Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: November 11, 2020

Secure Articulating Universal Tablet Mount

• (Optional -- for mounting) Electric Drill

• (Optional -- for mounting) Writing Utensil (i.e. Pencil, Pen, etc.)

• Phillips Head Screwdriver

Installation

Congure the Tablet Holder

1. Pull and hold the top and extend the top until it reaches its Tab Tablet Holder Arm

full length. (Figure 1)

2. Fold out the two lower .Tablet Holder Arms

3. (Optional -- for thin ) Peel and stick the three over the existing Tablets Spacers

Screen Protection Pads Tablet Holder Arms located within the tips of all three .

Install the Tablet Holder

1. While the is fully extended, align the hole in the Table Holder Arm (Top) Tablet

Holder Pivot Point Tablet Stand Tablet with the on the . Continue to hold the

Holder. (Figure 2)

Product Diagram (SECTBLTDT)

Rear View

Component Function

1Tablet Holder • Holds a single Tablet

• Allows for 360 of rotation°

2Lock Slot x 2

• Deters theft

• Insert (up to) two (one K-Slot Style Laptop Locks

included, one sold separately)

3Tablet Holder Arm

• Part of the Tablet Holder

• Three points of contact with the Tablet

• Integrated to prevent Tablet scratchesSpacers

• (Optional) can be inserted into the Spacers Tablet

Holder Arms Tablets for thin

4Tablet Stand • Holds the Tablet Holder

• Allows for 180 of tilt°

5Cable Management

Holes

• Route the and Tablet Charging Cable K-Slot

Style Laptop Lock Cables Tablet through the

Stand

Requirements

For the latest requirements, please visit:

www.startech.com/SECTBLTDT

• Tablet

• Size: 7.9 - 13 Inch (200.66 - 330.2 mm)

• Thickness (Maximum): 0.374 Inches (9.5 mm)

*Tablet sold separately.

Figure 1

Tab

(Top)

Tablet Holder Arm

(Top)

Figure 3 Figure 4

Tablet Holder

Arm (Bottom)

Tab

(Bottom)

Figure 2

Upper Hole

M4 Screw

Lower Hole

Pivot Point

Warning Statements

Make sure that you assemble this product according to the instructions.

This product is intended for indoor use only and should not be used outdoors.

Pinch hazard! Ensure ngers are not placed along any of the moving parts when making adjustments.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

PHILLIPS® is a registered trademark of the Phillips Screw Company in the United States and other countries.

Warranty Information

This product is backed by a two-year warranty.

For further information on product warranty terms and conditions, please refer to .

www.startech.com/warranty

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of

business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

FR: fr.startech.com

DE: de.startech.com

ES: es.startech.com

NL: nl.startech.com

IT: it.startech.com

JP: jp.startech.com

StarTech.com Ltd.

45 Artisans Cres

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Rd,

Brackmills

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

4490 South Hamilton

Road

Groveport, Ohio

43125

U.S.A.

Figure 5 Figure 6

Tablet Holder Arm

(Top)

Figure 8

2. Route the through one of the K-Slot Style Laptop Lock Cable Cable Management

Holes Tablet Stand in the rear of the .

3. Insert the into one of the in the rear of the K-Slot Style Laptop Lock Lock Slots

Secure Articulating Universal Tablet Mount.

4. (Optional -- for made of wood) Place the Mounting Surfaces Tablet Mount

Assembly Mounting Surface onto the desired and mark the location of the four

Screw Holes Tablet Stand Writing Utensil in the with a .

5. Remove the and drill four 2.5 mm into the Tablet Mount Assembly Pilot Holes

marked locations on the , using an . Mounting Surface Electric Drill

6. Place the back onto the desired and Tablet Mount Assembly Mounting Surface

align the four in the with the four in the Holes Tablet Stand Pilot Holes Mounting

Surface.

7. Insert the four through the and into the 3x12 mm Screws Tablet Stand Tablet

Surface.

8. Tighten the , using a . 3x12 mm Screws Phillips Head Screwdriver

Operation

Note: Ensure the are not tangled before completing all adjustments.Cables

Adjust the Tilt

Place one hand on the top edge of the and the Tablet

other hand on the bottom edge of the . Apply Tablet

light pressure to tilt the either upwards or Tablet

downwards. (Figure 8)

Adjust the Rotation

• Place one hand on the left side of the and Tablet

the other hand on the right side of the . Apply Tablet

light pressure to rotate the into a portrait or Tablet

landscape view.

For sizes of 7.9 - 10 Inches (200.66 - 254 mm), use the . Tablet Lower Hole

--Or--

For sizes of 10.1 - 13 Inches (256.54 - 330.2 mm), use the . Tablet Upper Hole

2. Insert the through the , the , and into the M4 Screw Tablet Holder Washer Pivot

Point Tablet Standon the .

3. Tighten the , using a .M4 Screw Phillips Head Screwdriver

4. For sizes of 7.9 - 10 Inches (200.66 - 254 mm), slide and hold the on one Tablet Tab

of the bottom while pushing the inwards to Tablet Holder Arms Tablet Holder Arm

collapse the , then release the . Tablet Holder Arm Tab (Figure 3)

--Or--

For sizes of 10.1 - 13 Inches (256.54 - 330.2 mm), slide and hold the on one Tablet Tab

of the bottom while pulling the outwards to Tablet Holder Arms Tablet Holder Arm

extend the , then release the .Tablet Holder Arm Tab (Figure 4)

5. Repeat step 7 for the second bottom . Tablet Holder Arm

Insert the Tablet into the Tablet Holder

1. Insert the into the , bottom-end rst. Tablet Tablet Holder Arms (Figure 5)

2. Press the top down until it is seated against the top of the Tablet Holder Arm Tablet.

(Figure 6)

Secure the Tablet and Mount

1. Wrap the looped end of the around the K-Slot Style Laptop Lock Mounting Point

(e.g. table leg, xed desk mounting point, etc.) and feed the lock head of the K-Slot

Style Laptop Lock through the looped end. (Figure 7)

Figure 7

Cable

Management

Hole

Lock Slot

K-Slot Style

Laptop Lock

Product specificaties

Merk:	StarTech.com
Categorie:	Overige telefoon accessoire
Model:	SECTBLTDT
Kleur van het product:	Zwart
Gewicht:	220 g
Breedte:	136 mm
Diepte:	118 mm
Hoogte:	300 mm
Gewicht verpakking:	220 g
Breedte verpakking:	145 mm
Diepte verpakking:	142 mm
Hoogte verpakking:	222 mm
Soort:	Multimedia-standaard
In hoogte verstelbaar:	Nee
Met slot:	Ja
Maximale gewichtscapaciteit:	0.68 kg
Certificering:	CE, RoHS
Materiaal:	Plastic, Steel
Aanbevolen gebruik:	Tablet
Aantal schroeven:	4
Aantal displays ondersteund:	1
(Buitenste) hoofdverpakking hoogte:	252 mm
(Buitenste) hoofdverpakking breedte:	315 mm
(Buitenste) hoofdverpakking lengte:	750 mm
Hoeveelheid per (buitenste) hoofdverpakking:	10 stuk(s)
Bereik kantelhoek:	-180 - 180 °
Maximale schermgrootte:	13 "
Code geharmoniseerd systeem (HS):	94031098
Minimale schermgrootte:	7.9 "
Slot type:	Sleutel
Aantal sleutels meegeleverd:	2 stuk(s)
