Pagina 1/13
INSTRUCTION
MANUAL
Thank you very much for purchasing our “HOT&COOL
CONVERTIBLE
CABI.”
CAUTION : Read the instructions before using the machine.
(2103D)
HC-11LX Pro
Single-phase 220-240V 50-60Hz
125W
Ｃool ：
7 - 10℃ (when ambient temperature is 25℃)
Peltier element
Ｗ450ｍｍ×Ｄ363ｍｍ×H322ｍｍ
10 kg
1×basket, 1×drain tray
The specifications or appearance are subject to change without notice.
Contents
■Product Specifications････････････････････････1
■Safety Precautions･･････････････････････････2-5
■After-Purchase Servicing…･････････････････5
■Purpose of Use･････････････････････････････････6
■Operational Mechanism･･････････････････････6
■Designation of Parts･･･････････････････････6-7
■Checking Prior to Use and Setting････7-8
■
Sequence of Usage･･･････････････････････････9
■After Use and Maintenance･･･････････････10
■Troubleshooting･･･････････････････････････････11
■Circuit Diagram･････････････････････････････････12
－1－
Product Specifications
HC-21LX Pro
250W
Model
ＨＣ-１１ＬＸＰｒｏ
ＨＣ-２１ＬＸＰｒｏ
Ｗ450ｍｍ×Ｄ363ｍｍ×H562ｍｍ
Ｗ348ｍｍ×Ｄ207ｍｍ×H152ｍｍ Two sets of Ｗ348ｍｍ×Ｄ207ｍｍ×H152ｍｍ
17 kg
2×baskets, 1×drain tray
11Ｌ (approx. 55 hand towels) 22Ｌ (approx. 110 hand towels)
Rated voltage
Power consumption
Model
Temperature
Cabinet dimensions
Inner box dimensions
Cabinet capacity
Weight
Accessories
Manufacturer
Country of manufacture
TAIJI & CO., LTD.
Japan
CONVERTIBLE CABI
Temperature control Microcomputer control
Ｈot
： 70 - 80℃ (when ambient temperature is under 30℃)
Heating and cooling system
HOT&COOL
Original Instructions
－2－
■
What precautionary measures should be abided by are expressed by certain marks
and explained as follows:
(2) Absolutely should not be disassembled, repaired, or modified
by anyone other than a repair technician. Could result in
ignition or abnormal performance.
Disassembling
forbidden
WARNING
(３) Do not immerse in or douse with water. Such could result in
electric shock or short-circuit.
Dousing
with water
forbidden
(1) To be set upon a stable and flat location and not to be
moved while plug is connected to power source. Could
result in abnormal performance.
Attention
required
for setting
(４) Periodically confirm that the plug contacts are kept clean
and that they are firmly inserted in the power outlet.
Dust accumulation or imperfect contact could be the cause
of an electric shock or fire.
Inspect
and clean
Safety Precautions
WARNING
CAUTION
What is assumed to possibly result in death or serious injury.
What is assumed to possibly result only in bodily injury or physical damage.
■
Please peruse these “Safety Precautions” carefully so that you can use your
product in the proper way.
■
Please keep these “Safety Precautions” handy for future reference after being read.
■
Precautionary measures referred to herein are matters which should be abided by for
safe use and to prevent harm and/or damage being inflicted on yourself or others.
Furthermore, the particulars of the precautionary measures have been classified into
“Warning” and “Caution” to express the degree or extent of conceivable harm
and damage which can be assumed to occur from mishandling. They are both of
importance as far as safety is concerned and should be strictly abided by.
△
indicates “Warning and caution is urged.”
(The one on the left indicates beware of electrical shock.)
　 indicates “Forbidden.”
(The one on the left indicates disassembling forbidden.)
●
indicates “Instructions” which should be followed by all means.
(The one on the left indicates grounding is a requirement.)
Many loads
on one
electrical
outlet
forbidden
(５) Ensure power source is from dedicated outlet of at least 15A.
Using branch sockets could be the cause of abnormal heat,
fire, etc.
－3－
(１０) Do not touch or manipulate electrical parts such as the plug,
power source switch, etc. with wet hands. It could be the
cause of an electric shock.
Wet hands
forbidden
WARNING
Outdoors
forbidden
(１１) Do not use outdoors. Using the product where there is
rainfall could cause electric leakage and/or electric shock.
Grounding
connection
(1４) Ensure grounding is connected.
Imperfect grounding could lead to electric shock.
Discarding
forbidden
(１２) Discarding of this product should be requested of
specialized contractor, public agency, or the distributor from
where the product was purchased. (A disposal fee is usually
charged.) Discarding it at random could result in third party
remodeling, using it for purposes other than as designed,
which could result in an unexpected accident.
Forbidden
(８) Do not intentionally bend plug contacts to prevent the plug
from dropping out of the electric outlet. Imperfect contact
could be the cause of fire.
Attention
required
for using
(１３)This appliance can be used by children aged from 16 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
- Children shall not play with the appliance.
- Cleaning and user maintenance shall not be made by
children without supervision.
(９) In the event of abnormal odor or sound, emission of smoke,
or in case water or a foreign substance should enter the
cabinet, switch off the unit immediately and remove the plug
from the electric outlet. Such could possibly lead to an
electric shock and outbreak of fire.
Removing
plug
→
(６) Handle the power cord with care.
In case the power cord is processed, pulled, bundled, or a
heavy item is placed upon or squeezes it, the cord is apt to
be damaged and could cause an electric shock or fire.
The power cord should not come into contact with a heat
source.
Forbidden
(７) The appliance shall be disconnected from its power source
during service and when replacing parts.
The removal of the plug has to be such that an operator
can check from any of the points to which he has access
that the plug remains removed.
Removing
plug
→
