 94
Closing the Web Viewer .................................................................................................................. 94
Included Software Setup ......................................................................................................................................... 95
The Surveillix App Overview .......................................................................................................................... 96
Emergency Agent Overview .......................................................................................................................... 96
Configuring the Recorder ................................................................................................................ 96
Configuring the Client PC ................................................................................................................ 97
Setup Window ................................................................................................................................. 97
14
Emergency Agent Window .............................................................................................................. 98
Search Alarm Window ..................................................................................................................... 99
Remote Software Overview ......................................................................................................................... 100
Remote Software Setup ................................................................................................................101
Digital Verifier Overview ............................................................................................................................... 103
Installing the Digital Verifier ........................................................................................................... 103
Using the Digital Verifier ................................................................................................................ 103
Backup Viewer Overview ............................................................................................................................. 104
Installing Backup Viewer ............................................................................................................... 104
Loading Video from DVD or Hard Drive ......................................................................................... 104
Software Upgrades ................................................................................................................................................ 105
SCS Overview .............................................................................................................................................106
Purchasing SCS Software Upgrade .............................................................................................. 106
Configuring the Server for Remote Connection ............................................................................. 106
Connecting to a Recorder .............................................................................................................. 106
31472A 15B
PREFACE
ABOUT THIS GUIDE
This manual is a setup and maintenance guide that can be used for reference when setting up the and for troubleshooting when recorder
a problem occurs. Only authorized personnel should attempt to repair this unit.
Toshiba reserves the right to make changes to the s represented by this manual without notice.recorder
The following text and symbols mark special messages throughout this guide:
N ote Text set off in this manner indicates topics of interests that can help the user understand the product better.
T ip Text set off in this manner indicates topics and points of interests that can be helpful when using or settings up the recorder.
TECHNICIAN NOTES
Warning Only authorized technicians trained by Toshiba should attempt to repair this . All troubleshooting and repair recorder
procedures that may be shown are for reference and minor repair only. Because of the complexity of the individual components
and subassemblies, no one should attempt to make repairs at the component level or to make modifications to any printed wiring
board. Improper repairs can create a safety hazard. And any indications of component replacement or printed wiring board
modifications may void any warranty
Warning To reduce the risk of electrical shock or damage to the equipment:
Do not disable the power grounding plug. The grounding plug is an important safety feature.
Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all times.
Disconnect the power from the computer by unplugging the power cord either from the electrical outlet or the computer.
Caution To properly ventilate your system, you must provide at least 3 inches (7.6 cm) of clearance at the front and back of the
recorder.
16
INTRODUCTION
PRODUCT DESCRIPTION
A Surveillix NVS Pro a is network video recorder a server that performs as a High Definition Digital Recorder. By utilizing the , Network
many features of a computer, including processing power, storage capacity, graphics compression, and security features, the recorder is
more powerful than the analog recorders of the past.
The Surveillix - server software comes pre configured for fast and seamless integration within your existing IT infrastructure. Designed
around Microsoft® Windows 7 Embedded®, the server software offers unparalleled stability, security, and ease of use. Accordingly, your
security investment has never been easier to maintain. Multiple users may simultaneously connect through any network connection for
instantaneous live viewing, digital search, and off site video storage. Users can also connect remotely through DSL, Cable Modems, or
ISDN. This powerful software enables users to establish recording schedules, create motion detection zones, use PTZ controls, and
configure alarm inputs and outputs for each of the system's cameras. With the latest advancements in the Server Software, searching IPS
and indexing your video archive has never been easier. Video can now be found, viewed, and exported in a number of file formats with
just a few clicks.
The Surveillix network video recorder is high performance security product ready to meet today’s security demands.
31472A 17B
FEATURES
Surveillix recorders include the following new features:
Optimized and designed for Microsoft® Windows 7 Embedded
Supports up to 64 network cameras
Remote system operation & configuration
Supports multiple simultaneous remote connections
PAN / TILT / ZOOM controls
Simultaneous video search, playback and backup
Video indexes for easy searching
Multiple levels of security access
Optional POS and ATM support
High performance, durable, rackmount case
Output the video to a NTSC/PAL display
Up to TB internal storage48
Digital signature support
Continuous, motion detection, alarm, pre- alarm, and scheduled recording modes
Software Watchdog
Camera dependant recording resolutions
18
CONTROLS AND CONNECTIONS
This chapter includes the following information:
Input / Output Connector Locations
Front Panel Controls and LEDs
Rear Panel Connectors
31472A 19B
F P C RONT ANEL ONTROLS
The front panel of the contains the devices that will be commonly used for data removal, retrieval, and backup replacement. The recorder
most common components and buttons are shown below.
2U Front Panel
4U Front Panel
Cooling fan intake USB ports Power switch
Reset
LEDs
Power Failure
Fan Failure
NIC2
NIC1
HDD
Power
1 2
!
1 2 43
5678
9 1 0 11 12
13 14 15 16
Cooling Fan Intake
Power Switch
USB 2.0 ports
Power
Failure
NIC 1 and 2
Reset Button
Alarm Mute
System HDD
HDD Tray
Activity LEDs
LEDs
20
REAR PANEL CONNECTORS
The rear panel of the contains the connectors used to attach cameras, sensors, and relays to the recorder are diagramsrecorder . Below
that outline the location and description of each connector.
2U Rear Panel
4U Rear Panel
AC power
Optical output
USB USB
NetworkeSATA
USB
Cooling fan
5.1 Surround sound
Line in – line level
Speaker out
Microphone in – not used
HDMI
DVI-I
Optical output
USB USB
NetworkeSATA
USB
5.1 Surround sound
Line in – line level
Speaker out
Microphone in – not used
HDMI
DVI-IAC power
Cooling fans
31472A 21B
GETTING STARTED
This chapter includes the following information:
Included Components
Setting up the DVR Hardware
Optional Components
22
IDENTIFYING INCLUDED COMPONENTS
Surveillix recorders come with a mouse, keyboard and selected software and cables. Identify the following components to make sure
everything has been properly included with the new . If any of the following items are missing, contact the dealer to arrange a recorder
replacement.
NVR Case Key
(varies by model) Mouse Keyboard
Repair Disc/ Software Disc Power Cable DVI to VGA Adapter
HDD Drives
(Shipped separately
for 4U only)
Bezel Cover
( 4U Only) Rackmount Rail Kit
31472A 23B
KEYBOARD SETUP
To attach the keyboard to the , plug the end of the Keyboard into ort located on the back of the machine. recorder a USB p
MOUSE SETUP
To attach the mouse to the , plug the end of the mouse into a USB port located on the back of the machine. recorder
The mouse uses a cursor called a pointer. Pointers come in many different shapes but are most commonly shaped like an arrow.
The ng. mouse has two buttons: a left button and a right button. Quickly pressing and releasing one of these buttons is called clicki
Sometimes you will need to double or click the same button twice quickly.- click
In this manual:
Click means to position the mouse cursor over an item and to single click the left button.
Right click means to position the mouse cursor over an item and to single click the right button.
Double-click means . to position the mouse cursor over an item and to click the left button twice
Select means to position the mouse cursor over a radio button, checkbox, or list item and click on it.
The (scrolling)scroll wheel in between the two buttons is used for added navigation functionality. By moving the wheel with index finger ,
quickly move through multiple pages, lines, or windows. The wheel may also function as a third button allowing the user to quickly click or
double-click an icon or a selected item
Right Button
Scroll Button / Third Button
Left Button
24
MONITOR SETUP
The recorder has the following connections available to attach a monitor.
HDMI Output To TV / Digital Monitor
DVI- I Output To TV / Digital Monitor
DVI to SVGA Adapter Connect adapter to DVI output to connect
an analog VGA Monitor.
Attach the or monitors r of the recorder using the cable supplied by the monitor to the rea monitor the monitor manufacturer. Refer to
manual for detailed information on how to setup and use it.
N ote The monitor must be capable of having a screen resolution of 1024 x 768 and display colors of at least 32 Bit
POWER SETUP
WARNING:
To reduce the risk of electrical shock or damage to the equipment:
Do not disable the power grounding plug.
The grounding plug is an important safety feature.
If the electrical plug you are using does not have a ground plug receptacle contact a licensed
electrician to have it replaced with a grounded electrical outlet.
Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all
times.
Disconnect the power from the computer by unplugging the power cord either from the
electrical outlet or the computer.
31472A 25B
HARD DRIVE ARRAY (2U ONLY)
Hard drives in the NVS Pro 8-2U are arranged top to bottom in the HDD cage. A minimum of one and a maximum of four hard drives
may be installed in the hard drive cage. The hard drive installed in bay one contains the operating system and if removed will render the
recorder inoperable.
Removing a Hard Drive
1. Push the release button for the drive to remove.
2. Pull the release handle outward, sliding the drive tray out of the drive cage.
Inserting a Hard Drive
1. Slide the drive tray into the drive cage.
2. Press the release handle until it clicks, locking the drive tray in place.
HARD DRIVE ARRAY (4U ONLY)
Hard drives in the 4U model are arranged top to bottom in the HDD cage. A minimum of one and a maximum of sixteen hard drives may
be installed in the hard drive cage. The is shipped with the hard drives in a separate box. To insert the drives, follow these 4U
instructions. The drives must be inserted in order, 1 16 (depending on how many drives you purchased). The drive trays are marked with -
the number of their port. See the diagram for the order of the hard drive ports on the 4U.
Inserting a Hard Drive
1. Pull the blue button on the drive tray to release the latch.
2. Slide the drive tray into the drive cage.
3. Close the latch until it clicks, locking the drive tray in place.
12
26
R ACKMOUNT KIT INSTALLATION
This section provides information on installing the Surveillix 2U and 4U into a rack unit with the rack rails provided. There are a s NVR
variety of rack units on the market which may mean the assembly procedure will differ slightly. You should refer to the installation
instructions that came with the rack unit you are using.
Preparing for Setup
The box your was shipped in should include two sets of rail assemblies, two rail mounting brackets and the mounting Surveillix recorder
screws you will need to install the system into the rack. Please read this section in its entirety before you begin the installation procedure
outlined in the sections that follow.
Note
Note
Note
NoteNote These rails are designed to fit a rack between 26 and 33.5 inches deep.
Separating the Section of the Rack Rails
The package includes two rail assemblies in the rack mounting kit. Each assembly consists of two sections: an inner fixed chassis rail that
secures directly to the server chassis and an outer fixed rack rail that secures directly to the rack itself.
1. Locate the rail assembly in the packaging.
2. Extend the rail assembly by pulling it outward.
3. Press the quick release tab.-
4. Separate the inner rail extension from the outer rail assembly.
5. assembly. Repeat steps for the second rail
31472A 27B
Installing the Inner Rail Extensions
Each rackmount kit includes a set of inner rails in two sections: inner rails and inner rail extensions. The inner rails are pre attached to the -
chassis, and do not interfere with normal use of the chassis if you decide not to use a server rack. The inner rail extension is attached to
the inner rail to mount the chassis in the rack.
1. Place the inner rail extensions on the side of the chassis aligning the hooks of the chassis with the rail extension holes.
Make sure the extension faces "outward" just like the pre attached inner rail.-
2. Slide the extension toward the front of
the chassis.
3. Optional: Secure the chassis with 2
screws as illustrated. (4 screws are
provided on 4U models.)
4. Repeat steps for the other inner rail
extension.
Installing the Outer Rack Rails
Outer rails attach to the rack and hold the
chassis in place. The outer rails will extend
between 30 inches and 33 inches.
1. Secure the back end of the outer rail
to the rack, using the leaf springs
and screws provided.
2. Press the button where the two
outer rails are joined to retract the
smaller outer rail.
3. Hang the hooks of the rails onto the
rack holes and if desired, use
screws to secure the front of the outer rail onto the rack.
4. Repeat steps for the other outer rail extension.
Installing the Recorder into a Rack
1. Extend the outer rails.
2. Align the inner rails with the outer rails on the rack.
3. Slide the inner rails into the outer rails, keeping pressure
even on both sides. When pushed all the way into the
rack, the rails will click into a locked position (preventing
removal without pressing the quick release tabs).-
28
4U FRONT BEZEL INSTALLATION
The 4U is shipped with handles attached to the front of the unit. If you choose to
mount the front bezel to your recorder, you will need to remove the handles and
attach the bezel before attaching the rackmount rails.
1. Remove the two screws from each handle.
2. Ins tall the include bezel clips and fasten with screws.
3. Align and slide the right side of the bezel into the right clip.
4. Slide the left side of the bezel into the left clip.
5. Lock the bezel by turning the key counterclockwise.
TURNING ON THE NVR
1. recorder Turn on the monitor and any external peripherals (ex. Printers, External Storage Devices, etc.) connected to the .
2. Turn on the Secondary Power Switch located in the rear of the recorder.
3. Press the Power Switch located on the front of the recorder.
4. The recorder will run a series of self tests. After two or three minutes, a series of messages may be displayed as the -
various hardware and software subsystems are activated. Under normal circumstances, users should not be asked to
respond to these messages. If asked to respond to the messages (adding a Printer, Monitor, etc for the first time) follow
the instructions carefully.
5. Startup is complete when the Surveillix NVR software is finished loading and displays the main menu screen.
TURNING OFF THE NVR
1. Click Exit on the main menu screen of the NVR software.
2. Select The recorder Power Off from the list and click OK. may take several minutes to shut down completely.
Caution
Caution
Caution
CautionCaution Always be sure to follow the proper procedures when turning off the power to the recorder. NEVER disconnect
the power to the while it is still running or in the process of shutting down. Doing so can cause data recorder
loss, file corruption, system instability and hardware failure.
31472A 29B
NVR BASICS
This chapter includes the following information:
Becoming familiar with the Display screen
Defining Screen Divisions
30
SETTING THE TIME AND DATE
1. and Exit to Windows by clicking Exit on the Display screen then clicking Restart in Windows Mode.
2. button Click the Start > Control Panel.
3. inside Click Date and Time Control Panel.
4. Adjust the Date and Time.
5. When finished, click Apply, then , then close all open windows and restart the this by OK recorder. Do clicking and Start
selecting Restart from the Shut Down menu.
ACCESSING THE DVR UTILITY
Exporting Settings
Exporting settings can help configure multiple recorders quickly or reconfigure a unit that has been reset to factory defaults. Some things
must be kept in mind when using this feature.
You cannot use this function on:
Recorders that are different models.
When upgrading from certain software versions. (This feature cannot be
used when upgrading from v2.x to v3.x)
1. on the Exit to Windows by clicking Exit Display screen then and select
Restart in Windows Mode.
2. button Click the Start > All Programs > Surveillix > vFormat.
3. Click Export in the System Setting tool section.
4. Select a location to save the settings file and click Save. The DVR
Utility will export the NVR settings and automatically close.
Importing NVR Settings
1. on the Exit to Windows by clicking Exit Display screen then and select
Restart in Windows Mode. (See the Display screen section later in this
chapter)
2. button Click the Start > All Programs > Surveillix > vFormat.
3. Click Import in the System Setting Tool section.
4. Select the location of the settings file to import and click Open.
5. Click Yes to import the data file.
Changing Video Format
1. on the Exit to Windows by clicking Exit Display screen then and select Restart in Windows Mode. (See the Display screen
section later in this chapter)
2. button Click the Start > All Programs > Surveillix > vFormat.
3. Select the appropriate video setting from the list in the Video Setting section NTSC or PAL.
4. Click Set.
31472A 31B
DISPLAY SCREEN
Each time the recorder starts, the program defaults to the Display screen. The following diagram outlines the buttons and features used
on the Display screen. You should become familiar with these options as this is the screen that will be displayed the majority of the time.
CPU Meter
Use the CPU meter to monitor the system resources on your
recorder.
GREEN - System configuration OK
YELLOW - Caution; evaluate system configuration
and consider decreasing system loading
RED - System configuration has been exceeded which may affect stability; decrease system loading or upgrade system with
CPU performance package
Live Camera Options
Right-click a camera on the Display screen to display these options:
Full Screen
Instant Recording
Se arch In Live
Opens:
Search
Setup
Backup
PTZ Controller
Current Date /
Time
Relay Outputs
Screen Division buttons
Opens Setup Display
CPU meter
32
CAMERA VIEW
Recording Status Indicator
The camera status for each camera is displayed in the upper right corner on the Video Display Area. The following are the different states
for each camera:
Recording Displayed when the camera is currently being recorded to the recorder.
Motion Detection Displayed when a camera (set up for motion detection) detects motion.
Display Displayed when the camera is currently not being recorded to the recorder.
Special Recording
There are two types of Special Recording. Text is displayed on the camera indicating what type of Special Recording is activated.
SENSOR
Sensor is displayed when a sensor, associated with a given camera, is activated.
INSTANT
Instant Recording is a manual activation of the recording for the selected camera. Regardless of the recording method, Instant Recording
will start the camera recording and also flag the video for future searches using the Index Search feature. INSTANT is displayed when a
user activates the instant recording option. Double the video display to activate and deactivate the Instant Recording option.right-c lick
INSTAN
T
Special Recording Ty
Recording Statu
Camera Number and Name
31472A 33B
EDIT LIVE VIEW CHANNELS
By default, the recorder only allows live video from four network channels at one time on the local server. This protects the processor
resources for recording data. The SCS software allows you to view live video from multiple recorders at once and with the same
limitations that the recorder has on the number of live IP based video channels. If more than four channels of live video are required on
the local server, you can enable the recorder to show up to 16 channels. Be aware that displaying 16 channels of live IP based video is
resource intensive and may dramatically impact system performance.
To enable the recorder to view 16 channels of live video:
1. Click Exit on the display screen and select Restart in Windows Mode.
2. Double - click the Edit Live View Channels icon on the desktop.
3. If you wish to continue, confirm the two warning windows.
The live view display will switch to 16 channel mode. To return the recorder to 4 channel mode, run the utility again using the same
instructions.
SCREEN DIVISION BUTTONS
Note When viewing live video from Network Cameras, only 4CH will display at one time. If more live view channels are required on the
local server, see the Edit Live View Channels instructions.
1st Four Cameras View – Displays cameras 1 4 in the Video Display Area. To return to a different Multi- -Camera
View, select a different Screen Division option from the Screen Division menu.
2nd Four Cameras View – Displays cameras 5 8 in the Video Display Area. To return to a different Multi- -Camera
View, select a different Screen Division option from the Screen Division menu.
3rd Four Cameras View – Displays cameras 9 12 in the Video Display Area. To return to a different Multi- -Camera
View, select a different Screen Division option from the Screen Division menu.
4th Four Cameras View – Displays cameras 13 16 in the Video Display Area. To return to a different Multi- -Camera
View, select a different Screen Division option from the Screen Division menu.
Full Screen
The Full Screen Option allows you to view the Video Display Area using the entire viewable area on
the monitor. When this is selected, no menu options are visible. You can activate the Full Screen Option by clicking
on the Full Screen within the Screen Division . You can deactivate Full Screen mode by right clicking button menu
on the screen.
Auto Sequence
Sequences through the Screen Divisions sets. For example, selecting the 1A and then the Loop
button will sequence through 1A, 2A, 3A, 4A and then repeat.
34
64 Channel Screen Division
To access channels 17 32, 33 48, and 49 64 on a 64 channel NVS,- - - -
Mouse over the channel section indicator next to the screen division buttons. The channel section will display as 16X 1, 16X 2, and 16X 4
to indicate the channel section you are currently viewing.
Click the desired channel section.
Custom Live View Divisions
Customize your Live View screen by changing the order of the cameras. Each screen division can be individually customized but a
camera can only be displayed once in each group view.
Create custom live view divisions:
1. On the Display screen click , and then click Setup General.
2. Click Sequence Setting.
3. Drag and drop cameras from the Channel List to the desired location within the Division Group.
Division Grou
Chan
nel
31472A 35B
SETUP OPTIONS
This chapter includes the following information:
Setup Overview
Camera Setup
Network Video
Motion
Schedule
Network
Administrative
Information
PTZ
36
SETUP OVERVIEW
The Setup options allow you to optimize your by adjusting things like camera names, recorder
restart schedules, recording schedules and more. It is extremely important that you setup your
recorder ns. correctly for several reaso
Recording Schedules – Increase the amount of pertinent recorded video that is
saved on the recorder by optimizing the recording schedule. Optimize the type of
recording done by adding motion detection to this as well, again increasing the
amount of useful video.
Camera Naming – Name each camera so the location can be easily identified and
include when any other pertinent information that may be helpful viewing it on the
Video Display Area.
Configure Network Cameras – Connect to and configure cameras that are available
on the network the NVR is connected to.
31472A 37B
CAMERA SETUP
Select Camera Selects the camera to be edited.
Selected Camera Display – Displays the live camera feed from the camera selected.
Sensor Connection – Sepecify which sensors are currently in use
Camera Name – Specify a name for each camera.
Define Camera Name
Selected
Camera
Display
38
NETWORK VIDEO
Connecting a Network Device
Connecting Manually
1. From the Live View . screen, click Setup
2. Click Network Video.
3. Select your network device from the Device Type list.
4. Type a Device Name.
5. and Type the IP/URL address, , Port# User ID Password of the device.
6. Click Add.
7. Click Apply.
8. Proceed to Assigning a Network Device to a Channel.
Connecting with Find Cameras
1. From the Live View . screen, click Setup
2. Click Network Video.
3. Click Find Cameras to automatically find all connected Network cameras.
4. Select the check box next to the desired camera.
5. and Type the User ID Password of the device.
6. Click Get Device.
7. Click Apply.
8. Proceed to Assigning a Network Device to a Channel.
31472A 39B
Assigning a Network Device to a Channel
1. From the Live View . screen, click Setup
2. Click Network Video.
3. Click the Channel Setup tab.
4. Click an available channel on the Channel List.
5. Type the desired Position Name.
6. On the Select Device list, select the appropriate network device added previously.
7. If the device has PTZ capabilities, select the check box to enable.PTZ Camera
8. If the device displays wide screen video, select the check box to allow it to display properly.Wide Screen
9. If supported, select the check box.Use Network Camera Motion Detection
10. Select Intensive Motion, Intensive Sensor, and/or to increase the recording rate on an event.Intensive Instant
11. Click Apply to save your selections.
40
Assigning Audio Channels to a Network Device
1. From the Live View screen, click Setup.
2. Click Network Video.
3. Click the Audio Setup tab.
4. Click an available channel on the Channel List.
5. On the Select Device list, select the appropriate network device added previously.
6. To record the network audio, select the Record Network Audio check box. The recorder will record incoming audio from the
selected camera and the audio channel will be available on the search screen.
7. To access the audio channel from the Live View screen, select the check box. This will Enable Network Video in Live View
allow users to listen to live audio from compatible connected cameras.
31472A 41B
Assigning Dual Streams
Dual stream support enables you to take advantage of two different streams from an IP camera. One stream can be high definition
forensic video, while the other stream can be a lower resolution for live display. This allows for SCS or Remote to display more cameras
while utilizing lower bandwidth and less CPU usage.
The second stream is used for motion detection in the server, which lightens the processing load for centrally managed motion detection -
configurations. Dual Stream can be configured to allow for the continued use of Hot Spot when desired.
Dual streaming functions are limited to cameras that support this feature.
1. From the Live View . screen, click Setup
2. Video Click Network .
3. Click the Channel Setup tab.
4. Click an available channel on the Channel List.
5. Type the desired Position Name.
6. On the Select Device list, select the appropriate network device added previously.
7. and drop down If the device has dual streaming capabilities, choose the appropriate streams in the Main Stream Sub Stream -
menus.
8. Click Apply to save your selections.
42
Camera Configuration
The Camera Configuration tab displays information on all cameras connected to the Surveillix recorder.
Note - The maximum bit rate with a non RAID recording solution is 90 megabits per second.
Disable/Enable Live Video
To disable the live view of a network device (to conserve resources), unselect the check to the left of the Camera Name. The
camera channel will display “Non Decoding Mode Enabled” on a black background-
To enable the live view of network device, select the check box next to the Camera Name that you want available for live video
display.
Displaying More Columns
The Camera Configuration tab can be customized to display the information you use most. Click to add or remove Select Column
specific columns.
Capture FPS IP Address Codec
Record FPS Port Number Quality
Schedule Resolution PTZ
Manufacturer Record FPS
Model Frame Rate
31472A 43B
Accessing the Configuration Menu
Use the Surveillix interface to access basic network device menu functions.
1. From the Live View . screen, click Setup
2. Click Network Cameras.
3. Click the Camera Configuration tab.
4. Highlight the desired camera.
5. Click Setup Network Device.
Upgrade and Registration
Have the following information available before registering the recorder upgrade.
Product Serial Number: This may be the Product Serial Number displayed on the product sticker on the left side of the recorder; or the the
unique Product Serial Number provided with the purchase of additional channel linceses.
System ID: The System ID is a number that is generated by the Surveillix unit. This is a unique code generated using the MAC address of
the recorder.
Locating the System ID
1. From the Display . screen, click Setup
2. Click Network Cameras.
3. tab. Click the License
44
Obtaining the Unlock Code
1. Open an Internet browswer and go to http://register.surveillixdvrsupport.com
2. Type the Product Serial Number that was provided by Surveillix.
3. Type the generated by the recorder.System ID
4. Click Submit.
5. Verify the information.
6. Click Next if the information is correct.
7. Once validated, you will be provided with the Unlock Code.
8. Print the page and save for later reference.
31472A 45B
MOTION SETUP
The recorder the user to adjust several different Motion Settings and create motion detection areas. allows
Create a Motion Area
1. From the Display screen, click Setup.
2. Click Motion.
3. Select a camera from the Select Camera list.
4. Select the check box.Detect Detail Motion Area
5. Click Clear.
6. Click Advanced Motion Area Setup.
7. a Click Motion Detection Area shape button.
8. Drag the mouse over the camera image.
Note To create a polygon shape, click the mouse at each point and double-click to close
the shape.
9. Click OK.
10. Move the sliders to adjust motion sensitivity and the noise filter.
11. Define the pre alarm and post alarm recording time for a motion event.- -
Pre Alarm – - 0 120 Seconds [The number of seconds the recorder records before motion is detected to ensure any motion occurring
between I frames is captured, set to a value greater than 0]-
Post Alarm (MOTION) – - 0 120 Seconds [The number of seconds the recorder records after it stops detecting motion]
Regular Interval Recording
Regular Interval Recording allows users to record a single frame every fiew minutes or hours when there is no motion. This option is only
available when Motion recording or Sensor recording is selected in the recording schedule.
Note Regular Interval Recording is only supported by the MJPEG codec. See Frame Setup for more information on selecting the
recording codec.
To enable Regular Interval Recording:
1. Select the Regular Interval Recording check box.
2. Specify how often to capture an image when no motion is occurring. Users can capture as few as one image per second.
Display full scree
video pop up o
motion even
Beep on motio
event
Display full scree
video pop up on senso
event
Reduces Analog Signal Noise from Motion Dete
46
GENERAL SETUP
Display
IP Camera Key Frame Decoding
This will only show key frames (I ) in the live view in order to reduce the CPU load. Enabling this fun does not impact -frames ction
recorded or remote streaming video.
Use Full Screen
Stretch the Surveillix interface to use the full monitor screen based on the resolution set in Windows.
Display Size
Select from available monitor display sizes. Use to correctly display video on wide screen monitors.
Function
Beep on Login Fail
Enables the to beep continuously in response to a failed login attempt. Only an authorized login will stop the beeping.recorder
Sequence Setting
Allows the video out picture to automatically cycle through channels at a set speed. Ex : .Cycle through channels 1ample -6 at four second -
intervals.
Dual Monitor
Enable a second monitor connected to the recorder. See for complete instructions. Connecting a Second Monitor
Hybrid Sensor Setup
This interface is used to link Hard Contact Sensor Inputs from supported Network Devices to the recorder software.
31472A 47B
Voice Warning
The er allows record users to play a sound file when either a Motion event or Sensor event occur . This file can be a custom created s
sound file that is unique to application. The selected WAV file is played through speakers attached to the the recorder.
1. Click the Open Sound File icon to browse for a WAV file. The selected file will display in the box on the left.
2. Click the Test icon to verify the audio file.
3. Select and/or Motion Event Sensor Event to trigger the audio file.
Connecting to a Wide Screen Display
1. Click Exit on the Display screen and select Restart in Windows Mode.
2. Right -click the Desktop and select Screen Resolution.
3. From the Resolution list, select the proper solution of the connected display.
Tip Refer to the display documentation for the proper resolution settings.
4. Click Apply, confirm the change, then click OK.
5. Double -click the Surveillix Server icon on the Desktop.
6. Click Setup on the Display screen and then click General.
7. Under Display Settings Use Full Screen, select .
8. Click Apply . then click Exit Setup
Connecting a Second Monitor
All recorders can support two connected monitors. If a second monitor is connected to the recorder, follow these steps to enable the Dual
Monitor settings.
1. Click Exit on the Display screen and select Restart in Windows Mode.
2. Right -click the Desktop and select Screen Resolution.
3. Click the secondary display screen and from the Multiple displays list click Extend these displays.
Tip If a second display is not shown click ; if the second display does not appear, verify that the second monitor is properly Detect
connected.
4. Click Apply, confirm the change, then click OK.
Tip Refer to the display documentation for the proper resolution settings.
5. Double -click the Surveillix Server icon on the Desktop.
6. Click Setup on the Display screen and then click General.
7. Under Function, select Dual Monitor.
8. Click Apply . then click Exit Setup
Volume
The volume control allows fine tuning of the volume settings on the recorder.
Volume Options:
Device/Speakers – . Used to adjust the volume for all sound coming from the system’s speakers
System Sounds – Used to adjust the volume for the system sounds exclusively.
Open Sound Fil
Test
48
Hybrid Sensor Setup
This interface is used to link Hard Contact Sensor Inputs from supported Network Devices to the recorder oftware. s
The Network Device List is a list of available IP camera devices that have sensors enabled. When a device is selected, the lower table will
populate with a list of the sensors for the device.
Click the arrow next to a sensor or relay to display the number of the sensor on the recorder. You can then associate a sensor
or relay from the recorder with a sensor or relay on the network device.
31472A 49B
Auto Sequence Setting
Auto Sequencing is available either in the Display screen when Auto Sequencing has been enabled. Auto Sequencing conveniently
displays video channels at specified intervals and sequences through each selected channel.
Custom Mode
Create non standard screen division layouts.-
Skip 0 FPS Channel
Sequence skips th no video signal.cameras wi
Create Custom Auto Sequence
1. From the Display screen, click Setup.
2. Click General.
3. Click Sequence Setting.
4. Click individual cameras in the left pane or click to include all cameras in the sequence.Select All
5. Select an Interval time (in seconds) to display each screen in the sequence.
6. Select screen division options for appropriate cameras.
7. Click OK, click Apply, then click Exit Setup.
Enable A
Cameras
Enable
Sequencing
Select interval betwee
switching camera
50
SCHEDULE SETUP
Recording Schedule
The Recording Schedule to create different recording schedules based on the day, time, and type of recording window you allows
desired. In addition, this window contains the System Restart options.
Single Day Selection / M
Day selectio
Create Special Da
recording schedule
Recording schedule window
Emergency IP setup
Recording mode options
31472A 51B
Sensor Schedule
The Sensors will supersede all other types of recording modes (Motion and Continuous). Regardless of the recording schedule of a
particular camera, if a sensor event occurs the associated cameras will begin recording as a Sensor Event. Sensor Recordings will be
flagged and searchable using the Index Search Mode. Cameras are associated to sensors in the Camera Setup menu.
Create a Recording Schedule
Select a day to begin creating the schedule for , enabling , to create the same - - or click Single Day Selection Multi Day Selection
schedule for multiple days.
Highlight the locks within the Time-B Recording Schedule -window for the camera(s) selected to schedule. Once the desired Time Blocks
are highlighted, Recording Mode The Time Blocks should now appear Blue for Motion, Yellow for Continuous and White for click a button. -
No Recording.
Note Leave cameras recording with Sensor Detection set to No Recording for the specified time block(s).
Create a Sensor Schedule
Click Schedule and then and then select the Sensor option. Select a single day or click Single Day Selection to include multiple days in
the schedule.
Highlight the locks within the Time-B Recording Schedule window for the sensor(s) to enable and schedule. Once the time blocks are
highlighted click . The time block will now appear red.Enable
Single Day Selection
Multi Day selecti
Create Special Da
Sensor schedules
Sensor schedule window
Emergency IP setup
52
Scheduling Alarm Events
There are three types of Alarm Events:
ALARM EVENT: This option logs the Alarm Events on the local server.
CENTRAL STATION: This option sends a Map Alarm to SCS.
EMERGENCY AGENT: This option sends the Alarm Event to the Emergency Agent software.
Motion can be designated as an alarm event. Often motion does not need to be treated as an Alarm event. For example: During work
hours, motion that occurs is expected and should not be treated as an alarm. However, after business hours, any motion that occurs
could be treated as an alarm.
1. From the Display screen, click Setup.
2. Click Schedule.
3. Select either Recording or Sensor.
4. Highlight time blocks in the schedule that have been set to Motion (or Sensor Event) and click the desired buttons (Alarm
Event, Central Station, Emergency Agent). A corresponding letter will display in the selected time blocks.
Emergency Agent Schedule
Video recording triggered by motion or sensor events can be sent to the Emergency Agent software.
1. Enable the . (see Scheduling Alarm Events above).Emergency Agent Event
2. Enter the of a PC running the Emergency Agent software under Emergency IP.IP Address
3. Select the check box next to the IP Address to enable it. Only one IP Address is supported at a time.
4. e box. Enter the recording duration (in seconds) in th Emergency Time
Tip See the Emergency Agent chapter for detailed information on setting up the Emergency Agent software.
Special Day Schedule
You etc. can create days that have a unique recording schedule. For example: Holidays, Special Events,
Creating/Editing a ‘Special Day’ Schedule
1. Click Normal Day Mode to enable the Special Day Mode.
2. Select a day by typing the date or clicking the down arrow to select the date from a calendar.
3. Highlight the time blocks within the - Recording Schedule window for the camera(s) selected. Once the desired Time-Blocks
are highlighted, click a Recording Mode button.
4. When finished creating the schedule click Save Special Day.
N ote The special day should now appear as a date in the Special Day Schedule. To edit it, highlight it on the list and repeat steps 3 and
4 above.
Configured Special Days List
Special Day Mode / Normal Day Mode
Date Selector (Calendar)
31472A 53B
Deleting a ‘Special Day’ Schedule
1. Select a date from the Special Days list.
2. Click Delete Special Day.
System Restart Setup
Restart Setup allows you to define a schedule wherein the recorder automatically restarts according to specified parameters.
Create System Restart Schedule
1. From the Display screen, click Setup.
2. Schedule Click .
3. Click Restart Setup.
4. Select Enable for each day of the week that a restart is desired.
5. Specify the time of day to schedule the system restart.
6. Select either Restart . or Off
N ote If Off is selected, the recorder will shut down at the specified time but not restart.
7. Click OK, click Apply, then click Exit Setup.
54
NETWORK SETUP
Network Setup allows the user to adjust settings such as Ports, setup emergency PPP information for use with the Emergency Agent and
enable Remote Access.
View IP Address Displays the IP address of the recorder.
Transport Rate Throttles the bandwidth on the recorder. This option is based on percentages of images sent.
Resolution By setting the resolution low, the images will be sent faster. However, the image quality will be reduced considerably. When
set to Original, full quality video will be sent [720 x 480 (NTSC 720 x 576 (PAL)]. The Original Setting is very bandwidth-intensive.
Time Out Value When attempting to connect to the recorder, if the connection does not succeed during the timeout period (seconds), the
connection will be terminated.
Emergency Port Used to connect the Alarm Monitor software.with
Center Port Used to connect with the Surveillix r remote software (Remote, SCS, MDVR). This port must be specified in the emote
s oftware to connect to the recorder.
Note . Center Port 1025 is not available
Image Port Used to transfer the video to the remote software.
Search Port Used to transfer search information to the remote software.
Note If connecting to the recorder through a firewall, the above ports must be open to incoming and outgoing traffic.
Health Check Port Enables SCS to receive information regarding the health of the recorder.
Keyboard control Keyboard ControlSelect the Use - check box to enable use of a connected RS 232 PTZ Joystick/Keyboard.
Two-Way Audio Communication Select the Enable Audio Communication check box to enable two way audio between the DVR and -
SCS using a microphone connected to the DVR.
Use with Emergency Agent
Enable two-way audio between DVR
and Remote Client
Remote Client Ports
31472A 55B
ADMINISTRATIVE SETUP
Disk Management
The Disk Management window is a native Windows function. This window displays the partition scheme and health status of the Hard
Disk Drives in the recorder. This window is often used to troubleshoot a recorder, or verify the amount of Hard Drive storage installed. For
more information about Disk Management, consult a Windows 7 manual.
Select
Date
Select
Log
Export Log Data (1 to 7 day
Log Data Display
56
Setting Up DDNS
Dynamic Domain Name System (DDNS) is a service that provides a static address to simplify remote connection to the . This recorder
service is most useful for installations where the WAN (public) IP address is dynamic (changes from time to time). Most public IP
addresses are dynamic unless a static address has been specifically ordered from the internet service provider.
Enable DDNS
To enable this functionality of the , follow the steps below:recorder
1. Click Setup on the Display screen and log in as Administrator if prompted.
2. Administrative Click .
3. Click Program Management (ETC) and enter the Administrator password when prompted.
4. Click Show (to the right of Dynamic DNS Configuration).
5. Select Enable DDNS.
6. Enter the User Name, Password, and Hostname specified on the DDNS document
shipped with your recorder.
7. window. Click OK, then close the Program Manager
Note Ensure the recorder has an IP address by setting it statically. The Network settings may
need to be changed. If you are not sure of the correct values, contact the individual or
department responsible for network administration at the site.
Set the IP Address
The IP address of the recorder is set in Windows; to set the IP address follow the steps below:
1. On the Display screen, click Exit and choose Restart in Windows Mode.
2. Right -click My Network Places and click Properties.
3. On the General tab, click Internet Protocol (TCP/IP) . and then click Properties
4. Select Use the following IP address.
5. Enter values for the (these may be specified by the department responsible IP Address, Subnet Mask, and Default Gateway
for network administration).
a. IP Address: The first three sets of numbers should match the routers local IP address and the last set should
be a unique number between 1-254.
b. Subnet Mask: This should match the routers setting (commonly 255.255.255.0 for 192.X addresses and
255.0.0.0 for 10.X addresses).
c. Default Gateway: This is the routers internal IP address. Once DDNS is configured, the router the recorder
connects to will need to have port forwarding configured .
For further instruction on this process, visit http://www.portforeward.com/english/routers/port_forwarding/outerindex.htm
Once DDNS and port forwarding have been configured, the recorder will be accessible from any remote site by entering the HOSTNAME
into the address bar of Internet Explorer or the IP Address field in remote software.
31472A 57B
User Management
The User Management Console allows the administrator to create, edit, and delete user accounts. Each user account can be assigned
different privileges to limit the usage of the system. Users can be given administrator privileges by enabling all rights, however recorder
only the true administrator account can log into the User Management Console.
Note The Delete User . button immediately deletes the user use cautiously
Add a New User
1. From the Display screen, click Setup.
2. Click Administrative.
3. Click User Management.
4. Click Add User to open the User window.
5. and Enter a User Name Password.
6. Enable appropriate Permissions.
7. Selecting channels Camera or Audio will hide those channels from the
user.
8. Assign a User Rank.
9. Click OK, click Exit, Click Apply, Click Exit Setup.
Enable Auto Log
Off
Log Off Users who are inactive for the designaed
time (this settings affects all users).
58
User Rank
The User Ranking structure allows the option to assign a privilege who access the recorder remotely 10 where one has level to users (1-
the highest privilege For example Since only one user is allowed to use the PTZ controls at any one time, a user with a rank of 1 will ). :
kick a user outwith a rank of 2 of the PTZ controls.
The User Rank option affects:
SETUP ACCESS - The recorder software can only have one user accessing Setup at any given time. A user with a higher rank will kick
another user of the out Setup menu .
NOTE Changes made by a lower ranked user may NOT save when a higher ranked user kicks the lower ranked user out of the Setup
menu.
PTZ CONTROL - The recorder software can only have one user using the PTZ controls at any given time. A user with a higher rank will
kick another user out of the PTZ controls.
1. From the Display screen, click Setup.
2. Click Administrative.
3. Click User Management.
4. Enter the Administrator password and click OK.
5. box Select a user from the Select User and click Update User.
6. and Set the user s rank using the User Rank list click OK to save changes.
Changing the Administrator Password
1. Inside Administrative setup, click User Management.
2. When the prompt appears, click Change Password.
3. Enter the new password and click OK.
Default Administrator Password
The default administrator login is:
User: Administrator
Password: <blank>
31472A 59B
Log Management
The Log Management window provides you the options to overwrite log files or schedule g deletion.lo
Set U p Log Management Options
1. From the Administrative setup click Log Management.
2. Select Log File Overwrite Option to enable.
3. Select Overwrite o . r Do Not Overwrite
4. If Overwrite is selected:
a. Enter a maximum Log File Size.
b. Choose a number of days to keep logs (Delete Log File Older Than).
Note Log files can also be manually deleted. Simply select the log you want to delete on the bottom portion of the window, then click
Delete All.
5. Click OK to save the settings and close the window.
60
Status Check / Email
General
1. From the Display screen, click Setup.
2. Click Administrative.
3. Click Status Check/Email.
4. Select Enable Email Alarm.
5. Enter a and email From Name Address.
N ote This name and address will appear in the From line of email alert
messages.
6. Enter the SMTP information for the email account that will be used
to send emails from the recorder. Contact your administrator for this
information if necessary.
7. If using a secondary email account select Use Secondary SMTP
and complete the SMTP information.
8. Click Test to check settings (a test message will be sent to the
From Address).
9. then When you are finished, click Apply Close.
Users
1. Set up the General tab first.
2. Select the type of Event to send email on.
3. and Enter the User E-mail Address of a desired recipient.
4. Click Add.
5. Repeat for additional recipients and types of events.
Note A separate email notification for each type of event must be set up for a
single recipient to receive notifications for each type of event.
6. then When you are finished, click Apply Close.
31472A 61B
Storage Check
1. Set up the General and Users tabs first.
2. Select Use Storage Check.
3. Define the frequency of storage checks (in minutes).
4. Select an additional if desired: Alert Option Beep or Popup
Message.
5. Add a that will be seen in the email message if desired.Comment
6. then When you are finished, click Apply Close.
Recording Data Check
1. Set up the General and Users tabs first.
2. Select Recording Data Check.
3. Define the frequency of data checks (in hours).
4. Select the Action Method: Popup Message Alert Beep Alert, , or
Email Alert.
5. Add a that will be seen in the email message if desired.Comment
6. then When you are finished, click Apply Close.
SMART Information
The SMART Information tab displays Hard Drive information.
62
SMART Alert
1. Set up the General and Users tabs first.
2. Select Enable SMART Alarm.
3. Define the frequency of SMART status checks (in hours).
4. Select the type of SMART event to trigger an action.
5. If selecting for temperature checks, define the maximum HDD
temperature.
Note . Recommend 65˚C/150˚F if using Temperature Threshold
6. Select an Action Method: Beep Alert Popup Message Alert, , or
Email Alert.
7. Add a that will be seen in the email message if desired.Comment
8. When you are finished, click Apply . then Close
Alarm Event
1. Set up the General and Users tabs first.
2. Select Use Email Alarm.
3. Define the frequency to send email alerts (in minutes).
4. Select the Event Type: , Motion Sensor, No Signal ( ). video loss
5. Select With Detail Info to receive a still image attachment of the
associated camera in the email message.
6. Max Count defines the number of message that will contain detailed
data within the frequency time frame.
7. Add a that will be seen in the email message if desired.Comment
8. When you are finished, click Apply . then Close
MySurveillix
1. and Set up the General Users tabs first.
3. Select My Surveillix.
4. Select Use MySurveillix.
5. Define the to designate the time the recorder will Send Time
send updates to MySurveillix.
6. Enter a numeric if desired (this is an additional Security Code
security measure to prevent unauthorized users from adding
the recorder to their MySurveillix account).
7. Select Send notification to MySurveillix on alarm events if
you want the recorder to report alarm events to MySurveillix.
8. When you are finished, click Apply . then Close
31472A 63B
INFORMATION
The Information display allows users to define the site code necessary for connecting to remo0te software, save comments relative to the
recorder, store tech support and contact number information, and see the currently running server software version.
Site Code
A user specified unique identification name used by other software to . (Remote, Emergency Agent, - recorder identify the recorder SCS,
Digital Signature Verifier)
INSTANT RECORDING
The Instant Recording feature allows users to manually initiate recording on a specific camera, overriding the current schedule. When
Instant Recording is activated the recorder flags the clip as an event so Instant Recording instances can be found using the Index Search
Instant Recording can be used, for example, when a suspicious object or person is you want to flag that section of video for detected and
easy retrieval at a later date.
Activate Instant Recording
1. From the Display screen, right click the camera on which to enable instant recording and choose - Instant Recording (or
double right click). An INSTANT label will be placed on the upper right corner of the video.-
2. To turn the Instant Recording Option off, right click the camera and choose - Instant Recording (or double right-click).
Searching ‘Instant Recorded’ Video
1. From the Display screen click Search.
2. Click Index Search.
3. Select the Instant Recording . option See the Search chapter for more information.
User-Defined
Contact Numbers
Total HDD /Available HDD Space
User Entered
Comments
Currently Running
Server Software Version
64
SEARCH
This chapter includes the following information:
Search Overview
Daylight Saving Time
Index Search
Preview Search
Graphic Search
Motion Search
31472A 65B
SEARCH OVERVIEW
The recorder Motion/Sensor has several options that allow the user to easily search through, and find, a particular section of video. From
indexing to calendar views recorded video; the is equipped to help the user quickly find a specific video or highlighting days with recorder
event.
The following chapter describe how to use the Search features.s
Note Audio Channel buttons are only viewable when one camera is selected.
Play Controls
Back Frame Moves video back one frame
Rewind Rewinds video
Stop Stops video playback
Play Plays video
Forward Frame Moves video forward one frame
Rewind
Stop
Play
Back Frame
Forward Frame
Current Date/Time
Playback
date/time
Audio channels
Hour/Minute
control bar
Screen division buttons
Play controls
Camera select buttons
Calendar button
66
Adjust the Brightness of an Image
Select an image to adjust by clicking on the desired image. Multiple images cannot be adjusted at one time.double-
1. Move the Brightness slide bar to the right or left to adjust the brightness.
2. rightness by Reset the B moving the slider back to the center of the bar.
Zooming in on an Image
1. Select an image to adjust by double clicking on the desired image. Multiple images cannot be adjusted at one time.-
2. Move the Zoom slide bar to the right or left to zoom in or out of an image.
3. Reset the Zoom by moving the slider back to its original position on the bar.
Zooming in on a Portion of an Image
1. Right -click the area of interest on the image and select Zoom.
- - - or Double right click the image.
2. Repeat to zoom in further.
3. Continue clicking the right mouse button and the image zoom will cycle back to the original size.
Open Video from a Saved Location
Previously saved video clips or backup files can be searched for content. Find file by date and time or by name.
1. Click Open to search for the saved file.
2. Select a file from the list of saved clips and backup files or search by start hour.
3. Click OK to open the saved file.
Time Sync
The Time Sync option synchronizes a single channel of video to playback in real time. Ordinarily the video may playback slower or faster
depending on several factors, including how many recorded and number of cameras playing at the same time.IPS
1. Select a single image to synchronize by double clicking on an image.-
2. Click Time Sync. The video will now playback in real time.
Clean Image
The recorder is capable of recording video using one of three different resolutions. When using the 720 x 480 resolution, two fields are
mixed. Because of the timing gap between the two fields, according to the standardized image rules, after image might occur to high
speed moving images. The Surveillix . recorder allows the user to remove this by clicking Clean Image
31472A 67B
PERFORMING A BASIC SEARCH
There are several different types of searches that can be performed on the . The most basic involves selecting the daterecorder , time,
camera, and clicking play.
1. Click the Calendar button to select a date.
2. Select a time by clicking the up and down arrows to the right of the time display.
3. Click OK.
4. Select one or more cameras.
5. frame by frame. Click Play. Video can be played forwards, backwards, or - -
PRINTING AN IMAGE
1. Using the Search screen, locate a frame to print.
Note Only one camera can be selected at a time for this function to work.
2. Click Print. A Print Options window appears. Depending on the printer being used, there may be several printing options
available. Refer to the printer manual for more information.
3. Click Print to print the selected images.
Note The message NO DEFAULT PRINTERS INSTALLED will display if no printer is installed.
DAYLIGHT SAVING TIME
The recorder automatically adjusts for Daylight Saving Time changes. When the hour jumps forward” no video is lost because an hour is
skipped. However when the hour “falls back” there is a duplicated hour that under normal circumstances would be recorded over. The
Surveillix recorder actually records both hours and allows the user to select which hour to play if the need arises.
To access the ‘lost hour’:
1. button. From the Search screen, click the Calendar
2. Select the date when Daylight Saving time ‘lost’ an hour. The Daylight
Saving option appears.
3. To play back the ‘lost hour’, select Daylight Saving, select 02:00 (2AM)
for the time.
4. Click OK to confirm the date and begin playing the video using standard
search features.
68
SAVE TO JPG OR AVI
The recorder can export single images in a JPG Image file format and save video clips in an AVI format. Both JPG and AVI file formats
are the most commonly used graphical formats today. Virtually every computer offers some type of support for these file formats which
make them the most ideal formats to use. Only one camera can be selected at a time for this function to work.
Image JPG JPG Images can be exported in , PNG, or BMP formats. The -format is optimized for compressing full color or grayscale
photographic images compression, and will create a small file size). The format is designed to maintain more (uses lossy PNG
quality while still compressing color or grayscale photographic images (uses a lossless compression, and will crea a medium full-
file size). The format can be used for color or grayscale photographic images (uses little, or no compression, and will BMP full-
create a large file size). any of these options to export a single image or frame.Use
AVI -AVI image data can be stored uncompressed, but it is typically compressed using a Windows supplied or third party compression
and decompression module called a codec. AVI is used to export a video clip.
1. From the Search screen, click Save.
2. Select the Export Type: Image File AVI File (JPG, PNG, or BMP) or .
Image File
a) Selec t Quality (50-100). When size is not an issue, set the quality to 100.
AVI File
a) Although Enter the (in seconds) to save. duration suggestions are provided, a selection between 1 and 3600 can
be entered manually.
b) Select a Compression Codec. Each codec provides different levels of quality, compatibility and file-size.
c) Select Quality - 50>100. When size is not an issue, set quality to 100.
3. The digital signature is already entered, but can be changed if required.
4. Click Export.
5. Select a location to save the file, enter a name for the file, and click Save.
c. Clicking Cancel will exit the window without exporting file.
31472A 69B
Bookmarks
Use bookmarks to mark a video clip during a search. Export bookmarked data
using the Clip Backup feature.
1. Perform a search for the desired video.
2. Stop playback at the beginning of the desired clip.
3. Right -click the video and select Start Bookmark.
4. Click the Play button to continue playback.
5. Stop playback at the end of the desired clip.
6. Right -click the video at the desired end point and select End
Bookmark.
7. box. Type a name to identify the bookmark in the Title
8. Enter a memo or notes in the More Information box.
9. You may also select additional channels to include video at
different locations recorded at the same time.
10. Click Create.
Modify Bookmarks
You can modify a previously created bookmark to change the start or end
time of the clip, add additional comments, change the title, or add additional
cameras.
1. From the Search screen, click Bookmark.
2. On the calendar, select the date the desired bookmarks were
created.
3. Select the desired bookmark from the list.
4. Make the desired change.
5. Click Modify.
6. When the modification is complete, click Cancel to close the
window.
70
Clip Backup
Within the Save option, Clip Backup can also be utilized to backup a single
camera or multiple channels. The Clip Backup option gives you the ability to
choose a backup time frame, choose a specific camera or cameras, add
memos, and even include the Backup Viewer if needed.
1. From the Search screen, click Save.
2. Select the drive from the file tree to save data to (Hard disk drive,
removable drive (USB), CD/DVD drive).
3. Select desired cameras from the list.
4. and Define the Start End time and date that you wanted to backup.
5. Select Include Viewer to include a copy of the proprietary Backup
Viewer Software to view the clip on virtually any Windows
workstation.
6. Click Add Memo to include additional information.
7. Click Backup to start the backup.
Note If backing up to a removable USB device click the Unplug or Eject
Hardware button after backup is complete to safely remove the device.
Single Clip Backup Using Bookmark Data
1. From the Search screen, click Save.
2. Select the drive from the file tree to save data to. (Hard disk drive,
removable drive, CD/DVD drive).
3. Click Use Bookmark Data.
4. On the calendar, select the date the desired bookmarks were created.
5. Select the desired bookmark from the list.
Note To include multiple bookmarks in a clip backup, select the Multi Backup
check box before selecting the desired bookmarks.
6. Select BV Copy to include a copy of the proprietary Backup Viewer
software to view the clip on virtually any Windows workstation.
7. Click Start Backup to start the backup.
Note If backing up to a removable USB device click the Unplug or Eject
Hardware button after backup is complete to safely remove the device.
31472A 71B
INDEX SEARCH
Using the Index Search can greatly decrease the amount of time spent searching through saved video. The Index Search allows you to
perform a search based on criteria such as Sensor, Motion and Instant Record events.
Performing an Index Search
1. Click the Calendar button on the Search screen to select the date to
search.
2. Click Index Search.
3. Select the cameras and sensors to include in the search.
4. Select the Select Time check box to define a specific period.
5. type Select an event to search (Sensor, Motion, Instant Record) or
select the All Event option.
6. Results Click OK. There may be a delay while results are returned.
will be displayed in a column on the side of the screenright – Each
line represents a segment of video. If no results are found, “NO
IMAGE FOUND” will appear in the column.
7. Once the results are displayed, double any one to play the - click
associated video.
8. Once the desired image is found, apply it to the Main Search by
clicking Close at the bottom of the results column.
Index Search Results Display
Image Display Area
Time Event Occurred
Event Recorded on Camera #
Event Type:
M – Motion
S – Sensor
IR – Instant Record
72
PREVIEW SEARCH
Preview Search can be used in a number of circumstances to quickly find an exact moment where an event, such as a theft, occurred.
The Preview Search gives a 24 Hour visual overview of a single camera by separating a 24 hour period (1 day) into 24 images, one
image for each hour of the day. The search can then be further narrowed down into ten minute increments and one minute increments by
selecting one of the images displayed.
These example images show how the Preview Search functions.
The first screen that appears has 24 images displayed. Each image represents the first second of recorded video in each hour. If there is
no image recorded during that period then nothing will be displayed.
When an hour is selected (by ing on the image), a new screen appears with 6 images. Each of these images represents double click the
first second of video for a 10 minute segment of video within the selected hour.
Once a 10 minute segment is selected (by double clicking on the image) the final screen appears which breaks down that 10 minute -
segment into 1 minute increments (10 images).
31472A 73B
Performing a Preview Search
1. Select a single camera channel.
2. Click Preview. 24 images display. If there is no recorded video during a portion of the day, “No Image” will be displayed where
the image would be.
3. Refine the search by double clicking on an image to select it. 6 images display. If needed, return to the previous 24 image view - -
by double on any image.-right- clicking
4. Refine the search clicking on an image to select it. 10 images display. If needed, return to the previous 6 image view by double- -
by double clicking on any image.-right-
5. Double -click an image to select the 1 minute segment of video to play. A single image displays. If needed, return to the -
previous 10 image view by double clicking on the image.- - -right
6. Use the controls to play the video of the selected segment.Play
7. again. To exit out of the Preview search with the current image still selected, click Preview
GRAPHIC SEARCH
The Status Search option displays video in graph format.
Performing a Graphic Search
1. Click Graphic Search on the Search screen.
2. Click the calendar icon to select a day.
3. displayed Click on an area of the blue recording block. Only one camera can be at a time.
Note Each recording block represents a 10 minute time frame.
4. Recorded video from the corresponding camera and time block will display above.
5. Use the mouse or arrow buttons to move through recording blocks and view video.
6. again. To exit out of search with the current image still selected, click Status Status
Cameras
Recording Block
H - ours 0 23 (24 hours)
74
OBJECT SEARCH
Object Search is a powerful search utility that is used to search a region on the video for any motion changes. Results are neatly
displayed and can be viewed quickly.
Performing an Object Search
1. Select a single camera channel.
2. Click Object Search.
3. Click and drag the mouse on the video display to define a motion region area. Resize by pulling on the small square boxes
located on the outer perimeter of the area.
4. Click Start Search Search Filter, the Object Information
window will open
5. date/time Select an End .
6. Adjust the sensitivity if necessary.
7. Click OK.
8. Select a motion event from the search results list
displayed on the right
9. Click Apply to Main Search to display the selected image
in the main screen and to use play controls.Search
10. To start a new object search using the original image,
click Reload First Frame.
11. To exit Object Search without selecting an image, click
Cancel.
31472A 75B
MOTION SEARCH
The Motion Search provides a dynamic display of the levels of motion in recorded video. Adjust the level of motion to only play clips of
video at or above that level.
To enable motion data to be saved for Motion search, ensure that you select the following settings:
1. On the Motion setup page under Motion Regions, select Detect Detail Motion Area.
2. Display On the Gen setup page under eral , select Motion Detect on Continuous Recording.
Note Motion Search is only available for newly recorded video; it is not compatible with video recorded prior to installing version 3.6.
Performing a Motion Search
1. Select a single camera channel.
2. Click Motion.
3. Click the calendar icon to select a day.
4. Adjust the motion level line.
5. Adjust the timeline display settings.
6. Click the play button to start playback.
7. again. To exit out of search with the current image still selected, click Motion Motion
Tip You can drag the blue line on the Timeline or motion level box to adjust the time.
AUDIO PLAYBACK
Audio is played back at 48,000Hz.
To play audio with the video:
1. Select a single camera channel. The audio options will be displayed in the lower right.
2. Select a single audio channel to play. When an audio channel is selected, the button will be automatically selected.Time Sync
3. Click Play.
Camera Information
Timeline
Motion Tolerance Level
76
SEARCH IN LIVE
The Search in Live feature allows users to review events immediately while monitoring live video. Pause, rewind, and resume live video
within seconds of an alarm event or suspicious activity.
1. Move the mouse cursor over the desired live video display on the Live Display screen.
2. Right -click and choose (or click the scroll wheel on the mouse).Search In Live
3. The Search In Live controls will display at the bottom of the image.
4. by Use the controls to pause, rewind, move frame- -frame or resume playing as desired.
5. To exit Search in Live, right click the camera channel again and choose (or click the scroll wheel on the - Search In Live
mouse).
31472A 77B
PAN / TILT / ZOOM
This chapter includes the following information:
Overview
Setting up the PTZ
Creating and Viewing a Preset Position
Creating and Viewing a Preset Pattern
78
PAN /TILT / ZOOM OVERVIEW
The PTZ controls within the recorder allow for powerful control over the cameras. This can be extremely beneficial to you by increasing
the usefulness of the recorded video. Using the PTZ controls, you can create custom preset configurations that can continuously sweep
across large areas.
Note - - PTZ setup and control is only available for supported video encoders with a PTZ RS 485 pass through.
Enable the PTZ Settings
1. Inside the recorder PTZ Setup, select the PTZ camera using the Camera Channel list.
2. Enable the PTZ functio s of the camera by selecting the check box.n Enable Pan/Tilt
3. Select the appropriate Protocol and set the PTZ Driver Address and Serial Port Settings (See Advanced PTZ Setup in this
chapter).
Note rThe majority of major PTZ manufactu er protocols are included in this software. Refer to the Supported Protocols list in this
manual.
4. Click Apply, then click Exit.
5. Display From the screen, click . The PTZ Controller will open.PTZ
6. Select the PTZ camera to control by clicking on the display screen. The camera number will appear inside the PTZ controls.
7. You can now move the PTZ camera using the PTZ controls.
ADVANCED PTZ SETUP
Note Preset and tour options may vary depending on the camera
Adjust Speed Settings
Connection Settings
31472A 79B
Creating and Viewing Preset Positions
A Preset Position is a user defined location where the camera can be pointed, zo in, and focused. Preset postions can be defined - med-
and labeled if the camera supports this.
Creating a Preset
1. Inside Setup, click and select the camera. PTZ
2. If the camera is already selected, click Open PTZ Controller.
3. Move the selected camera to the desired position using the Pan/Tilt/Zoom/Focus controls.
4. In the section, choose a 10) using the list or the Right and Left Arrow buttons and click Preset & Tour Detail Preset # -(1
Select.
Note Preset positions can be created using the advanced buttons on the PTZ graphical controller.
Viewing a Preset
1. From the Display screen, select the PTZ camera by clicking on it.
2. Using the keyboard, click the number keys corresponding with the Preset Positions. The camera will move to the saved Preset.
PTZ Address Settings
Some protocols support software address settings.
The RX- Addresses and ID settings are compatible with a particular line of receivers that support 2 ID addresses.
The PT Driver Address is associated with the PTZ ID address set on the camera. The addresses must match for the recorder
to communicate with the proper PTZ camera. This is especially important when a large number of PTZ cameras are connected
to the recorder.
Note - To select a PT Driver Address of 129 256, manually enter the ID in the box.
ACCESSING PTZ MENUS
Some protocols support the ability to access the Internal PTZ Onscreen menu.
Since every PTZ camera is different, the function of these options can vary slightly.
The Surveillix recorder provides an easy way to access the camera options. For explanations of what those options are, please
refer to the user manual for the camera.
Note Use the arrow buttons on the PTZ controller to move through the PTZ menu options and/or highlight options.
80
CONTROLLING A PTZ CAMERA
Surveillix a recorders provide control for PAN/TILT/ZOOM camera in two
different ways.
Use the Graphical PTZ Controller that appears when the PTZ button
is clicked on the Display screen.
Use the mouse to control the camera directly from the live video
display (On reen Compass)-Sc
Using the Graphical PTZ Controller
1. Use the Arrow buttons to control the direction of the PTZ camera.
2. To select a new camera, click the video display of a different camera
on the Display screen display.
Note Eight directions are available only for select . Only four of the cameras
PTZ Control buttons work for all protocols (UP, DOWN, LEFT, RIGHT).
Note The Advanced menu panel on the graphical PTZ controller can be used
to set PTZ preset positions (on supported cameras), as well as move to
presets up to 254.
Using the On-Screen Compass
1. Click Setup on the Display screen.
2. Click PTZ.
3. Select the check box to enable the On Screen Compass
feature.
4. Click Apply.
5. Click Exit to return to the Display screen.
6. Click PTZ.
7. Control the PTZ by dragging the mouse on the screen in the
desired direction.
Note A green line will appear to show the direction in which the PTZ
camera will move. The shorter the line, the less the PTZ will
move. The longer the line, the more the PTZ will travel in the
specified direction.
Opens & Closes
the Advanced
Panel
Displays
Current
Camera
Channel
Arrow buttons
Move To
Preset
Positions 1- 10
Set Presets, and
Move to Presets
11- 254


Product specificaties

Merk: Toshiba
Categorie: Server
Model: NVSPRO8
Kleur van het product: Zwart
Gewicht: 26762 g
Breedte: 668.8 mm
Diepte: 430.5 mm
Hoogte: 175.3 mm
Soort: NAS
LED-indicatoren: Fan fail, Power
Inclusief besturingssysteem: Windows 7 Embedded
Ethernet LAN: Ja
Aantal USB 2.0-poorten: 8
Aantal HDMI-poorten: 1
Aantal Ethernet LAN (RJ-45)-poorten: 2
Intern geheugen: 4 GB
Meegeleverde software: Surveillix VMS
Ethernet LAN, data-overdrachtsnelheden: 10,100,1000 Mbit/s
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A: 2
Soort optische drive: DVD±RW
Ondersteunde netwerkprotocollen: TCP/IP, UDP, Internet
Type behuizing: Rack (4U)
Opslagdrives geïnstalleerd: Ja
Geïnstalleerde opslag-drive: HDD
Capaciteit opslag-drive: - GB
Totale geïnstalleerde opslagcapaciteit: 48 TB
Maximaal ondersteunde opslagcapaciteit: 24 TB
RAID support: Ja
Soorten RAID: 5
Aantal eSATA-poorten: 1
Wifi: Nee
AC-ingangsspanning: 100-240 V
AC-ingangsfrequentie: 50 - 60 Hz
Stroomverbruik (typisch): 340 W
Ingebouwde optical-drive: Ja
Ondersteunde types opslag-drives: HDD

Heb je hulp nodig?

Als je hulp nodig hebt met Toshiba NVSPRO8 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden




Handleiding Server Toshiba

Toshiba

Toshiba NVSPRO8 Handleiding

14 Februari 2023
Toshiba

Toshiba NVSPRO Handleiding

25 November 2022

Handleiding Server

Nieuwste handleidingen voor Server
