Installation and User Manual for

Model UF424 and UN324

UF424 / UN324 Installation and User Manual

August 2017

To the owner or user: the service manual is intended

to provide you and the maintenance or service

technician with the information needed to install,

startup, clean, maintain and repair this product.

Observe any caution or warning notices. They are

important and provide notice of potential hazards.

Keep this manual for future reference.

If additional technical information is needed, go to

Scotsman’s website, www.scotsman-ice.com to

download a service manual.

Note: This is a commercial product. If service is

needed on a unit in a residence, warranty may be

limited. Use a commercial service company. Locate

one from the Scotsman website: www.Scotsman-ice.

com

Table of Contents

Specications ....................................................................................................................3

Cabinet Drawing ................................................................................................................4

Placement..........................................................................................................................5

Installation: Water and Drain ............................................................................................6

Initial Start up.....................................................................................................................7

Maintenance and Cleaning ................................................................................................8

Basic Troubleshooting .................................................................................................... 10

UF424 / UN324 Installation and User Manual

October 2017

Specications

This ice maker is designed to be installed in-

doors, in a controlled environment. Although

it can operate in a wide range of air and water

temperatures, it will provide the best performance

if not subject to extremes.

Air Temperature Limitations

• Maximum: 100o

F or 38o C

• Minimum: 50o F or 10o C

Water Temperature Limitations

• Maximum: 100o F or 38o C

• Minimum: 40o F or 4.4o

Water Pressure, Potable

• Maximum: 80 PSI or 5.5 BAR

• Minimum: 20 PSI or 1.3 BAR

Water Pressure, Condenser inlet

• Maximum: 145 PSI or 10 BAR

• Minimum: 20 PSI or 1.3 BAR; can be as low

as 5 PSI or 0.3 BAR if clean and supplied

with 45o F water.

Condenser GPM

• 70oF or 21oC water: 0.25 GPM or 0.95 LPM

• 50o F or 10oC water: 0.15 GPM or 0.57 LPM

Voltage

115 volt models

• Maximum 126 VAC

• Minimum 104 VAC

230 volt models

• Maximum 207 VAC

• Minimum 253 VAC

Water Conductivity:

Minimum:10 micro Siemens/CM

RO water may be supplied to the potable water

system, but if it has less than the above conduc-

tivity, the water level sensor will not detect water

and the unit will not make ice.

Deionized water is not recommended due to

it’s potential corrosive nature and any damage

caused by DI water will not be covered by war-

ranty.

Operating the machine outside of any of the

above limitations is considered abuse and any

resulting damage is not covered by warranty and

could cause a complete loss of warranty cover-

age.

Warranty Information

The warranty statement for this product is pro-

vided separately from this manual. Refer to it for

applicable coverage. In general warranty covers

defects in material or workmanship. It does not

cover maintenance, corrections to installations,

or situations when the machine is operated in

circumstances that exceed the limitations printed

above.

Product Information:

The UF424 produces aked ice and the UN324

produces nugget ice. The ice is stored in an

insulated bin with ice level automatically main-

tained by the control system.

• A back ow preventer may be required by

local plumbing codes.

• Has a 5.5 ft. power cord with NEMA 5-15P

plug.

• Air cooled models ows in the right front and

out the left front and include a cleanable air

lter.

• Legs are provided, thread size is 5/8-11.

• Machine may be installed without legs.

• For available options and kits, see sales

literature.

Model

Electrical

(Volts/Hz/Phase)

Condenser

Maximum Fuse Size

or Breaker

(Amps)

UF424A-1A / UN324A-1A 115/60/1 Air 15A

UF424W-1A / UN324W-1A 115/60/1 15AWater
