SUPERMICR R
ContaCt nformatIon I
• Manuals: http://www.supermicro.com/support/manuals
• Drivers & Utilities: https://www.supermicro.com/wdl/driver/
• Safety: http://www.supermicro.com/about/policies/safety_information.cfm
© 2024 Supermicro Computer Inc. All rights reserved. Reproduction of this document whether in part or in whole is strictly prohibited without Supermicro's written
consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing; however, it is not guaranteed.
P CaCkage ontents
X14saZ-tLn4f/f
Q r g 1.0uICk eferenCe uIde 0
• One Supermicro Motherboard
• One Quick Reference Guide
• One I/O Shield
• Four SATA Cables
• Website: www.supermicro.com
• General Information: marketing@supermicro.com
• Technical Support: support@supermicro.com
• Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008
F or your system to work properly please download appropriate,
drivers images user s manual From the links below/ / ' :
MNL-2741-QRG-100
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!
IPMI CODE
MAC CODE
MAC CODE
X14SAZ-F
REV:1.00
DESIGNED IN USA
A
C
CA
A
CA
C
C
MB S/N
BIOS LICENSE
BAR CODE
JPW3
JPW2
JTPM1
JPCIE4
JPCIE7
JPCIE6
SRW1
MH3
MH1
MH5
MH7
MH2
MH6
MH8
MH4
JIPMB1
J1
SP1
UID_LED1
LED2
LED3
JPWR1
JPW1
JPTG1
JPI2C1
JPH1
JNVME1
JL1
JGP1
JF1
JWD1
JRF1
JID3
JID2
JRF2
JPME2_PCH
JPME2_CPU
JDB1
JPG1
JPT1
JDB4
JPL2
JPL1
JPAC1
JDB2
JDB3
JSMB1
JD1
JBT1
I-SGPIO1
FANB
FANA
FAN3
FAN2
FAN1
FAN4
BT1
BMC
PCH
I-SATA0
I-SATA1
I-SATA3
I-SATA2
JMD1
P1 SLOT4 PCIe 4.0 p1-x4 (IN x8)
SRW2
UID-SW
COM1/2
VGA
USB6/7 (3.2(10Gb))
BMC_LAN
AUDIO FP
P1 SLOT6 PCIe 5.0 x16
USB2/3
USB8/9(3.2(10Gb))
USB4/5
(3.2(10Gb))
USB0/1
LAN1/LAN2
HDMI1/DP1 HDMI2/DP2
LAN3/LAN4
CPU
DIMMB1
DIMMB2
DIMMA1
DIMMA2
PCH SLOT7 PCIe 4.0 p1-x4 (IN x8)
JF1
ON
PWR RST PS
FAIL
UID
LED
NIC
1
NIC
2
HDD
LED
PWR X
LED NMI
LED1
DIMM Memory Installation
Jumpers and Connectors
Memory Support
Motherboard Layout and Features
Note: Graphics shown in this quick reference guide are for illustrative purposes only. Your components may or may not look exactly the same as drawings
shown in this guide.
Note: Refer to Chapter 1 of the User Manual for detailed information on jumpers, connectors,
and LED indicators.
Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/
motherboard installation instructions.
Front Control Panel (JF1)
Processor Support
The X14SAZ-TLN4F/F motherboard supports up to 192 GB of ECC or Non-ECC
DDR5 UDIMM memory with speeds of up to 5600 MT/s with one DIMM single rank/
dual rank, or 4400 MT/s with two DIMM single rank/dual rank in four memory slots.
When installing memory modules, the DIMM slots should be populated in the
following order: DIMMA1, DIMMA2, then DIMMB1, DIMMB2.
It is recommended to use DIMM modules of the same type, size, and speed.
Mixed DIMM speeds can be installed. However, all DIMMs will run at the speed
of the slowest DIMM. The motherboard will support odd-numbered modules.
However, for best memory performance, install DIMM modules in pairs to activate
memory interleaving.
The X14SAZ-TLN4F/F motherboard supports the 15
th Generation Intel® CoreTM
Ultra 5/7/9 processor with a thermal design power of up to 125 W in the LGA
1851 socket.
Connector Description
AUDIO FP Front Panel Audio Header (Mic-In/Line-Out)
BMC_LAN Dedicated BMC LAN Port
BT1 Onboard Battery
COM1/2 COM Header (supports RS232)
FAN1–FAN4
FANA, FANB CPU/System Fan Headers (FAN1–FAN4: CPU Fan)
HDMI1/DP1, HDMI2/DP2 High Deîš¿nition Multimedia Interface 2.1, DisplayPort
I-SATA0–3 Intel® SATA 3.0 Ports (I-SATA2: SATA DOM)
I-SGPIO1 Serial ATA GPIO Header
J1 External RTC Battery Connector
JD1 Speaker/Buzzer (Pins 1–4: Speaker, Pins 3–4: Buzzer)
JF1 Front Control Panel Header
JGP1 General Purpose I/O Header
JIPMB1 4-pin BMC External I2C Header
JL1 Chassis Intrusion Header
JMD1 M.2-C PCIe 5.0 p1-x4 Slot
JNVME1 NVMe p1-x4 + p1-x4 Slot
JPCIE4 CPU SLOT4 PCIe 4.0 p1-x4 (IN x8) Slot
JPCIE6 CPU SLOT6 PCIe 5.0 p1-x16 Slot
JPCIE7 PCH SLOT7 PCIe 4.0 p1-x4 (IN x8) Slot
JPH1 4-pin HDD Power Connector
JPI2C1 Power System Management Bus (SMB) I2C Header
JPW1 24-pin ATX Main Power Connector (Required)
JPW2, JPW3 +12 V 8-pin CPU Power Connectors (Required)
JPWR1 4-pin Power Out for GPU Card
JSMB1 System Management Bus Header
JTPM1 Trusted Platform Module/Port 80 Connector
LAN1/LAN2 2.5G (RJ45) LAN ports
LAN3/LAN4 10G LAN Ports (TLN4F SKU)
MH1–MH8 Mounting Holes
SP1 Internal Speaker/Buzzer
Connectors and LED Indicators
LED Description Status
LED1 Power LED Solid Green: Power On
LED2 Power Fail LED Soild Red: PWR Fail or FAN Fail
LED3 BMC Heartbeat LED Blinking Green: BMC Normal
UID_LED1 Unit Identiîš¿er (UID) LED Solid Blue: Unit Identiîš¿ed
I/O Ports
1
9
8
7
6
5
3
2
10
11
OH/Fan Fail LED
20
NIC1 Link LED
19
HDD LED
PWR LED
X
GND
NMI
X
NIC2 Link LED
+3.3 V
Power Button
Reset Button
Reset
PWR GND
GND
1 2
X
+3.3 V
+3.3 V
+3.3 V Stby
+3.3 V Stby
+3.3 V Stby
12
Connector Description
SRW1, SRW2 M.2 Mounting Holes
USB0/1, USB2/3 Front Accessible USB 2.0 Headers
USB4/5, USB6/7 Back Panel USB 3.2 (10 Gb) Ports
USB8/9 Front Accessible USB 3.2 (10 Gb) Type-A Ports
UID-SW Unit Identiîš¿er Button
VGA VGA Port
Connectors
LED Indicators
Jumpers
Connectors
# # #Description Description Description
1. 6. HDMI2BMC LAN LAN1 (2.5G) 11.
2. 7. 12. DP1USB6 (3.2, 10 Gb) LAN2 (2.5G)
3. 8. 13. HDMI1USB7 (3.2, 10 Gb) LAN3 (10G) (TLN4F)
4. 9. 14.USB4 (3.2, 10 Gb) LAN4 (10G) (TLN4F) UID Button
5. 10. DP2USB5 (3.2, 10 Gb)
Jumper Description Default Setting (*)
JBT1 CMOS Clear Open (Normal)
JPAC1 Audio Enable/Disable Pins 1–2 (Enabled)
JPG1 VGA Enable/Disable Pins 1–2 (Enabled)
JPL1, JPL2 LAN1, LAN2 Enable/Disable Pins 1–2 (Enabled)
JPME2_CPU ME Manufacturing Mode Pins 1–2 (Normal)
JPME2_PCH ME Manufacturing Mode Pins 1–2 (Normal)
JPT1 Onboard TPM 2.0 Enable/Disable Pins 1–2 (Enabled)
JPTG1 10G LAN Enable/Disable (TLN4F SKU) Pins 1–2 (Enabled)
JRF1, JRF2 PCIe Bifurcation
JRF1
Pins 2–3
Pins 2–3
JRF2
Pins 2–3
Pins 1–2
PEG
x16* (PCIe)
2x8 (PCIe)
JWD1 Watchdog Timer Pins 1-2 (Reset)
= mounting hole
13 14
Heatsink InstallationProcessor Installation
Screw
Screw
Screw
Motherboard top side
CPU Key
Pin1
Socket Key
Apply thermal grease
