Pagina 1/16

30W GaN

Power Delivery Wall Charger

with LED display

Type: CH-1001

POWER

User manual

EN: User manual CH-1001 30W Power Delivery Wall

Charger with LED display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

NL: Handleiding CH-1001 30W Power Delivery Wall

Charger met LED display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

DE: Benutzerhandbuch CH-1001 30-W-Power-Delivery-

Wandladegerät mit LED-Anzeige . . . . . . . . . . . . . . . . . . . . . 5

FR: Guide de l’utilisateur CH-1001 Chargeur mural

Power Delivery 30W avec achage LED . . . . . . . . . . . . . . 6

IT: Manuale dell’utente CH-1001 Caricabatteria da parete

Power Delivery da 30 W con display a LED . . . . . . . . . . . .7

ES: Manual de usuario CH-1001 Cargador de pared con

suministro de energía de 30 W con pantalla LED . . . . . . 8

PT: Manual do utilizador CH-1001 Carregador de parede de

voornecimento de energia de 30 W com display LED 9 . .

PL: Instrukcja obsługi CH-1001 Ładowarka ścienna Power

Delivery o mocy 30 W z wyświetlaczem LED . . . . . . . . .10

ΕΛ: Εγχειρίδιο χρήστη CH-1001 Φορτιστής τοίχου 30W

με παροχή ρεύματος με οθόνη LED . . . . . . . . . . . . . . . . . . 11

Legal & Compliance Information . . . . . . . . . . . . . . . . . . . .12

EN At a glance

Item Specications Description

1 EURO

plug

EURO mains plu g Suitable for use in most European

countries.

2USB-C

port

5.0V 3.0A,15.0W /

9.0V 3.0A,27.0W /

12.0V 2.5A,30.0W /

15.0V 2.0A, 30.0W /

20.0V 1.5A, 30.0W

Charge any USB-C device up to

30W. Please refer to the technical

specications table for the output rating

when using mu ltiple ports.

USB-A

1 / 2 port

Per port:

5.0V 3.0A,15.0W /

9.0V 2.0A,18.0W/

12.0V 1.5A,18.0W

Charge any USB-A device up to

18W. Please refer to the technical

specications table for the output rating

when using mu ltiple ports.

5 LED

Display

White LED Indicates how much power (Watt) is

being used.

Other specications

Supported

Devices

USB-C and USB-A devices: Can charge or power any USB-C

device that requires 30W power or less. The power supply unit

is suitable for mains voltages of 100 – 240 V and therefore can

be used worldwide. Please note that a country-specic adapter

may be necessary

Dimensions 52 x 94 x 35 mm Weight 84 grams

Package contents 1x CH-1001 & 1x User manual

Important safety instructions

• Do not drop. Frequent dropping may lead to malfunctioning.

• Do not disassemble. Repairs should only be done by qualied service centers.

Do not use the product if the AC adapter, adapter cable or power cable is

damaged.

• Do not expose to liquids, heat or re. Risk of electric shock. As with all electrical

products, this device should be kept out of the reach of children.

• Do not extend cable. Extending cable may lead to poor performance. Always

pull directly on the plug when disconnecting the cable, never on the

cable itself.

• Do not exceed 40° Celsius ambient temperature.

Support

Warranty 24 months warranty. Please note that your rights u nder national

law remain unaected by this warranty.

Support Lifetime technical support

Disclaimer Sitecom Europe B.V. assumes no liability and provides no warranty

for damage resulting from improper installation/ mounting,

improper use of the product or from f ailure to observe the

operating instructions and/or safety notes.

Website www.sitecom.com Contact support@sitecom.com

Product specificaties

Merk:	Sitecom
Categorie:	Oplader voor mobiel apparaat
Model:	CH-1001
Kleur van het product:	Zwart
Gewicht:	117 g
Breedte:	52 mm
Diepte:	94 mm
Hoogte:	35 mm
Gebruikershandleiding:	Ja
LED-indicatoren:	Ja
Stroom:	0.85 A
Type stroombron:	AC
Ingangsspanning:	100-240 V
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	2
Stroomspanning bescherming:	Over current, Overload, Short circuit
Frequentie:	50/60 Hz
Maximaal vermogen:	30 W
Type oplader:	Binnen
Lader compatibiliteit:	Universeel
Uitgangsspanning (max):	20 V
Aantal gelijktijdig verbonden apparaten (max):	3
Aantal USB-Type-C-poorten:	1
Uitgangsspanning (min):	5 V
Poort 1 uitgangsstroom:	3 A
Poort 2 uitgangsstroom:	3 A
Poort 3 uitgangsstroom:	3 A
Poort 3 uitgangsvermogen:	18 W
