Pagina 1/40

OWNER'S

MANUAL

Please read this

manual BEFORE

operating your

battery charger

Switch Mode,

Automatic, Lead

Acid Battery

Charger

MODELS:

SEC-1215UL

SEC-1230UL

SEC-2415UL

2 | SAMLEX AMERICA INC.

OWNER'S MANUAL: Battery Chargers | Index

SECTION 1

Safety Precautions ................................................................ 3

SECTION 2

Layout .......................................................................... 4

SECTION 3

Description, Features & Cooling ........................................... 7

SECTION 4

Charging Stages & Protections ............................................. 8

SECTION 5

Installation & Charger Operation 10 .......................................

SECTION 6

Troubleshooting ................................................................. 15

SECTION 7

Internal Fuse Rating & Specications 17 ..................................

SECTION 8

Warranty ......................................................................... 18

Disclaimer of Liability

UNLESS SPECIFICALLY AGREED TO IN WRITING, SAMLEX AMERICA INC.:

1. MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR OTHER INFORMATION

PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION.

2. ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR EXPENSES, WHETHER SPECIAL, DIRECT,

INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT OF THE USE OF SUCH INFORMATION. THE USE OF

ANY SUCH INFORMATION WILL BE ENTIRELY AT THE USERS RISK.

Samlex America reserves the right to revise this document and to periodically make changes to the content

hereof without obligation or organization of such revisions or changes.

document is prohibited without express written permission by Samlex America Inc.

SAMLEX AMERICA INC. | 3

SECTION 1 | Safety Precautions

Hazardous conditions may result if

the charger is not installed or operat-

ed correctly. Please read the following

instructions to prevent personal injury

or damage to the charger:

Battery Related

• To reduce the risk of battery explosion,

follow these instructions and those

marked on the battery

• Never smoke or allow an open spark

or ame in the vicinity of the battery or

engine

• Charge only Lead Acid type of batteries

(Flooded / Absorbed Glass Mat (AGM)

/ Gel Cell). Do not charge other type of

batteries like Nickel Cadmium

(NiCad)

• Nickel-Metal Hydride (Ni-MH), Dry-Cell

etc. Other types of batteries might burst

causing personal injury

• Never charge a frozen battery

• Working in the vicinity of Lead Acid bat-

teries is dangerous. Batteries generate

explosive gases during normal opera-

tion. Take necessary safety precautions

when installing the charger near a

battery or in a battery compartment

(Follow safety instructions given by the

battery manufacturer)

• Never place the charger directly above

or below the battery being charged;

gases or uids from the battery will cor-

rode and damage the charger. Locate

the charger as far away from the bat-

tery as DC cables permit. Do not install

in the same compartmentas batteries

Charger Related

• Do not operate the charger in a closed-

in area or restrict ventilation in any way.

• Install in a well ventilated, cool,

dry place.

• The charger must not be operated in

a damp or wet environment. When

mounting in a boat, make sure it is not

subjected to bilge water splash

• Do not block the ventilation openings

/ openings for the cooling fan. There

should be at least 6 inches clearance all

around the unit

• Installation and wiring must comply

with the local and the national

electrical codes.

• It is recommended that installation

and wiring may be done by a

certied electrician

• Wrong installation on a boat may lead

to corrosion of the boat. It is recom-

mended that installation on the boat

must be carried out by a boat electrician

• Disconnect the AC input power to the

charger before connecting / disconnect-

ing the batteries or other DC loads or

when working on the charger

• Disconnect the AC input power before

changing setting of the DIP Switch

• The chassis of the charger is connected

to the earth ground pin of the power

cord plug. Ensure that the earth ground

pin of AC receptacle feeding the

charger is connected to earth ground

• Do not use an adapter. If a grounding

type of receptacle is not available,

do not use this charger until the

proper outlet is installed by a

qualied electrician.

• Do not operate the charger if the power

cord is damaged

Product specificaties

Merk:	Samlex
Categorie:	Batterij-oplader
Model:	SEC-1230UL
Kleur van het product:	Geel
Gewicht:	6400 g
Breedte:	214 mm
Diepte:	280 mm
Hoogte:	83 mm
Soort:	Batterijlader voor de auto/binnengebruik
Gebruikershandleiding:	Ja
Type stroombron:	AC
Ondersteund aantal accu's/batterijen:	3
Ingangsspanning:	120 V
Frequentie:	60 Hz
Output current:	30 A
Spanning:	12 V
Bedrijfstemperatuur (T-T):	-20 - 40 °C
