Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support

Manual Revision: June 20, 2022 4:53 PM

Product Diagram (ADJ-TABLET-STAND-W)

Front View

Component Function

1Clamp

• For up to 12.9 in . on either side Tablets Holders

support the in placeTablet

• Width range from 5 to 8 in (12.8 to 22.4 cm)

• Maximum thickness 0.4 in (1.1 cm)

• Allow to rotate 360°, up and down, and side to side

2Rotation Adjustment

Knob

• Varies the resistance of the or xes it Rotation Clamp

on a specic position

3Clamp Tilt

Adjustment Screw • Adjust the of the of the Resistance Tilt Angle Clamp

4Support Arm Tilt

Adjustment Screws

• Adjust the of the of the Resistance Tilt Angle Upper

and sections of the Lower Support Arm

5Support Arm • Supports the weight of the and provides Tablet

Height Tilt Adjustment and

6Mounting Holes • Allow to x the on a permanent locationTablet Stand

7Base • Supports the in place. at the Assembly Foam Pads

bottom protect the desk or table surface

Universal Tablet Desk Stand - White

Package Contents

• Tablet Stand x 1

• 4.2x19 mm Wood Screws x 4

• 3 mm Hex Key x 1

• 5 mm Hex Key x 1

• Quick-Start Guide x 1

Requirements

For the latest manuals, product information, technical specications, and declarations of

conformance, please visit:

www.startech.com/ADJ-TABLET-STAND-W

• Phillips head screwdriver

Operation

WARNINGS!

Do not exceed the weight capacity of this product. Overloading this product might

result in injury or property damage. This product can support the following weight: up

to 2.2 lb (1 kg).

When adjusting the tilt or height of this product, ensure that the mounted equipment

is properly secured and the weight is fully supported. Failure to follow these guidelines

may result in property damage and/or personal injury.

When not xed to a surface, always use two hands to ensure a controlled movement

when adjusting the height or tilt angle of this product to prevent tipping it over.

Is recommended to remove any protective case from the Tablet to t properly on the

Holders.

1. Slide the outwards to make enough room to mount the Holders Tablet Vertically

on the If the is enough, it can be mounted too. Clamp. Tablet Small Horizontally

Figure 1

*Product may vary from image

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or

symbols of third-party companies not related in any way to StarTech.com. Where they occur these references

are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.

com, or an endorsement of the product(s) to which this manual applies by the third-party company in question.

StarTech.com hereby acknowledges that all trademarks, registered trademarks, service marks, and other

protected names and/or symbols contained in this manual and related documents are the property of their

respective holders.

Warranty Information

This product is backed by a 5-year warranty. For further information on product warranty terms and conditions,

please refer to .

www.startech.com/warranty

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors,

employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential,

or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the

product exceed the actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this

statement may not apply to you.

Safety Measures

• Read the entire manual and ensure the instructions are fully understood before assembling and/or using

this product.

FR: startech.com/fr

DE: startech.com/de

ES: startech.com/es

NL: startech.com/nl

IT: startech.com/it

JP: startech.com/jp

StarTech.com Ltd.

45 Artisans Crescent

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Road

Brackmills,

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

4490 South Hamilton

Road

Groveport, Ohio

43125

U.S.A.

StarTech.com Ltd.

Siriusdreef 17-27

2132 WT Hoofddorp

The Netherlands

Mesures de sécurité

• Lisez tout le manuel et assurez-vous que vous comprenez les instructions avant de commencer à assembler et utiliser ce

produit.

安全対策

• 最初に取扱説明書を最後まで読み、本製品の組み立て方をすべて理解してから組み立て作業を始めて下さい。

Misure di sicurezza

• Leggere l’intero manuale e assicurarsi di aver compreso tutte le istruzioni prima di iniziare ad assemblare e a utilizzare

questo prodotto.

Säkerhetsåtgärder

• Läs hela manualen och se till att du förstår instruktionerna innan du börjar montera och använda produkten.

2. Insert one side of the on one of the . Keep the weight Tablet Holders Supporting

of the .Tablet

3. Slide the remaining to secure the in place. Figure 1.Inwards Holder Table

Adjust the Rotation Resistance of the Clamp

1. Rotate to the at the back of the . The Clockwise Tighten Resistance Knob Clamp

right resistance allows the to rotate 360°, up and down, and side to side Clamp

while keeping its position when the is in use.Tablet

Adjust the Tension of the Clamp Tilt

1. Use the and rotate to the . The 5 mm Hex Key Clockwise Increase Resistance

right allows the Clamp to rotate up and down while keeping its Resistance

position when the is in use.Tablet

Adjust the Tension of the Support Arm Tilt

1. Use the to tune one or two of the5 mm Hex Key Support Arm Tilt Adjustment

Screws. Clockwise Increase ResistanceRotate to the .

Attach the Tablet Stand to a Desk

May need pilot holes before mounting the Tablet Stand.

The supplied Wood Screws may not be suitable if they are longer than the thickness

of the mounting surface.

1. Insert the (x 4) onto the (x 4) on the 4.2x19 mm Wood Screws Mounting Holes

Base.

2. Use a to fasten the to the Phillips Head Screwdriver 4.2x19 mm Wood Screws

Desk Table or .

(Optional) Secure the Support Arm onto the Base

1. If the at the bottom of the come loose, use the to Screws Base 3 mm Hex Key

Tighten Clockwise Tighten them. Rotate to .

Product specificaties

Merk:	StarTech.com
Categorie:	Overige telefoon accessoire
Model:	ADJ-TABLET-STAND-W
Kleur van het product:	Wit
Gewicht:	1500 g
Breedte:	160 mm
Diepte:	160 mm
Hoogte:	470 mm
Gewicht verpakking:	1200 g
Breedte verpakking:	320 mm
Diepte verpakking:	180 mm
Hoogte verpakking:	120 mm
Soort:	Multimedia-standaard
In hoogte verstelbaar:	Ja
Snelstartgids:	Ja
Maximale gewichtscapaciteit:	1 kg
Materiaal:	Aluminium, Steel
Aantal per verpakking:	1 stuk(s)
Aanbevolen gebruik:	Tablet
Draaibaar:	Ja
Inclusief moersleutel:	Ja
Draaihoek:	185 °
Aantal schroeven:	4
Aantal displays ondersteund:	1
(Buitenste) hoofdverpakking hoogte:	370 mm
(Buitenste) hoofdverpakking breedte:	655 mm
(Buitenste) hoofdverpakking lengte:	375 mm
Hoeveelheid per (buitenste) hoofdverpakking:	12 stuk(s)
Maximale schermgrootte:	12.9 "
Minimale schermgrootte:	4.7 "
Type moersleutel:	Zeskantsleutel
