Pagina 1/12
1
Introduction
The Wireless 1080P HDMI Video Kit - Mid-Range transmits
HDMI A/V signals up to 165ft (line-of-sight) wirelessly
and supports high-definition video signals up to 1080p
@60Hz.
Features and Benefits
•Transmits HDMI A/V signals wirelessly up to 165ft,
no complicated cable or wire installation needed
•An ideal solution to setup your home entertainment
system or remote display in apartments, condos
and where wiring is prohibited, also great for digital
signage, POP for small business office and
showrooms
•Supports high-definition vivid video up 1080p
@60Hz, streaming flawless stereo audio, and works
with most HDMI equipped devices including
Blu-ray players, set-top boxes, AV receivers, cable/
satellite boxes, and computers
•Built-in IR signal extension feature allows you to
control the playback device remotely
•Plug-n-play installation, no software installation or
Wi-Fi connection required, wall-mountable case
design provides multiple placement options for
best signal broadcasting or reception angles
04-1048B
Wireless 1080P HDMI
Video Kit - Mid-Range
Installation Guide
2
Package Contents
•Wireless 1080P HDMI Video Kit - Mid-Range (TX &RX)
•IR blaster extension cable
•IR receiver extension cable
•Power adapters (x2)
•Power extension cables (x2)
•User Reference Guide
Specifications
Transport Protocol HDbitT
Signal Type HDMI
HDMI version HDMI 1.3 compatible
HDCP version HDCP 1.2 compatible
Transmission Distance Up to 50m (165ft) / line-of-sight
Supported Resolutions 1080p/1080i/720p/576p/576i/480p/480i
HDMI Cable Distance Up to 2m (Input & Output)
Audio format R/L stereo audio (2-ch)
Power
Input:
AC 100-240V, 50/60Hz
Output:
DC 5V/3A
Color Black
Dimensions (TX & RX) 7.69" (W) x 1.21" (H) x 5.41" (D)
Weight Transmitter (TX): 1.17lbs
Receiver (RX): 1.16lbs
Operating Temperature 32 to 104 degrees F
Storage Temperature -4 to 158 degrees F
Operating Humidity 0% to 95% RH (non-condensing)
Note: The transmission distance will vary depending on building layout, electronic
interference, other environmental conditions, and may be much less than the
line-of-sight maximum.
3
Product Layout
Figure 1: Transmitter (TX) - front side
Power LED
Data Transmission LED
Connection LED
•Power LED: On when the Transmitter is powered on
•Data Transmission LED:
- Slow blinking: Establishing wireless connection
- Fast blinking: The wireless connection is connected
successfully and transmitting data
•Connection LED: On when the wireless connection
is linked properly


Product specificaties

Merk: SIIG
Categorie: AV extender
Model: CE-H22G12-S1
Soort: AV-zender & ontvanger
Gebruikershandleiding: Ja
Ondersteunde video-modi: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Maximum resolutie: 1920 x 1080 Pixels
Meegeleverde kabels: AC, IR
Inclusief AC-adapter: Ja
Certificering: FCC, CE
HDCP: Ja
Materiaal: Metaal
HDMI versie: 1.3
Remote (IR) ingang: 1
Duurzaamheidscertificaten: RoHS
Temperatuur bij opslag: -20 - 70 °C
Luchtvochtigheid bij opslag: 0 - 95 procent
Audio-uitgangskanalen: 2.0 kanalen
Output current: 3 A
Remote (IR) uitgang: 1
HDMI in: 1
Draadloze technologie: HDbitT
Aantal HDMI-uitgangen: 1
Receiver afmetingen (B x D x H): 195 x 137 x 30 mm
Operating voltage: 5 V
Maximaal bereik: 50 m
AC-ingangsspanning: 100-240 V
AC-ingangsfrequentie: 50 - 60 Hz
Bedrijfstemperatuur (T-T): 0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V): 10 - 85 procent
Receiver gewicht: 526 g
Transmitter afmetingen (WxDxH): 195 x 137 x 30 mm
Transmitter gewicht: 530 g
