User's Manual
Benutzerhandbuch
Mode d’emploi
Manual del usuario
Manuale dell’utente
Manual do Utilizador
安裝說明書
用戶手冊
ユーザーズマニュアル
Руководство пользователя
kullan c elkitabı ı ı
(EEE Yönetmeli ine Uygundur)ğ
คู่มือการใช้
view
2
2
2
22 1
1
1
1 1
T
T
T
TT G
G
G
GG
Join Tt Community To Receive Benefits
Tt LCS-Liquid Cooling Support Certification
Dear Valued Customer,
Thank you for choosing Thermaltake.
As a new user we value your thoughts and opinions and
your feedback is important to us. We at Thermaltake
would like to use this opportunity to invite you to join our
Community Forums. Register today to start enjoying the
full benefits of our community.
Benefits of being a member:
Quick and responsive user support
Receive help and advice with new builds
Keep up to date with new product releases
Share your thoughts and builds with the community
Enter monthly contests and giveaways
Tt LCS Certified is a Thermaltake exclusive certification
applied to only products that pass the design and
hardcore enthusiasts standards that a true LCS chassis
should be held to. The Tt LCS certification was created
so that we at Thermaltake can designate to all power
users which chassis have been tested to be best
compatible with extreme liquid cooling configurations to
ensure you get the best performance from the best
features and fitment.
Brand official website
http://www.thermaltake.com/
Global Facebook
https://www.facebook.com/ThermaltakeInc
Taiwan Facebook
http://www.facebook.com/ThermaltakeTW
Global community forums
http://community.thermaltake.com
Chapter 1. Product Introduction
Specification
Accessory
Warning and Not ice
1.0
1.1
1.2
01
01
02
Co ntents
Chapter 2. Installation Guide
2.0
2.1
2.2
2.3
2.4
2.5
2.6
Side Panels Disasse mbly
Power Supply Unit (PSU) Installation
Motherboard Installation
3.5" & 2.5" HDD Installation
PCI Card Installation
Air Cooling Installation
Liquid Cooling Installat ion
04
05
06
07
09
10
11
Chapter3 Leads Installation Guide
Case LED connection
USB 3.0 con nection
Audio connection
3.0
3.1
3.2
13
13
13
Specification
Accessory
4
Case Fan
Figure Parts Name
Screw 6-32 x 6mm ＃
Power Rear Holder
Q'ty
8
16
20
1
1
Used for
Cable Management
Power
Buzzer
2.5”HDDScrew M3 x 5mm
Mid Tower
Radiator Support
4mm Tempered Glass x 2 (Left & Right)
SPCC
Case Type
Dimension (H*W*D)
Side Panel
Material
Fan Support
Clearance
CPU cooler height limitation: 160mm
VGA length limitation: 410mm
PSU length limitation: 220mm
Front:
3 x 120mm, 2 x 140mm
Top:
1 x 120mm, 1 x 140mm
Rear:
1 x 120mm
Bottom:
1 x 120mm
492 x 208 x 471mm (19.4 x 8.2 x 18.5 inch)
Front:
1 x 360mm, 1 x 280mm
Rear:
1 x 120mm
Color Exterior & Interior : Black
USB 3.0 x 2, HD Audio x 1
I/O Port
Drive Bays
-Accessible
-Hidden 2 x 2.5’’ ; 2 x 2.5’’2 x 3.5’’ or
Screw 6-32 x 6mm ＃
17 Motherboard, 3.5”HDD
Screw T5 x 10mm
Movable tie
Power Rear Holder
Buzzer
1
