Pagina 1/4
Tile bridge
Bafe
Installation aid/paint mask
Grille
Grille safety restraint
Speed Wingâ„¢ mounting arms
Box contents
1 Speaker
1 Flexible conduit clamp
1 6-pin Euroblock connector
1 Cover plate
1 Grille
1 Installation aid/paint mask
Min
0.9 mm (0.035 in)
Max
57.1 mm (2.25 in)
Ceiling thickness tolerances
Do not spec or install speaker near support beam, ventilation duct or other
structure that may interfere with speaker function or dispersion.
Warning Warning
SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for optimum audio
performance, installer must follow all directions issued by SoundTube Entertainment.
© 2015 SoundTube Entertainment, Inc. All rights reserved. PN INS-IP4-BGM Rev11.10.2015
1.435.647.9555
| | 800.647.TUBE
www.soundtube.com
Flexible conduit clamp
Install Instructions For:
IPD4-CM52-BGM & IPD4-CM62-BGM
IPD4-BGM SeriesIPD4-BGM Series
Secondary attachment point
Cover plate
Ne spéciez pas ou installer haut-parleur près de poutre de support, une
conduite d'aération ou une autre structure qui pourrait interférer avec la fonction
haut-parleur ou de dispersion.
Haut-parleurs SoundTube doivent être installés par un installateur / contracor de l'audio professionnel. Par mesure de
sécurité et pour des performances audio optimales, l'installateur doit suivre toutes les directives émises par SoundTube
Entertainment.
6-pin Euroblock connector
1.435.647.9555 | 800.647.TUBE | www.soundtube.com
Install Instructions For:
IPD4-CM52-BGM & IPD4-CM62-BGM
IPD4-BGM SeriesIPD4-BGM Series
Important Safety Instructions

1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
9) Only use the attachments/accessories specied by the manufacturer.
10) Unplug this apparatus during lightning storms or when unused for long periods of time.
11) Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in
any way, such as power-supply cord or plug is damaged, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
This device complies with Part 15 of the FCC Rules / Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur
de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
Changes or modications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Consignes de sécurité importantes

1) Lisez ces instructions.
2) Conservez ces instructions.
3) Respectez tous les avertissements.
4) Suivez toutes les instructions.
5) Ne pas utiliser cet appareil près de l'eau.
6) Nettoyer seulement avec un chiffon sec.
7) Ne pas bloquer les ouvertures de ventilation. Installer conformément aux instructions du fabricant.
8) Ne pas installer près de sources de chaleur telles que des radiateurs, registres de chaleur, poêles ou autres
appareils (incluant les amplicateurs) qui produisent de la chaleur.
9) Utiliser uniquement les xations / accessoires spéciés par le fabricant.
10) Débranchez cet appareil pendant les orages ou si inutilisé pendant de longues périodes de temps.
11) Conez toute réparation à un personnel qualié. Une réparation est nécessaire lorsque l'appareil a été
endommagé de quelque façon que ce cordon d'alimentation ou la che est endommagé, l'appareil a été exposé à la
pluie ou à l'humidité, s'il ne fonctionne pas normalement ou s'il est tombé.
1. Unpack speaker & set
aside grille assembly.
2. Use included tile bridge
to mark cutout in tile.
3. Use Rotozip or other tool
to cut hole.
1.435.647.9555 | 800.647.TUBE | www.soundtube.com
Hole Diameters
CM42-EZs-II
165.1 mm (6.50 in)
All other CMEZ, FS and BGM models
266.7 mm (10.50 in)
3. Use Rotozip or other tool
to cut hole.
Hole Diameters
CM42-EZs-II
165.1 mm (6.50 in)
All other CMEZ, FS and BGM models
266.7 mm (10.50 in)
2. Use included tile bridge
to mark cutout in sheetrock.
Install Instructions For:
IPD4-CM52-BGM & IPD4-CM62-BGM
IPD4-BGM SeriesIPD4-BGM Series
Ceiling preparation - For Tile Ceilings
Ceiling preparation - For Sheetrock / gypsum board ceilings
